The document discusses trees as a data structure. It defines trees as connected acyclic graphs with nodes connected in a parent-child relationship. It describes tree terminology like root, leaf, internal and external nodes. It also covers tree traversal algorithms like preorder, inorder and postorder traversal and their applications. Finally, it discusses types of binary trees and basic tree operations.

2. TREE

3. leaves
branches
root

4. roo
t
nodes
leav
es
branch
es

5.  Connected graph.Connected graph.
 Acyclic graph.
 A finite non-empty set of elements.
 CConsisting of nodes with a parent-child
relation.
Introduction of a Tree
B C
FD E G
A

6. Family Structures of a Tree
 Root-node without parent (A)
 Siblings-nodes share the same parent.
Internal node-node with at least one child (A, B, C, E)
External node (leaf): node without children (D,F,G, H, I)
Ancestors of a node: parent, grandparent, grand-grandparent,
etc.
Descendant of a node: child, grandchild, grand-grandchild, etc.
Depth of a node: number of ancestors
Height of a tree: maximum depth of any node (3)
Degree of a node: the number of its children
Degree of a tree: the maximum number of its node.
 Subtree: tree consisting of a node and its descendants

8. Left Child Right Sibling
Representation
Data
Left Child Right
Sibling
A
B C D
IHGFE
J K L

9.  Preorder Sequence.
 Inorder Sequence.
 Postorder Sequence.
 Level order Sequence
Tree Traversal Technique
Tree Traversal Technique
Preorder Inorder Postorder Level order

10. Tree Traversal Technique
(CONT.)
Preorder Sequence:
 Visits the nodes of a tree in a systematic manner
 A node is visited before its descendants
 Application: print a structured document
Algorithm:
void preorder(node *root){
if(root!=NULL){
printf(“%c”,root->data);
if(root->left!=NULL)
preorder(root->left);
if(root->right!=NULL)
preorder(root->right);
}
}

12. Inorder Sequence:
 A node is visited after its left subtree and before its right sub
tree
Algorithm :
void inorder(node *root){
if(root!=NULL){
if(root->left!=NULL)
inorder(root->left);
printf(“%c”,root->data);
if(root->right!=NULL)
inorder(root->right);
}
}

14. Postorder Sequence:
 A node is visited after its descendants
 Application: compute space used by files in a directory
and its subdirectories
Algorithm :
void postorder(node *root){
if(root!=NULL){
if(root->left!=NULL)
postorder(root->left);
if(root->right!=NULL)
postorder(root->right);
printf(“%c”,root->data);
}
}

16. Level order Sequence:
 A node is traversed in a level by level
order.
Algorithm :
Queue<-root
while Queue !=Empty
v<-Queue
visit v
Visited Sequence<-v
if left(v) !=NULL then
Queue<-left(v)
if right(v) !=NULL then
Queue<-right(v)
endwhile
return Visited Sequence

18.  Each internal node has at most two children
(degree of two)
 The children of a node are an ordered pair
Alternative Recursive Defintion:
 A tree consisting of a single node, or
 A tree whose root has an ordered pair of children.
Applications:
 Arithmetic expressions.
 Decisions process searching.
 Searching.
A
B C
F GD E
H I

19. Strict Binary Tree:
 Each node exactly having two or zero child.
Full Binary Tree:
 Each node exactly having two node or zero child
and leaf node at the same level.
Complete Binary Tree:
 All leaf node is at the same height.
 No missing node in the sequence.

20. Strict Binary Tree
Full Binary Tree
A
B C
GE
I
D
H
F
Complete Binary Tree
A
B C
GF

21. Basic Operations:
 Inserting an element into tree.
 Deleting an element from tree.
 Searching for an element.
 Traversing the tree.
Auxiliary Operations:
 Finding size of tree.
 Calculating height of tree.

22.  Expressions trees are used in compiler.
 Huffman coding trees which are used in data compression
technique.
 Binary Search Tree (BST) supports insertion & deletion of node
with o(log n)
 Priority queue supports search and deletion of min or max on a
collection of items in a logarithmic times.

23. Method 1:
 height=max(level(i))
Method 2:
 height= log2(n)
Method 3:
 height(T)=max(height(Tl),height(Tr))+1

24. Algorithm :
int height(node *root){
if(root==NULL)
return -1;
else if(root->left==NULL && root->right==NULL)
return 0;
else
return max(height(root->left),height(root->right))+1;
}
Int max(int x,int y){
if(x>y)
return x;
else
return y;
}
