Write a Java application that involves the following functions: A non-recursive method
intPower1(int n, int pow). The first argument is a number that is to be raised to a (non-negative)
power, and the second argument is the power. Do not use any methods of class Math. A
recursive method intPower2(int n, int pow) with the same functionality as above. Put both
methods into one class. The program should ask the user to input the numbers n and pow and
output the results. Name the project Hw4_2
Solution
/*
* To change this license header, choose License Headers in Project Properties.
* To change this template file, choose Tools | Templates
* and open the template in the editor.
*/
package chegg;
import java.util.Scanner;
public class Power {
int power1(int n,int pow)
{
int res = 1;
for(int i=1;i<=pow;i++)
res = res*n;
return res;
}
int power2(int n,int pow)
{
if(pow==0)
return 1;
if(pow==1)
return n;
return n*power2(n,pow-1);
}
public static void main(String[] args)
{
Power p = new Power();
int n,pow;
Scanner input = new Scanner(System.in);
System.out.println(\"Input the value of n : \");
n = input.nextInt();
System.out.println(\"Input the value of pow : \");
pow = input.nextInt();
System.out.println(\"Result of iterative function is : \" + p.power1(n, pow));
System.out.println(\"Result of recursive function is : \" + p.power2(n, pow));
}
}.
1. write a MATLAB GUI program that implements an ultrasound image viewing and manipulation
program. Your program must have the following features: (a) Load and display an image. (b)
One or more methods of manipulating the image. You should start by making a flow chart of any
tricky algorithmic steps. The GUI program should be beautiful, and most importantly, easy and
fun to use. Included with the program will be a README file containing instructions on how to
use it. (Test the program and instructions by having someone not associated with the class try
them out.) Make sure your program is thoroughly documented with internal comments, and that
the code is easy to read. That means lots of white space, descriptive variable names, and that the
comments don’t extend beyond the right edge of a normal page if you were to print it out.
Solution
function varargout = DSPView(varargin)
% DSPVIEW Framework for ultrasound processsing.
% DSPView MATLAB framework for ultrasound B-mode, velocity,
% strain and elastographic processing.
% See also: ImagingSystem, strainEstimatorLSQ, velocityEstimator
% Edit the above text to modify the response to help DSPView
%
% Begin initialization code - DO NOT EDIT
gui_Singleton = 0;
gui_State = struct('gui_Name', mfilename, ...
'gui_Singleton', gui_Singleton, ...
'gui_OpeningFcn', @DSPView_OpeningFcn, ...
'gui_OutputFcn', @DSPView_OutputFcn, ...
'gui_LayoutFcn', [] , ...
'gui_Callback', []);
if nargin && ischar(varargin{1})
gui_State.gui_Callback = str2func(varargin{1});
end
if nargout
[varargout{1:nargout}] = gui_mainfcn(gui_State, varargin{:});
else
gui_mainfcn(gui_State, varargin{:});
end
2. end
% End initialization code - DO NOT EDIT
function DSPView_OpeningFcn(hObject, ~, handles, varargin)
% Add all folders to search path
addpath(genpath(pwd))
handles.output = hObject;
handles.imagingSystem = [];
handles.frameNo = 1;
handles.displays = [];
guidata(hObject, handles);
% Enable the slider to notify other function when moved
if verLessThan('matlab','7.12')
addlistener(handles.slider, 'Action', ...
@(src,evnt)sliderMoved(src, evnt, hObject));
else
addlistener(handles.slider, 'ContinuousValueChange', ...
@(src,evnt)sliderMoved(src, evnt, hObject));
end
end
function varargout = DSPView_OutputFcn(~, ~, handles)
varargout{1} = handles.output;
end
% ==================================================
% ------ Fig creation and deletion functions ------
% ==================================================
function newFig(hObject, handles, displayType)
% create the new display struct, which holds the figure handle
currDisplay.fig = figure('DeleteFcn', ...
@(src,evnt)figDeleteFnc(src, evnt, hObject, displayType));
currDisplay.axes = axes('Parent',currDisplay.fig);
set(currDisplay.axes,'FontSize', 14);
currDisplay.modality = displayType;
currDisplay.medFiltEn = 0;
currDisplay.medFiltDim = [3,3];
% Check to see if other displays exist, if so use their size
if ~isempty(handles.displays)
3. pos=get(handles.displays(end).fig,'position');
set(currDisplay.fig, 'position', pos+[pos(3), 0,0,0]);
end
if strcmp(displayType,'rfLine') || strcmp(displayType, 'rfLineFreq')
currDisplay = createPlotHandles(handles, currDisplay, displayType);
else
currDisplay = createPriAndSecHandle(handles, ...
currDisplay, displayType);
end
addDisplay(hObject, handles, currDisplay)
updateDisplay(handles, currDisplay);
end
function figDeleteFnc(~, ~, hObject, displayType)
handles=guidata(hObject);
removeDisplay(hObject, handles, displayType);
end
% A display represents a data set that will be visualized to the user,
% such as a b-mode image, velocity data or strain data.
function addDisplay(hObject, handles, display)
if isempty(handles.displays)
handles.displays=display;
enableColorPanel(handles);
set(handles.figSelect,'String',{display.modality});
else
handles.displays(end+1)=display;
figList=get(handles.figSelect,'String');
figList=[figList; display.modality];
set(handles.figSelect,'String', figList);
end
setActiveDisplay(handles, display);
guidata(hObject, handles)
end
function removeDisplay(hObject, handles, displayType)
idx=idxOfDisplay(handles, displayType);
if idx
handles.displays(idx)=[];
4. guidata(hObject, handles);
set(handles.(displayType), 'Value',0)
noDisplays=length(handles.displays);
if noDisplays == 0 % All figures closed, disable figSelector
set(handles.figSelect,'Enable','off');
else % Still figures enabled, switch active figure
figList = get(handles.figSelect, 'String');
figList(idx)=[];
set(handles.figSelect, 'String', figList);
n=mod(idx-2,noDisplays)+1;
setActiveDisplay(handles, handles.displays(n));
end
end
end
function setActiveDisplay(handles, display)
idx = idxOfDisplay(handles, display.modality);
if idx
set(handles.figSelect, 'Value', idx);
cLim = get(display.axes, 'CLim');
set(handles.cMin, 'string', num2str(cLim(1)));
set(handles.cMax, 'string', num2str(cLim(2)));
medFiltEn = display.medFiltEn;
medFiltDim = display.medFiltDim;
set(handles.medFiltEn, 'value', medFiltEn);
set(handles.medFiltX, 'string', num2str(medFiltDim(1)));
set(handles.medFiltY, 'string', num2str(medFiltDim(2)));
end
end
% Image figures are contained in MATLAB handles. Since each image figure
% can potentially plot two images in the same view (background and
% foreground), both a primary and a secondary handle is needed.
% This function handles the creation of these handles, is responsible
% for aligning the two images, for setting the correct image labels,
% aspect ratio and colormap.
function currDisplay = createPriAndSecHandle(handles, currDisplay, displayType)
5. % Get the primary image (foreground image) and associated axis
im = handles.imagingSystem.getFrame(handles.frameNo, displayType);
xAx = handles.imagingSystem.getLateralAxis();
yAx = handles.imagingSystem.getDepthAxis();
% Convert to uint8 image
[cMin, cMax] = autoScale(im, displayType);
im = uint8(thresholdAndScale(im, [cMin, cMax], 192))+64;
% Need to know how to align the foreground (sub) image
% with the larger background image
[xData, yData] = centerCoords(handles.imagingSystem.rfDim, size(im));
% First display the background image
backgroundImage = zeros(handles.imagingSystem.rfDim, 'uint8');
currDisplay.secHandle = image([xAx(1), xAx(end)], [yAx(1), yAx(end)], ...
backgroundImage, 'Parent', currDisplay.axes);
hold(currDisplay.axes,'on');
% Then the foreground image
currDisplay.priHandle = image([xAx(xData(1)), xAx(xData(2))], ...
[yAx(yData(1)), yAx(yData(2))], im, 'Parent', currDisplay.axes);
% Update axis' labels
set(currDisplay.axes,'CLim',[cMin, cMax]);
xlabel(currDisplay.axes, 'Lateral axis [mm]', 'FontSize', 14);
ylabel(currDisplay.axes, 'Depth axis [mm]' , 'FontSize', 14);
% Fix the aspect ratio of the figure equal to that of the recording
set(currDisplay.axes,'DataAspectRatio', ...
[1, handles.imagingSystem.aspectRatio(), 1]);
% Set the colormap;
cMap = defaultCmap(displayType);
if get(handles.mixEn,'Value') && isMixable(currDisplay.modality)
set(currDisplay.priHandle, 'alphadata', ...
str2double(get(handles.alpha,'String')));
set(currDisplay.secHandle, 'UserData' , bModeClim(handles));
cMap = [gray(64); cMap];
else
cMap = [ones(64,3); cMap];
end
6. colormap(currDisplay.axes, cMap);
end
% createPlotHandles is responsible for creating new line plots of an RF
% data line, either in time or frequency domain.
function currDisplay = createPlotHandles(handles, currDisplay, displayType)
y=handles.imagingSystem.getLine(handles.frameNo, 36, displayType);
if strcmp(displayType,'rfLine')
x=handles.imagingSystem.getDepthAxis();
else
x=handles.imagingSystem.getFreqAxis();
end
currDisplay.secHandle=[];
currDisplay.priHandle=plot(x,y);
set(currDisplay.axes,'NextPlot','replacechildren');
peak=max(abs(y));
peak=peak+0.05*peak;
if strcmp(displayType,'rfLine')
xLab='Depth (mm)';
yLab='Rf amplitude';
set(currDisplay.axes, 'YLim',[-peak peak]);
else
xLab='Frequency (mHz)';
yLab='Power spectrum estimate (dB)';
set(currDisplay.axes, 'YLim',[peak-70 peak]);
end
set(get(currDisplay.axes,'XLabel'),'String',xLab);
set(get(currDisplay.axes,'YLabel'),'String',yLab);
set(currDisplay.axes, 'XLim',[x(1) x(end)]);
grid(currDisplay.axes, 'on');
end
% =====================================
% ---- Visualization/Presentation -----
% =====================================
function drawAllModalities(handles)
%tic
for i=1:size(handles.displays,2)
7. updateDisplay(handles, handles.displays(i));
end
%toc
end
% Refreshes a display when a new image data is available
function updateDisplay(handles, display)
if ~isImage(display.modality)
updateRfLine(handles, display);
else
cLim = get(display.axes,'CLim');
% If image pixel masking is enabled
% we need to create an image mask.
if get(handles.qualityEn,'Value') && isMixable(display.modality)
[im, alphaMat] = handles.imagingSystem.getFrame( ...
handles.frameNo, display.modality);
thr = str2double(get(handles.qualityThr, 'string'));
alphaMat(alphaMat < thr)=0;
alphaMat(alphaMat >= thr)=1;
alphaMat=bwareaopen(alphaMat, 300, 4);
alphaMat=alphaMat*str2double(get(handles.alpha,'string'));
else
im = handles.imagingSystem.getFrame(handles.frameNo, ...
display.modality);
alphaMat = str2double(get(handles.alpha,'string'));
end
% Handles median filtering
if (display.medFiltEn)
im = medfilt2(im, display.medFiltDim);
end
% Handles image scaling to the colormap, hardcoded to 192 colors
scaledIm = uint8(thresholdAndScale(im,cLim,192))+64;
set(display.priHandle, 'CData', scaledIm);
8. % If we have to post process the image, (image masking or
% image mixing is enabled).
if ( get(handles.mixEn,'Value') || get(handles.qualityEn,'value') ) ...
&& isMixable(display.modality)
bMode=handles.imagingSystem.getFrame(handles.frameNo, 'bMode');
bModeClim=get(display.secHandle,'UserData');
if numel(bModeClim) == 0
[mini, maxi] = autoScale(bMode,'bMode');
bModeClim = [mini,maxi];
end
set(display.secHandle, 'CData', ...
uint8(thresholdAndScale(bMode, bModeClim, 64)));
set(display.priHandle, 'alphadata', alphaMat);
end
end
title(display.axes, [display.modality, ', frame: ', ...
num2str(handles.frameNo), '/', ...
num2str(get(handles.slider,'Max'))]);
end
function updateRfLine(handles, display)
[x]=handles.imagingSystem.getLine(handles.frameNo, 36, display.modality);
set(display.priHandle,'YData',x);
end
% =====================================
% ----------- UI Callbacks ------------
% =====================================
function strainParamUpdate(hObject, ~, handles)
dx=str2double(get(handles.dx,'String'));
algList = get(handles.strainAlg,'String');
strainAlg = char(algList(get(handles.strainAlg,'Value')));
handles.imagingSystem.strainEstParam(dx, strainAlg);
strainDisps={'strain','absStrain','elasto'};
for i=1:length(strainDisps)
displayType=char(strainDisps(i));
idx=idxOfDisplay(handles, displayType);
if idx
9. currDisplay=handles.displays(idx);
cLim = get(currDisplay.axes,'CLim');
currDisplay=createPriAndSecHandle(handles, currDisplay, displayType);
set(currDisplay.axes,'CLim',cLim);
handles.displays(idx)=currDisplay;
updateDisplay(handles, currDisplay);
end
end
guidata(hObject, handles);
end
function sliderMoved(sliderObj, ~, hObject)
handles=guidata(hObject);
sliderVal=floor(get(sliderObj,'Value')+0.49);
if sliderVal ~= handles.frameNo
handles.frameNo=sliderVal;
drawAllModalities(handles)
guidata(hObject, handles);
end
end
function cMapChanged(hObject, ~, handles)
figList=get(handles.figSelect,'String');
displayType=figList(get(handles.figSelect,'Value'));
idx=idxOfDisplay(handles, displayType);
if idx
currDisplay=handles.displays(idx);
cMin=str2double(get(handles.cMin,'string'));
cMax=str2double(get(handles.cMax,'string'));
set(currDisplay.axes,'Clim',[cMin, cMax]);
updateDisplay(handles, currDisplay)
end
guidata(hObject, handles);
end
% Called when median filter settings are updated
function medFiltChanged(hObject, ~, handles)
figList=get(handles.figSelect,'String');
displayType=figList(get(handles.figSelect,'Value'));
10. idx=idxOfDisplay(handles, displayType);
if idx
medFiltEn = get(handles.medFiltEn, 'value');
medFiltX = str2double(get(handles.medFiltX, 'string'));
medFiltY = str2double(get(handles.medFiltY, 'string'));
medFiltDim = [medFiltX, medFiltY];
handles.displays(idx).medFiltEn = medFiltEn;
handles.displays(idx).medFiltDim = medFiltDim;
guidata(hObject, handles);
updateDisplay(handles, handles.displays(idx));
end
end
% Called when play button is pressed
function play(hObject, ~, handles)
for i=handles.frameNo+1:get(handles.slider,'Max')
handles.frameNo=handles.frameNo+1;
drawAllModalities(handles)
drawnow
set(handles.slider,'Value',handles.frameNo);
end
guidata(hObject, handles);
end
% Called when the figure selection drop-down menu changes
function figSelect_Callback(~, ~, handles)
figList=get(handles.figSelect,'String');
displayType=figList(get(handles.figSelect,'Value'));
idx=idxOfDisplay(handles, displayType);
if idx
newDisplay=handles.displays(idx);
setActiveDisplay(handles, newDisplay);
end
end
% Called when the different modality checkboxes change
function modality_Callback(hObject, ~, handles)
if get(hObject,'Value')
newFig(hObject, handles, get(hObject,'Tag'));
11. else
idx=idxOfDisplay(handles, get(hObject, 'Tag'));
if idx
delete(handles.displays(idx).fig);
end
end
end
% Called when the color map settings are updated
function autoCmap_Callback(hObject, ~, handles)
idx=get(handles.figSelect, 'Value');
if isstruct(handles.displays)
display=handles.displays(idx);
im=handles.imagingSystem.getFrame(handles.frameNo, display.modality);
[cMin,cMax]=autoScale(im, display.modality);
set(handles.cMin, 'string', num2str(cMin));
set(handles.cMax, 'string', num2str(cMax));
cMapChanged(hObject, 0, handles);
end
end
% Called when the color bar button is pushed
function cBar_Callback(~, ~, handles)
idx=get(handles.figSelect, 'Value');
if isstruct(handles.displays)
display=handles.displays(idx);
cMin = str2double(get(handles.cMin, 'string'));
cMax = str2double(get(handles.cMax, 'string'));
cLim = [cMin, cMax];
cMap = colormap(display.axes);
cMap=cMap(65:end,:);
switch(display.modality)
case 'vel'
cLim=cLim*1e03;
unit='mm/s';
case {'strain', 'absStrain'}
cLim=cLim*1e03;
12. unit='10^{-3}';
otherwise
unit='';
end
createColorbar(cLim, cMap, unit);
end
end
% Called when the velocity estimator settings are updated
function velParamUpdate(hObject, ~, handles)
rngGate = str2double(get(handles.rngGate,'String'));
latGate = str2double(get(handles.latGate,'String'));
ensLength = str2double(get(handles.ensLength,'String'));
velFiltOrder = str2double(get(handles.velFiltOrder,'String'));
velFiltCutOff= str2double(get(handles.velFiltCutOff,'String'));
twoDimCorrEn = get(handles.twoDimCorrEn,'Value');
fDem = str2double(get(handles.fDem,'String'));
unwrapEn = get(handles.unwrapEn,'Value');
handles.imagingSystem.velEstParam(rngGate, latGate, twoDimCorrEn, ...
fDem, unwrapEn, ensLength, velFiltOrder, velFiltCutOff);
displayType='vel';
idx=idxOfDisplay(handles, displayType);
if idx
currDisplay=handles.displays(idx);
cLim = get(currDisplay.axes,'CLim');
currDisplay=createPriAndSecHandle(handles, currDisplay, displayType);
set(currDisplay.axes,'CLim',cLim);
handles.displays(idx)=currDisplay;
updateDisplay(handles, currDisplay);
end
strainParamUpdate(hObject, 0, handles);
end
% Called when the RF filter settings are updated
function rfFiltUpdate(~, ~, handles)
enable=get(handles.filtEn,'Value');
order=str2double(get(handles.filtOrder, 'String'));
13. fMin=str2double(get(handles.filtLow, 'String'));
fMax=str2double(get(handles.filtHigh, 'String'));
handles.imagingSystem.rfFilt(enable, order, [fMin, fMax]);
drawAllModalities(handles);
end
% Called when the visualization settings are updated
function visualizationUpdate(~, ~, handles)
if get(handles.mixEn, 'Value')
cLim = bModeClim(handles);
for i=1:size(handles.displays,2)
currDisplay=handles.displays(i);
if isMixable(currDisplay.modality)
cMap=colormap(currDisplay.axes);
cMap(1:64,:)=gray(64);
colormap(currDisplay.axes, cMap);
set(currDisplay.priHandle,'alphadata', str2double(get(handles.alpha,'String')));
set(currDisplay.secHandle,'UserData', cLim);
updateDisplay(handles, currDisplay);
end
end
else
for i=1:size(handles.displays,2)
currDisplay=handles.displays(i);
if isMixable(currDisplay.modality)
cMap=colormap(currDisplay.axes);
cMap(1:64,:)=ones(64,3);
colormap(currDisplay.axes, cMap);
set(currDisplay.priHandle,'alphadata', 1.0);
updateDisplay(handles, currDisplay);
end
end
end
end
% Called when the elastogram settings are updated
function elastoParamUpdate(~, ~, handles)
eFiltOrder = str2double(get(handles.eFiltOrder,'String'));
14. eThr = str2double(get(handles.eThr,'String'));
handles.imagingSystem.elastoParam(eFiltOrder, eThr);
idx=idxOfDisplay(handles, 'elasto');
if idx
updateDisplay(handles, handles.displays(idx));
end
end
% Called when File->Load is pressed
function Load_Callback(hObject, ~, handles)
[fileName, pathName, filterIndex]=uigetfile( ...
{'*.mat;*.rf','RF data (*.mat, *.rf)'});
switch filterIndex
case 0 % User pressed cancel
set(handles.slider,'Enable','off');
return
case 1 % load RF-data file
handles.imagingSystem=ImagingSystem([pathName, fileName]);
end
enableUi(handles);
newFig(hObject, handles, 'bMode');
end
% Called when "File->Save all as images" is pressed
function saveAllToFile(~, ~, handles)
folder_name = uigetdir();
if folder_name
ratio=handles.imagingSystem.aspectRatio;
for j=1:size(handles.displays,2)
currDisplay=handles.displays(j);
if isImage(currDisplay.modality)
mkdir([folder_name,'/',currDisplay.modality])
end
end
h=waitbar(0,'Storing visible figures to disk');
for i=1:get(handles.slider,'Max')
for j=1:size(handles.displays,2)
currDisplay=handles.displays(j);
15. if isImage(currDisplay.modality)
im=handles.imagingSystem.getFrame(i, currDisplay.modality);
cLim=get(currDisplay.axes,'CLim');
cMap=colormap(currDisplay.axes);
cMap=cMap(65:end,:);
im=imresize(im,[size(im,1),floor(size(im,1)*ratio)]);
if strcmp(currDisplay.modality,'elasto')
im=medfilt2(uint8(thresholdAndScale(im,cLim, 256)));
im=histeq(im,64);
cMap=jet(256);
else
im=uint8(thresholdAndScale(im,cLim, 192));
end
% extra stuff
imwrite(im, cMap,strcat(sprintf('%s/%s/%.4d',folder_name,currDisplay.modality,i),'.png'));
end
end
waitbar(i/get(handles.slider,'Max'));
end
end
close(h);
end
% Called when "File->Export to workspace" is pressed
function exportDataToWorkspace(~, ~, handles)
assignin('base','imSystem', handles.imagingSystem);
end
% Called when "File->Preprocess all frames" is pressed.
function preprocessAll(~, ~, handles)
N=handles.imagingSystem.noFrames();
handles.imagingSystem.setBufLength(N);
h=waitbar(1/N);
for i = 1:N
[~,~]=handles.imagingSystem.getFrame(i,'strain');
waitbar(i/N);
16. end
delete(h);
end
function closeAll(~, ~, handles)
try
if isstruct(handles.displays)
for i=1:size(handles.displays,2)
delete(handles.displays(i).fig);
end
end
% Attempt to close file.
if ~isempty(handles.imagingSystem)
handles.imagingSystem.close();
end
catch exc
warning('GUI:failedToClose','Caught exception: ');
disp(exc);
end
delete(gcf);
end
% =====================================
% -------- Misc functions --------
% =====================================
function b=isImage(modality)
if strcmp(modality, 'rfLine') || ...
strcmp(modality, 'rfLineFreq')
b=0;
else
b=1;
end
end
function b=isMixable(modality)
if strcmp(modality, 'bMode') || ...
strcmp(modality, 'rfLine') || ...
strcmp(modality, 'rfLineFreq')
b=0;
17. else
b=1;
end
end
function cMap = defaultCmap(displayType)
switch (displayType)
case 'bMode'
cMap = gray(192);
case 'vel'
cMap = velMap192;
case 'absStrain'
cMap = (hot(192));
otherwise
cMap = jet(192);
end
end
function idx=idxOfDisplay(handles, displayType)
idx=find(ismember({handles.displays.modality},displayType),1);
if isempty(idx)
idx=0;
end
end
function enableUi(handles)
N=handles.imagingSystem.noFrames;
set(handles.slider,'Max',N);
set(handles.slider,'SliderStep',[1/(N-1), 10/(N-1)]);
set(handles.slider,'Value',1);
set(handles.slider,'Enable','on');
set(handles.bMode, 'Enable','on');
set(handles.bMode, 'Value',1);
set(handles.vel, 'Enable','on');
set(handles.strain, 'Enable','on');
set(handles.absStrain, 'Enable','on');
set(handles.rfLine, 'Enable','on');
set(handles.rfLineFreq, 'Enable','on');
end
18. function enableColorPanel(handles)
set(handles.figSelect, 'Enable','on');
set(handles.cMax,'Enable', 'on');
set(handles.cMin,'Enable', 'on');
end
function cLim = bModeClim(handles)
idx=idxOfDisplay(handles, 'bMode');
if idx
cLim=get(handles.displays(idx).axes,'CLim');
else
bModeFrame=handles.imagingSystem.getFrame(handles.frameNo, 'bMode');
[cMin, cMax]=autoScale(bModeFrame, 'bMode');
cLim = [cMin, cMax];
end
end
