Storm distributed processing
- 1. Storm distributed processing BarCamp Saigon 2012 Duc Quoc
- 2. Hello! I’m Duc • Senior Software Engineer – KMS Technology • Open source advocate – www.ducquoc.vn – ducquoc.vn@gmail.com – @ducquoc_vn
- 3. Agenda • Why Storm created • Basic concepts • Some use cases • Q&A
- 4. Agenda • Why Storm created • Basic concepts • Some use cases • Q&A
- 5. Storm? • Twitter’s stream processing framework
- 6. Storm • Originally from BackType for analyzing tweets – (More than 2000 watchers on GitHub) • “the realtime Hadoop” – continuous computation system (open source) • distributed, reliable, fault-tolerant – suitable for big data processing
- 7. Big Data challenges • Scalability – vertical, horizontal • (high) Avalaibility • Stability (fault-tolerance) caching, replication, partitioning/sharding, load-balancing, …
- 8. Google! • published papers on MapReduce, Google FileSystem (GFS), BigTable
- 9. Apache Hadoop • MapReduce, HDFS, HBase – later on: Hive, Pig, Mahout, ZooKeeper, … Task Tracker ZooKeeper Task Job Tracker ZooKeeper Tracker Task ZooKeeper Tracker Task Tracker Task Tracker
- 10. Hadoop limits • Batch processing with jobs -> not realtime • Stateful nodes, SPOF – JobTracker/NameNode • Cumbersome API now Unprocessed Data t Fully processed Latest full Hadoop job period takes this long for this data
- 11. Agenda • Why Storm created • Basic concepts • Some use cases • Q&A
- 12. Cluster • Nimbus: daemon master node • Supervisor: daemon worker nodes • Coordination via ZooKeeper Supervisor ZooKeeper Supervisor Nimbus ZooKeeper Supervisor ZooKeeper Supervisor UI Supervisor
- 13. Tuple • Ordered list of elements – (“user-1234”, “email:ducquoc.vn@gmail.com”)
- 14. Stream • Unbounded sequence of tuples
- 15. Spout • Source of stream – emitting tuples • Talks with queue, logs, API calls, event data
- 16. Bolt • Process tuples, may emit new stream • Apply functions, transforms, access DB & API – filter, aggregate, join, …
- 17. Topology • A directed graph of Spout and Bolt
- 18. Task • Thread which executes a Spout or Bolt • Deploy a topology: $ storm jar myCode.jar com.example.MyTopology arg1 arg2 • Kill a topology: $ storm kill topologyName
- 19. Sample code Create stream called “word” Run 10 tasks Create stream called “first-…” Run 3 tasks Subscribes to stream “word”, using shuffle grouping Source code of this sample: https://ducquoc.googlecode.com/svn/trunk/storm/
- 20. Sample code (2/3) • RandomWordSpout emits a random string from the array words, each 100 milliseconds
- 21. Sample code (3/3) • InterrogativeBolt appends a question mark to the first field of Tuple then emit
- 22. Stream grouping • Decides which task in the bolt, the tuple is sent to • ShuffleGrouping: randomly • FieldsGrouping: groups tuples by named fields • Global grouping, All grouping, None grouping, Direct grouping
- 24. More abstractions • Distributed RPC server • Transactional/Batch • Trident • https://github.com/nathanmarz/storm/wiki – http://groups.google.com/group/storm-user
- 25. Agenda • Why Storm created • Basic concepts • Some use cases • Q&A
- 26. Popular use cases • Continuous/realtime query with low latency – analyzing, monitoring, statistics, classifying, … • Back-end processing for streaming data – automated scoring, log processing/auditing, … • Distributed, high-volume data processing – ETL, realtime integration/synchronization, …
- 27. Storm integration • Data to Storm – storm-jms, storm-kafka, storm-redis-pubsub, storm- scribe, storm-contrib-sqs, … • Storm to databases – storm-cassandra, storm-hbase, storm-contrib-mongo, storm-state, storm-rdbms, … • Polyglotism (language agnostic) – Clojure, Java, python, ruby, PHP, Perl, JRuby, …
- 28. Storm dependencies • Java 5+, Clojure • ZeroMQ 2.1.7-, JZMQ, Python 2.6+ • Thrift, ZooKeeper, Kryo, Jetty, … – slf4j, joda, snakeyaml, guava, …
- 29. Storm UI
- 31. Agenda • Why Storm created • Basic concepts • Some use cases • Q&A
- 32. Q&A Thank you!
- 33. Bonus • I wanna know how many queries I get – Per second, minute, day, week • Results should be available – within <2 seconds 99.8+% of the time – within 50 seconds almost always • History should last >2 years • Should work for 0.01 q/s up to 50,000 q/s • Failure tolerant, yadda, yadda
- 34. Real-time and Long-time together Blended now View view t Hadoop works Storm great back here works here
Editor's Notes
- Map takes one pair of data with a type in one data domain, and returns a list of pairs in a different domain: Map(k1,v1) -> list(k2,v2)The Reduce function is then applied in parallel to each group, which in turn produces a collection of values in the same domain:Reduce(k2, list (v2)) -> list(v3)
- A bolt can subscribe to an unlimited number of streams, by chaining groupings.
- declareOutputFields is used to declare streams and their schemas. It is possible to declare several streams and specify the stream to use when outputting tuples in the emit function call.
- Each spout or bolt are running X instances in parallel (called tasks). All grouping: send to all tasks• Global grouping: pick task with lowest id
