Beyond Google Maps - FOWA 2008 London

Beyond GoogleMaps Andrew Turner, Mapufacture & FortiusOne

or... Evolved Maps, desconstructed

A Brief History of Mapping * *IANAH

StoryMapping

Emphemeral Maps http://maps.google.com

Meaning

Navigation

Compass

1492 - Columbus sails the ocean blue

Cartographic Renaissance

So geographers, in Afric maps, With savage pictures ﬁll their gaps, And o’er unhabitable downs Place elephants for want of towns. - Jonathan Swift

Ortelius Atlas

Exploration

Travel Guides

Driving Guides

Internet Maps

2005 - Google slips the map

urban renewal participatory web 2005 - Google slips the map mobile computing GPS becomes ubiquitous

HousingMaps http://housingmaps.com

Slippy Maps & Spinny Globes

GoogleMaps http://maps.google.com

Interactivity http://maps.google.com

Design

Usability

http://maps.google.com/maps?f=q&hl=en&geocode=&q=Cape+Town&ie=UTF8&ll=-33.938803,18.486214&spn=0.182293,0.331306&z=12 Data Coverage and Quality

http://maps.google.com/maps?f=q&hl=en&geocode=&q=Cape+Town&ie=UTF8&ll=-33.938803,18.486214&spn=0.182293,0.331306&z=12 Data Coverage and Quality http://openstreetmap.org/?lat=-33.9377&lon=18.4745&zoom=12&layers=B000FTF

Brighton, UK

Data Ownership and Access

Technology Limitations

Where Next? http://ﬂickr.com/photos/loupiote/25426957

Storage

id name rating lat lon 10045 Vibe Bar 4.3 52.81 0.295 10046 Half Moon 3.8 53.432 0.312 Pub 10047 Windmill 2.6 50.982 0.256 10048 Marquess 1.7 51.023 1.24 oAnglesey Grange 10049 4.5 52.110 0.4562 Pub Coopers 10050 3.5 50.862 0.821 Arms Old 10051 3.2 52.591 0.312 Queens Oxo 10052 1.3 51.93 -0.351 Head Tower 10053 Riverside 3.9 52.18 0.62

SELECT name,latitude,longitude, acos(SIN( PI()* 40.7383040 /180 )*SIN( PI()*latitude/180 ) )+(cos(PI()* 40.7383040 /180)*COS( PI()*latitude/180) *COS(PI()*longitude/180-PI()* -73.99319 /180) )* 3963.191 AS distance FROM allcountries WHERE 3963.191 * ACOS( (SIN(PI()* 40.7383040 /180)*SIN(PI() * latitude/180)) + (COS(PI()* 40.7383040 /180)*cos(PI()*latitude/180)*COS(PI() * longitude/180-PI()* -73.99319 /180)) ) < = 1.5 ORDER BY 3963.191 * ACOS( (SIN(PI()* 40.7383040 /180)*SIN(PI()*latitude/180)) + (COS(PI()* 40.7383040 /180)*cos(PI()*latitude/180)*COS(PI() * longitude/180-PI()* -73.99319 /180)) )

SELECT the_geom FROM geom_table WHERE ST_Distance(the_geom, GeomFromText('POINT(0.02839 51.50807)', -1)) < 100

SELECT the_geom FROM geom_table WHERE the_geom && 'BOX3D(0.02 51,0.03 52)'::box3d AND ST_Distance(the_geom, GeomFromText('POINT(0.02839 51.50807)', -1)) < 100

SpatiaLite SQLite + Spatial Types http://www.gaia-gis.it/spatialite/

GeoHash http://geohash.org/

GeoHash SELECT name FROM pubs WHERE geohash LIKE quot;GCPUV%quot; http://geohash.org/

GeoHash SELECT name FROM pubs WHERE geohash LIKE quot;GCPUVR%quot; OR geohash LIKE quot;GCPVJ2%quot; http://geohash.org/

GeoNames http://geonames.org

Implicit GeoData http://geocodr.net

OpenStreetMap http://openstreetmap.org

OpenStreetMap London http://openstreetmap.org

Wiki for the World

Flickr OSM http://www.ﬂickr.com/map? &fLat=39.9227&fLon=116.4694&zl=6

OpenAerialMap http://openaerialmap.org

GeoCommons Finder! http://geocommons.com

GeoCommons Finder! http://ﬁnder.geocommons.com

Sharing

GeoRSS

GeoRSS +

GeoRSS <georss:point> + 45.256 -71.92 </georss:point>

RSS / Atom <?xml version=quot;1.0quot; encoding=quot;UTF-8quot;?> <feed xml:lang=quot;en-USquot; xmlns:dc=quot;http://purl.org/dc/elements/1.1/quot; xml:base=quot;http://grwifi.net/feedquot; xmlns=quot;http://www.w3.org/2005/Atomquot;> <title>Grand Rapids WiFi: News, Updated Hotspot Locations, and Comments</title> <id>http://grwifi.net/atom/locations</id> <link href=quot;http://grwifi.net/feedquot; rel=quot;selfquot; type=quot;application/atom+xmlquot;/> <rights>Creative Commons Attribution-NonCommercial-ShareAlike 2.0 http://creativecommons.org/licenses/by-nc-sa/2.0/ </rights> <updated>2007-03-28T17:31:33+00:00</updated> <entry> <id>http://grwifi.net/location/view/skelletones#comment3862</id> <title>Grand Rapids WiFi: Comment on The Euclid</title> <link href=quot;http://grwifi.net/location/view/skelletones#comment3862quot; rel=quot;alternatequot; type=quot;text/htmlquot;/> <category term=quot;The Euclidquot;/> <author><name>mari</name></author> <content type=quot;xhtmlquot;><p>i know a local band in kalamazoo called rising vacancy. i was wondering how …/p></content> <published>2007-03-28T17:31:33+00:00</published> </entry> <entry> <id>http://grwifi.net/location/view/bk-east-paris#comment3855</id> <title>Grand Rapids WiFi: Comment on Burger King - East Paris</title> <link href=quot;http://grwifi.net/location/view/bk-east-paris#comment3855quot; rel=quot;alternatequot; type=quot;text/htmlquot;/> <category term=quot;Burger King - East Parisquot;/> <author><name>Brandino</name></author> <content type=quot;xhtmlquot;><p>I love burger king </p></content> <published>2007-03-21T16:38:19+00:00</published> </entry> <entry> <id>http://grwifi.net/location/view/common-ground#comment3843</id> <title>Grand Rapids WiFi: Comment on Common Ground Coffee Shop</title> <link href=quot;http://grwifi.net/location/view/common-ground#comment3843quot; rel=quot;alternatequot; type=quot;text/htmlquot;/> <category term=quot;Common Ground Coffee Shopquot;/> <author> <name>Rex Cowan</name> </author> <content type=quot;xhtmlquot;> <div xmlns=quot;http://www.w3.org/1999/xhtmlquot;><p>Common Ground is a welcoming place with a warm atmosphere, the clerk I talked to had …</p></ content> <published>2007-03-17T01:45:59+00:00</published> </entry> </feed>

GeoRSS <?xml version=quot;1.0quot; encoding=quot;UTF-8quot;?> <feed xml:lang=quot;en-USquot; xmlns:dc=quot;http://purl.org/dc/elements/1.1/quot; xml:base=quot;http://grwifi.net/feedquot; xmlns:georss=quot;http://www.georss.org/georssquot; xmlns=quot;http:// www.w3.org/2005/Atomquot;> <title>Grand Rapids WiFi: News, Updated Hotspot Locations, and Comments</title> <id>http://grwifi.net/atom/locations</id> <link href=quot;http://grwifi.net/feedquot; rel=quot;selfquot; type=quot;application/atom+xmlquot;/> <rights>Creative Commons Attribution-NonCommercial-ShareAlike 2.0 http://creativecommons.org/licenses/by-nc-sa/2.0/ </rights> <updated>2007-03-28T17:31:33+00:00</updated> <entry> <id>http://grwifi.net/location/view/skelletones#comment3862</id> <title>Grand Rapids WiFi: Comment on The Euclid</title> <link href=quot;http://grwifi.net/location/view/skelletones#comment3862quot; rel=quot;alternatequot; type=quot;text/htmlquot;/> <category term=quot;The Euclidquot;/> <author><name>mari</name></author> <georss:point>42.960126 -85.667997</georss:point> <content type=quot;xhtmlquot;><p>i know a local band in kalamazoo called rising vacancy. i was wondering how …/p></content> <published>2007-03-28T17:31:33+00:00</published> </entry> <entry> <id>http://grwifi.net/location/view/bk-east-paris#comment3855</id> <title>Grand Rapids WiFi: Comment on Burger King - East Paris</title> <link href=quot;http://grwifi.net/location/view/bk-east-paris#comment3855quot; rel=quot;alternatequot; type=quot;text/htmlquot;/> <category term=quot;Burger King - East Parisquot;/> <author><name>Brandino</name></author> <georss:point>42.911495 -85.568665</georss:point> <content type=quot;xhtmlquot;><p>I love burger king </p></content> <published>2007-03-21T16:38:19+00:00</published> </entry> <entry> <id>http://grwifi.net/location/view/common-ground#comment3843</id> <title>Grand Rapids WiFi: Comment on Common Ground Coffee Shop</title> <link href=quot;http://grwifi.net/location/view/common-ground#comment3843quot; rel=quot;alternatequot; type=quot;text/htmlquot;/> <category term=quot;Common Ground Coffee Shopquot;/> <author> <name>Rex Cowan</name> </author> <georss:point>42.962927 -85.637179</georss:point> <content type=quot;xhtmlquot;> <div xmlns=quot;http://www.w3.org/1999/xhtmlquot;><p>Common Ground is a welcoming place with a warm atmosphere, the clerk I talked to had …</p></content> <published>2007-03-17T01:45:59+00:00</published> </entry> </feed>

GeoNames GeoRSS http://www.geonames.org/rss-to-georss-converter.html

KML <?xml version=quot;1.0quot; encoding=quot;UTF-8quot;?> <kml xmlns=quot;http://earth.google.com/kml/2.2quot;> <Placemark> <name>Simple placemark</name> <description>Attached to the ground. Intelligently places itself at the height of the underlying terrain.</description> <Point> <coordinates>-122.0822035425683,37.42228990140251,0</coordinates> </Point> </Placemark> </kml>

KML Extended Data <ExtendedData id=quot;roomsquot;> <name>Rooms</name> <value>3</value> </ExtendedData>

KML Network Links </NetworkLink> <NetworkLink> <name><![CDATA[Pubs in London]]></name> <Link> <href>http://maker.geocommons.com/maps/839/overlays/1</href> </Link> </NetworkLink>

GeoJSON { quot;typequot;: quot;Pointquot;, quot;coordinatesquot;: [100.0, 0.0] }

GeoJSON { quot;blogquot;: { quot;postsquot;: [ { quot;typequot;: quot;atom:itemquot;, quot;atom:summaryquot;: quot;post 1quot;, quot;atom:descriptionquot;: quot;i love bloggingquot; }, { quot;typequot;: quot;atom:itemquot;, quot;atom:summaryquot;: quot;post 2 from CAquot;, quot;atom:descriptionquot;: quot;geoblogging in Californiaquot; quot;geometryquot;: { quot;typequot;, quot;Pointquot;, quot;coordinatesquot;: [-120, 40] } }, ], quot;geometryquot;: { quot;typequot;: quot;Polygonquot;, quot;coordinatesquot;: [[[-121, 39], [-119, 39], [-119, 41], [-121, 41], [-121, 39]]] } } }

GeoWeb

Resources • /places • /places/89 • /places/89.atom • /places/89.kml

Web Aligned http://highearthorbit.com/a-proposal-georss-kml

Formats HTML : RSS

Formats HTML : RSS ::

Formats HTML : RSS :: KML : GeoRSS

Formats HTML : RSS :: KML : GeoRSS Visualization : Syndication

Mapufacture http://mapufacture.com

Visualization

Mapstraction

Mapstraction API <script src=quot;http://maps.google.com/maps?file=api&v=2&key=YOUR_KEYquot; type=quot;text/javascriptquot;> </script> <script type=quot;text/javascriptquot; src=quot;mapstraction.jsquot;></script> <div id=quot;mapstractionquot; style=quot;width: 400px; height: 400px;quot;></div> <script type=quot;text/javascriptquot;> var mapstraction = new Mapstraction('mapstraction','google'); var myPoint = new LatLonPoint(37.4041, -122.0081); mapstraction.setCenterAndZoom(myPoint, 10); mapstraction.addControls({ pan: true, zoom: 'small', map_type: true }); </script>

Power of the Swap var mapstraction = new Mapstraction(‘map’, ‘google’);

Power of the Swap mapstraction.swap(‘mapstraction’, ‘yahoo’);

Power of the Swap mapstraction.swap(‘mapstraction’, ‘microsoft’);

Power of the Swap mapstraction.swap(‘mapstraction’, ‘openstreetmap’);

Overlays mapstraction.addImageOverlay (quot;overquot;,ﬁle,opacity,west,south,east,north); mapstraction.addImageOverlay(quot;overquot;,quot;images/ santodomingo.pngquot;,50,-70.01544, 18.39777, -69.80567, 18.563517);

Filters mapstraction.removeAllFilters(); mapstraction.addFilter('category', 'eq', 10 ); mapstraction.doFilter();

Filters mapstraction.removeAllFilters(); mapstraction.addFilter('category', 'eq', 10 ); mapstraction.doFilter(); mapstraction.toggleFilter('category', 'eq', 10 );

Sliders

OpenLayers http://openlayers.org

map = new OpenLayers.Map(quot;mapquot;, { maxResolution: 360/512, projection: quot;EPSG:4326quot; , numZoomLevels: 20, minZoomLevel: 0, maxZoomLevel: 19, controls: [ new OpenLayers.Control.Navigation(), new OpenLayers.Control.PanPanel(), new OpenLayers.Control.ZoomPanel() ] }); var wms = new OpenLayers.Layer.WMS( quot;worldquot;, quot;/cgi-bin/tilecache/tilecache.cgi?quot;, {layers: 'world'} ); map.addLayers([wms]); map.setCenter(new OpenLayers.LonLat(0, 32), 7);

Accessibility

ModestMaps

package { public class ModestMapsSample extends Sprite { private var map:Map; public function ModestMapsSample() { map = new TweenMap(stage.stageWidth - 2 * PADDING, stage.stageHeight - 2 * PADDING, true, new MicrosoftRoadMapProvider(), new MapExtent(37.829853, 37.700121, -122.212601, -122.514725)); map.addChild(new MapControls(map)); map.addChild(new ZoomSlider(map)); addChild(map); } } }

London2012 http://london2012.co.uk

Hurricane Tracking http://hurricanewiki.org

Analysis

WalkScore http://walkscore.com

MySociety House Price http://www.mysociety.org/2007/more-travel-maps/ vs. Travel Time

pgRouting http://pgrouting.postlbs.org/

Safe Routing http://www.ridethecity.com

Fuel Efﬁciency Routing

Bakery Routing

Cartography

NeoCartography

wrp.geothings.net

BurningManEarth http://earth.burningman.org

Maps for Farmers http://serveyourcountryfood.com

Mapnik

<?xml version=quot;1.0quot; encoding=quot;utf-8quot;?> <!DOCTYPE Map> <Map bgcolor=quot;#b5d0d0quot; srs=quot;+proj=latlong +datum=WGS84quot;> <Style name=quot;worldquot;> <Rule> <MaxScaleDenominator>250000000000</MaxScaleDenominator> <MinScaleDenominator>6000000</MinScaleDenominator> <PolygonSymbolizer> <CssParameter name=quot;fillquot;>#f2efe9</CssParameter> </PolygonSymbolizer> <LineSymbolizer> <CssParameter name=quot;strokequot;>#b5d0d0</CssParameter> <CssParameter name=quot;stroke-widthquot;>0.5</CssParameter> </LineSymbolizer> </Rule> </Style> <Layer name=quot;worldquot; status=quot;onquot; srs=quot;+proj=latlong +datum=WGS84quot;> <StyleName>world</StyleName> <Datasource> <Parameter name=quot;typequot;>shape</Parameter> <Parameter name=quot;filequot;>/Users/ajturner/Projects/mapnik/world_borders</Parameter> </Datasource> </Layer> </Map> Mapnik http://mapnik.com

OpenCycleMap http://opencyclemap.org

Shenzen Maps

example.mml example.mss <?xml version=quot;1.0quot; encoding=quot;utf-8quot;?> * { <!DOCTYPE Map> line-width: 1; <Map bgcolor=quot;#b5d0d0quot; srs=quot;...quot;> line-color: #999; <Stylesheet> polygon-fill: #fff; Map { map-bgcolor: #ccc; } } </Stylesheet> <Stylesheet src=quot;example.mssquot;/> *[zoom>=6][zoom<12] { <Layer name=quot;worldquot; status=quot;onquot; srs=quot;...quot;> line-color: #f90; <StyleName>world</StyleName> } <Datasource> #world-borders[zoom<10] NAME <Parameter name=quot;typequot;>shape</Parameter> { <Parameter name=quot;filequot;>...</Parameter> text-fill: #333; </Datasource> } </Layer> </Map> Cascadenick http://code.google.com/p/mapnik-utils/

TileCache TileCache http://tilecache.org

Image WMS Mapnik TileCache Image CRS TileCache http://tilecache.org

Image WMS TMS Mapnik TileCache 900913 Image (google) CRS TileCache http://tilecache.org

Mapstraction Tiles mapstraction.addTileLayer(quot;http://oakland-1950s.s3.amazonaws.com/{Z}-r{Y}-c{X}.jpgquot;, 80);

New Orleans http://maps.thinknola.com

EveryBlock http://everyblock.com

Mobile

Mobline Placemarking

uLocate WHERE

Android Innovations cab4me

Ambient Location OmniFocus

UrbanSpoon

API Dash http://dash.net

PocketMaps

PocketMaps height = 11 width = 8.5 margin = .25 dpi = 144 bbox = (45.482882,-73.619899,45.532687,-73.547801) zoom = 16 out = quot;montreal_pocketmmap.pdfquot; pm = pocketMMap(height, width, margin, dpi) pm.load_provider('OPEN_STREET_MAP') pm.draw(bbox, zoom) pm.save(out) ruby: http://github.com/ajturner/pocketmaps python: http://aaronland.info/python/pocketMMap

Geolocation

W3C Geolocation http://dev.w3.org/geo/api/spec-source.html

navigator.geolocation.getCurrentPosition(function(pos) { alert( pos.latitude + quot;, quot; + pos.longitude ); })

interface Geolocation { readonly attribute Position lastPosition; void getCurrentPosition(in PositionCallback successCallback); int watchPosition(in PositionCallback successCallback); void clearWatch(in int watchId); };

PlundrDS

FireEagle http://ﬁreeagle.com

geotagging pacers M T W Th

geotagging pacers M T W Th 1 23 4

BBC Bangladesh Boat Journey

Public Geodata Repository

Metadata, Statistics, Open Data

GeoData Visualization

Thematic Styling

Classiﬁcation

Styling

Base Data

Comparative Analysis http://maker.geocommons.com/maps/839

Inspect the Data

Styled KML

GeoWeb We’re Hiring Help build the GeoWeb

Asante sana! andrew@highearthorbit.com highearthorbit.com twitter.com/ajturner
