1. RelHy International Workshop on
High Temperature Electrolysis Limiting Factors
June 09-10, 2009
Karlsruhe, Germany
S. Elangovan, J. Hartvigsen,
Feng Zhao, Insoo Bay, and Dennis Larsen
Office of Naval Research Contract: N00014-08-C-0680
DOE subcontract through Idaho National Lab.
2. Energy, Environment & Economy
• Environment
– Climate Change
• GHG sources
– 8 tons CO2/kW-yr from coal or oil
– Leaky natural gas pipelines
– Ruminants
• Ozone hole - no, that’s a different topic
– Habitat Impacts One Thing Is Clear
• Drilling in Arctic National Wildlife Refuge
Energy Is The Key To Prosperity
• Wind turbines in Chesapeake Bay
– Air pollution
• Limited Resources
– Oil
• National security
– Gas
• Heating vs. power generation
• Transportation issues
– Renewables
3. Carbon Free Energy Source Options
• Renewable energy resources
– Large Scale Wind
• 800 GW at class 4+ US wind sites
– Small Hydro
• 45GW potential, 2000 sites
– Concentrator Photovoltaic
• Land area 12km2 /GW
– Biomass
• Ag/Forestry byproduct
• Carbon neutral cycle assuming production
and processing are carbon free
• Nuclear
– 25 new plants announced
– Increased output of existing units
• Note trend in figure since 1970
• Hydrogen production from electrolysis
• High temperature 29 tons/GW-hr
• Conventional 21 tons/GW-hr
http://www.eia.doe.gov/emeu/aer/pdf/pages/sec1_6.pdf
4. Storing Hydrogen With CO2
• Energy Sources
– Wind, Solar (PV & heat), Hydro, Nuclear
• Carbon Sources
– Metallurgical Reduction, Cement Kilns
– Fermentation, Digester gas
– Biomass gasifiers
– Fossil Power Systems
• Conversion Technology
– SOFC electrolyzer, steam+CO2=> syngas
• Products
– SNG, Fischer Tropsch liquids
5. Why Electrolytic Synfuels
• Electrolysis efficiency
• Energy storage density
• Fits in existing distribution infrastructure
• Synergy with intermittent energy sources
• No added CO2 emissions
• Reduced work of compression
• Compatible with existing vehicle fleet
– 20 to 50 year crossover
6. The New Alchemy: C ⇒ Au
• Turning carbon into gold
– Low value carbon
• CO2 -$55/ton (Norway C tax)
• Coal $20-100/ton
• Bitumen ~ $100/ton
– High value carbon
• Natural Gas $444/ton carbon
($7/decatherm)
• Crude Oil $888/ton carbon ($105/bbl)
• Refined fuel (pre-tax) ~$1000/ton carbon
7. Synthetic methane from electrolysis of CO2
Gas analysis in volume %
From From
Electrolysis Methanation
Unit
CH4 CO H2 CH4 CO H2
Test 1 .0 14.3 60.7 42.5 0 13.8
Test 2 .7 18.5 58.0 47.7 0 9.2
Test 3 .3 20.1 63.5 50.0 0 9.4
Test 4 .1 15.8 58.9 42.0 0 4.6
Test 5 .1 15.2 59.5 40.4 0 8.2
FEED TO ELECTROLYSIS IS CO2 + H2O + ELECTRIC ENERGY
8. FT- Liquid Products
• Ceramatec produced catalyst
– FeCuK composition
– 8mm La promoted alumina rings
– Automated in-situ reduction
profile using dewpoint controlled
temperature ramp
– Oil fraction
– Water fraction
235 C Reactor Operation
9. One Technology - Multiple Modes Of Operation
Solid Oxide Stack Module
NG
Biogas
Diesel Fuel Syngas
JP-8
Coal
Electricity CO2 & Steam
+ Electricity
Steam + Hydrogen
Electricity (High Purity)
10. SOFC - SOEC Differences
• Cells tested to date are virtually identical
– Same electrolyte, electrodes, pattern, etc.
• SOEC seals more challenging
– Higher back pressure on seals due to product
collection
– Low molecular weight stream vs. reformate
• Diffusion mechanism more active relative to
hydrodynamic
• Hydrogen permeation in metal icon destabilizes air
side scale
11. Repeat Unit Elements
Ferritic Stainless Steel Separator
Corrugated Ferritic Stainless Steel or High Ni alloy
50 µm
50 µm Cobaltite (current distribution layer)
air
electrode Manganite + Zirconia Composite
electrolyte Sc - ZrO2 (partially stabilized)
Ni + ceria cermet
H
electrode Ni (current distribution layer)
Corrugated Ni flow field on hydrogen side
21. Pre-ILS Module Test at Ceramatec
• “Half-ILS Module” test at Ceramatec
– Integrated Laboratory Scale (ILS) Demonstration
– 2x60 cell stacks, 10x10 cm cells
– Summer 2006, ~2000 hr operation
– Cells & Stacks same as full ILS modules 2007,2008
– Show performance scales with stack height
– Assess system issues with tall stacks
– Exercise component production capacity
– Probably most extensive post test examination
• Tested component examination
– ANL, MIT, UNLV, Ceramatec
22. Half ILS Initial Performance
– 3.8 kW
– 1,200 Liters/hr
– Electrical Efficiency = 96.4%
– System thermal distribution issues
– 2,000 hrs total operation
– 1,000 hrs on CO2/H2O
• Syngas production sufficient for 100
gallons of FT diesel
24. Half-ILS Post-Test Observations
• Electrodes
– Oxygen electrode delamination for 2,000 hr test
• No delamination in short stacks tested for shorter periods (~300 hrs)
– Hydrogen electrode & current distribution layer in good condition
• Electrolyte
– No cracking
– Some cubic to tetragonal/mono-clinic transition noted
• Metal Interconnect Edge Corrosion
– Edge rail coating & elimination of silica in seal eliminated the corrosion seen
in early SOEC stacks
– Cr transport to air electrode bond layer
– Sr migration from air electrode/bond layer
• Gross changes in bond layer chemistry, phase assemblage, conductivity and performance
• Initial Performance Reproducible – short to tall stacks
• Unacceptably High Initial Degradation
26. Full-ILS Module #3 Post Test Examination
Hydrogen electrode attached,
bond layer separated with icon
Oxygen electrode delamination
27. ILS Module #3 Post Test Examination
It appears a layer deposited
at electrode interface is causing
the delamination
Oxygen electrode and icon
contacting layer (bond layer)
28. ILS Module #3 Post Test Examination
EDS Indicates only ScSz at the
interface. The apparent deposition
layer is a layer of zirconia that
has spalled off. Our hypothesis is
that Mn diffusing in from the
manganite electrode introduces
enough electronic conductivity
to allow oxygen to evolve inside
the electrolyte, build up pressure
and split off a layer near the
electrode.
29. ILS Module #3 Post Test Examination
Electrode section in following EDS Maps
Manganite-Zirconia Composite
Manganite Electrode
Cobaltite (LSCo) icon
contacting layer (bond layer)
41. Hydrogen Electrode & Bond Layer
Adherent and conductive hydrogen electrode
Most areas of bond layer separated with flowfield
42. Oxygen Electrode and Bond Layer
Extensive delamination of standard manganite Perovskite electrodes
No delamination of new cobalt-ferrite Perovskite electrodes
46. High Temperature Electrolysis
• Leverage decades of SOFC R&D
• Inputs
– e- (green electrons)
– steam => hydrogen
– co-electrolysis of H2O + CO2 => syngas
– heat input optional, depends on operating point
• Most efficiency means of hydrogen production
– e- to hydrogen
• η=100% at 1.285V
• η= 95% at 1.35V
• η=107% at 1.20V, (heat required)
• Hot O2 and steam byproduct
– Valuable for biomass gasification
