1. Development
and implementation
of Connected Car
technologies
Smart Driving Labs, July 2019

2. 100 7 years 40 15
The Laboratory is founded by professionals in cross disciplinary fields of
knowledge: developers, engineers, insurance specialists and data scientists
People On the market Software
engineers
Hardware
engineers

3. We use a state
of the art Device
Our Platform The platform is
compatible with over
90% of all world wide
vehicles
Connected to the ODB2
socket with GPS, micro
controller, accelerometer,
GSM and RF modules,
making it a totally
autonomous device
Resides on the cloud
gathering real time data
and is easy integrated with
external systems due to its
modular architecture and
APIs/SDK availability
Being able to instantly
gather real time data from
the vehicle, added to the
remote control features
when available in the car
A one of a kind
security anti-theft
That is fully integrated
with the platform
Our mission has always been for the last 3 years to create the best
connected car platform in the market
• E-Call solution
• Supports CAN, LIN and
K-line
• Meets global OEM
standards
Our firmware /
software
Has one of the best
algorithms and logic on
the market, consuming
the least amount of
internet data possible
{
}
• Customization for OEM
• Integration with any TCU
units
• Full Localisation to meet
any legal requirements

4. We are combining technologies, data
and vehicles into a unified ecosystem
which benefits drivers, insurers, dealers,
car makers and fleet operators

5. Insurance
companies
Scoring
Online insurance
New insurance
programs
Car makers
CC-services
Security
MarketPlace
Online insurance
Corporate
clients
Fleet management
Security
Driver scoring
Private person
CC-services
Security
Reducing driving cost
Discounts on Hull
Online services
Car dealers
Additional sales
revenue
Return to technical
inspection
Discount on Hull

6. Antitheft features
blocking device and
identification tag
Police Support and
Road Assistance in
case of emergency
Features and services
for vehicles on the road
Telematics with
all the trips, car
diagnostics, stats and
insurance programs

7. Test Drive Bi
optimises usage of
test-drive vehicles
Client Profiling
additional
personalised offers
depending on how
clients drive
Features and services
for dealerships
Crash Ai detects and
analyses collisions and
mechanically caused
accidents
Remote Diagnostics
detects engine
malfunctions and
allows to schedule
timely maintenance
GEO Zone Control
for leased vehicles and
real-time monitoring
for fleets
Push and SMS
communication
efficient personalised
marketing channel

8. Software and hardware developed
for transportation of tomorrow

9. Element app is an ultimate tool for drivers with remote control functions,
smart engine autostart, trip logging, event notifications, usage stats

10. Favorit Motors
Koptevo
59 автомобилей, 3.07—3.10.2017
ЗОНЫ ИСПОЛЬЗОВАНИЯ
Новомосковский
СЗАО
ВАО
ЮЗАО
ЮВАО
ЦАО
СВАО
ЮАО
ЗАО
Троицкий
САО
(blank)
ЗелАО
9,3%
5,0%
4,8%
4,2%
3,1%
2,1%
2,0%
1,9%
1,8%
1,7%
0,7%
0,5%
0,0%
2773 км
1489 км
1439 км
1267 км
915 км
624 км
604 км
562 км
524 км
494 км
204 км
140 км
5,53 км
Москва
Московская
область
Регионы
37,0%
23,6%
37,0%
11049 км
11049 км
11049 км
ИНТЕНСИВОНОСТЬ
ИПОЛЬЗОВАНИЯ АВТОМОБИЛЯ
SLD Atlas is a universal fleet, communications and marketing platform
scalable for vehicle fleets, insurance companies, car dealers and auto makers.

11. SLD Atlas
Fleet Monitoring
Real-time vehicle location
tracking
Trips’ logging
Evaluation of driving quality
for each driver
Road speed limit profiling
Accidents and crashes
displayed on the map

12. SLD Atlas
Crashes & Accidents
Crashes detected by SDL Crash
Ai displayed in unified interface
Location, accident severity,
vehicle details of an affected
party
Transparency of each accident
handling

13. SLD Atlas
Campaigns
Marketing communication
though free push notifications
Personalised advertising
messages based on age, make
and model of the car,
geography of use, etc.

14. Element technical and physical characteristics
Supply voltage, V
(direct current)
8 ... 35 V
Current consumption
in active mode (medium)
100 mA
Current consumption
in sleep mode
10 mA (GPS receiver
is switched on 30mA)
Operating temperature
range
-30…+65 °C
Built-in battery Li-ion, 450 mAh
Battery life time Up to 12 h (depending on
settings and temp)
Accelerometer sensitivity ±0.008 G
Interface 2 CAN interfaces, K-line,
LIN
Radio interface Radio transceiver
for 868 MHz
Number of outputs 2
Number of inputs 2
Type of inputs RS-232/frequency/analog
GPS Receiver Type 100mANAVIA, GLONASS/
GPS
GSM modem Quectel M66 GSM
900/1800, microSIM
Built-in non-volatile
Flash memory
4 Mb (20,000 packages)
Dimensions 70mm x 45mm x 20mm
Weight 150g
Body material ABS plastic or Polycarbonate
Waterproofness None
Guarantee 12 months from the date
of purchase
Average service life 10 years
Battery life 500 charge/discharge
cycles
45 mm
70mm
20mm

15. ERA / E-call technical and physical characteristics
Supply voltage, V
(direct current)
8 ... 35 V
Current consumption
in active mode (medium)
200 mA
Current consumption
in sleep mode
10 mA (GPS receiver
is switched on 30mA)
Operating temperature
range
-40…+85 °C
Built-in battery Li-ion, 1400 mAh
Battery life time Up to 12 h (depending on
settings and temp)
Accelerometer sensitivity ±0.008 G
Interface 2 CAN interfaces, K-line,
LIN
Radio interface Radio transceiver
for 868 MHz
Number of outputs 11
Number of inputs 9
Type of inputs Digital/analog
GPS Receiver Type EVA-M8M, GLONASS/GPS /
EGNOS-Galileo
GSM modem Quectel UC15, GSM/UMTS
Built-in non-volatile
Flash memory
4 Mb (20,000 packages)
Dimensions 145mm x 90mm x 36.3mm
Weight 250g
Body material ABS plastic or Polycarbonate
Waterproofness None
Guarantee 12 months from the date
of purchase
Average service life 10 years
Battery life 500 charge/discharge
cycles
90mm
145 mm
36.3 mm

16. Power Bi
optimises usage
of test-drive
vehicles

17. Crash Ai is a neural network capable of detecting, evaluating and measuring
vehicle collisions, crashes and mechanically caused accidents
Speed Dynamics
Impact Force
100
60
40
0
0
3
6
9
-3
-6
-9
Impact force Medium
Speed at the moment 82 км/ч
Impact vector Front – Right
Ignition status On
Time of impact 2 Feb 2019, 23:47
Location MKAD, 56 km, Moscow, Russia

18. Driver's scoring– based on our own
cartography, constantly updated device and
data processing platform, we have created
a unique scoring model that allows us to
quantify the use of the car and the driving
style.
Driving Score
8.7 / 10
Speedings
Hard turns
Hard accels
Hard brakes
7
3
4
6
A B

19. Case studies of SDL platform
implementation results

20. Mitsubishi
Brazil Test Drive
Analytics
Objective: Analyze the
effectiveness of test drive
vehicles usage, develop
metrics and KPI, correlate
test drives with car sales
Solution: Over 150 new
Mitsubishi Pajero cars were
connected to the SDL
platform, reports were set
up in BI with an assessment
of idle time, inappropriate
use of vehicles, real test
drives, etc.

21. LADA Connect
Manufacturing
Connected Car
Objective: Develop
a solution for integrating
Connected Car system into
the manufacturing process

22. Nikita Kasyanenko
International Business Development +7 916 130 3714
Thank you!
