Constructing Web APIs with Rack, Sinatra and
mongoDB
oisín hurley

oi.sin@nis.io
@oisin
web API (ecosystem)
web API (mobile access)
web API (revenue)
a good API is...focussed


   ‣   clear in its intent

   ‣   epitomizes good coding/behavioural practice

   ‣   has minimal sugar

   ‣   has a minimum of control surfaces
a good API is...evolvable



   ‣   your API will have consumers

   ‣   you don’t suddenly break the consumers, ever

   ‣   you control the API lifecycle, you control the expectations
a good web API is...responsive


   ‣   unchatty

   ‣   bandwidth sensitive

   ‣   latency savvy

   ‣   does paging where appropriate

   ‣   not unnecessarily fine-grained
a good web API is...resilient


   ‣   stable in the presence of badness

   ‣   traps flooding/overload

   ‣   adapts to surges

   ‣   makes good on shoddy requests, if possible

   ‣   authenticates, if appropriate
example application


  ‣    flavour of the month - location tracker!

  ‣    now that apple/google no longer do our work for us

  ‣    register a handset

  ‣    add a location ‘ping’ signal from handset to server




      https://github.com/oisin/plink
design (focussed)


   ‣   PUT   a handset for registration


   ‣   POST location details


   ‣   DEL   a handset when not in use

   ‣   focussed and short
design (evolvable)


   ‣   hit it with a hammer - put a version into URL - /api/v1.3/...

   ‣   in good company - google, twitter

   ‣   produce a compatibility statement

   ‣   what it means to minor/major level up

   ‣   enforce this in code
design (resilience)


   ‣   mongoDB for scaling

   ‣   write code to work around badness

   ‣   throttling of client activity with minimum call interval

   ‣   not using auth in this edition...
design (responsiveness)


 ‣   this API is very fine-grained, but not chatty

 ‣   we should queue to decouple POST response time from db

 ‣   but mongo is meant to be super-fast

 ‣   so maybe we get away with it in this edition :)
technologies (sinatra)


   ‣   web DSL

   ‣   low hassle                                    whut?




   ‣   rack compatible




                         http://www.sinatrarb.com/
technologies (rack)


   ‣   rack - a ruby webserver interface

   ‣   we’re going to use this for two things

   ‣   throttling for bad clients using a Rack middleware

   ‣   mounting multiple Sinatra apps with Rack::Builder (later on)




                            http://rack.rubyforge.org/
technologies (mongodb)


 ‣   high performance

 ‣   non-relational

 ‣   horizontal scaling

 ‣   may give us resilience and
     responsiveness

 ‣   also nice client on MacOS :)



  http://www.mongodb.org            http://mongohub.todayclose.com/
technologies (mongo_mapper)


 ‣   ORM for mongoDB

 ‣   a slight tincture of ActiveRecord : models, associations, dynamic
     finders

 ‣   embedded documents

 ‣   indices

 ‣   also, I like DataMapper and this is a little similar


                             http://mongomapper.com/
mongoDB (deploys)
mongoDB is document-oriented


 ‣   collections contain documents, which can contain keys, arrays and
     other documents

 ‣   a document is like a JSON dictionary (in fact, it’s BSON)

 ‣   indices, yes, but no schema in the RDBMS sense - but you do plan!
mongoDB is a database


 ‣   foreign keys - can reference documents living in other collections

 ‣   indices - same as RDBMS - use in the same way

 ‣   datatypes - JSON basics plus some others including regex and code

 ‣   flexible querying with js, regex, kv matching

 ‣   but no JOINs


                                          all the same query
mongoDB can scale


   ‣   by relaxing some of the constraints of relational DBs, better horizontal
       scaling can be achieved

   ‣   replica sets for scaling reads

   ‣   replica sets & sharding for scaling writes

   ‣   map/reduce for batch processing of data (like GROUP BY)


http://www.mongodb.org/display/DOCS/Replication
http://www.mongodb.org/display/DOCS/Sharding
cap/brewer’s theorem

                           All nodes see all data
                              at the same time

                           Consistency




                                                      Partition
       Availability                                  Tolerance
    Node failures do not                           Only total network failure
     prevent operation                     will cause system to respond incorrectly


                       Pick Any Two
consistency model (read)




                                                                            master

                                                                            slave

 http://blog.mongodb.org/post/475279604/on-distributed-consistency-part-1
mongoDB is performance oriented


  ‣   removes features that impede performance

  ‣   will not replace your SQL store

  ‣   good for this example app - because we want fast ‘write’
      performance and scale (consistency not so much)

  ‣   GridFS - chunkifies and stores your files - neat!
code (API)



             ➊

             ➋
                                                              ➍
                 ➌

                                                      config.ru




                     https://github.com/oisin/plink
code (versioning)


                                       ➊


                                 ➋



                                            ➌




                    https://github.com/oisin/plink
code (mongo)

                                               ➊
                                                      ➋
           ➌




                                                      ➍




                                      ➎


               https://github.com/jnunemaker/mongomapper
                     https://github.com/oisin/plink
code (mongo configure)




                                                         ➊
                             ➋




             https://github.com/jnunemaker/mongomapper
                  https://github.com/oisin/plink
mongo (console)


 ➊

 ➋




 ➌
code (mongo queries)

                         ➊                       where query
                                               ➋     &
                                                  creation



                 dynamic query                                 ➌




                  ➍                             deletion


            https://github.com/jnunemaker/mongomapper
                   https://github.com/oisin/plink
code (mongo embedded docs)


                                                   ➊

                                            ➋

                                          ➌
      ➍

           ➎




           https://github.com/jnunemaker/mongomapper
                  https://github.com/oisin/plink
mongo (capped collections)

 ‣   Fixed size, high performance LRU

 ‣   Maintains insertion order - great for logs/comments/etc

 ‣   not in use in this example application

     ‣   embedded documents - no cap on arrays

     ‣   putting location data in another collection - not sensible

     ‣   hacked it in the example app
code (throttling)

                                                                 ➋




                     ➊                                                  ➌




                                                   custom throttle strategy


                    https://github.com/datagraph/rack-throttle
                          https://github.com/oisin/plink
deploy
deploy




         DE
          VE
         CR  LO
            AC   PE
               K    R
deploy
deploy




           BU
         CR TT
           AC
              K
viewing the data



                               ➋




               ➊   another rack app
fast test (restclient)




                   https://github.com/archiloque/rest-client
wraps (mongo)


  ‣   programming is straightforward with mongo_mapper

  ‣   works well with heroku

  ‣   haven’t done any work with sharding/replication

  ‣   complement RDBMS - e.g. for GridFS files storage, logs, profiles

  ‣   worthy of further study and experimentation
improvements (example)


 ‣   authentication using Rack::Warden

 ‣   queued invocations using delayed_job

 ‣   some eye candy for the tracking data

 ‣   suggestions welcome :-)




                        http://github.com/oisin/plink
