Distributed transactions in SOA and Microservices
- 1. 1CONFIDENTIAL DISTRIBUTED TRANSACTIONS IN SOA AND MICROSERVICES KANSTANTSIN SLISENKA LEAD SOFTWARE ENGINEER NOV 9, 2017
- 2. 2CONFIDENTIAL kanstantsin_slisenka@epam.com Kanstantsin Slisenka Java Team Lead Financial services, trading solutions Speaker at: Minsk Java Tech Talks, IT Week, SEC Online, Java Professionals github.com/kslisenko
- 3. 3CONFIDENTIAL AGENDA Local transactions1 Distributed transactions2 Compensations: SAGA pattern3 Live demo4
- 4. 4CONFIDENTIAL WHY DO WE NEED TRANSACTIONS?
- 5. 5CONFIDENTIAL WHY DO WE NEED TRANSACTIONS? New order created Payment received Product shipped Data must be in known state anytime
- 6. 6CONFIDENTIAL Application Business workflows Infrastructure Transactions in file systems, databases, message brokers, caches, application servers
- 7. 7CONFIDENTIAL Transaction processing is based on logging of states and transitions HOW IT WORKS
- 8. 8CONFIDENTIAL Transaction log • Always in known state • States and transitions are logged • Log can be used for recovery DATABASE TRANSACTION AS STATE MACHINE begin in progress commit rollback INSERT UPDATE DELETE commitbegin
- 9. 9CONFIDENTIAL ACID TRANSACTION GUARANTEES Atomicity All or nothing Write-ahead log
- 10. 10CONFIDENTIAL ACID TRANSACTION GUARANTEES Atomicity All or nothing Write-ahead log Consistency Data always in valid state Constraints
- 11. 11CONFIDENTIAL ACID TRANSACTION GUARANTEES Atomicity All or nothing Write-ahead log Consistency Data always in valid state Constraints Isolation Visibility of concurrent actions Locking
- 12. 12CONFIDENTIAL ACID TRANSACTION GUARANTEES Consistency Data always in valid state Constraints Isolation Visibility of concurrent actions Locking Durability Changes become permanent Write-ahead log Atomicity All or nothing Write-ahead log
- 13. 13CONFIDENTIAL Transactions guarantee the data to always be in valid state
- 16. 16CONFIDENTIAL Book trip 1. Book hotel 2. Book flight 3. Hire rental car 4. Record booking
- 17. 17CONFIDENTIAL TRAVEL BOOKING SYSTEM DBBackend browser hotels flights cars bookings
- 18. 18CONFIDENTIAL TRAVEL BOOKING TRANSACTION hotels flights cars bookings DB Action Rollback action
- 19. 19CONFIDENTIAL TRAVEL BOOKING TRANSACTION Begin hotels flights cars bookings DB Action Rollback action begin
- 20. 20CONFIDENTIAL TRAVEL BOOKING TRANSACTION Begin hotels flights cars bookings DB Action Rollback action begin room_id=15 status=booked, traveler=Kostia room_id=15 status=free, traveler=null LOCK UPDATE
- 21. 21CONFIDENTIAL TRAVEL BOOKING TRANSACTION Begin hotels flights cars bookings DB Action Rollback action begin room_id=15 status=booked, traveler=Kostia room_id=15 status=free, traveler=null seat_id=17c status=booked, traveler=Kostia seat_id=17c status=free, traveler=null LOCK UPDATE LOCK UPDATE
- 22. 22CONFIDENTIAL TRAVEL BOOKING TRANSACTION Begin hotels flights cars bookings DB Action Rollback action begin room_id=15 status=booked, traveler=Kostia room_id=15 status=free, traveler=null seat_id=17c status=booked, traveler=Kostia seat_id=17c status=free, traveler=null car_num=1234AA7 status=booked, traveler=Kostia car_num=1234AA7 status=free, traveler=null LOCK UPDATE LOCK UPDATE LOCK UPDATE
- 23. 23CONFIDENTIAL TRAVEL BOOKING TRANSACTION Begin hotels flights cars bookings DB Action Rollback action begin room_id=15 status=booked, traveler=Kostia room_id=15 status=free, traveler=null seat_id=17c status=booked, traveler=Kostia seat_id=17c status=free, traveler=null car_num=1234AA7 status=booked, traveler=Kostia car_num=1234AA7 status=free, traveler=null INSERT traveler=Kostia, room_id=15, seat_id=17c, car_num=1234AA7 DELETE traveler=Kostia, room_id=15, seat_id=17c, car_num=1234AA7 LOCK UPDATE LOCK UPDATE LOCK UPDATE LOCK UPDATE
- 24. 24CONFIDENTIAL TRAVEL BOOKING TRANSACTION Begin hotels flights cars bookings DB Action Rollback action begin room_id=15 status=booked, traveler=Kostia room_id=15 status=free, traveler=null seat_id=17c status=booked, traveler=Kostia seat_id=17c status=free, traveler=null car_num=1234AA7 status=booked, traveler=Kostia car_num=1234AA7 status=free, traveler=null INSERT traveler=Kostia, room_id=15, seat_id=17c, car_num=1234AA7 DELETE traveler=Kostia, room_id=15, seat_id=17c, car_num=1234AA7 commit LOCK UPDATE LOCK UPDATE LOCK UPDATE LOCK UPDATE Commit
- 25. 25CONFIDENTIAL TRAVEL BOOKING TRANSACTION Begin hotels flights cars bookings DB UPDATE UPDATE UPDATE UPDATE Rollback Action Rollback action begin room_id=15 status=booked, traveler=Kostia room_id=15 status=free, traveler=null seat_id=17c status=booked, traveler=Kostia seat_id=17c status=free, traveler=null car_num=1234AA7 status=booked, traveler=Kostia car_num=1234AA7 status=free, traveler=null INSERT traveler=Kostia, room_id=15, seat_id=17c, car_num=1234AA7 DELETE traveler=Kostia, room_id=15, seat_id=17c, car_num=1234AA7 rollback LOCK LOCK LOCK LOCK
- 26. 26CONFIDENTIAL NOT ONLY IN DATABASES TRANSACTIONS ARE
- 27. 27CONFIDENTIAL • Isolation levels • Locking • Commit logs • Transactions – ONE and TWO phase
- 28. 28CONFIDENTIAL Cache Messages Transactions Subscriptions ACKs, … • Transacted sessions • JMS attributes – JMSXConsumerTXID – JMSXProducerTXID
- 29. 29CONFIDENTIAL AGENDA Local transactions1 Distributed transactions2 Compensations: SAGA pattern3 Live demo4
- 33. 33CONFIDENTIAL
- 34. 34CONFIDENTIAL
- 37. 37CONFIDENTIAL WEB-SERVICE AS STATE MACHINE /reserve /confirm /cancel reserved confirmed cancelled /reserve /confirm /cancel timeout 2 1 Idempotent operations
- 39. 39CONFIDENTIAL 2-PHASE COMMIT ALGORITHM begin in progress commit rollback prepare All changes saved to log Changes copied to storage Changes cancelled 2 1
- 40. 40CONFIDENTIAL JTA AND XA SPECIFICATION Java application
- 41. 41CONFIDENTIAL Application server JTA AND XA SPECIFICATION Transaction Manager Java application
- 42. 42CONFIDENTIAL Application server JTA AND XA SPECIFICATION Resource manager Resource manager Resource manager Transaction Manager DB JMS ? Java application JDBC CUSTOM
- 43. 43CONFIDENTIAL JTA AND XA SPECIFICATION Resource manager Resource manager Resource manager Application server Transaction Manager DB ? Java application begin begin begin
- 44. 44CONFIDENTIAL Application server JTA AND XA SPECIFICATION Resource manager Resource manager Resource manager Transaction Manager DB ? Java application update update update
- 45. 45CONFIDENTIAL Application server JTA AND XA SPECIFICATION Resource manager Resource manager Resource manager Transaction Manager DB ? Java application prepare prepare prepare
- 46. 46CONFIDENTIAL Application server JTA AND XA SPECIFICATION Resource manager Resource manager Resource manager Transaction Manager DB ? Java application commit commit commit
- 47. 47CONFIDENTIAL TM does all the job for us, but: • Needs too many messages • Doesn’t scale well • Not all vendors support XA
- 48. 48CONFIDENTIAL AGENDA Local transactions1 Distributed transactions2 Compensations: SAGA pattern3 Live demo4
- 50. 50CONFIDENTIAL SAGA EXAMPLE Book hotel Book flight Book car Cancel hotel Cancel flight Confirm booking Fail! Retry Retry failed Start Finish Skip
- 53. 53CONFIDENTIAL ACID Availability Consistency Isolation Durability BASE Basic Availability Soft state Eventual consistency (Trading consistency for availability) 2-PHASE COMMIT SAGA
- 54. 54CONFIDENTIAL System is partitioned CAP THEOREM CONSISTENCY AVAILABILITY Consistency and Availability System is single node
- 55. 55CONFIDENTIAL AGENDA Local transactions1 Distributed transactions2 Compensations: SAGA pattern3 Live demo4
- 59. 59CONFIDENTIAL Car service Frontend Tier 1 Backend cache Tier 2 /bookTrip Agency DB Hotels DB Flight service requests responses JMS JMS Distributed transaction JMS endpoint Remote call Local call JMS queue /getTrips github.com/kslisenko/distributed-transactions
- 60. 60CONFIDENTIAL Frontend Tier 1 Backend cache Tier 2 /bookTrip requests responses Car service Agency DB Hotels DB Flight service JMS JMS Distributed transaction JMS endpoint Remote call Local call JMS queue /getTrips github.com/kslisenko/distributed-transactions
- 61. 61CONFIDENTIAL Frontend Tier 1 Backend cache Tier 2 /bookTrip requests responses Car service Agency DB Hotels DB Flight service JMS JMS JMS Distributed transaction JMS endpoint Remote call Local call JMS queue /getTrips github.com/kslisenko/distributed-transactions
- 62. 62CONFIDENTIAL Frontend Tier 1 Backend cache Tier 2 /bookTrip requests responses Car service Agency DB Hotels DB Flight serviceJMS JMS JMS JMS /getTrips Distributed transaction JMS endpoint Remote call Local call JMS queue github.com/kslisenko/distributed-transactions
- 64. 64CONFIDENTIAL CONCLUSION 1. State machines everywhere 2. Transactions everywhere 3. Design for failure 4. Rely on tools or handle by own
