Using flow approaches to effectively manage agile testing at the enterprise level
- 1. #LSSC11 /CC @yuvalyeret Testing Flow Using flow approaches to effectively manage agile testing at the enterprise level Yuval Yeret – Kanban Lead - AgileSparks
- 4. What we covered Testing Elasticity Test-specific Challenges To Flow Why Flow for Testing Issues at Scale
- 5. Distress call! “We need to release much more frequently” “the business cannot live with months of hardening” We want Agile to save us!
- 6. So why not just do Scrum+XP? Sufficient?Not for Enterprise scale Necessary? Not all of it Pragmatic? So so
- 7. DONE DONE– The Enterprise Testing Challenge “We are doing agile iterations for development and testing and it is going quite well. One of our greatest challenges is dealing with the stuff we cannot finish within the iteration – currently its one big pile at the end” R&D GM Large Enterprise Software Group
- 8. What are the alternatives? Longer Sprints Sprint Synchronized Handoffs Flow-based Handoffs
- 9. Flowing all the way to DONE DONE DONE DONE READY DONE 9
- 10. Complement Solutions Focus Pragmatic Pace
- 11. So... We started to use a recipe based on Flow
- 12. Current Reality Tree Let’s dive into why this is a problem LOW PREDICTABILITY HIGH STABILIZATION COSTS QUALITY @ THE END LATE FEEDBACK HEAVY MANUAL TESTING LONG CYCLE TIMES LARGE WIP BIG BATCHES BIG FEATURES FEATURE PER PERSON DONE DONE LIMIT FEATURES IN PROGRESS AUTOMATE AS PART OF DONE CONTINUOUS INTEGRATION SPECIALIZAT-ION LONE WOLFS NOT EFFECTIVE FEATURE FREEZE POLICY TOO STRICT HIGH COST OUR BUILD IS NOT STABLE LIMIT OPEN DEFECTS SMALLER FEATURES COLLECTIVE OWNERSHIP LIMIT AT THE FEATURE LEVEL WHOLE TEAM AUTOMATION PYRAMID INVEST IN REMOVING INSTABILITY IMPROVEMENT BACKLOG START AS IS, SHORTEN WHEN PREDICTABLE FIX M/L DEFECTS? LOSE SIGHT OF THE BIG PICTURE LARGE OVERHEAD EXISTING GAP IS TOO BIG EFFECTIVE SLICING PRAGMATIC RISK PROFILING TRANSITION BASED ON NECESSITY elad@agilesparks.com http://blog.crisp.se/henrikkniberg http://www.flickr.com/photos/librarygoblin/4307610546/lightbox/
- 13. Is this Evolution or Revolution? k/K? Performance Distress Calls + Israeli Impatience? Evolution Time This is what we see in Israel...
- 14. Lets see how it looks like in practice
- 15. “What is the gapbetween dev and test? What are we doing to close it?”
- 16. BAD GOOD Limit Defects in Process – Early Quality is Cheap Quality
- 17. “We used to feel comfortable to release quarterly and anxious to release every two weeks. “ “Now releasing every two weeks is natural. We are anxious when we can’t do it [due to holiday freeze]” FiftyOne.com
- 18. Always go for Continuous Deployment??? Not necessarily
- 19. What we covered Testing Elasticity Test-specific Challenges To Flow
- 20. Limiting WIP – pull according to the bottleneck DONE R D C Hardening R D C T R D C T R D C T R D C T R D C T Time
- 22. WIP Limits SLACKTIME ??? * No coaches were idle due to the preparation of this presentation
- 23. Feature Freeze Coding Done DONE Hardening R D C T R D C T R D C T R D C T R D C T R D C T
- 24. What LIMITED WIP Does Fix open defects on current work 3 WIP Limit! Can’t startnew DEV work! Help us with Blocker T D T D T D Help us automate tests for current work How can we help current work?
- 25. What LIMITED WIP Does Automate Setups and Test Data Improve quality you deliver to QA! Half of our work is not core test work. Maybe you can take some of it, or help us reduce waste there 3 T D T D Ways to share the test load – e.g. automation/setups work T D How can I help you be more efficient?
- 26. Developers Developers Testers Where Kanbanis used, Whole Team, ATDD and other Agile Testing approaches emerge MUCH faster
- 27. problem solved?
- 28. “Testing was always like a pillow – it took whatever space was left. We used to have a cap on testing because there was a deadline... ...Now with the new Flow mode the inmates are running the asylum [and we have no cap on how long testing takes]” A worried Dev Manager
- 29. Testing/Verification is a highly Elastic activityLets look at a few ways to cope ...
- 30. Cadence of releases/drops, will drive completion
- 31. Have an explicit policy regarding the desired/acceptable size of work
- 32. Care about Cycle Time & Done Testing End to End
- 33. Due Datescan help(Especially if doable and agreed upon with delivery team) http://yuvalyeret.com/2010/09/19/kanban-early-warning-using-a-predictive-variant-of-spc/
- 34. No REAL external Due Date? tryInternal Cycle Time Soft Goals based on learned capabilities Avoidlocal due dates! http://yuvalyeret.com/2010/09/19/kanban-early-warning-using-a-predictive-variant-of-spc/
- 36. Energizing Purpose and Whole Team Accountability
- 37. Can testing be overdone?
- 38. Talk about what is DoneEstablish Explicit Policies
- 39. Experiment with using an Explicit Policies board documenting your process
- 40. Different work types / CoS can have different Done/Release Criteria
- 42. 1 2 3 Goals+Visibility enhance Purpose
- 43. What we covered Testing Elasticity Issues at Scale
- 44. Will visualizing and managing flow in each of those roads be enough?
- 45. Need to visualize and manage the global end to end flow across sharedresources
- 46. Sharing
- 47. Manage flow at the level at which resources are shared
- 48. 3
- 49. Example Policy - Classes of Service for Downstream Involvement Classes of Treatment Risk Profiling Involvement mode of the shared resource
- 50. What we covered Testing Elasticity
- 51. yuval@agilesparks.com @yuvalyeret Get the slides at http://www.slideshare.net/yyeret Questions? Blogging at http://yuvalyeret.com
- 52. Images Attribution http://www.flickr.com/photos/yuvalyeret/265568342/in/set-72157594323037021/ www.slideshare.net/wnazzaro/agile-it-and-the-business-community http://www.freefoto.com/images/41/03/41_03_4---Weight-Limit-Sign_web.jpg?&k=Weight+Limit+Sign http://www.flickr.com/photos/maisonbisson/267746261/sizes/o/in/photostream/ http://www.flickr.com/photos/malavoda/4195215934/sizes/l/in/photostream/ http://www.flickr.com/photos/njj4/5044361592/sizes/l/in/photostream/ http://www.flickr.com/photos/grafixer/3527166081/sizes/l/in/photostream/ http://www.flickr.com/photos/librarygoblin/4307610546/lightbox/ http://www.flickr.com/photos/orinrobertjohn/2188280583/sizes/l/in/photostream/ http://www.flickr.com/photos/kwl/4809326028/ http://www.flickr.com/photos/justin_case/54087334/sizes/o/in/photostream/ http://www.flickr.com/photos/noneck/869906174/sizes/l/in/photostream/ http://www.flickr.com/photos/wendycopley/1332359314/ http://www.flickr.com/photos/frumbert/307532180/sizes/l/in/photostream/ http://www.flickr.com/photos/tgillin/4599272187/ http://www.flickr.com/photos/rolleh/3475746680/sizes/o/in/photostream/ http://www.flickr.com/photos/pamilne/3401930511/sizes/l/in/photostream/ http://www.flickr.com/photos/batintherain/112826092/sizes/l/in/photostream/ http://sherisays.files.wordpress.com/2010/08/drivers-stuck-in-traffic-jam-for-9-days-in-china.jpg http://www.flickr.com/photos/slidesf/2648616262/sizes/l/in/photostream/ http://www.flickr.com/photos/jongales/391648530/sizes/l/in/photostream/ http://www.flickr.com/photos/andreasnilsson1976/1307180278/sizes/l/in/photostream/ http://www.flickr.com/photos/basf/4837105835/sizes/l/in/photostream/
Editor's Notes
- Recipe for Continuous Stabilization How to deal with Elasticity in Testing (and in general...)How to deal with Shared Test LabsClasses of treatment
- Recipe for Continuous Stabilization How to deal with Elasticity in Testing (and in general...)How to deal with Shared Test LabsClasses of treatment
- http://www.flickr.com/photos/andreasnilsson1976/1307180278/sizes/l/in/photostream/
- TODO Highlight where I’m going to focus today.
- Can do it either way – but last few examples we see are a “Burning platform” so willing to sacrifice in order to see quick improvementsInteresting though – even under distress, going Scrum all the way is usually not chosen. Several theories why? Offline...
- What does it mean to manage flow? Managers take action to stop the line in case of high WIPIdentify bottlenecks and divert resources / focusManagement attention
- Vote:Who here is working on V<1.0?Of those – who knows up front the majority of the scope of V1.0? The rest should care.On those working
- Recipe for Continuous Stabilization How to deal with Elasticity in Testing (and in general...)How to deal with Shared Test LabsClasses of treatment
- Empty after testing, development in done testing busy bottleneck in testingThis is a classic bottleneck in an R&D team.Testing are at their work in progress limit, meaning they cannot take on more work. Acceptance has no work in progress, what we call a “bubble”Development are at their limit as well. Nothing from Testing is DONE waiting to be pulled, which explains why Acceptance has a bubble
- Automation – not just test automation!How can we help you spend more time actually testing (compared to setup, and other wastes) (http://theoryofconstraints.blogspot.com/2007/06/toc-stories-2-blue-light-creating.html) How often do we need to retest? Why?ATDD - drives better code into testing, as well as offload some testing workAgree on “READY for Testing” criteria for stories, setup relevant team rules and processes.
- http://www.flickr.com/photos/basf/4837105835/sizes/l/in/photostream/High variability – you never know what you get...High elasticity – You can always do more – Which is a special kind of Variability...
- http://www.flickr.com/photos/basf/4837105835/sizes/l/in/photostream/High variability – you never know what you get...High elasticity – You can always do more – Which is a special kind of Variability...
- What does it mean to manage flow? Managers take action to stop the line in case of high WIPIdentify bottlenecks and divert resources / focusManagement attention
- Explicit expectation – can be via uniform size, or via some level of estimations.
- When there is an external due date – sure, put it on there, and it will create purposeBut what if there isn’t really an external due date? Put the estimated due date based on your current cycle time predictability control chart.
- Testers should not feel like the “last line of defense” – they should really get higher quality stuff to begin with. Everyone should support doing the right amount of testing, sometimes it will be more, sometimes it will be lessEveryone should start to think about the right economic decision, not just perfect quality. With history of low quality, it is hard for testers to trust this will happen. When you start building quality in, trust can build, and risks can start to be taken. Talk about my experience in SANRAD about this? 51? What happens when Whole Team approach starts to kick in. Testers should
- Sometimes fixing all defects is NOT the right economic decision...
- Main point is to have a discussion about the policies, share the view about why they should work for you, and be clear about the expectations. Talk about Testing Yield
- Main point is to have a discussion about the policies, share the view about why they should work for you, and be clear about the expectations.
- Recipe for Continuous Stabilization How to deal with Elasticity in Testing (and in general...)How to deal with Shared Test LabsClasses of treatment
- TODO – summarize the tools/tips until nowPut the tips on the screen
- TODO – emphasize the shared resources
- Red– performance team Must be involved hands onYellow– performance team Advise/Consult, but most work is in TeamsGreen– don’t need any involvement from performance teamDrives collective ownership of performance (and other “Ilities”) – And is another form of subordinationto the constraint
- Recipe for Continuous Stabilization How to deal with Elasticity in Testing (and in general...)How to deal with Shared Test LabsClasses of treatment
- Recipe for Continuous Stabilization How to deal with Elasticity in Testing (and in general...)How to deal with Shared Test LabsClasses of treatment
