1. ArgenAR
Electric Power Generator
based on Archimedes paradox

2. Archimedes Paradox this is surprising consequence
Pascal's law - is the basic law of hydrostatics.
The paradox claims that the body can float in water
volume much smaller than the volume of the body itself.
Of course provided that the density of the body is less
than the density of water.
Thus the huge ship can float in pool if it is surrounded by
at least a few liters water.
This paradox comes from the fact that for the force
Archimedes important volume of the submerged part
floating body rather than the volume of water displaced.
Electric Power Generator
based on Archimedes paradox
1.Archimedes paradox

3. Therefore using small amounts of water we can
receive the mechanical energy is much greater
than with any other method use of water energy
(turbines or water wheels).
For such devices do not require large swings
streams and large water velocity.

4. Take two vessels. In both vessels pour 200 ml of water. The smaller
vessel put into the larger vessel and observe equality levels.
Add in a smaller vessel has 200ml water repeat the experiment. The
water level rose in a larger vessel but smaller vessel is still floating in
the water.
Add the water until the smaller vessel is not immersed in the bottom.
This occurs when the weight of the smaller vessel in 0.55kg.
Increased levels of water in a large vessel and the value is visible
dive a common image.
Thus the weight 400 grams freely swims in water with quantity of 200
grams. Only almost triple the weight of a small the vessel makes it
sink to the bottom.
2.Demonstration of the paradox Archimedes

5. We have found that feeding a small amount of water into
the vessel we can lift much heavier loads. Also we can
transform the movement of the float to rotate an electric
generator. What is our aim.
The main components of the generator are the two
vessel with water and floats as well as an electric
generator.
The main condition is the volume of the float and the
container should be as close as possible.
To make the process of cyclical two vessels are used
which operate alternately.
3.Convert gravity energy into electricity

6. When we pour water into the vessel 1 the float
seeks to rise upward by the force of Archimedes.
As soon as the water pumping the float through a
mechanical transmission is loaded onto the shaft
generator. Water pumped up until its level reaches
the top edge of the vessel.
The second vessel at this time is empty. Once the
water in the first vessel reached the upper edge the
duty cycle is switched to the vessel 2.
4.The working process

7. Power of the unit depends on several
factors:
● the amount of working vessels
● height of working vessels
● the number of vessels and floats
● transfer speed (or pumping) of water
The graph shows the calculated value of the Archimedes force depending on the diameter of the
vessels. The height of the containers is 1000 mm and the stroke floats about the same - 90mm.
Floats diameters smaller diameter vessels to 10 mm.
5.Power and mechanical characteristics

8. The most attractive option is a home generator power from 500 W to
5 kW. As used low-RPM axial electric DC generator you will need to
24DC-220AC inverter.
This generator can be used on all rivers and streams without the
construction of dams.
It requires a small amount of water to produce a huge power.
Therefore such a generator is well suited to the low-water rivers and
streams.
Water lifting can be applied hydraulic ram pump when the water
head low.
6.Applying

9. Archimedes' principle is widely used in aeronautics. No one was
surprised by the huge balloons lifting height. Hypothetically
practically we provide a cyclical rise balloons shutter (banal
pumping light gas from one to another of the balloon) it is possible to
obtain electrical power from a difference of densities of air and
helium, hydrogen or warm air.
Also lifting cargo from the deep sea is also a common practice.
ArgenAR is the first application of the
Archimedes' principle for power generation.
7.Conclusions.

10. At the moment all work on the development of a working
prototype has been completed. Main components of the
mechanical part are made using 3D printing.
We developed our own 3-phase axial electric generator for the
project.
All files will be freely available for individual (but not
commercial) use.
The principle of using paradox Archimedes is very promising
way to convert gravity energy for the benefit of people.
ArgenAR is our contribution to green energy
free from harmful emissions and hazardous
waste for the benefit of all of our Earth!
8.Summary
