1. Cross-Platform Auth
with Google+ Sign-In
Google+ Platform
Peter Friese - Developer Advocate

2. Peter Friese - Developer Advocate
+PeterFriese
@peterfriese
http://www.peterfriese.de

3. What is Google+ ?

4. https://www.flickr.com/photos/dainbinder/10538549606/

5. http://openclipart.org/detail/26329/aiga-immigration-bg-by-anonymous

6. What is Authentication?

7. What is Authentication?
αὐθεντικός (greek):
!
“that comes from the author” /
authentic /original /genuine
Authentication:
!
The act of confirming the truth of
an attribute of a datum or an
entity.
datum or an entity.

8. Authentication Factors
Ownership Knowledge Inherence
https://www.flickr.com/photos/europealacarte/9152848988/ https://www.flickr.com/photos/gcfairch/3595771919/https://www.flickr.com/photos/z0/5055081370/

9. Authentication - How hard can it be?
https://www.flickr.com/photos/isherwoodchris/7018779395/

10. Quite hard, actually!
https://www.flickr.com/photos/govwin/5609940697/
Things to consider
• Encrypt traffic
• Hash + salt passwords
• Two-factor auth
• Account recovery
http://upload.wikimedia.org/wikipedia/commons/4/41/Space_Shuttle_Columbia_launching.jpg

11. You might end up in the News

12. On the shoulders of Giants…
https://www.flickr.com/photos/govwin/5609940697/
Use an identity provider
• Easier for you
• Easier for the user
• Established, trusted brand
• Focus on your business model
(rather than re-inventing the wheel)
http://www.nasa.gov/centers/dryden/images/content/690557main_SCA_Endeavour_over_Ventura.jpg

13. ±
KEEP CALM
AND
SIGN IN
WITH
GOOGLE+

14. Google+ Sign-in Features

15. Google: trusted brand
2-factor verification, using your phone
Works alongside existing sign-in systems
Secure Authentication
Google+ Sign-in Features
Learn more about your users (with their consent)

16. Sign-in to web site
Cross-Device Single Sign-on and Over-the-Air Install (OTA)
Google+ Sign-in Features

17. Sign-in to web site
Cross-Device Single Sign-on and Over-the-Air Install (OTA)
Google+ Sign-in Features

18. Sign-in to web site
Cross-Device Single Sign-on and Over-the-Air Install (OTA)
Google+ Sign-in Features

19. Sign-in to web site
Cross-Device Single Sign-on and Over-the-Air Install (OTA)
Google+ Sign-in Features
OTA consent dialog

20. Sign-in to web site
Cross-Device Single Sign-on and Over-the-Air Install (OTA)
Google+ Sign-in Features
OTA consent dialog
OTA installation

21. Sign-in to web site
Cross-Device Single Sign-on and Over-the-Air Install (OTA)
Google+ Sign-in Features
OTA consent dialog
OTA installation

22. Sign-in to web site
Cross-Device Single Sign-on and Over-the-Air Install (OTA)
Google+ Sign-in Features
OTA consent dialog
OTA installation
Auto signed in on other device

23. Sign-in to web site
Cross-Device Single Sign-on and Over-the-Air Install (OTA)
Google+ Sign-in Features
OTA consent dialog
OTA installation
Auto signed in on other device

24. How does Google+ Sign-in work?

25. AppUser
Google
Based on OAuth 2.0
How does Google+ Sign-in work?
Consent Permission

26. AppUser
Google
Based on OAuth 2.0
How does Google+ Sign-in work?
Consent Permission
No password sharing
Scoped access
Revocable

27. Implementing Google+ Sign-in

28. Developer Console Project
Setting up
https://developers.google.com/console
APIs
Credentials
iOS Client ID
Android Client ID
Web Client ID
Branding
Permissions
Management

29. Developer Console Project
Setting up
https://developers.google.com/console
APIs
Credentials
iOS Client ID
Android Client ID
Web Client ID
Branding
Permissions
Management
One project, multiple clients

30. Developer Console Project
Setting up
https://developers.google.com/console
APIs
Credentials
iOS Client ID
Android Client ID
Web Client ID
Branding
Permissions
Management
One project, multiple clients
Authorization is granted to
your application, not a specific
client!
* Single user consent across
devices
* Cross-Device Single Sign-on
* Available for Web &
Android

31. You Google
The Auth Triangle
Connecting lines
need authentication
Client
Server
Google APIs

32. You Google
Client
Server
Google APIs
Client Authentication

33. Client Authentication

34. Create OAuth 2.0 client ID
Link with Google Play Services API
Setup Sign-In
Overview
Client Authentication: Android

35. SDK Architecture
Client Authentication: Android
iOS
Your App
Google APIs
Google Play
Client Library
Google Play
Services APK
Authorize using existing
accounts on Android device

36. mApiClient = new GoogleApiClient.Builder(this)
.addConnectionCallbacks(this)
.addOnConnectionFailedListener(this)
.addApi(Plus.API, null)
.addScope(Plus.SCOPE_PLUS_LOGIN)
.build();
Java
GoogleApiClient Lifecycle
Client Authentication: Android
onCreate()
onStart() mApiClient.connect();
Java
onStop()
if (mApiClient.isConnected()) {
mApiClient.disconnect();
}
Java
<com.google.android.gms.common.SignInButton
android:id="@+id/sign_in_button"
android:layout_width="wrap_content"
android:layout_height="wrap_content"/>
XML
running

37. Handle connection failure
Client Authentication: Android
public void onConnectionFailed(ConnectionResult result) {
if (!mIntentInProgress && result.hasResolution()) {
try {
mIntentInProgress = true;
startIntentSenderForResult(result.getResolution().getIntentSender(),
RC_SIGN_IN, null, 0, 0, 0);
} catch (SendIntentException e) {
// The intent was canceled before it was sent. Return to the default
// state and attempt to connect to get an updated ConnectionResult.
mIntentInProgress = false;
mApiClient.connect();
}
}
}
Java

38. Handle connection failure
Client Authentication: Android
public void onConnectionFailed(ConnectionResult result) {
if (!mIntentInProgress && result.hasResolution()) {
try {
mIntentInProgress = true;
startIntentSenderForResult(result.getResolution().getIntentSender(),
RC_SIGN_IN, null, 0, 0, 0);
} catch (SendIntentException e) {
// The intent was canceled before it was sent. Return to the default
// state and attempt to connect to get an updated ConnectionResult.
mIntentInProgress = false;
mApiClient.connect();
}
}
}
Java
User needs to select account, consent to permissions, ensure
network connectivity, etc. to connect

39. Connection successful
Client Authentication: Android
public void onConnected(Bundle connectionHint) {
// Retrieve some profile information to personalize our app for the user.
Person currentUser = Plus.PeopleApi.getCurrentPerson(mApiClient);
// Indicate that the sign in process is complete.
mSignInProgress = STATE_DEFAULT;
}
Java

40. Create OAuth 2.0 client ID
Integrate SDK
Setup Sign-In
Overview
Client Authentication: iOS

41. iOS
Your App
Google APIs
Google+
iOS SDK
SDK Architecture
Client Authentication: iOS
Statically linked library

42. #import <GooglePlus/GooglePlus.h>
#import <GoogleOpenSource/GoogleOpenSource.h>
!
...
!
!
GPPSignIn *signIn = [GPPSignIn sharedInstance];
signIn.shouldFetchGoogleUserEmail = YES;
!
signIn.clientID = @“YOUR_CLIENT_ID”;
signIn.scopes = @[@"profile"];
signIn.delegate = self;
Objective-C
Configure Sign-In
Client Authentication: iOS

43. Perform Sign-In, Option 1 (use our button)
Client Authentication: iOS

44. Create own button / use action sheet / …
// trigger sign-in
[[GPPSignIn sharedInstance] authenticate];
Objective-C
Silent sign-in if user has signed in before:
// silently sign in
[[GPPSignIn sharedInstance] trySilentAuthentication];
Objective-C
Perform Sign-In, Option 2 (create your own button)
Client Authentication: iOS

45. Receiving the authorisation
Client Authentication: iOS
// In ApplicationDelegate
- (BOOL)application:(UIApplication *)application
openURL:(NSURL *)url
sourceApplication:(NSString *)sourceApplication
annotation:(id)annotation
{
return [GPPURLHandler handleURL:url
sourceApplication:sourceApplication
annotation:annotation];
}
!
!
// GPPSignInDelegate
- (void)finishedWithAuth:(GTMOAuth2Authentication *)auth
error:(NSError *)error
{
if (!error) {
NSString *gplusId = [GPPSignIn sharedInstance].userID;
}
}
Objective-C

46. Create OAuth 2.0 client ID
Include JavaScript client on your web page
Add Google+ Sign-in button
Handle callback
Overview
Client Authentication: Web

47. Browser
Your site
Google APIsplusone.js
Architecture
Client Authentication: Web

48. <div id="gConnect">
<button class="g-signin"
data-scope="https://www.googleapis.com/auth/plus.login"
data-requestvisibleactions="http://schemas.google.com/AddActivity"
data-clientId="YOUR_CLIENT_ID"
data-callback="onSignInCallback"
data-cookiepolicy="single_host_origin">
</button>
</div>
!
<!-- Place plusone.js asynchronous JavaScript just before your </body> tag —>
HTML
Integrate sign-in button
Client Authentication: Web

49. function onSignInCallback(authResult) {
if (authResult['access_token']) {
// Successfully authorized
} else if (authResult['error']) {
// User is not signed in.
}
}
JavaScript
Handle authorization callback
Client Authentication: Web

50. Server Authentication
You Google
Client
Server
Google APIs

51. One-Time-Code Flow
C
li
e
n
t
S
e
r
v
e
r
Google
APIs
1: Client-side auth request
2: OAuth dialog
triggeredOAuth
2.0
Dialog
3: access_token,
one-time code,
id_token
4: one-time code 5: exchange one-time codefor access_token andrefresh_token
6: access_token,
refresh_token
7: “fully logged in”

52. <div id="gConnect">
<button class="g-signin"
data-scope="https://www.googleapis.com/auth/plus.login"
data-requestvisibleactions="http://schemas.google.com/AddActivity"
data-clientId="YOUR_CLIENT_ID"
data-callback="onSignInCallback"
data-cookiepolicy=“single_host_origin">
data-callback="signInCallback">
</button>
</div>
!
<!-- Place plusone.js asynchronous JavaScript just before your </body> tag —>
HTML
Integrate sign-in button
Server Auth: One-Time Code

53. function signInCallback(authResult) {
if (authResult['code']) {
// Send the code to the server
$.ajax({
type: 'POST',
url: 'plus.php?storeToken',
contentType: 'application/octet-stream; charset=utf-8',
success: function(result) {
// Handle or verify the server response if necessary.
console.log(result);
} else {
$('#results').html('Failed to make a server-side call.');
}
},
processData: false,
data: authResult['code']
});
} else if (authResult['error']) {
console.log('There was an error: ' + authResult['error']);
}
}
JavaScript
Handle authorization callback
Server Auth: One-Time Code

54. $code = $request->getContent();
!
// Exchange the OAuth 2.0 authorization code for user credentials.
$client->authenticate($code);
!
$token = json_decode($client->getAccessToken());
!
// Verify the token
...
!
// Store the token in the session for later use.
$app['session']->set('token', $client->getAccessToken());
$response = 'Successfully connected with token: ' . print_r($token, true);
PHP
Exchange one-time code
Server Auth: One-Time Code

55. Best practices and Common Pitfalls

56. Best practices and Common Pitfalls
Common Pitfalls
Guidelines
Best practices
Useful resources

57. Guidelines
• Use our client libraries (they’re well debugged) instead of rolling your
own HTTP requests
• Provide a way for the user to sign out / disconnect your app
• Use “Sign in with Google” when labelling your sign in buttons. Don’t use
“Sign in with Google+”
• Equal rights to everyone: sign-in buttons should be equally sized for all
networks you support
• Ask only for permissions you really need. Also, consider using
incremental auth - this will likely increase sign-up rates.

58. Pitfalls: iOS
• Not providing a URL type for callback
• Not providing the ApplicationDelegate
application:openURL:sourceApplication:
annotation: callback or failing to call
GPPURLHandler
handleURL:sourceApplication:annotation

59. Best practices and Common Pitfalls
deprecated)
Use Stop using
profile
(for basic login)
https://www.googleapis.com/auth/userinfo.profile
plus.login
(if you need more info about a user. Includes profile)
email
(the user’s email address)
https://www.googleapis.com/auth/userinfo.email

60. Useful resources
• Scopes
https://developers.google.com/+/api/oauth#scopes
• Developer Console
https://console.developers.google.com/project
• OAuth 2.0 Playground
https://developers.google.com/oauthplayground/
• Tokeninfo
https://www.googleapis.com/oauth2/v1/tokeninfo?access_token=

61. Review

62. • Do not build your own authentication system
• Google+ makes authentication easy
• Authentication models depends on architecture
• Learn more: check out our Quickstarts at
https://developers.google.com/+/ and
https://github.com/googleplus
Cross-Platform Auth With Google+ Sign-in
Review

63. <Thank You!>
developers.google.com/+
Peter Friese - Developer Advocate
+PeterFriese
@peterfriese
http://www.peterfriese.de
