Network Stack in
Userspace (NUSE)
!
Hajime Tazaki
Ryo Nakamura
(University of Tokyo)
!
New Directions in Operating Systems
London, 2014
Motivation
Implementation of the Internet
is not finished yet
!
!
Faster evolution of OSes (network
stack)
OS personalization
2
I have a new Layer-3/4
protocol! Yay!
I have new, great Layer-3/4 protocol ! It
will change the WORLD !
Replace network stack ?
No: destroy my life ?!
(experimental ? not tested ?)
Yes: I wanna be your slave.
Slow evolution of network stack ?
VM on personal device ?
3
Virtual Machine ?
Poll: “When you download and run software, how often do you use a virtual machine (to reduce
security risks)?”
Jon Howell, Galen Hunt, David Molnar, and Donald E. Porter, Living Dangerously: A Survey of Software Download
Practices, no. MSR-TR-2010-51, May 2010
4
costin.raiciu@cs.pub.ro, j.araujo@ucl.ac.uk, rizzo@iet.unipi.it
Internet paths
that it is still
despite the
the blame
extensions taking
placed on end
moving protocols
deployment
optimizations.
support for user-level
commodity
number of
host stack,
s.
our mux/de-mux
line rate (up
Slow evolution of network stack
Honda et al., Rekindling Network Protocol Innovation with User-Level Stacks, ACM
SIGCOMM CCR, Vol.44, Num. 2, April 2014
cores, and
over a basic
same server
1.00
0.75
0.50
0.25
0.00
2007 2008 2009 2010 2011 2012
Date
Ratio of flows
Option
SACK
Timestamp
Windowscale
Direction
Inbound
Outbound
Figure 1: TCP options deployment over time.
pen infrequently not only because of slow release cycles, but
also due to their cost and potential disruption to existing
setups. If protocol stacks were embedded into applications,
they could be updated on a case-by-case basis, and deploy-ment
would be a lot more timely.
For example, Mac OS, Windows XP and FreeBSD still
use a traditional Additive Increase Multiplicative Decrease
(AIMD) algorithm for TCP congestion control, while Linux
Meanwhile in
Filesystem world..
There is,
Filesystem in Userspace
(FUSE)
Userspace code can host
new filesystem (sshfs,
GmailFS, etc)
Performance is bad,
but doesn’t matter
Flexibility and
functionality do matter
6
http://fuse.sourceforge.net/
Alternatives
Container (LXC, OpenVZ, vimage)
share kernel with host operating system (no
flexibility)
Library OS
full scratch: mtcp, Mirage, lwIP
Porting: OSv, Sandstorm, libuinet (FreeBSD),
Arrakis (lwIP), OpenOnload (lwIP?)
Glue-layer: LKL (Linux-2.6), rumpkernel (NetBSD)
7
Network Stack
in Userspace
What’s NUSE ?
Network stack in Userspace
A library operating system
Library version of network
stack (of monolithic kernel)
Linux (latest), FreeBSD (plan)
(UNIX) Process-based
virtualization
9
nuse example
kernel bypassed
TCP/IP
ARP/
ndisc
libnuse
glibc
NIC
userspace
kernel
raw sock
netmap
DPDK (etc)
Why NUSE ?
minimized porting effort
Linux (net-next) changes frequently
!
full functional network stack for
netmap
DPDK
(any kernel-bypass technology)
10
How it works
Application
POSIX glue
TCP UDP DCCP SCTP
ICMP ARP
IPv6 IPv4
Qdisc
Netfilter Bridging
Netlink
IPSec Tunneling
Kernel layer
NUSE core
bottom halves/
rcu/timer/
interrupt
struct
net_device
RAW DPDK netmap ...
NIC
petit-scheduler
1. (monolithic) kernel
source
2. scheduler
3. POSIX glue
redirect system calls
4. network I/O
raw socket, DPDK,
netmap, etc..
11
1) kernel build
Application
POSIX glue
TCP UDP DCCP SCTP
ICMP ARP
IPv6 IPv4
Qdisc
Netfilter Bridging
Netlink
IPSec Tunneling
Kernel layer
NUSE core
bottom halves/
rcu/timer/
interrupt
struct
net_device
RAW DPDK netmap ...
NIC
petit-scheduler
patch to kernel tree
with new (hw independent)
arch (arch/sim)
robust to (frequent)
mainstream changes
12
2) scheduler
Application
POSIX glue
TCP UDP DCCP SCTP
ICMP ARP
IPv6 IPv4
Qdisc
Netfilter Bridging
Netlink
IPSec Tunneling
Kernel layer
NUSE core
bottom halves/
rcu/timer/
interrupt
struct
net_device
RAW DPDK netmap ...
NIC
petit-scheduler
offer alternate
context primitives
interrupts, timer,
thread, bottom halves
(tasklet, workqueue,
waiter, etc)
wrap with POSIX thread
easily debuggable
ucontext fiber for low
overhead (not yet)
13
3) POSIX glue code
Application
POSIX glue
TCP UDP DCCP SCTP
ICMP ARP
IPv6 IPv4
Qdisc
Netfilter Bridging
Netlink
IPSec Tunneling
Kernel layer
NUSE core
bottom halves/
rcu/timer/
interrupt
struct
net_device
RAW DPDK netmap ...
NIC
petit-scheduler
Hijack function calls
socket => nuse_socket
read => nuse_read
apps not aware of
LD_PRELOAD=libnuse.so ..
14
4) network I/O
Application
POSIX glue
TCP UDP DCCP SCTP
ICMP ARP
IPv6 IPv4
Qdisc
Netfilter Bridging
Netlink
IPSec Tunneling
Kernel layer
NUSE core
bottom halves/
rcu/timer/
interrupt
struct
net_device
RAW DPDK netmap ...
NIC
petit-scheduler
connect NUSE to NIC
options
raw socket (default)
DPDK (if available)
netmap (if available)
Tap
15
Usage
download
git clone git://github.com/libos-nuse/net-next-
nuse
compile
make library ARCH=sim (NETMAP=yes) (DPDK=yes)
execute
sudo NUSECONF=nuse.conf ./nuse (application)
16
configs
17
# Interface definition.!
interface eth0!
address 192.168.0.10!
netmask 255.255.255.0!
macaddr 00:01:01:01:01:01!
viftype TAP!
!
interface p1p1!
address 172.16.0.1!
netmask 255.255.255.0!
macaddr 00:01:01:01:01:02!
!
# route entry definition.!
route!
network 0.0.0.0!
netmask 0.0.0.0!
gateway 192.168.0.1
(possible) use cases
New protocol deployment
Chrome + Linux mptcp (on NUSE)
Process-level virtual instance
% NUSE-linux-ovs | NUSE-freebsd-NAT |
NUSE-router | NUSE-nginx!
VM chaining via UNIX command line
18
Limitation (ongoings)
no fork(2)/exec(2) support
no multi-processes
no sysctl/proc
(inefficient) thread scheduling
19
Experiments
1. Can we benefit with OS personalization?
present a custom (NUSE) kernel with an
application (OS personalization)
2. How much overhead does NUSE add?
Simple performance measurements
20
Tested applications
working
ping, iperf, nginx (partially), sleep,
need patches
nc, wget, dig, host
21
Setup: Performance
measurement
NUSE node Tx/Rx nodes
CPU Xeon E5-2650v2 @
ping!
flowgen
10G 10G
22
2.60GHz
(16 core)
Xeon L3426 @ 1.87GHz
(8 core)
Memory 32GB 4GB
NIC Intel X520 Intel X520
ping!
flowgen
vnstat!
(packet count)
Tx NUSE Rx
Host Tx
(NUSE->Receiver)
NUSE Rx
23
avg max min
dpdk! 2.610 8.000 0.156
netmap 0.370 0.494 0.252
raw 0.396 0.501 0.290
tap 0.397 0.538 0.303
500
450
400
350
300
250
200
150
100
50
0
dpdk netmap raw tap
Throughput (Mbps)
ping (RTT) throughput
(1024byte,UDP)
8
7
6
5
4
3
2
1
0
dpdk netmap raw tap
RTT (ms)
L3 Routing
Sender->NUSE->Receiver
Tx NUSE Rx
24
avg max min
dpdk! 11.998 27.700 0.252
netmap 0.664 0.741 0.556
raw 0.663 0.761 0.575
tap 0.694 0.749 0.602
ping (RTT)
500
450
400
350
300
250
200
150
100
50
0
netmap raw tap
Throughput (Mbps)
throughput
(1024byte,UDP)
30
25
20
15
10
5
0
dpdk netmap raw tap
RTT (ms)
Discussions
not so bad performance
we don’t care much about performance
network stack is full functional
but supplemental tools are not sufficient
25
Network Simulator
Integration (ns-3)
network stack +ns-3 network simulator
!
Direct Code Execution (DCE)
Established by Mathieu Lacage (2006)
part of ns-3 project
!
Features
reproducible (deterministic clock)
controllable (simulator’s facility)
http://www.nsnam.org/overview/projects/direct-code-execution/
26
27
NUSE vs DCE
NUSE DCE
shared
kernel library ARCH=sim ARCH=sim
scheduler (host) pthread simulator’s scheduler!
28
(deterministic)
POSIX hijack hijack
network I/O raw/netmap/DPDK/tap ns3:NetDevice
execution LD_PRELOAD
dlmopen(3)!
single proc/multi-instances
DCE Architecture
Application
(ip, iptables, quagga)
POSIX layer
TCP UDP DCCP SCTP
ICMP ARP
IPv6 IPv4
Netfilter Bridging
struct net_device
29
Qdisc
Netlink
IPSec Tunneling
bottom halves/rcu/
timer/interrupt
Kernel layer
Heap Stack
memory
Virtualization Core
layer
ns-3 (network simulation core)
DCE
ns-3
applicati
on
ns-3
TCP/IP
stack
3) POSIX!
Layer
1) Core!
Layer
2) Kernel!
Layer
Bug reproducibility
Home Agent
AP1 AP2
30
Wi-Fi Wi-Fi
handoff
ping6
correspondent
node
mobile node
(gdb) b mip6_mh_filter if dce_debug_nodeid()==0
Breakpoint 1 at 0x7ffff287c569: file net/ipv6/mip6.c, line 88.
<continue>
(gdb) bt 4
#0 mip6_mh_filter
(sk=0x7ffff7f69e10, skb=0x7ffff7cde8b0)
at net/ipv6/mip6.c:109
#1 0x00007ffff2831418 in ipv6_raw_deliver
(skb=0x7ffff7cde8b0, nexthdr=135)
at net/ipv6/raw.c:199
#2 0x00007ffff2831697 in raw6_local_deliver
(skb=0x7ffff7cde8b0, nexthdr=135)
at net/ipv6/raw.c:232
#3 0x00007ffff27e6068 in ip6_input_finish
(skb=0x7ffff7cde8b0)
at net/ipv6/ip6_input.c:197
Debugging
==5864== Memcheck, a memory error detector
==5864== Copyright (C) 2002-2009, and GNU GPL'd, by Julian Seward et al.
==5864== Using Valgrind-3.6.0.SVN and LibVEX; rerun with -h for copyright info
==5864== Command: ../build/bin/ns3test-dce-vdl --verbose
==5864==
==5864== Conditional jump or move depends on uninitialised value(s)
==5864== at 0x7D5AE32: tcp_parse_options (tcp_input.c:3782)
==5864== by 0x7D65DCB: tcp_check_req (tcp_minisocks.c:532)
==5864== by 0x7D63B09: tcp_v4_hnd_req (tcp_ipv4.c:1496)
==5864== by 0x7D63CB4: tcp_v4_do_rcv (tcp_ipv4.c:1576)
==5864== by 0x7D6439C: tcp_v4_rcv (tcp_ipv4.c:1696)
==5864== by 0x7D447CC: ip_local_deliver_finish (ip_input.c:226)
==5864== by 0x7D442E4: ip_rcv_finish (dst.h:318)
==5864== by 0x7D2313F: process_backlog (dev.c:3368)
==5864== by 0x7D23455: net_rx_action (dev.c:3526)
==5864== by 0x7CF2477: do_softirq (softirq.c:65)
==5864== by 0x7CF2544: softirq_task_function (softirq.c:21)
==5864== by 0x4FA2BE1: ns3::TaskManager::Trampoline(void*) (task-manager.==5864== Uninitialised value was created by a stack allocation
==5864== at 0x7D65B30: tcp_check_req (tcp_minisocks.c:522)
==5864==
Memory error detection
among distributed nodes
in a single process
using Valgrind
!
!
31
Fine-grained parameter coverage
Code coverage measurement with DCE
With fine-grained network, node, protocol parameters
32
Continuous integration
http://ns-3-dce.cloud.wide.ad.jp/jenkins/job/daily-net-next-sim/
33
Summary
NUSE (Network Stack in Userspace)
OS personalization (fast evolution, easy
deployment)
DCE (Direct Code Execution)
Flexible network experiment/test with
deterministic clock
34
github: https://github.com/libos-nuse/net-next-
nuse
DCE: http://bit.ly/ns-3-dce
twitter: @thehajime
35
Backups
Potentials of Userspace
Networking
High-performance networking
Useful debugging facilities
Operating system personalization
37
1) kernel build
build kernel source tree w/ the patch
make menuconfig ARCH=sim
make library ARCH=sim
➔ libnuse-linux-3.17-rc1.so
38
Example: How timer
works
39
add_timer()
TIMER_SOFTIRQ
timer_list
run_timer_softirq ()
timer handler
timer thread
(timer_create (2))
3) POSIX glue code
extern int sim_sock_socket (int,int,int, struct socket **);
int socket (int family, int type, int proto)
{
sim_update_jiffies ();
struct socket *kernel_socket =
sim_malloc (sizeof (struct socket));
memset (kernel_socket, 0, sizeof (struct socket));
int ret = sim_sock_socket (family, type, proto, &kernel_socket);
g_fd_table[curfd++] = kernel_socket;
sim_softirq_wakeup ();
return curfd - 1;
}
https://github.com/libos-nuse/net-next-nuse/blob/nuse/arch/sim/nuse-glue.c
40
Tx callgraph
sendmsg () (socket API)
sim_sock_sendmsg () (NUSE)
sock_sendmsg ()
ip_send_skb ()
ip_finish_output2 ()
dst_neigh_output () (ex-kernel)
neigh_resolve_output ()
arp_solicit ()
dev_queue_xmit ()
sim_dev_xmit () (NUSE)
nuse_vif_raw_write ()
41
Rx callgraph
start_thread () (pthread)
nuse_netdev_rx_trampoline ()
nuse_vif_raw_read () (NUSE)
sim_dev_rx ()
netif_rx () (ex-kernel)
start_thread () (pthread)
do_softirq () (NUSE)
net_rx_action ()
process_backlog () (ex-kernel)
__netif_receive_skb_core ()
ip_rcv ()
42
vNIC!
rx
softirq!
rx

More Related Content

What's hot

netfilter and iptables
netfilter and iptablesnetfilter and iptables
netfilter and iptables
Kernel TLV


What's hot (20)

DPDK: Multi Architecture High Performance Packet Processing
DPDK: Multi Architecture High Performance Packet ProcessingDPDK: Multi Architecture High Performance Packet Processing
DPDK: Multi Architecture High Performance Packet Processing

DevConf 2014 Kernel Networking Walkthrough
DevConf 2014   Kernel Networking WalkthroughDevConf 2014   Kernel Networking Walkthrough
DevConf 2014 Kernel Networking Walkthrough

Dpdk performance
Dpdk performanceDpdk performance
Dpdk performance

Faster packet processing in Linux: XDP
Faster packet processing in Linux: XDPFaster packet processing in Linux: XDP
Faster packet processing in Linux: XDP

netfilter and iptables
netfilter and iptablesnetfilter and iptables
netfilter and iptables

Debug dpdk process bottleneck & painpoints
Debug dpdk process bottleneck & painpointsDebug dpdk process bottleneck & painpoints
Debug dpdk process bottleneck & painpoints

DPDKによる高速コンテナネットワーキング
DPDKによる高速コンテナネットワーキングDPDKによる高速コンテナネットワーキング
DPDKによる高速コンテナネットワーキング

Linux Network Stack
Linux Network StackLinux Network Stack
Linux Network Stack

EBPF and Linux Networking
EBPF and Linux NetworkingEBPF and Linux Networking
EBPF and Linux Networking

DPDK KNI interface
DPDK KNI interfaceDPDK KNI interface
DPDK KNI interface

How Linux Processes Your Network Packet - Elazar Leibovich
How Linux Processes Your Network Packet - Elazar LeibovichHow Linux Processes Your Network Packet - Elazar Leibovich
How Linux Processes Your Network Packet - Elazar Leibovich

Performance Wins with eBPF: Getting Started (2021)
Performance Wins with eBPF: Getting Started (2021)Performance Wins with eBPF: Getting Started (2021)
Performance Wins with eBPF: Getting Started (2021)

introduction to linux kernel tcp/ip ptocotol stack
introduction to linux kernel tcp/ip ptocotol stack introduction to linux kernel tcp/ip ptocotol stack
introduction to linux kernel tcp/ip ptocotol stack

eBPF maps 101
eBPF maps 101eBPF maps 101
eBPF maps 101

10GbE時代のネットワークI/O高速化
10GbE時代のネットワークI/O高速化10GbE時代のネットワークI/O高速化
10GbE時代のネットワークI/O高速化

DPDK In Depth
DPDK In DepthDPDK In Depth
DPDK In Depth

SR-IOV, KVM and Emulex OneConnect 10Gbps cards on Debian/Stable
SR-IOV, KVM and Emulex OneConnect 10Gbps cards on Debian/StableSR-IOV, KVM and Emulex OneConnect 10Gbps cards on Debian/Stable
SR-IOV, KVM and Emulex OneConnect 10Gbps cards on Debian/Stable

Cilium - API-aware Networking and Security for Containers based on BPF
Cilium - API-aware Networking and Security for Containers based on BPFCilium - API-aware Networking and Security for Containers based on BPF
Cilium - API-aware Networking and Security for Containers based on BPF

Intel DPDK Step by Step instructions
Intel DPDK Step by Step instructionsIntel DPDK Step by Step instructions
Intel DPDK Step by Step instructions

The TCP/IP Stack in the Linux Kernel
The TCP/IP Stack in the Linux KernelThe TCP/IP Stack in the Linux Kernel
The TCP/IP Stack in the Linux Kernel


Similar to NUSE (Network Stack in Userspace) at #osio

Direct Code Execution - LinuxCon Japan 2014
Direct Code Execution - LinuxCon Japan 2014Direct Code Execution - LinuxCon Japan 2014
Direct Code Execution - LinuxCon Japan 2014
Hajime Tazaki

Mirage: ML kernels in the cloud (ML Workshop 2010)
Mirage: ML kernels in the cloud (ML Workshop 2010)Mirage: ML kernels in the cloud (ML Workshop 2010)
Mirage: ML kernels in the cloud (ML Workshop 2010)
Anil Madhavapeddy


Similar to NUSE (Network Stack in Userspace) at #osio (20)

Direct Code Execution - LinuxCon Japan 2014
Direct Code Execution - LinuxCon Japan 2014Direct Code Execution - LinuxCon Japan 2014
Direct Code Execution - LinuxCon Japan 2014

Network Stack in Userspace (NUSE)
Network Stack in Userspace (NUSE)Network Stack in Userspace (NUSE)
Network Stack in Userspace (NUSE)

mTCP使ってみた
mTCP使ってみたmTCP使ってみた
mTCP使ってみた

Dpdk applications
Dpdk applicationsDpdk applications
Dpdk applications

LibOS as a regression test framework for Linux networking #netdev1.1
LibOS as a regression test framework for Linux networking #netdev1.1LibOS as a regression test framework for Linux networking #netdev1.1
LibOS as a regression test framework for Linux networking #netdev1.1

PLNOG16: Obsługa 100M pps na platformie PC , Przemysław Frasunek, Paweł Mała...
PLNOG16: Obsługa 100M pps na platformie PC, Przemysław Frasunek, Paweł Mała...PLNOG16: Obsługa 100M pps na platformie PC, Przemysław Frasunek, Paweł Mała...
PLNOG16: Obsługa 100M pps na platformie PC , Przemysław Frasunek, Paweł Mała...

Network Programming: Data Plane Development Kit (DPDK)
Network Programming: Data Plane Development Kit (DPDK)Network Programming: Data Plane Development Kit (DPDK)
Network Programming: Data Plane Development Kit (DPDK)

FD.io - The Universal Dataplane
FD.io - The Universal DataplaneFD.io - The Universal Dataplane
FD.io - The Universal Dataplane

Fast datastacks - fast and flexible nfv solution stacks leveraging fd.io
Fast datastacks - fast and flexible nfv solution stacks leveraging fd.ioFast datastacks - fast and flexible nfv solution stacks leveraging fd.io
Fast datastacks - fast and flexible nfv solution stacks leveraging fd.io

D. Fast, Simple User-Space Network Functions with Snabb (RIPE 77)
D. Fast, Simple User-Space Network Functions with Snabb (RIPE 77)D. Fast, Simple User-Space Network Functions with Snabb (RIPE 77)
D. Fast, Simple User-Space Network Functions with Snabb (RIPE 77)

Playing BBR with a userspace network stack
Playing BBR with a userspace network stackPlaying BBR with a userspace network stack
Playing BBR with a userspace network stack

Skills Summary for GASteele
Skills Summary for GASteeleSkills Summary for GASteele
Skills Summary for GASteele

Mirage: ML kernels in the cloud (ML Workshop 2010)
Mirage: ML kernels in the cloud (ML Workshop 2010)Mirage: ML kernels in the cloud (ML Workshop 2010)
Mirage: ML kernels in the cloud (ML Workshop 2010)

Install FD.IO VPP On Intel(r) Architecture & Test with Trex*
Install FD.IO VPP On Intel(r) Architecture & Test with Trex*Install FD.IO VPP On Intel(r) Architecture & Test with Trex*
Install FD.IO VPP On Intel(r) Architecture & Test with Trex*

100 M pps on PC.
100 M pps on PC.100 M pps on PC.
100 M pps on PC.

Pushing Packets - How do the ML2 Mechanism Drivers Stack Up
Pushing Packets - How do the ML2 Mechanism Drivers Stack UpPushing Packets - How do the ML2 Mechanism Drivers Stack Up
Pushing Packets - How do the ML2 Mechanism Drivers Stack Up

LinuxCon2009: 10Gbit/s Bi-Directional Routing on standard hardware running Linux
LinuxCon2009: 10Gbit/s Bi-Directional Routing on standard hardware running LinuxLinuxCon2009: 10Gbit/s Bi-Directional Routing on standard hardware running Linux
LinuxCon2009: 10Gbit/s Bi-Directional Routing on standard hardware running Linux

Seastar at Linux Foundation Collaboration Summit
Seastar at Linux Foundation Collaboration SummitSeastar at Linux Foundation Collaboration Summit
Seastar at Linux Foundation Collaboration Summit

XPDS13: Enabling Fast, Dynamic Network Processing with ClickOS - Joao Martins...
XPDS13: Enabling Fast, Dynamic Network Processing with ClickOS - Joao Martins...XPDS13: Enabling Fast, Dynamic Network Processing with ClickOS - Joao Martins...
XPDS13: Enabling Fast, Dynamic Network Processing with ClickOS - Joao Martins...

Userspace networking
Userspace networkingUserspace networking
Userspace networking


More from Hajime Tazaki (6)

Linux rumpkernel - ABC2018 (AsiaBSDCon 2018)
Linux rumpkernel - ABC2018 (AsiaBSDCon 2018)Linux rumpkernel - ABC2018 (AsiaBSDCon 2018)
Linux rumpkernel - ABC2018 (AsiaBSDCon 2018)

Network stack personality in Android phone - netdev 2.2
Network stack personality in Android phone - netdev 2.2Network stack personality in Android phone - netdev 2.2
Network stack personality in Android phone - netdev 2.2

Linux Kernel Library - Reusing Monolithic Kernel
Linux Kernel Library - Reusing Monolithic KernelLinux Kernel Library - Reusing Monolithic Kernel
Linux Kernel Library - Reusing Monolithic Kernel

IIJlab seminar - Linux Kernel Library: Reusable monolithic kernel (in Japanese)
IIJlab seminar - Linux Kernel Library: Reusable monolithic kernel (in Japanese)IIJlab seminar - Linux Kernel Library: Reusable monolithic kernel (in Japanese)
IIJlab seminar - Linux Kernel Library: Reusable monolithic kernel (in Japanese)

Direct Code Execution @ CoNEXT 2013
Direct Code Execution @ CoNEXT 2013Direct Code Execution @ CoNEXT 2013
Direct Code Execution @ CoNEXT 2013

Kernelvm 201312-dlmopen
Kernelvm 201312-dlmopenKernelvm 201312-dlmopen
Kernelvm 201312-dlmopen


Recently uploaded

Cloud Frontiers: A Deep Dive into Serverless Spatial Data and FME
Cloud Frontiers:  A Deep Dive into Serverless Spatial Data and FMECloud Frontiers:  A Deep Dive into Serverless Spatial Data and FME
Cloud Frontiers: A Deep Dive into Serverless Spatial Data and FME
Safe Software


Recently uploaded (20)

AI+A11Y 11MAY2024 HYDERBAD GAAD 2024 - HelloA11Y (11 May 2024)
AI+A11Y 11MAY2024 HYDERBAD GAAD 2024 - HelloA11Y (11 May 2024)AI+A11Y 11MAY2024 HYDERBAD GAAD 2024 - HelloA11Y (11 May 2024)
AI+A11Y 11MAY2024 HYDERBAD GAAD 2024 - HelloA11Y (11 May 2024)

How to Check CNIC Information Online with Pakdata cf
How to Check CNIC Information Online with Pakdata cfHow to Check CNIC Information Online with Pakdata cf
How to Check CNIC Information Online with Pakdata cf

ChatGPT and Beyond - Elevating DevOps Productivity
ChatGPT and Beyond - Elevating DevOps ProductivityChatGPT and Beyond - Elevating DevOps Productivity
ChatGPT and Beyond - Elevating DevOps Productivity

The Zero-ETL Approach: Enhancing Data Agility and Insight
The Zero-ETL Approach: Enhancing Data Agility and InsightThe Zero-ETL Approach: Enhancing Data Agility and Insight
The Zero-ETL Approach: Enhancing Data Agility and Insight

Repurposing LNG terminals for Hydrogen Ammonia: Feasibility and Cost Saving
Repurposing LNG terminals for Hydrogen Ammonia: Feasibility and Cost SavingRepurposing LNG terminals for Hydrogen Ammonia: Feasibility and Cost Saving
Repurposing LNG terminals for Hydrogen Ammonia: Feasibility and Cost Saving

ADP Passwordless Journey Case Study.pptx
ADP Passwordless Journey Case Study.pptxADP Passwordless Journey Case Study.pptx
ADP Passwordless Journey Case Study.pptx

Design and Development of a Provenance Capture Platform for Data Science
Design and Development of a Provenance Capture Platform for Data ScienceDesign and Development of a Provenance Capture Platform for Data Science
Design and Development of a Provenance Capture Platform for Data Science

Choreo: Empowering the Future of Enterprise Software Engineering
Choreo: Empowering the Future of Enterprise Software EngineeringChoreo: Empowering the Future of Enterprise Software Engineering
Choreo: Empowering the Future of Enterprise Software Engineering

Event-Driven Architecture Masterclass: Challenges in Stream Processing
Event-Driven Architecture Masterclass: Challenges in Stream ProcessingEvent-Driven Architecture Masterclass: Challenges in Stream Processing
Event-Driven Architecture Masterclass: Challenges in Stream Processing

Continuing Bonds Through AI: A Hermeneutic Reflection on Thanabots
Continuing Bonds Through AI: A Hermeneutic Reflection on ThanabotsContinuing Bonds Through AI: A Hermeneutic Reflection on Thanabots
Continuing Bonds Through AI: A Hermeneutic Reflection on Thanabots

Overview of Hyperledger Foundation
Overview of Hyperledger FoundationOverview of Hyperledger Foundation
Overview of Hyperledger Foundation

ERP Contender Series: Acumatica vs. Sage Intacct
ERP Contender Series: Acumatica vs. Sage IntacctERP Contender Series: Acumatica vs. Sage Intacct
ERP Contender Series: Acumatica vs. Sage Intacct

Less Is More: Utilizing Ballerina to Architect a Cloud Data Platform
Less Is More: Utilizing Ballerina to Architect a Cloud Data PlatformLess Is More: Utilizing Ballerina to Architect a Cloud Data Platform
Less Is More: Utilizing Ballerina to Architect a Cloud Data Platform

JohnPollard-hybrid-app-RailsConf2024.pptx
JohnPollard-hybrid-app-RailsConf2024.pptxJohnPollard-hybrid-app-RailsConf2024.pptx
JohnPollard-hybrid-app-RailsConf2024.pptx

AI in Action: Real World Use Cases by Anitaraj
AI in Action: Real World Use Cases by AnitarajAI in Action: Real World Use Cases by Anitaraj
AI in Action: Real World Use Cases by Anitaraj

WSO2 Micro Integrator for Enterprise Integration in a Decentralized, Microser...
WSO2 Micro Integrator for Enterprise Integration in a Decentralized, Microser...WSO2 Micro Integrator for Enterprise Integration in a Decentralized, Microser...
WSO2 Micro Integrator for Enterprise Integration in a Decentralized, Microser...

Cloud Frontiers: A Deep Dive into Serverless Spatial Data and FME
Cloud Frontiers:  A Deep Dive into Serverless Spatial Data and FMECloud Frontiers:  A Deep Dive into Serverless Spatial Data and FME
Cloud Frontiers: A Deep Dive into Serverless Spatial Data and FME

Intro to Passkeys and the State of Passwordless.pptx
Intro to Passkeys and the State of Passwordless.pptxIntro to Passkeys and the State of Passwordless.pptx
Intro to Passkeys and the State of Passwordless.pptx

Platformless Horizons for Digital Adaptability
Platformless Horizons for Digital AdaptabilityPlatformless Horizons for Digital Adaptability
Platformless Horizons for Digital Adaptability

Modernizing Legacy Systems Using Ballerina
Modernizing Legacy Systems Using BallerinaModernizing Legacy Systems Using Ballerina
Modernizing Legacy Systems Using Ballerina


NUSE (Network Stack in Userspace) at #osio

  • 1. Network Stack in Userspace (NUSE) ! Hajime Tazaki Ryo Nakamura (University of Tokyo) ! New Directions in Operating Systems London, 2014
  • 2. Motivation Implementation of the Internet is not finished yet ! ! Faster evolution of OSes (network stack) OS personalization 2
  • 3. I have a new Layer-3/4 protocol! Yay! I have new, great Layer-3/4 protocol ! It will change the WORLD ! Replace network stack ? No: destroy my life ?! (experimental ? not tested ?) Yes: I wanna be your slave. Slow evolution of network stack ? VM on personal device ? 3
  • 4. Virtual Machine ? Poll: “When you download and run software, how often do you use a virtual machine (to reduce security risks)?” Jon Howell, Galen Hunt, David Molnar, and Donald E. Porter, Living Dangerously: A Survey of Software Download Practices, no. MSR-TR-2010-51, May 2010 4
  • 5. costin.raiciu@cs.pub.ro, j.araujo@ucl.ac.uk, rizzo@iet.unipi.it Internet paths that it is still despite the the blame extensions taking placed on end moving protocols deployment optimizations. support for user-level commodity number of host stack, s. our mux/de-mux line rate (up Slow evolution of network stack Honda et al., Rekindling Network Protocol Innovation with User-Level Stacks, ACM SIGCOMM CCR, Vol.44, Num. 2, April 2014 cores, and over a basic same server 1.00 0.75 0.50 0.25 0.00 2007 2008 2009 2010 2011 2012 Date Ratio of flows Option SACK Timestamp Windowscale Direction Inbound Outbound Figure 1: TCP options deployment over time. pen infrequently not only because of slow release cycles, but also due to their cost and potential disruption to existing setups. If protocol stacks were embedded into applications, they could be updated on a case-by-case basis, and deploy-ment would be a lot more timely. For example, Mac OS, Windows XP and FreeBSD still use a traditional Additive Increase Multiplicative Decrease (AIMD) algorithm for TCP congestion control, while Linux
  • 6. Meanwhile in Filesystem world.. There is, Filesystem in Userspace (FUSE) Userspace code can host new filesystem (sshfs, GmailFS, etc) Performance is bad, but doesn’t matter Flexibility and functionality do matter 6 http://fuse.sourceforge.net/
  • 7. Alternatives Container (LXC, OpenVZ, vimage) share kernel with host operating system (no flexibility) Library OS full scratch: mtcp, Mirage, lwIP Porting: OSv, Sandstorm, libuinet (FreeBSD), Arrakis (lwIP), OpenOnload (lwIP?) Glue-layer: LKL (Linux-2.6), rumpkernel (NetBSD) 7
  • 8. Network Stack in Userspace
  • 9. What’s NUSE ? Network stack in Userspace A library operating system Library version of network stack (of monolithic kernel) Linux (latest), FreeBSD (plan) (UNIX) Process-based virtualization 9 nuse example kernel bypassed TCP/IP ARP/ ndisc libnuse glibc NIC userspace kernel raw sock netmap DPDK (etc)
  • 10. Why NUSE ? minimized porting effort Linux (net-next) changes frequently ! full functional network stack for netmap DPDK (any kernel-bypass technology) 10
  • 11. How it works Application POSIX glue TCP UDP DCCP SCTP ICMP ARP IPv6 IPv4 Qdisc Netfilter Bridging Netlink IPSec Tunneling Kernel layer NUSE core bottom halves/ rcu/timer/ interrupt struct net_device RAW DPDK netmap ... NIC petit-scheduler 1. (monolithic) kernel source 2. scheduler 3. POSIX glue redirect system calls 4. network I/O raw socket, DPDK, netmap, etc.. 11
  • 12. 1) kernel build Application POSIX glue TCP UDP DCCP SCTP ICMP ARP IPv6 IPv4 Qdisc Netfilter Bridging Netlink IPSec Tunneling Kernel layer NUSE core bottom halves/ rcu/timer/ interrupt struct net_device RAW DPDK netmap ... NIC petit-scheduler patch to kernel tree with new (hw independent) arch (arch/sim) robust to (frequent) mainstream changes 12
  • 13. 2) scheduler Application POSIX glue TCP UDP DCCP SCTP ICMP ARP IPv6 IPv4 Qdisc Netfilter Bridging Netlink IPSec Tunneling Kernel layer NUSE core bottom halves/ rcu/timer/ interrupt struct net_device RAW DPDK netmap ... NIC petit-scheduler offer alternate context primitives interrupts, timer, thread, bottom halves (tasklet, workqueue, waiter, etc) wrap with POSIX thread easily debuggable ucontext fiber for low overhead (not yet) 13
  • 14. 3) POSIX glue code Application POSIX glue TCP UDP DCCP SCTP ICMP ARP IPv6 IPv4 Qdisc Netfilter Bridging Netlink IPSec Tunneling Kernel layer NUSE core bottom halves/ rcu/timer/ interrupt struct net_device RAW DPDK netmap ... NIC petit-scheduler Hijack function calls socket => nuse_socket read => nuse_read apps not aware of LD_PRELOAD=libnuse.so .. 14
  • 15. 4) network I/O Application POSIX glue TCP UDP DCCP SCTP ICMP ARP IPv6 IPv4 Qdisc Netfilter Bridging Netlink IPSec Tunneling Kernel layer NUSE core bottom halves/ rcu/timer/ interrupt struct net_device RAW DPDK netmap ... NIC petit-scheduler connect NUSE to NIC options raw socket (default) DPDK (if available) netmap (if available) Tap 15
  • 16. Usage download git clone git://github.com/libos-nuse/net-next- nuse compile make library ARCH=sim (NETMAP=yes) (DPDK=yes) execute sudo NUSECONF=nuse.conf ./nuse (application) 16
  • 17. configs 17 # Interface definition.! interface eth0! address 192.168.0.10! netmask 255.255.255.0! macaddr 00:01:01:01:01:01! viftype TAP! ! interface p1p1! address 172.16.0.1! netmask 255.255.255.0! macaddr 00:01:01:01:01:02! ! # route entry definition.! route! network 0.0.0.0! netmask 0.0.0.0! gateway 192.168.0.1
  • 18. (possible) use cases New protocol deployment Chrome + Linux mptcp (on NUSE) Process-level virtual instance % NUSE-linux-ovs | NUSE-freebsd-NAT | NUSE-router | NUSE-nginx! VM chaining via UNIX command line 18
  • 19. Limitation (ongoings) no fork(2)/exec(2) support no multi-processes no sysctl/proc (inefficient) thread scheduling 19
  • 20. Experiments 1. Can we benefit with OS personalization? present a custom (NUSE) kernel with an application (OS personalization) 2. How much overhead does NUSE add? Simple performance measurements 20
  • 21. Tested applications working ping, iperf, nginx (partially), sleep, need patches nc, wget, dig, host 21
  • 22. Setup: Performance measurement NUSE node Tx/Rx nodes CPU Xeon E5-2650v2 @ ping! flowgen 10G 10G 22 2.60GHz (16 core) Xeon L3426 @ 1.87GHz (8 core) Memory 32GB 4GB NIC Intel X520 Intel X520 ping! flowgen vnstat! (packet count) Tx NUSE Rx
  • 23. Host Tx (NUSE->Receiver) NUSE Rx 23 avg max min dpdk! 2.610 8.000 0.156 netmap 0.370 0.494 0.252 raw 0.396 0.501 0.290 tap 0.397 0.538 0.303 500 450 400 350 300 250 200 150 100 50 0 dpdk netmap raw tap Throughput (Mbps) ping (RTT) throughput (1024byte,UDP) 8 7 6 5 4 3 2 1 0 dpdk netmap raw tap RTT (ms)
  • 24. L3 Routing Sender->NUSE->Receiver Tx NUSE Rx 24 avg max min dpdk! 11.998 27.700 0.252 netmap 0.664 0.741 0.556 raw 0.663 0.761 0.575 tap 0.694 0.749 0.602 ping (RTT) 500 450 400 350 300 250 200 150 100 50 0 netmap raw tap Throughput (Mbps) throughput (1024byte,UDP) 30 25 20 15 10 5 0 dpdk netmap raw tap RTT (ms)
  • 25. Discussions not so bad performance we don’t care much about performance network stack is full functional but supplemental tools are not sufficient 25
  • 26. Network Simulator Integration (ns-3) network stack +ns-3 network simulator ! Direct Code Execution (DCE) Established by Mathieu Lacage (2006) part of ns-3 project ! Features reproducible (deterministic clock) controllable (simulator’s facility) http://www.nsnam.org/overview/projects/direct-code-execution/ 26
  • 27. 27
  • 28. NUSE vs DCE NUSE DCE shared kernel library ARCH=sim ARCH=sim scheduler (host) pthread simulator’s scheduler! 28 (deterministic) POSIX hijack hijack network I/O raw/netmap/DPDK/tap ns3:NetDevice execution LD_PRELOAD dlmopen(3)! single proc/multi-instances
  • 29. DCE Architecture Application (ip, iptables, quagga) POSIX layer TCP UDP DCCP SCTP ICMP ARP IPv6 IPv4 Netfilter Bridging struct net_device 29 Qdisc Netlink IPSec Tunneling bottom halves/rcu/ timer/interrupt Kernel layer Heap Stack memory Virtualization Core layer ns-3 (network simulation core) DCE ns-3 applicati on ns-3 TCP/IP stack 3) POSIX! Layer 1) Core! Layer 2) Kernel! Layer
  • 30. Bug reproducibility Home Agent AP1 AP2 30 Wi-Fi Wi-Fi handoff ping6 correspondent node mobile node (gdb) b mip6_mh_filter if dce_debug_nodeid()==0 Breakpoint 1 at 0x7ffff287c569: file net/ipv6/mip6.c, line 88. <continue> (gdb) bt 4 #0 mip6_mh_filter (sk=0x7ffff7f69e10, skb=0x7ffff7cde8b0) at net/ipv6/mip6.c:109 #1 0x00007ffff2831418 in ipv6_raw_deliver (skb=0x7ffff7cde8b0, nexthdr=135) at net/ipv6/raw.c:199 #2 0x00007ffff2831697 in raw6_local_deliver (skb=0x7ffff7cde8b0, nexthdr=135) at net/ipv6/raw.c:232 #3 0x00007ffff27e6068 in ip6_input_finish (skb=0x7ffff7cde8b0) at net/ipv6/ip6_input.c:197
  • 31. Debugging ==5864== Memcheck, a memory error detector ==5864== Copyright (C) 2002-2009, and GNU GPL'd, by Julian Seward et al. ==5864== Using Valgrind-3.6.0.SVN and LibVEX; rerun with -h for copyright info ==5864== Command: ../build/bin/ns3test-dce-vdl --verbose ==5864== ==5864== Conditional jump or move depends on uninitialised value(s) ==5864== at 0x7D5AE32: tcp_parse_options (tcp_input.c:3782) ==5864== by 0x7D65DCB: tcp_check_req (tcp_minisocks.c:532) ==5864== by 0x7D63B09: tcp_v4_hnd_req (tcp_ipv4.c:1496) ==5864== by 0x7D63CB4: tcp_v4_do_rcv (tcp_ipv4.c:1576) ==5864== by 0x7D6439C: tcp_v4_rcv (tcp_ipv4.c:1696) ==5864== by 0x7D447CC: ip_local_deliver_finish (ip_input.c:226) ==5864== by 0x7D442E4: ip_rcv_finish (dst.h:318) ==5864== by 0x7D2313F: process_backlog (dev.c:3368) ==5864== by 0x7D23455: net_rx_action (dev.c:3526) ==5864== by 0x7CF2477: do_softirq (softirq.c:65) ==5864== by 0x7CF2544: softirq_task_function (softirq.c:21) ==5864== by 0x4FA2BE1: ns3::TaskManager::Trampoline(void*) (task-manager.==5864== Uninitialised value was created by a stack allocation ==5864== at 0x7D65B30: tcp_check_req (tcp_minisocks.c:522) ==5864== Memory error detection among distributed nodes in a single process using Valgrind ! ! 31
  • 32. Fine-grained parameter coverage Code coverage measurement with DCE With fine-grained network, node, protocol parameters 32
  • 34. Summary NUSE (Network Stack in Userspace) OS personalization (fast evolution, easy deployment) DCE (Direct Code Execution) Flexible network experiment/test with deterministic clock 34
  • 35. github: https://github.com/libos-nuse/net-next- nuse DCE: http://bit.ly/ns-3-dce twitter: @thehajime 35
  • 37. Potentials of Userspace Networking High-performance networking Useful debugging facilities Operating system personalization 37
  • 38. 1) kernel build build kernel source tree w/ the patch make menuconfig ARCH=sim make library ARCH=sim ➔ libnuse-linux-3.17-rc1.so 38
  • 39. Example: How timer works 39 add_timer() TIMER_SOFTIRQ timer_list run_timer_softirq () timer handler timer thread (timer_create (2))
  • 40. 3) POSIX glue code extern int sim_sock_socket (int,int,int, struct socket **); int socket (int family, int type, int proto) { sim_update_jiffies (); struct socket *kernel_socket = sim_malloc (sizeof (struct socket)); memset (kernel_socket, 0, sizeof (struct socket)); int ret = sim_sock_socket (family, type, proto, &kernel_socket); g_fd_table[curfd++] = kernel_socket; sim_softirq_wakeup (); return curfd - 1; } https://github.com/libos-nuse/net-next-nuse/blob/nuse/arch/sim/nuse-glue.c 40
  • 41. Tx callgraph sendmsg () (socket API) sim_sock_sendmsg () (NUSE) sock_sendmsg () ip_send_skb () ip_finish_output2 () dst_neigh_output () (ex-kernel) neigh_resolve_output () arp_solicit () dev_queue_xmit () sim_dev_xmit () (NUSE) nuse_vif_raw_write () 41
  • 42. Rx callgraph start_thread () (pthread) nuse_netdev_rx_trampoline () nuse_vif_raw_read () (NUSE) sim_dev_rx () netif_rx () (ex-kernel) start_thread () (pthread) do_softirq () (NUSE) net_rx_action () process_backlog () (ex-kernel) __netif_receive_skb_core () ip_rcv () 42 vNIC! rx softirq! rx
