AEM instance is traditionally see as a "pet" - an application that requires manual work for the deployment and the constant oversee in the runtime. Transforming instances into "cattle" and moving them into cloud brings a number of challenges around persistence, replication, scaling, monitoring, upgrades and maintenance. However, cloud computing services like Azure and container orchestration systems like Kubernetes allows to solve these problems in the new, creative ways, while the resulting cloud setup offers scalability not possible before. This session will provide an overview on the Kubernetes setup we internally use in Adobe, the issues we've run into and the ways we're dealing with them.

1. APACHE SLING&FRIENDSTECHMEETUP
2- 4SEPTEMBER 2019
Deep-diveinto cloud-native AEM deployments based on Kubernetes
Tomek Rękawek, Adobe

2. 2
Cloud: whatand why?

3. Wewanttomovefrom
3

4. to
4

5. Cloud:why?
5
 RunningAEM at scale
 Hassle-freedeployments
 The cloud provider (AWS, Azure) should worry about
infrastructure

6. Agenda
6
 Jobs
 Content migration
 New indexes
 QA
 Docker&Kubernetesintroduction
 Architectureoverview
 Publishpersistence
 Cloud Segment Store
 Golden publish
 Compaction
 Sidecarservices

7. 7
Docker & Kubernetesintroduction

8. Thepowerofstandardization
8

9. DockerizedAEM
9
 AEM in Docker image
 Composite Node Store
 /apps& /libs storedin thecontainer
 Actualcontentlives outside,in the VOLUMEorMongoDB
 OSGi Feature Model
 DefinesAEMandcustomerapplication
 Featurelauncherstartsit inside container
 Covered in Karl& David’spresentation
 SeeadaptTo() 2017 talk for moredetails

10. Mini intro toKubernetes
10
 Launches Docker containers without worrying about the underlying VMs
 Dictionary
 Pod–a groupofcontainersstartingtogetheron asingle machine
 Service –internalloadbalancer,exposinganumberofpodreplicas underasingle address
 Ingress– exposesa service underanpublic httpaddress
 Everyentity is represented by a YAML object in K8s API server
 TheYAML is the desired state, K8s knows how to get there

11. DeploymentswithHelm
11
 Helm – K8s apps management
 Chart – a bunch of K8s YAML descriptors,
with a simple templating
 Whole AEMdeployment canbe
installed/upgraded with a single command
Image:https://helm.sh

12. 12
Architecture overview

13. AEMKubernetessetup
13

14. 14
Publishpersistence evolution

15. Problemdefinition
15
 Author persistence is easy-ish with MongoDB
 Publish is harder –local SegmentMK, no clustering
 Thepublish farm is kept up-to-date with replication
 However:
 weneed toprovidethenew publishinstanceswitha segment store,
 copyit fromanotherinstance.
 Problems:
 copyingfiles betweenpodsis hardandhacky,
 whatif there’snopublishto copyfrom?

16. Cloud SegmentStore
16
 A new plugin for the Segment Node Store
 Nodes are stored in a cloud storage service
 No tar files, raw segments grouped in dirs
 Can be used in RW or RO modes

17. Goldenpublish
17
 A designated publish instance
 Not connectedto LB
 It maintainsa “golden copy” of the
segmentstore
 New publish just clone it

18. Problem:duplicatedbinaries andstartuptime
18
Golden publish
Segment 1
Segment 2
Segment 4
Segment 3
Segment x
Publish 1
Segment 1
Segment 2
Segment 4
Segment 3
Segment y
Publish 2
Segment 1
Segment 2
Segment 4
Segment 3
Segment z
Publish 3 (starting)
Segment 1
Segment 2
Segment 3
Segment 4
 Multiple copies of the same segments 1-4 ($$$)
 Cloning a bucket takes time during the publish start ( 🕑🕑🕑)

19. Optimization:a singlesegmentstore
19

20. 20
Publishpersistence: compaction

21. Compaction
21

22. Out-of-bandpublish update
22
 This pattern willbe usefulin many cases
 We may clone thepublish repository,
modify it and re-deploy instanceson
top of it
 Persisted message queuewill apply
missingchanges

23. 23
Sidecar services

24. Sidecar approach
24
 A single pod can run many containers, sharing their volumes and
localhost interface
 We can use them for the auxiliaryservices (sidecars):
 Dispatcher in the publish pod
 Upload logs to Splunk
 Warmup service

25. AEMpod withsidecars
25Sidecaricon: Flaticons.com

26. 26
Jobs

27. Kubernetesjob
27
 Starts a pod
 Meantto perform a specific task and finish
 Unlikethe deployment, which run indefinitely
 Willbe restarted if fails
 Jobs provides a way to interactwiththe deployed AEM

28. 28
Contentmigration

29. Contentmigration
29
 How to migrate old content to K8s?
 Access problem
 old AEM envs shouldn’t have access to the K8s (encapsulation)
 K8s shouldn’t be able to access oldAEMs (they can be installed
anywhere)
 Solution:demilitarized zone

30. 2-phasemigration
30
 Phase 1
 Themigrator tool (crx2oak-like jar) is used to
export old AEM content into a cloud storage
service
 Phase 2
 A Kubernetes job is used to apply the migrated
content on the cloud instances

31. 31
Newindexes

32. Addingnew index
32
 Indexesaretricky
 /oak:index is a part of the mutable content
 But indexdefinitions belongs to the application
 Onlyaddingnew indexesis supported
 Whena new indexis addedin /oak:index,it’ll haveanextra
useIfExistspropertyreferencing immutable part/apps
 This bounds the index definition tothe application version andDocker
 This /appspathhaveto beaddedas well
• /oak:index/my-new-index
• useIfExists: /apps/indexes@v3
• /apps/indexes
• v3: true
Mutable part
Immutable part

33. Mutablecontent:addingnew index
33
 Indexingjob should be runbefore the actual app deployment
 Thejob will:
1. Look forthe new index defs in /oak:index
2. Perform out of band indexing ofthe content
3. Save the new indexing content tothe production repository
 TheuseIfExists will makesure that the newindexis ignored, untilthe
newimageis installed
 When the new image is deployed, the /apps part will be updated and the
new index will beused

34. 34
Other topics

35. Relatedtopics
35
 Feature model usage in Docker (covered in David’s and Karl’stalk)
 Replication (covered in Timothee’s talk)
 Monitoring with Prometheus and Grafana
 CI/CD pipeline
 Network policies
 …

36. 36
Thanks!
