1. DESIGNING SERVICE APPLICATIONS IN SHAREPOINT 2010 Targer: IT Pros Thuan Nguyen – ICT24H Team Founder of http://sharepointvn.net/ Blog: http://thuansoldier.net Twitter: @nnthuan Email: nguyenthuan@ict24h.net 2ND SHAREPOINT SATURDAY VIETNAM

3. Business Adoption

4. Writting2ND SHAREPOINT SATURDAY VIETNAM

5. Session Objects 2ND SHAREPOINT SATURDAY VIETNAM

7. Not flexibleExcel Calc BDC Monolithic architecture http://hrweb/ http://itweb/ 2ND SHAREPOINT SATURDAY VIETNAM

8. Share Service Provider in SharePoint 2007 The monolithic design meant that all services were available to all Web applications. You could not have a separate service for one Web application There was only one SSP for each farm, which meant that there was a single point of failure. If this SSP failed, all users lost all SSP functionality You could not implement granular services to individual business groups SSP limited the security functionality of SSP 2ND SHAREPOINT SATURDAY VIETNAM

9. Farewell to Shared Service Provider Welcome to Service Application 2ND SHAREPOINT SATURDAY VIETNAM

12. Shared across farmsBCS Visio WAC 3rd party Service http://itweb/ http://hrweb/ 2ND SHAREPOINT SATURDAY VIETNAM

13. Service Applications is buffet 2ND SHAREPOINT SATURDAY VIETNAM

14. Service Application in SharePoint 2010 Deploy granular services, delivering only the services that are requested for each Web application Design a flexible deployment that provides scalable resilience and security through the implementation of multiple instances of service applications Manage performance by deploying multiple instances of a service application for the same Web application Minimize central IT overheads and provide more effective local management by delegating administration of serviceapplications Share service applications across Web applications. Extend service functionality by deploying third-party service applications such as Microsoft Project Server 2010 2ND SHAREPOINT SATURDAY VIETNAM

15. SERVICE APPLICATIONS

16. Single Farm services vesus Cross-Farm services 2ND SHAREPOINT SATURDAY VIETNAM

17. Service Application Architecture Service: A set of bits installed on a farm that’s capable of providing some functionality. Service Application: A specific farm-level configuration of the Service in SharePoint. Service Instance: An instance of the Service running on an Application server. Service Application Proxy: A pointer to a Service Application that exists on the WFE. Service Consumer: A SharePoint feature, such as a web-part, that talks with the service and makes its functionality available to an end user. 2ND SHAREPOINT SATURDAY VIETNAM

18. SA Proxies A proxy is automatically created for an SA when the SA is created via central admin. It’s a virtual link used to connect web apps to SAs Proxies in the local farm are not created by admins, but they appear along with the SAs in central admin Some proxies might include settings that can be modified - For example, for the Managed Metadata SA, you must indicate which proxy is the default taxonomy store 2ND SHAREPOINT SATURDAY VIETNAM

21. Create a custom proxy group by selecting

22. Which SA proxies should be includedThe custom proxy group for one web app cannot be reused with a different web app 2ND SHAREPOINT SATURDAY VIETNAM

23. Hosting multiple tenants in 2010 The ability to uniquely separate each customer on a shared environment 1 2 SA WA Tenant 1 Tenant 2 SC SC SC SC SC SC SC SC SC SC 2ND SHAREPOINT SATURDAY VIETNAM

25. Allows multiple organizations to be ‘hosted’ on the same SharePoint configuration, but keeps their data isolated

26. Configurable ‘per-service’ to allow for “Mixed-Mode Partitioning”Data Partition A Partition B 2ND SHAREPOINT SATURDAY VIETNAM

27. DESIGNING SERVICE APPLICATION ARCHITECTURE 2ND SHAREPOINT SATURDAY VIETNAM

28. IT COMES TO BUSINESS REQUIREMENT Can you? I can 2ND SHAREPOINT SATURDAY VIETNAM

29. Planning? Service Application Dependencies Service Application Components “Translate” Business Requirement to SA Logical Architecture for Service Application 2ND SHAREPOINT SATURDAY VIETNAM

30. Service Application Dependencies Just example 2ND SHAREPOINT SATURDAY VIETNAM

31. Service Application Components Service Application Connection (aka Proxy) Service Application Proxy Group Service Application Databases 2ND SHAREPOINT SATURDAY VIETNAM

32. Where is your pen and paper? Worksheet 1 2ND SHAREPOINT SATURDAY VIETNAM

33. Worksheet 2 0 = No √ = Yes 2ND SHAREPOINT SATURDAY VIETNAM

34. LOGICAL ARCHITECTURE Using Planning Worksheet for designing Logical architecture 2ND SHAREPOINT SATURDAY VIETNAM

36. Mainly uses Collaboration, Search

38. Search content

39. Collaboration

41. Excel Service

42. Managed Metadata Service

43. User Profile

44. Business Data Connectivity

45. Secure Store Service

47. My Site (App Pool B)

48. Team Site (App Pool B)2ND SHAREPOINT SATURDAY VIETNAM

49. Access Service Excel Service User Profile Managed Metadata Search Service Business Data Connectivity Secure Store Service Default Group Web Application Publish Intranet Web Application Team Site Web Application My Site Application Pool Application Pool 2ND SHAREPOINT SATURDAY VIETNAM

50. Managed Metadata Excel Service User Profile Access Service Search Service Excel Service Business Data Connectivity Secure Store Service Default Group Custom Group Web Application Department Site Web Application My Site Web Application Publish Intranet Application Pool Application Pool 2ND SHAREPOINT SATURDAY VIETNAM

52. Using all or some SharePoint workloads.

54. Search content

55. Social Network

57. Excel Service

58. Managed Metadata Service

59. User Profile

60. Business Data Connectivity

61. Secure Store Service

63. My Site (App Pool B)

64. Team Site (App Pool B)

65. Isolation site (App Pool C)2ND SHAREPOINT SATURDAY VIETNAM

66. Managed Metadata Managed Metadata Excel Service User Profile Excel Service Access Service Business Data Connectivity Secure Store Service Search Service Business Data Connectivity Custom Group Default Group Custom Group Finance Site Published Intranet Team Site My Site 2ND SHAREPOINT SATURDAY VIETNAM

68. Using all or some SharePoint workloads

69. Optimize administrative tasks

70. Flexible and Scalable architecture

71. Organizational boundaries

73. Dedicated Collaboration

74. Implement solutions: Search, ECM, Social Network and so on..

75. Published Content

76. Isolate Department for security policy2ND SHAREPOINT SATURDAY VIETNAM

77. Farm 1 – Enterprise farm User Profile Search Managed Metadata Secure Store Service Business Data Connectivity Farm 4 Department Farm 2 Published content Default Group Published Intranet Excel Service Farm 3 Collaboration farm Visio Graphic Excel Service InfoPath Default Group Managed Metadata Default Group Word Automation Visio Graphic Access Service Usage and Heath Data Collection Access Service Usage and Heath Data Collection PowerPoint Department Sites My Site Team Site

78. Q & A 2ND SHAREPOINT SATURDAY VIETNAM

79. Thanks you for attending 2ND SHAREPOINT SATURDAY VIETNAM
