The Trusted Platform Module (TPM) is an international standard for a secure cryptoprocessor developed by the Trusted Computing Group to provide hardware-based security related features. It measures the boot process and software running on a device to ensure integrity and allows for remote attestation of the device's state. The TPM provides roots of trust for measurement, reporting, and storage and utilizes platform configuration registers, sealed storage, and keys to securely store and report information based on the device's configuration.

1. TRUSTED PLATFORM MODULE

2. INTRODUCTION
• The Trusted Platform Module (TPM) is an international
standard for a secure crypto-processor.
• The TPM technical specification was written by a computer
industry consortium called the Trusted Computing Group
(TCG).
• The International Organization for Standardization (ISO) and
the International Electro-technical Commission (IEC)
standardized the specification as ISO/IEC 11889 in 2009.
2 of 36

3. ABBREVIATIONS
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
TPM – Trusted Platform Module
TCG – Trusted Computing Group
TCB - Trusted Computing Base
BIOS – Basic Input-Output System
EK – Endorsement Key
SRK – Storage Root Key
PCR – Platform Configuration Register
AIK – Attestation Identity Key
ROT – Root of Trust
CRTM – Core Root of Trust
RTM – Root of Trust for Measurement
RTR – Root of Trust for Reporting
RTS – Root of Trust for Storage
MBR – Master Boot Record
GRUB – Grand Unified Boot Loader
DRM – Digital Rights Management
3 of 36

4. TRUSTED COMPUTING GROUP
• The Trusted Computing Group (2003), successor to the Trusted
Computing Platform Alliance (TCPA)
• An initiative started by AMD, Cisco, Hewlett-Packard, IBM, Intel,
Microsoft and Wave Systems Corp.
• TCG is a non-profit organization formed to develop, define, and promote
open standards for hardware-enabled trusted computing and security
technologies, including hardware building blocks and software interfaces
across multiple platforms
• Promoters + Contributors + Adopters = 108
4 of 36

5. TRUSTED COMPUTING BASE
Trusted Computing Base
Trusted Computing Environment
Applications
5 of 36

6. TRUSTED COMPUTING
• The computer will consistently behave in expected ways, and those
behaviors will be enforced by computer hardware and software
• Enforcing this behavior is achieved by loading the hardware with a unique
encryption key inaccessible to the rest of the system
• TC is controversial as the hardware is not only secured for its owner, but
also secured against its owner
6 of 36

7. FUNDAMENTAL TRUSTED COMPUTING
FUNCTIONALITY
• A mechanism is required to record (measure) what software
is/was running
•
•
•
•
Requires to monitor the boot process
Needs an anchor to start the measurement from a Root of Trust
Nobody should be able to modify or forge these measurements
Some shielded location for the measurements is required
7 of 36

8. FUNDAMENTAL TRUSTED COMPUTING
FUNCTIONALITY
• Now you know that your platform is in a defined state
• Why should someone else believe this claim?
• A mechanism to securely report the measurements to a 3rd party is
required
• Secure storage
• Allow access to data only if system is in a known state
• Cost efficient implementation and production
8 of 36

9. TPM SPECIFICATION
Design Principles
TPM Structures
TPM Specifications
for 1.2
TPM Commands
Compliance
9 of 36

10. TCG Doc. ROADMAP
10 of 36

11. TPM
• The TPM is a platform component
• NOT a platform all by itself
• TPM becomes a permanent component of the platform
• The TPM is NOT an active component, always a responder to a request and
never initiates an interrupt or other such operation
• TPM cannot alter execution flow of system (e.g. booting, execution of
applications)
11 of 36

12. TPM: CHANGES TO PC
• Extra hardware
• TPM
• Single 33 MHz clock
• Software changes
• BIOS
• OS & Apps
12 of 36

13. TPM COMPONENTS
13 of 36

14. PLATFORM CONFIGURATION REGISTERS
• There are at least 16 PCRs in a TPM.
• They store platform configuration measurements.
• These measurements are normally hash values (SHA-1) of entities
(applications) running on the platform.
• PCRs can not be written directly; data is stored by a process called
extending the PCR.
• PCR = SHA-1(PCR + measurement)
• PCR extends are not commutative
• PCRs initialized to default value (e.g. 0) at boot time
• After boot, PCRs contain hash chain of booted software
14 of 36

15. INTEGRITY MEASUREMENT WITH TPM
• A measures entity B (could be executable or other files ...). Result is
a B's "fingerprint".
• This fingerprint is stored in a Stored Measurement Log (SML)
which resides in the hard drive (outside, and not protected by a
TPM).
• A then inserts B's fingerprint into a PCR (via the PCR's extend
operation).
• Control is passed to B.
15 of 36

16. TRUSTED BOOT
16 of 36

17. ROOTS OF TRUST
• Root of Trust is a hardware or software mechanism that one implicitly trusts
• Root of Trust for Measurement (RTM)
• Uses Platform Configuration Registers (PCR) to record the state of a system
• Static entity like the PC BIOS
• Root of Trust for Reporting (RTR)
• Entity trusted to report information accurately and correctly
• Uses PCR and RSA signatures to report the platform state to external parties in an
unforgettable way
• Root of Trust for Storage (RTS)
• Entity trusted to store information without interference leakage
• Uses PCR and RSA encryption to protect data and ensure that data can only be accessed if
platform is in a known state
17 of 36

18. ROOT OF TRUST FOR MEASUREMENT
• Involved steps:
• Measure (compute the hash value of) the next entity: e.g. the
BIOS measures the OS loader
• The measurement is extended into one of the TPM PCR
• Control is passed to the measured entity
• This process is continued for all components of a system up to
user level applications
• Measurements change with system updates and patches
18 of 36

19. ROOT OF TRUST FOR REPORTING
• Endorsement Key (EK) forms the RTR
• Private part never leaves the TPM (only exists in shielded location)
• EK is unique for every TPM and therefore uniquely identifies a
TPM
• The EK is backed by an EK certificate typically issued by the TPM
manufacturer
• The EK certificate guarantees that the key actually is an EK and is
protected by a genuine TPM
19 of 36

20. ROOT OF TRUST FOR STORAGE
• Two approaches
• Without using PCR: bind/unbind
• With using PCR: seal/unseal
• Binding
• Happens outside of the TPM
• Encrypt data with the public part of a TPM key
• Only the TPM that the key pair belongs to can decrypt the data and private key can
only be used inside the TPM
• Binding to a specific TPM, use a non-migratable binding key (migratable keys can
also be used)
• Unbinding
• Decryption of bound data inside the TPM using the private key
20 of 36

21. TPM KEYS
• Storage Root Key (SRK)
•
•
•
•
2048 bit RSA key
Is top level element of TPM key hierarchy
Created during take ownership
Non-migratable, store inside the chip, can be removed
• Storage Keys
• RSA keys used to wrap (encrypt) other elements in the TPM key hierarchy
• Created during user initialization
• Signature Keys
• RSA keys used for signing operations
• Must be a leaf in the TPM key hierarchy
21 of 36

22. KEY CONCEPTS
• Endorsement key
• Secure input and output
• Memory curtaining / protected execution
• Sealed storage
• Remote attestation
22 of 36

23. ENDORSEMENT KEY
• The endorsement key is a 2048-bit RSA public and private key
pair
• Created randomly on the chip at manufacture time
• Non-migratable, store inside the chip, cannot be removed
• It is never used for encryption or signing
23 of 36

24. SECURE INPUT AND OUTPUT
• Secure I/O provides a secure hardware path from the keyboard
to an application
• From the application back to the screen.
• No other software running on the same PC will be able to
determine what the user typed, or how the application
responded.
24 of 36

25. MEMORY CURTAINING
• Memory curtaining extends common memory protection
techniques to provide full isolation of sensitive areas of
memory
• Even the operating system does not have full access to
curtained memory
• The exact implementation details are vendor specific
25 of 36

26. SEALED STORAGE
• Sealed storage protects private information by binding it to
platform configuration information including the software and
hardware being used
• Data can be released only to a particular combination of
software and hardware
• Embedding PCR values in blob ensures that only
certain apps can decrypt data
• Messing with MBR or OS kernel will change PCR values
26 of 36

27. SEALED STORAGE
• Encrypt data using RSA key on TPM
• TPM_Seal
•
•
•
•
(some) Arguments:
keyhandle: which TPM key to encrypt with
KeyAuth: Password for using key `keyhandle’
PcrValues: PCRs to embed in encrypted blob
data block: at most 256 bytes (2048 bits)
•
Used to encrypt symmetric key (e.g. AES)
• Returns encrypted blob.
• Blob can only be decrypted with TPM_Unseal when:
• PCR-reg-vals = PCR-vals in blob.
• TPM_Unseal will fail otherwise
27 of 36

28. REMOTE ATTESTATION
• Remote attestation allows changes to the user's computer to be
detected by authorized parties
• Good applications:
• Bank allows money transfer only if customer’s machine runs “up-to-date”
OS patches.
• Enterprise allows laptop to connect to its network only if laptop runs
“authorized” software
• Quake players can join a Quake network only if their Quake client is
unmodified.
• DRM:
• Music Stores sell content for authorized players only.
28 of 36

29. REMOTE ATTESTATION- HOW IT WORKS
• Recall: EK private key on TPM.
• Cert for EK public-key issued by TPM vendor.
• Step 1: Create Attestation Identity Key (AIK)
• AIK Private key known only to TPM
• AIK public cert issued only if EK cert is valid
29 of 36

30. REMOTE ATTESTATION- HOW IT WORKS
• Step 2: sign PCR values (after boot)
• Call TPM_Quote (some) Arguments:
• keyhandle: which AIK key to sign with
• KeyAuth: Password for using key `keyhandle’
• PCR List: Which PCRs to sign.
• Challenge: 20-byte challenge from remote server
• Prevents replay of old signatures.
• Userdata: additional data to include in sig.
• Returns signed data and signature.
30 of 36

31. MISCONCEPTIONS CLARIFIED
• The TPM does not measure, monitor or control anything
• The TPM is a passive device in the system
• The TPM has no way of knowing what was measured
• Measurements are made by host software and sent to the TPM
• TPM does not perform bulk encryption
• (e.g. File and Folder encryption or Full Disk encryption)
• Digital Right Management (DRM) is not a goal of TCG specifications
• All technical aspects of DRM are not inherent in the TPM
• TPM can work with any operating systems or application software
• The specification is open and the API is defined, no TCG secrets
31 of 36

32. BENEFITS
•
•
•
•
•
•
•
Enhance confidence in platform
Proof that a platform is a Trusted Platform
Binding of data to a particular platform
Sealing data to a trusted system state/configuration
Owner privacy and control
Secure boot
Low cost exportable technology
32 of 36

33. CRITICISM
•
•
•
•
•
•
Digital rights management
Users unable to modify software
Users have no control over data
Users unable to exercise legal rights
Users vulnerable to vendor withdrawal of service
Users unable to override
33 of 36

34. STANDARDIZATION
• JTC1, a joint committee of the International Organization for
Standardization, or ISO, and IEC, the International Electro-technical
Commission, has accepted and published the Trusted Computing
Group Trusted Platform Module specification Version 1.2 as
ISO/IEC standard 11889.
• Abstract
• ISO/IEC 11889 defines the Trusted Platform Module (TPM), a device that enables
trust in computing platforms in general. ISO/IEC 11889-1:2009 is an overview of
the TPM. It describes the TPM and how it fits into the trusted platform. ISO/IEC
11889-1:2009 describes trusted platform concepts such as the trust boundary,
transitive trust, integrity measurement, and integrity reporting.
34 of 36

35. 35 of 36

36. THANK YOU
36 of 36
