1. AUTOMATIC FIRE
EXTINGUISHING SYSTEM
AT RECORD ROOM,
DHA KARACHI OFFICE
12/30/13
COPYRIGHT@2007 PARAGON
1

2. Project Goals
 Secure
the record room from fire.
 Optimum performance of proposed
system.
 Minimize project completion time.
12/30/13
COPYRIGHT@2007 PARAGON
2

3. Description
 Installation
of Automatic fire
Extinguishing system, cylinder based
to secure record room from fire.
 Proposed system is based on Fire
Alarm system instead of Automatic Gas
Extinguishers.
FOR MORE INFO...
See the documentation or product catalogues.
12/30/13
COPYRIGHT@2007 PARAGON
3

4. Competitive Analysis
 Pioneer
in introducing low cost
technologies in the field of Safety &
Security.
 Not completely depending on foreign
manufacturers.
 Maximum utilization of components
available in local market or
manufactured in country.
12/30/13
COPYRIGHT@2007 PARAGON
4

5. Technology
 Conventional
Fire Alarm system to be
used for Fire detection. Integration of
instrumentation with Fire Cylinders and
detection system to activate Gas
Extinguishing system.
 All installation and products are
compliance with NFPA, ISO, ASTM, ANSI
standards
12/30/13
COPYRIGHT@2007 PARAGON
5

6. Team/Resources
 Following
resources will be allocated to
this project
– People
Full Time Supervisor with the team of skilled
technicians.
Project coordinator to communicate between
customer and our management for all
technical and commercial issues.
– Technical Support & after sale services.
12/30/13
COPYRIGHT@2007 PARAGON
6

7. Procedures
 Normally
regular projects of this type are
based on automatic fire suppression
system or automatic BCF cylinders.
 Our proposed solution is a mix & match of
conventional fire alarm system and normal
BCF cylinders.
FOR MORE INFO...
See the documentation or product catalogues.
12/30/13
COPYRIGHT@2007 PARAGON
7

8. Procedures
 Fire
suppression system based on
FM 200 Gas, which is most
expensive fire extinguishing gas.
 We can achieve our goal with the low
cost BCF gas.
FOR MORE INFO...
See the documentation or product catalogues.
12/30/13
COPYRIGHT@2007 PARAGON
8

9. Procedures
 Re-filling
of BCF cylinders whenever
required will be economical and easy
to manage.
 Easy operation, low maintenance
cost, user friendly, no high tech
equipments,
FOR MORE INFO...
See the documentation or product catalogues.
12/30/13
COPYRIGHT@2007 PARAGON
9

10. Components / Products
12/30/13
COPYRIGHT@2007 PARAGON
10

11. Components / Products
12/30/13
COPYRIGHT@2007 PARAGON
11

12. Components / Products
12/30/13
COPYRIGHT@2007 PARAGON
12

13. Components / Products
12/30/13
COPYRIGHT@2007 PARAGON
13

14. Components / Products
12/30/13
COPYRIGHT@2007 PARAGON
14

15. Schedule
 Review
high-level schedule milestones here
Electrical wiring
Piping & Instrumentation
Final Installation
Day 01
Day 07
Day 20
FOR MORE INFO...
Detailed Work schedule will be submitted before
commencement of work.
12/30/13
COPYRIGHT@2007 PARAGON
15
Day 30

16. Expected Status
 High-level
overview of progress against
schedule
– On-track in wiring job.
– Behind in piping work due to less working
hours or work to be done in nights.
– Ahead in final Installation
 Expected
delays due to low geared inter
office processing as measured in pre and
post tendering activities.
12/30/13
COPYRIGHT@2007 PARAGON
16

17. Related Documents
 Design
Layout with schematic
drawings.
 Final As-Built Drawing.
 Catalogues / Leaflet of Components.
 Maintenance manuals and user
training.
12/30/13
COPYRIGHT@2007 PARAGON
17
