Hi-Tech is an engineering services company specializing in finite element analysis (FEA) and various structural, mechanical, and electrical design services for global clients. Recent projects include stress and thermal analyses for various components such as welding skid accumulators and oil storage tanks, utilizing software like SolidWorks and ANSYS. The company emphasizes achieving safety and efficiency through detailed analytical assessments across multiple industries.

1. Finite Element Analysis
ENGINEERING OUTSOURCING

2. Hi-Tech Offerings
Architectural Structural MEP
SERVICES
Mechanica BIM
l
FEA/CFD Electrica
ll

3. Hi-Tech Clientele – Worldwide 2
Hi-Tech is a leading engineering services company
for structural, civil, architectural, mechanical and
electrical design, drafting, modeling and animation.
INTERNATIONAL DOMESTIC

4. FEA Services
Hi-Tech provides professional finite element analysis services to clients across the
globe which includes structural, thermal, stress and electromagnetic analysis
SERVICES
STRESS ANALYSIS STRUCTURAL DYNAMICS
Stress analysis on different models Studying different structural analysis
THERMAL ANLAYSIS STATIC STRUCTURAL
Thermal analysis ANALYSIS
Structural analysis

5. Recent Projects #1
Stress Analysis of Welding
Skid Accumulator
Client
Pumps & Hydraulic Company in Norway
Scope of Work
To find the effect of weight of Pressure
Compensator & Gravity on the Tray
Inputs
3D Drawing of Welding Skid Accumulator
Material of All Parts
Material Model Type
Application Data
Output
Under the given condition, Pressure of
pressure accumulator on each tray &
three times gravity in y direction , result
& plot the Welding Skid-Accumulator
assembly is found safe.
Software Solidworks - Cosmoworks | Team 1 | Duration 5 Days

6. Recent Projects #2
Stress Analysis of a
Plastic Pin
Client
An Electronic Manufacturing Company in
United States
Scope of Work
To compare the deflection of two
different models of the pin
Inputs
Model Information
Properties of the Material
Output
After Applying 70 Newton force on both
the model, we found that model no
00097517B has less deflection compare
to the 00097517A
Software Solidworks - Cosmoworks | Team 1 | Duration 2 days

7. Recent Projects #3
Structural Dynamics of
Storage Frames
Client
An Innovative Building Solutions
Company in India
Scope of Work
To Study the effect of various loading
conditions on two different types of racks
Inputs
Drawing of two Racks
Application Data
Output
Negative Angle is the absolute angle
between the box inclination with
absolute.
For all the loading conditions, Maximum
Equivalent Stress is less than the
permissible(540MPa for Carbon Steels)
For all the loading conditions, Maximum
Shear Stress is less than permissible(270
MPa for Carbon Steels)
Software ANSYS | Team 2 | Duration 5days

8. Recent Projects #4
Thermal Analysis of Curing
Tool
Client
A Heat Transfer Engineering Solution
provider in Canada
Scope of Work
To analyze Curing Tool for Temperature
Distribution
Inputs
Heat load on the Oil Heating Channels in
375 F
Properties of the Material
Output
Outer most surfaces have minimum
temperature(steady state)
however, inner region where three
channels are nearby, seems to be high
temperature zone
Software Solidworks - Cosmoworks | Team 1 | Duration 3 days

9. Recent Projects #5
Static Structural Analysis of
Oil Storage Tank
Client
A Piping Designer Company
in Netherlands
Scope of Work
To analyze the storage tank subjected to
weight of Oil
Inputs
Drawing of Tank
Load value for Analysis
Output
The Max deformation is 4.0 mm at the
unsupported region of the Tank which is
as per expectation
Due to added support bars, the
deformation is reduced compared to
initial Design
If further reduction is required, a
longitudinal support is suggested at the
bottom region
Software Ansys | Team 1 | Duration 2 days

10. Recent Projects #6
Static Structural Analysis
Valve Body assembly
Client
Actuators Manufacturing Company
in USA
Scope of Work
To analyze Valve body subjected to
internal pressure
Inputs
3D Drawing of Valve
Material of All Parts
Material Model Type
Application Data
Output
At the given 7500 psi internal induced
Pressure
250 F Temperature Condition
Time: 5 min (300 Sec)
FOS = Yield Strength/Max. Stress
Total Deformation of 0.00196” is seen.
Software Ansys | Team 1 | Duration 4 days

11. Recent Projects #7
Static Structural and
vibrational Analysis of
Bracket
Client
Service Providing company from USA
Scope of Work
To analyze the brackets considering
weight of 2 kg and vibrational Analysis
Inputs
3D Drawing of Valve
Material of All Parts
Material Model Type
Load Data
Output
The maximum displacement observed is
1.13 mm.
The maximum stress observed in the
structure is 128.16 MPa.
Software Ansys | Team 1 | Duration 3 days

12. Recent Projects #7
Structural Analysis of Fifth
wheel Assembly
Client
A client from transport industry
Scope of Work
To analyze the fifth wheel assembly with
kingpin , drawbar and tow bar
Inputs
3D Drawing of Valve
Material of All Parts
Material Model Type
Load Data
Output
The maximum displacement plots
The von-mises stress plots
Software Ansys | Team 1 | Duration 2 days
