JB-Konstruktion is a tool and mold design company that specializes in plastic parts. They upgraded from Pro/ENGINEER to PTC Creo software. Using PTC Creo's Flexible Modeling Extension, they can now directly model parametric geometry and easily open third party data. This allows for easy redesigning of parts like adding drafts or removing radii. Using PTC Creo's modeling capabilities has reduced their design time by up to 90% in some cases. The software has improved their work efficiency and paid for itself.

1. 1
JB-Konstruktion supports customers in all stages throughout the
entire development chain in tool making. With years of experience
and industry knowledge, use of modern development tools and
innovative solution concepts the design specialist is a partner of
choice for the plastics processing industry. JB-Konstruktion
specializes in plastic-compatible (re)design of injection molded parts
to developing and optimizing complete mold assemblies.
“Using PTC Creo Flexible Modeling Extension (FMX)
allows us to easily relocate a dome, remove radii or
add drafts. The ability of directly modeling 3rd party or
parametric parts has really improved our work.
Sometimes we're up to 90% faster; just a few parts
and FMX has paid off.“
“We are still exploring the full potential of parametric
design within an associative development chain from
part to tool assembly with PTC Creo: replace or
modify the reference part, regenerate and done!“
Jürgen Brichta
CEO, JB-Konstruktion
JB-Konstruktion benefits from a 90% time savings in tool and mold
design using PTC Creo

2. 2
S o l u t i o n
• Upgraded from Pro/ENGINEER
Wildfire 5.0 to PTC Creo
• PTC Creo Flexible Modeling
Extension is used for direct
modeling of parametric geometry
and easily opens 3rd party data
• PTC Creo Complete Mold Design
Extension is used for specialized
mold assemblies
• Easy to use interface
I n i t i a t i v e s
• Include direct modeling for
redesigning, quick geometry
modification for tool design, change
management, and variant design
• Need bidirectional data interchange
with customer CAD systems without
rework
• Take advantage of a parametric
development environment with
integrated, fully associative mold
features especially for multiple usage
of tools/molds and variants
• Increase CAD user productivity
through faster handling via the new
interface
R e s u l t s
• Up to 90% time savings when
redesigning products through direct
modeling using PTC Creo Flexible
Modeling Extension
• 50% faster at modification and
variant design in mold construction
with PTC Creo Complete Mold
Design Extension
• Tools and molds designed with PTC
Creo are 100% accurate
• Significantly less mouse interaction
and faster access via the new user
interface
JB-Konstruktion benefits from a 90% time savings in tool and mold
design using PTC Creo
JB-Konstruktion supports customers in all stages throughout the entire
development chain in tool making. With years of experience and
industry knowledge, use of modern development tools and innovative
solution concepts the design specialist is a partner of choice for the
plastics processing industry. JB-Konstruktion specializes in plastic-
compatible (re)design of injection molded parts to developing and
optimizing complete mold assemblies.

3. 3
Business Challenges & Initiatives Sales Win Overview PTC Product Use
Headquartered in PingTung Neipu, Taiwan, O-TA
Precision Industry specializes in the manufacture
of golf club heads, graphite shafts, and golf club
assembly
• O-TA Precision Industry is looking to
reduce time to market and improve the
quality of their product design
• An existing PTC customer, they are
looking to upgrade their use of PTC
products in order to address challenges
with 3D design and enterprise
validation & review.
Congratulations to the team that contributed to this win:
Sales: Jackie Chen, Ken Lin
Technical Sales: Scorpio Su
Global Support: Jack Chang
Product Management: Anderson Tsai
• $400K (License and Global Support) sales
win. The customer will upgrade from Creo
Elements/Pro 5.0 to PTC Creo 2.0. They
also purchased licenses of PTC Creo
Complete Mold Design and PTC Creo
Interactive Surface Design (ISDX).
• Key stakeholders at O-TA Precision
Industry in the buying process included the
Chairman (Economic Buyer) and R&D
Head (Technical Buyer).
Q4 FY13 Sales Win: PTC Creo 2.0 Win at
O-TA Precision Industry
• O-TA Precision Industry plans to use
PTC Creo to accelerate the CAE
workflow, automate the creation of
engineering deliverables, and improve
product performance, quality, and
durability. With PTC Creo’s powerful
and flexible 3D CAD capabilities they'd
like to improve productivity and
creativity in concept design, and
improve surface creation and aesthetic
design.
• 60 individuals will use PTC Creo 2.0
