This document summarizes a distributed protocol for dynamic IP address assignment in mobile ad hoc networks (MANETs). In MANETs, nodes can enter and leave the network dynamically, so a static pre-assignment of IP addresses is not feasible. Existing solutions like DHCP require centralized servers that may not exist in MANETs. The proposed solution guarantees unique IP address assignment in MANETs under various conditions like message losses and network changes, with low latency and communication overhead. It provides a distributed alternative to address the dynamic nature of nodes in MANETs.
