13. Androidでの解決 Binder
• プロセス間通信をドライバで実装
• 共用メモリを利用した高速処理
• 処理要求のためのプロセス毎にスレッドプールを用意
• 参照カウントとプロセスと超えてオブジェクトの参照
• プロセス間の同期呼び出し
“In the Android platform, the binder is used for
nearly everything that happens across processes
in the core platform. " – Dianne Hackborn
https://lkml.org/lkml/2009/6/25/3
13
59. SMからBinder Driver
Client Service Manager
service list
1 登録 Server
IXXX
Name:Handle onTransact(…)
2 Name:Handle thread pool
Handle=0 Name:Handle
transact(…)
問い合わせ
3 4 5 User Space
Kernel Spac
Binder Driver: /dev/binder
59
74. 実際の例
Binder IPC is used for communicating between Graphics client and server.
Taken from http://www.cnblogs.com/xl19862005/archive/2011/11/17/2215363.html 74
75. Surface
Source: frameworks/base/core/java/android/view/Surface.java
/* Handle on to a raw buffer that is being managed by the
screen compositor */
public class Surface implements Parcelable {
public Surface() {
mCanvas = new CompatibleCanvas();
}
private class CompatibleCanvas
extends Canvas { /* ... */ }
}
Surface のinstancesはParcelとして読み書きできる
75
