8. Using freely available
spreadsheet off of the Internet
for Excel analysis of GRR a
model was developed for
analysis using these 2
boundary conditions
8
9. Test Engineers
have been told to
follow 2 boundary
conditions
1. The error in the
measurement has to be 10
times less than the
measured value.
2. The error between the
USL and LSL has to be 10%
of the difference between
USL and LSL
X Instrument Error
0
2X Instrument Error
LSL
USL
ΔCV
ΔCV - Boundary Condition # 2
LCV - Boundary Condition # 1
Test Engineering Boundary Conditions
LCV
Where
USL = Upper Specifica>on Limit LSL = Lower Specifica>on Limit
LCV = Lowest Capable Value ΔCV = USL - LSL = Differen>al Capability
The variable, the RED “X”, needs to be understood
9
10. GRR Tools
Critical Evaluation with underlying Test
Engineering Boundary Conditions
The model created is using an OE (offset error of
±4mV with GE (gain error = 0%). The initial
evaluation used 10 samples, 3 tests, 3 Testers. One
tester had 0 offset, another -4mV, and the third
+4mV. Repeatability was 0.0001 to insure that just
equipment reproducibility is what is being examined.
Manage Instrument Error to achieve a passing
qualification on devices for GRR: ANOVA or XBAR&R
The experiment objective is to understand instrument
specification and how it affects GRR ALONE
10
11. GRR Tools
Manage Instrument Error to achieve a passing
qualification on devices for GRR: ANOVA or XBAR&R
GRR Calculation
# Samples
# Testers
Methods
# of Measurements
USL & LSL
Objective: Understand GRR from Instrument
Error Perspective
2-10 samples
Sample location: determines GRR
Random Selection
Intelligent selection
Plus Offset - one tester
Zero Offset - one tester
Minus Offset - one tester
ANOVA
Xbar&R
One value - Ideal
Second value: + 0.0001
Third value: - 0.0001
Note: sample location is
NOT usually looked at;
and it turns out to be
very important
11
12. How do these affect GRR
Results
• There are essentially 2 methods for doing GRR
• ANOVA
• Xbar&R
• Spreadsheets for each can be found on the internet free of
charge. Some with just one of the methods or the other, and
at least one with both methods in the spreadsheet.
• Each method was confirmed to give the same results with
identical data when comparing ANOVA to ANOVA and
Xbar&R to Xbar&R
12
13. The question is:
Are the 2 boundary conditions listed on slides 6 and 7 necesary
and sufficient to insure that the goal of GRR 10% passes?
1. Random samples within USL and LSL
2. 10 perfect evenly distributed samples within USL and LSL
3. 10 select samples to cause worst case within center ±50% of perfect samples placement
4. 10 select samples to cause worst case within center ±100% of perfect samples placement
5. 10 select samples to cause worst case within center ±150% of perfect samples placement
6. 10 select samples to cause worst case within center ±200% of perfect samples placement
6 ways to look at:
# Instrument errors range from 10X to shown on graphs
13
14. Necessary Equations
The diagram on Slide 2 shows 11X for instrument errors
to take into account the need for repeatability. This
works out to a GRR of approximately 9% for just
instrument errors, which is the objective of the exercise
USL =
LSL 1+10GE( )+ 20OE
1−10GE
USL − LSL = ΔCV
ΔCV = 10 GE i(USL + LSL)+ 2 iOE( )
ΔCV = 20 iOE +10 GE i(USL + LSL)( )
LSL = +LCV =
OE
0.1− GE
+LCV =
OE
0.1− GE
The model created us using an OE (offset error of ±4mV with GE
(gain error = 0%). The initial evaluation used 10 samples, 3 tests, 3
Testers. One tester had 0 offset, another -4mV, and the third +4mV.
Repeatability was 0.0001 to insure that just equipment reproducibility
is what is being examined.
14
15. 0
LSL
USL
±100% of perfect
samples
placement
±50% of perfect
samples
placement
0
LSL
USL
Random perfect
samples
placement
0
LSL
USL
Perfect Placement
±100 % Placement - Worst Case
0
LSL
USL
0
LSL
USL
Perfect Placement
±50 % Placement - Worst Case
15
17. Random selection of measurement for 10 DUTs with zero offset, +
offset and - offset.
1.5200 10 device randomly selected measurement values
using Monte Carlo simulations for Xbar&R from Statistical
Solutions, Tolerance and GRR results.
2.1010 10 device randomly selected measurement values
using Monte Carlo simulations using the ANOVA method
from www.dmaictools.com, Tolerance and GRR results.
Lower Specification limits started at 40mV (10X), Upper Specification limit start at 120mV (10X), ranging to
40X instrument errors. This means that the difference between USL-LSL, ranged from 10X to 40X.
Simulations were done for a process distribution width of 5.15 (encloses the central 99% of the process
distribution).
0
LSL
USL
Please note that the number of instrument
errors is the inverse of the instrument error
17
18. 409 12 14 16 18 20 22 24 26 28 30 32 34 36 38
1
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
(# X) Number of Instrument Errors
Percentage(%)over10%
GRR% Xbar&R
Xbar&R Monte Carlo Simula3on
in Excel. 5200 simula3ons of 10
devices.
Random devices within limits
Using Gage R&R
(XBar&R Motorola Version)
from Sta;s;cal Solu;ons
Please note that 11X and
greater is acceptable. However
neither the Xbar&R Method
nor ANOVA correctly calculate
GRR at the corners of
instrument limits
GRR% ANOVA
ANOVA Monte Carlo Simula3on
in Excel. 1010 simula3ons of 10
devices.
Random devices within limits
± 4mV offset Error
LSL starts at +40mV (10X)
USL starts at +120mV
USL-LSL starts at 80mV (10X)
Anova - www.dmaictools.com/measure/grr
30.0
Percentage of simulations (Monte Carlo) that showed the instances greater than GRR
10% for each Instrument X.
To read the graph, 20 on the X axis is the number of instrument errors. For GRR ANOVA,
approximately 0.5% of the simulation results showed greater than a GRR of 10%. For
GRR Xbar&R 1% of the simulation results showed greater than a GRR of 10%.
0
LSL
USL
Random
samples
placement
18
19. 4. 10 select perfect samples to cause worst case
within center ±50% of perfect samples placement
NOTE: solid line on graph of next slide
1. ANOVA 5.15 Standard deviations
2.Xbar&R 5.15 Standard deviations
Lower Specification limits started at 40mV (10X), Upper Specification limit
start at 120mV (10X), ranging to 40X instrument errors. This means that
the difference between USL-LSL, ranged from 10X and following.
Calculations were done for a process distribution width of 5.15 (encloses
the central 99% of the process distribution) at worst case values..
0
LSL
USL
±50% of perfect
samples
placement
Please note that the number of instrument
errors is the inverse of the instrument error
19
30. For 9% GRR the correct choices for allowable
instrument error to achieve the desired 10%
GRR with the 1% selection for repeatability are:
• Primary conclusion: Initial boundary condition is NOT SUFFICIENT to pass GRR at all!!
• Perfect parts and ONLY instrument error use 5.43% to 6.06% of the GRR 10% Goal
• Perfect parts and ONLY instrument error use 2.7% to 3.02% of the GRR 5% Goal
• Perfect parts, ONLY instrument and Sample Placement variation error use 4.22% to 5.62% of the GRR 10% Goal
• Perfect parts, ONLY instrument and Sample Placement variation error use 2.09% to 2.80% of the GRR 5% Goal
• Sample placement accounts for up to 1.3% of GRR 10% Goal for ANOVA
• Sample placement accounts for up to 0.63% of GRR 10% Goal for XBAR&R
Anova Perfect 16.5 (6.06%)
Anova ±50 17.8 (5.62%)
Anova ±100 19.3 (5.18%)
Anova ±150 21.0 (4.76%)
Anova ±200 22.9 (4.37%)
Xbar Perfect 18.4 (5.43%)
Xbar ±50 19.5 (5.13%)
Xbar ±100 20.7 (4.83%)
Xbar ±150 22.0 (4.55%)
Xbar ±200 23.7 (4.22%)
Xbar Perfect 37.1 (2.70%)
Xbar ±50 39.3 (2.54%)
Xbar ±100 41.7 (2.40%)
Xbar ±150 44.4 (2.25%)
Xbar ±200 47.8 (2.09%)
Anova Perfect 33.1 (3.02%)
Anova ±50 35.7 (2.80%)
Anova ±100 38.8 (2.58%)
Anova ±150 42.2 (2.37%)
Anova ±200 46.1 (2.17%)
9% GRR Target 4.5% GRR Target
30
