 The network is a crucial component of
today’s computing systems.
 Resource sharing across networks has taken
the form of multitier architectures having
many different servers.
 If you think of a computing system as
collection of workstations and servers, then
surely the network is the transportation of this
configuration.
 A network is, fundamentally, a system of
senders and receivers – a common feature
of any communication system.
 The sender, or source, is a computer which
sends information to another.
 The receiver, or destination computer, is the
computer to which the information is sent.
 Any machine capable of communicating on
the network is a device or node.
There are THREE types of network available
 Local Area Networks (LAN)
 Wide Area Networks (WAN)
 Metropolitan Area Networks (MAN)
 Used in small geographical areas like Building or
Campus.
 Offer high-speed communications (10/100/1000Mbps)
 Provide access to many devices
 Use LAN-specific devices such as Hubs, Switches
and network interface cards
 Cover large areas – may span the world
 Compared to LANs – slow speed communication
 Access to WANs is limited – a LAN will access a WAN
through a single point (often a bottleneck)
 Will use devices such as routers, modems and WAN
switches
 Made up of LANs which are interconnected across a
metropolitan area
 Also may appeal to regional businesses
 Gives access speeds in hundreds of megabits per
second (or even gigabits speeds)
 Uses a single connection point to connect LANs
 As well as using routers will also use switches
 Bus Topology
 Ring Topology
 Star Topology
 Mesh Topology
 Network maintained by a single cable
 Cable segment must end with a terminator
 Uses thin coaxial cable (backbones will be thick
coaxial cable)
 Extra stations can be added in a daisy chain manner
Advantages
 Inexpensive to install
 Easy to add stations
 Use less cable than
other topologies
 Works well for small
networks
Disadvantages
 No longer recommended
 Backbone breaks, whole
network down
 Limited no of devices
can be attached
 Difficult to isolate
problems
 Sharing same cable
slows response rates
 No beginning or end (a ring in fact !!)
 All devices of equality of access to media
 Single ring – data travels in one direction only, guess
what a double ring allows !?
 Each device has to wait its turn to transmit
Advantages
 Data packets travel at
great speed
 No collisions
 Easier to fault find
 No terminators required
Disadvantages
 Requires more cable
than a bus
 A break in the ring will
bring it down
 Not as common as the
bus – less devices
available
 Like the spokes of a wheel (without the symmetry)
 Centre point is a Hub
 Segments meet at the Hub
 Each device needs its own cable to the Hub
 biggest type of topology
 Easy to maintain and expand
Advantages
 Easy to add devices as the
network expands
 One cable failure does not
bring down the entire
network (resilience)
 Hub provides centralised
management
 Easy to find device and
cable problems
 Can be upgraded to faster
speeds
Disadvantages
 A star network requires
more cable than a ring or
bus network
 Failure of the central hub
can bring down the entire
network
 Costs are higher
(installation and
equipment) than for most
bus networks
 Not common on LANs
 Most often used in WANs to interconnect LANS
 Each node is connected to every other node
 Allows communication to continue in the event of a
break in any one connection
 It is “Fault Tolerant”
Advantages
 Improves Fault
Tolerance
Disadvantages
 Expensive
 Difficult to install
 Difficult to manage
 Difficult to troubleshoot
 Hubs
 Bridges
 Switches
 Routers
 A central point of a star topology
 Allows the multiple connection of devices
 Can be more than a basic Hub – providing additional
services (Managed Hubs, Switched Hubs, Intelligent
Hubs)
 In reality a Hub is a Repeater with multiple ports
 Functions in a similar manner to a Repeater
 Works at the Physical Layer of the OSI model
 Passes data no matter which device it is addressed to
 Advantages – Cheap, can connect different media
types
 Disadvantages – Extends the collision domain, can
not filter information, passes packets to all connected
segments
 Like a Hub it connects segments
 Works at Data Layer – not Physical
 Uses Mac address to make decisions
 Acts as a ’filter’, by determining whether or not to
forward a packet on to another segment
 Builds a Bridging Table, keeps track of devices on
each segment
 It forwards packets whose destination address is on
a different segment from its own
 It divides a network in to multiple collision domains –
so reducing the number of collisions
 Advantages – Limits the collision domain, can extend
network distances, uses MAC address to filter traffic,
eases congestion, can connect different types of
media, some can connect differing architectures.
 Disadvantages – Broadcast packets can not be
filtered, more expensive than a repeater, slower than
a repeater – due to additional processing of packets.
 A multiport Bridge, functioning at the Data Link Layer
 Each port of the bridge decides whether to forward
data packets to the attached network
 Keeps track of the Mac addresses of all attached
devices (just like a bridge)
 Acts like a Hub, but filters like a Bridge
 Each port on a Switch is a collision domain
 Advantages - Limits the collision domain, can
provide bridging, can be configured to limit broadcast
domain
 Disadvantages – More expensive than a hub or
bridge, configuration of additional functions can be
very complex
 Works at Network Layer in an intelligent manner
 Can connect different network segments, if they are
in the same building or even on the opposite side of
the globe
 Work in LAN, MAN and WAN environments
 Allows access to resources by selecting the best
path
 Can interconnect different networks – Ethernet with
Token Ring
 Changes packet size and format to match the
requirements of the destination network
 Advantages – Limits the Broadcast domain, can
function in LAN or WAN, connects differing media
and architectures, can determine best path/route,
can filter broadcasts
 Disadvantages – Expensive, must use routable
protocols, can be difficult to configure (static routing),
slower than a bridge
 The OSI model was developed to enable different
manufacturers networking products to work together.
 For a variety of reasons, the model was never widely
implemented.
 However it is used widely in colleges to teach
network layers and by companies to describe their
products.
 The OSI reference model defines 7 layers for network
communication - each layer defines a particular
network function.
 It breaks network communication into smaller simpler
parts.
 It standardizes network components to allow multiple-
vendor development and support.
 It allows different types of network hardware and
software to communicate with each other.
 It prevents changes in one layer from affecting the
other layers, so that they can develop more quickly.
 It breaks network communication into smaller parts to
make learning it easier to understand.
 The lowest, bottom, layer – responsible for the
physical connection between devices
 The NIC converts the data (bits) in to transmission
signals.
 Transmissions may be analogue or digital
 Responsible for the rate of transmission
 Includes all components such as the type of
connector (RJ-45, Token Ring, BNC, SC connector)
 Devices at this level include NICs, repeaters, hubs
and concentrators
 The data link is responsible for node to node validity
and integrity of the transmission
 The data link layer uses MAC, or hardware addresses
for communication.
 LAN communications, each machine on the same
connected media type needs a unique MAC address.
 A MAC address is 48 bits as 12 characters length in
hexadecimal number.
 Each host on segments needs a unique host number
from within the assigned network number. (IP
Address)
 The combination of the network and host number
assigned to a device provides a unique layer-3
address throughout the entire network.
 IP is 32 Bit Dotted decimal Number.
 The network layer supports both connection-orientated
and connectionless service from higher-layer
protocols.
 Network-layer protocols typically are routing protocols.
 It sets up and maintains a session connection between
two devices.
 It can provide for the reliable or unreliable delivery of
data across this connection. (TCP, UDP)
 Transport-layer functions typically include flow control,
virtual circuit management (Ports or Threads), and
error checking and recovery using checksum.
 Ensure Delivery of entire file or message
 The lowest layer that have any awareness of Network
 The Session layer arbitrates the dialogue between two
communicating nodes, opening and closing that
dialogue as necessary.
 It controls the direction and mode (half -duplex or full-
duplex).
 It also supplies recovery checkpoints during file
transfers.
 Responsible for
 Handshaking, Keep alive message, Session
termination
 Dialog Control (Simplex, Half duplex, Full Duplex)
 Example : NFS, SQL, RPC
 When data are transmitted between different types of
computer systems, the presentation layer negotiates
and manages the way data are represented and
encoded.
 For example, it provides a common denominator
between ASCII and EBCDIC machines formats.
 Tasks like Data Compression, Decompression,
Encryption, Decryption are associated with this layer.
 Also associated with Multimedia operations.
 Examples of presentation layer protocols and
standards include ASCII, BMP, GIF, JPEG, WAV, AVI,
and MPEG.
 ‘Closest’ layer to the user
 Works with the applications you use to communicate
over the network
 This interface can be command-line-based or
graphics-based.
 The most common are telnet, FTP, web browsers, and
e-mail.
 One of the most important protocols.
 Main purpose is to provide logical addressing through
the use of an IP address.
 Uses IP address to route information between
networks, therefore every device requires a unique
address.
 Developed to function within a UNIX environment in
the days of ARPAnet.
 require connect different network segments.
 Routing can be done over the LAN, WAN or MAN
 Routing table is use to route the packet across the
networks.
 Route added can be added 2 ways.
 Static Routes : routes are manually configured by a
network administrator.
 Dynamic Routes : adjust automatically to changes in
network topology, and information it receives from
other routers.
networking

networking

  • 2.
     The networkis a crucial component of today’s computing systems.  Resource sharing across networks has taken the form of multitier architectures having many different servers.  If you think of a computing system as collection of workstations and servers, then surely the network is the transportation of this configuration.
  • 3.
     A networkis, fundamentally, a system of senders and receivers – a common feature of any communication system.  The sender, or source, is a computer which sends information to another.  The receiver, or destination computer, is the computer to which the information is sent.  Any machine capable of communicating on the network is a device or node.
  • 5.
    There are THREEtypes of network available  Local Area Networks (LAN)  Wide Area Networks (WAN)  Metropolitan Area Networks (MAN)
  • 6.
     Used insmall geographical areas like Building or Campus.  Offer high-speed communications (10/100/1000Mbps)  Provide access to many devices  Use LAN-specific devices such as Hubs, Switches and network interface cards
  • 7.
     Cover largeareas – may span the world  Compared to LANs – slow speed communication  Access to WANs is limited – a LAN will access a WAN through a single point (often a bottleneck)  Will use devices such as routers, modems and WAN switches
  • 8.
     Made upof LANs which are interconnected across a metropolitan area  Also may appeal to regional businesses  Gives access speeds in hundreds of megabits per second (or even gigabits speeds)  Uses a single connection point to connect LANs  As well as using routers will also use switches
  • 9.
     Bus Topology Ring Topology  Star Topology  Mesh Topology
  • 10.
     Network maintainedby a single cable  Cable segment must end with a terminator  Uses thin coaxial cable (backbones will be thick coaxial cable)  Extra stations can be added in a daisy chain manner
  • 11.
    Advantages  Inexpensive toinstall  Easy to add stations  Use less cable than other topologies  Works well for small networks Disadvantages  No longer recommended  Backbone breaks, whole network down  Limited no of devices can be attached  Difficult to isolate problems  Sharing same cable slows response rates
  • 12.
     No beginningor end (a ring in fact !!)  All devices of equality of access to media  Single ring – data travels in one direction only, guess what a double ring allows !?  Each device has to wait its turn to transmit
  • 13.
    Advantages  Data packetstravel at great speed  No collisions  Easier to fault find  No terminators required Disadvantages  Requires more cable than a bus  A break in the ring will bring it down  Not as common as the bus – less devices available
  • 14.
     Like thespokes of a wheel (without the symmetry)  Centre point is a Hub  Segments meet at the Hub  Each device needs its own cable to the Hub  biggest type of topology  Easy to maintain and expand
  • 15.
    Advantages  Easy toadd devices as the network expands  One cable failure does not bring down the entire network (resilience)  Hub provides centralised management  Easy to find device and cable problems  Can be upgraded to faster speeds Disadvantages  A star network requires more cable than a ring or bus network  Failure of the central hub can bring down the entire network  Costs are higher (installation and equipment) than for most bus networks
  • 16.
     Not commonon LANs  Most often used in WANs to interconnect LANS  Each node is connected to every other node  Allows communication to continue in the event of a break in any one connection  It is “Fault Tolerant”
  • 17.
    Advantages  Improves Fault Tolerance Disadvantages Expensive  Difficult to install  Difficult to manage  Difficult to troubleshoot
  • 18.
     Hubs  Bridges Switches  Routers
  • 19.
     A centralpoint of a star topology  Allows the multiple connection of devices  Can be more than a basic Hub – providing additional services (Managed Hubs, Switched Hubs, Intelligent Hubs)  In reality a Hub is a Repeater with multiple ports  Functions in a similar manner to a Repeater  Works at the Physical Layer of the OSI model  Passes data no matter which device it is addressed to
  • 20.
     Advantages –Cheap, can connect different media types  Disadvantages – Extends the collision domain, can not filter information, passes packets to all connected segments
  • 21.
     Like aHub it connects segments  Works at Data Layer – not Physical  Uses Mac address to make decisions  Acts as a ’filter’, by determining whether or not to forward a packet on to another segment  Builds a Bridging Table, keeps track of devices on each segment  It forwards packets whose destination address is on a different segment from its own  It divides a network in to multiple collision domains – so reducing the number of collisions
  • 22.
     Advantages –Limits the collision domain, can extend network distances, uses MAC address to filter traffic, eases congestion, can connect different types of media, some can connect differing architectures.  Disadvantages – Broadcast packets can not be filtered, more expensive than a repeater, slower than a repeater – due to additional processing of packets.
  • 23.
     A multiportBridge, functioning at the Data Link Layer  Each port of the bridge decides whether to forward data packets to the attached network  Keeps track of the Mac addresses of all attached devices (just like a bridge)  Acts like a Hub, but filters like a Bridge  Each port on a Switch is a collision domain
  • 24.
     Advantages -Limits the collision domain, can provide bridging, can be configured to limit broadcast domain  Disadvantages – More expensive than a hub or bridge, configuration of additional functions can be very complex
  • 25.
     Works atNetwork Layer in an intelligent manner  Can connect different network segments, if they are in the same building or even on the opposite side of the globe  Work in LAN, MAN and WAN environments  Allows access to resources by selecting the best path  Can interconnect different networks – Ethernet with Token Ring  Changes packet size and format to match the requirements of the destination network
  • 26.
     Advantages –Limits the Broadcast domain, can function in LAN or WAN, connects differing media and architectures, can determine best path/route, can filter broadcasts  Disadvantages – Expensive, must use routable protocols, can be difficult to configure (static routing), slower than a bridge
  • 28.
     The OSImodel was developed to enable different manufacturers networking products to work together.  For a variety of reasons, the model was never widely implemented.  However it is used widely in colleges to teach network layers and by companies to describe their products.  The OSI reference model defines 7 layers for network communication - each layer defines a particular network function.
  • 29.
     It breaksnetwork communication into smaller simpler parts.  It standardizes network components to allow multiple- vendor development and support.  It allows different types of network hardware and software to communicate with each other.  It prevents changes in one layer from affecting the other layers, so that they can develop more quickly.  It breaks network communication into smaller parts to make learning it easier to understand.
  • 31.
     The lowest,bottom, layer – responsible for the physical connection between devices  The NIC converts the data (bits) in to transmission signals.  Transmissions may be analogue or digital  Responsible for the rate of transmission  Includes all components such as the type of connector (RJ-45, Token Ring, BNC, SC connector)  Devices at this level include NICs, repeaters, hubs and concentrators
  • 32.
     The datalink is responsible for node to node validity and integrity of the transmission  The data link layer uses MAC, or hardware addresses for communication.  LAN communications, each machine on the same connected media type needs a unique MAC address.  A MAC address is 48 bits as 12 characters length in hexadecimal number.
  • 33.
     Each hoston segments needs a unique host number from within the assigned network number. (IP Address)  The combination of the network and host number assigned to a device provides a unique layer-3 address throughout the entire network.  IP is 32 Bit Dotted decimal Number.  The network layer supports both connection-orientated and connectionless service from higher-layer protocols.  Network-layer protocols typically are routing protocols.
  • 34.
     It setsup and maintains a session connection between two devices.  It can provide for the reliable or unreliable delivery of data across this connection. (TCP, UDP)  Transport-layer functions typically include flow control, virtual circuit management (Ports or Threads), and error checking and recovery using checksum.  Ensure Delivery of entire file or message  The lowest layer that have any awareness of Network
  • 35.
     The Sessionlayer arbitrates the dialogue between two communicating nodes, opening and closing that dialogue as necessary.  It controls the direction and mode (half -duplex or full- duplex).  It also supplies recovery checkpoints during file transfers.  Responsible for  Handshaking, Keep alive message, Session termination  Dialog Control (Simplex, Half duplex, Full Duplex)  Example : NFS, SQL, RPC
  • 36.
     When dataare transmitted between different types of computer systems, the presentation layer negotiates and manages the way data are represented and encoded.  For example, it provides a common denominator between ASCII and EBCDIC machines formats.  Tasks like Data Compression, Decompression, Encryption, Decryption are associated with this layer.  Also associated with Multimedia operations.  Examples of presentation layer protocols and standards include ASCII, BMP, GIF, JPEG, WAV, AVI, and MPEG.
  • 37.
     ‘Closest’ layerto the user  Works with the applications you use to communicate over the network  This interface can be command-line-based or graphics-based.  The most common are telnet, FTP, web browsers, and e-mail.
  • 38.
     One ofthe most important protocols.  Main purpose is to provide logical addressing through the use of an IP address.  Uses IP address to route information between networks, therefore every device requires a unique address.  Developed to function within a UNIX environment in the days of ARPAnet.
  • 39.
     require connectdifferent network segments.  Routing can be done over the LAN, WAN or MAN  Routing table is use to route the packet across the networks.  Route added can be added 2 ways.  Static Routes : routes are manually configured by a network administrator.  Dynamic Routes : adjust automatically to changes in network topology, and information it receives from other routers.

Editor's Notes

  • #31 All People Seems To Need Data Processing
