Ceragon is a global wireless backhaul specialist that provides disruptive, high-capacity hauling solutions. It has experienced 35% revenue CAGR from 2004-2011 and has a portfolio of solutions including microwave radios, E-band radios, and small cell solutions to meet various capacity, coverage, and deployment needs for backhaul and fronthaul. Ceragon focuses on in-house radio technology development and sees the market evolving towards a holistic heterogeneous network hauling approach.
