Barcode Grader: Why Use And How Barcode Grading Work A barcode grader enables you to rate each barcode's quality, as opposed to a scanner, which can only tell you whether it can be read by that specific scanner. See more: https://barcodelive.org/filemanager/data-images/imgs/20221118/Barcode-Grader.jpg

1. BARCODE GRADER
barcodelive.org

2. Table Of
Content
01 What Is A
Barcode Grader?
02
03
How Does Barcode Grading
Work?
04
Barcode Grading
Parameters
05 What To Do If You
Receive Failing Grades?
barcodelive.org
Why Should You Use
A Barcode Grader?

3. What Is A
Barcode Grader?
barcodelive.org

4. It is a device that
evaluates numerous
variables or criteria
A symbol's overall
grade serves as a
pointer to the
readability of a
symbol
barcodelive.org

5. Why Should You
Use A Barcode
Grader?
barcodelive.org

6. Benefits
Decrease product returns
Lessen packing waste & costs
Save time
Ensure requirements of are met
barcodelive.org

7. How Does
Barcode Grading
Work?
barcodelive.org

8. The most recent ISO/IEC
standards outline the
procedures necessary for 1D &
2D barcodes
7 different characteristics of
the barcode will be measured
by a linear barcode verifier
barcodelive.org

9. Symbol contrast How monochromatic it appears to a scanner
Minimum reflectance Whether dark bars & white areas differ sufficiently
Edge contrast minimum The smallest distinction between a space and a bar
Modulation
Varying amounts of black & white contrast are present
throughout the barcode
Defects
The presence of light or dark marks in the spaces or
white marks within the bars
Decodability
How precise various bar & spacing lengths of barcode
are
Decode
Whether the data encoding, light margins on each
side, & check digit are all accurate

10. ISO/IEC grade ANSI grade
3.5 - 4.0 A
2.5 - 3.5 B
1.5 - 2.5 C
0.5 - 1.5 D
0 - 0.5 F
barcodelive.org
A barcode's total grade, which ranges from 4.0 to 0, is determined
by the results of this testing

11. Barcode Grading
Parameters
Note: The symbology affects the
characteristics that a barcode grader
measures
barcodelive.org

12. Edge Determination
Minimum Edge Contrast
Quiet Zone
Minimum Reflectance
Modulation
Defects
Decode
Decodability
Symbol Contrast
Error Correction Not
Used
Damage to the Fixed
(Finder) Pattern
Grid Inhomogeneity
Axial Inhomogeneity
barcodelive.org

13. What To Do If
You Receive
Failing Grades?
barcodelive.org

14. You can view a complete detailed report if the
verification software indicates that the symbol failed.
The findings of each of the 10 separate scans will be
shown, and each parameter will receive a grade.
barcodelive.org
