The document discusses BGP zombie routes, which occur when an active routing table entry remains for a prefix that has been withdrawn by its origin network. This can cause issues like partial outages or routing loops. The document provides examples of real-world incidents involving zombie routes, including outages at Telia, Interoute, and CenturyLink/Level3. It also covers ways to detect and debug zombie routes, such as looking for routing loops or inconsistencies using traceroute. Mitigation strategies are also discussed.
