4. Introduction
Theoretical foundations
Software
Introduction
The stack of tasks provides a control framework for real-time
redundant manipulator control
◮ implementation of a data-flow,
◮ control of the graph by python scripting,
◮ task-based hierarchical control,
◮ portable: tested on HRP-2, Nao, Romeo.
The stack of tasks
5. Introduction
Theoretical foundations
Software
Introduction
The stack of tasks provides a control framework for real-time
redundant manipulator control
◮ implementation of a data-flow,
◮ control of the graph by python scripting,
◮ task-based hierarchical control,
◮ portable: tested on HRP-2, Nao, Romeo.
The stack of tasks
6. Introduction
Theoretical foundations
Software
Introduction
The stack of tasks provides a control framework for real-time
redundant manipulator control
◮ implementation of a data-flow,
◮ control of the graph by python scripting,
◮ task-based hierarchical control,
◮ portable: tested on HRP-2, Nao, Romeo.
The stack of tasks
7. Introduction
Theoretical foundations
Software
Introduction
The stack of tasks provides a control framework for real-time
redundant manipulator control
◮ implementation of a data-flow,
◮ control of the graph by python scripting,
◮ task-based hierarchical control,
◮ portable: tested on HRP-2, Nao, Romeo.
The stack of tasks
8. Introduction
Theoretical foundations
Software
Introduction
The stack of tasks provides a control framework for real-time
redundant manipulator control
◮ implementation of a data-flow,
◮ control of the graph by python scripting,
◮ task-based hierarchical control,
◮ portable: tested on HRP-2, Nao, Romeo.
The stack of tasks
10. Introduction
Theoretical foundations
Software
Rigid body B
◮ Configuration represented by an homogeneous matrix
MB =
RB tB
0 0 0 1
∈ SE(3)
RB ∈ SO(3) ⇔ RT
B RB = I3
Point x ∈ R3 in local frame of B is moved to y ∈ R3 in
global frame:
y
1
= MB
x
1
The stack of tasks
11. Introduction
Theoretical foundations
Software
Rigid body B
◮ Configuration represented by an homogeneous matrix
MB =
RB tB
0 0 0 1
∈ SE(3)
RB ∈ SO(3) ⇔ RT
B RB = I3
Point x ∈ R3 in local frame of B is moved to y ∈ R3 in
global frame:
y
1
= MB
x
1
The stack of tasks
12. Introduction
Theoretical foundations
Software
Rigid body B
◮ Configuration represented by an homogeneous matrix
MB =
RB tB
0 0 0 1
∈ SE(3)
RB ∈ SO(3) ⇔ RT
B RB = I3
Point x ∈ R3 in local frame of B is moved to y ∈ R3 in
global frame:
y
1
= MB
x
1
The stack of tasks
13. Introduction
Theoretical foundations
Software
Rigid body B
◮ Velocity represented by (vB, ωB) ∈ R6 where
˙RB = ˆωBRB
and
ˆω =
0 −ω3 ω2
ω3 0 −ω1
−ω2 ω1 0
is the matrix corresponding to the cross product operator
◮ Velocity of point P on B
vp = ˙tB + ωB × OBP
where OB is the origin of the local frame of B.
The stack of tasks
14. Introduction
Theoretical foundations
Software
Rigid body B
◮ Velocity represented by (vB, ωB) ∈ R6 where
˙RB = ˆωBRB
and
ˆω =
0 −ω3 ω2
ω3 0 −ω1
−ω2 ω1 0
is the matrix corresponding to the cross product operator
◮ Velocity of point P on B
vp = ˙tB + ωB × OBP
where OB is the origin of the local frame of B.
The stack of tasks
15. Introduction
Theoretical foundations
Software
Rigid body B
◮ Velocity represented by (vB, ωB) ∈ R6 where
˙RB = ˆωBRB
and
ˆω =
0 −ω3 ω2
ω3 0 −ω1
−ω2 ω1 0
is the matrix corresponding to the cross product operator
◮ Velocity of point P on B
vp = ˙tB + ωB × OBP
where OB is the origin of the local frame of B.
The stack of tasks
16. Introduction
Theoretical foundations
Software
Configuration space
◮ Robot: set of rigid-bodies linked by
joints B0, · · · Bm.
◮ Configuration: position in space of each
body.
q = (qwaist , θ1, · · · θn−6) ∈ SE(3) × Rn−6
qwaist = (x, y, z, roll, pitch, yaw)
◮ Position of Bi depends on q:
MBi
(q) ∈ SE(3)
The stack of tasks
17. Introduction
Theoretical foundations
Software
Configuration space
◮ Robot: set of rigid-bodies linked by
joints B0, · · · Bm.
◮ Configuration: position in space of each
body.
q = (qwaist , θ1, · · · θn−6) ∈ SE(3) × Rn−6
qwaist = (x, y, z, roll, pitch, yaw)
◮ Position of Bi depends on q:
MBi
(q) ∈ SE(3)
The stack of tasks
18. Introduction
Theoretical foundations
Software
Configuration space
◮ Robot: set of rigid-bodies linked by
joints B0, · · · Bm.
◮ Configuration: position in space of each
body.
q = (qwaist , θ1, · · · θn−6) ∈ SE(3) × Rn−6
qwaist = (x, y, z, roll, pitch, yaw)
◮ Position of Bi depends on q:
MBi
(q) ∈ SE(3)
The stack of tasks
22. Introduction
Theoretical foundations
Software
Task
◮ Definition: function of the
◮ robot configuration,
◮ time and
◮ possibly external parameters
that should converge to 0:
T ∈ C∞
(C × R, Rm
)
◮ Example: position tracking of an end-effector Bee
◮ M(q) ∈ SE(3) position of the end-effector,
◮ M∗
(t) ∈ SE(3) reference position
T(q, t) =
t(M∗−1(t)M(q))
uθ(R∗−1(t)R(q))
where
◮ t() is the translation part of an homogeneous matrix,
◮ R and R∗
are the rotation part of M and M∗
.
The stack of tasks
23. Introduction
Theoretical foundations
Software
Task
◮ Definition: function of the
◮ robot configuration,
◮ time and
◮ possibly external parameters
that should converge to 0:
T ∈ C∞
(C × R, Rm
)
◮ Example: position tracking of an end-effector Bee
◮ M(q) ∈ SE(3) position of the end-effector,
◮ M∗
(t) ∈ SE(3) reference position
T(q, t) =
t(M∗−1(t)M(q))
uθ(R∗−1(t)R(q))
where
◮ t() is the translation part of an homogeneous matrix,
◮ R and R∗
are the rotation part of M and M∗
.
The stack of tasks
24. Introduction
Theoretical foundations
Software
Task
◮ Definition: function of the
◮ robot configuration,
◮ time and
◮ possibly external parameters
that should converge to 0:
T ∈ C∞
(C × R, Rm
)
◮ Example: position tracking of an end-effector Bee
◮ M(q) ∈ SE(3) position of the end-effector,
◮ M∗
(t) ∈ SE(3) reference position
T(q, t) =
t(M∗−1(t)M(q))
uθ(R∗−1(t)R(q))
where
◮ t() is the translation part of an homogeneous matrix,
◮ R and R∗
are the rotation part of M and M∗
.
The stack of tasks
25. Introduction
Theoretical foundations
Software
Task
◮ Definition: function of the
◮ robot configuration,
◮ time and
◮ possibly external parameters
that should converge to 0:
T ∈ C∞
(C × R, Rm
)
◮ Example: position tracking of an end-effector Bee
◮ M(q) ∈ SE(3) position of the end-effector,
◮ M∗
(t) ∈ SE(3) reference position
T(q, t) =
t(M∗−1(t)M(q))
uθ(R∗−1(t)R(q))
where
◮ t() is the translation part of an homogeneous matrix,
◮ R and R∗
are the rotation part of M and M∗
.
The stack of tasks
26. Introduction
Theoretical foundations
Software
Task
◮ Definition: function of the
◮ robot configuration,
◮ time and
◮ possibly external parameters
that should converge to 0:
T ∈ C∞
(C × R, Rm
)
◮ Example: position tracking of an end-effector Bee
◮ M(q) ∈ SE(3) position of the end-effector,
◮ M∗
(t) ∈ SE(3) reference position
T(q, t) =
t(M∗−1(t)M(q))
uθ(R∗−1(t)R(q))
where
◮ t() is the translation part of an homogeneous matrix,
◮ R and R∗
are the rotation part of M and M∗
.
The stack of tasks
27. Introduction
Theoretical foundations
Software
Hierarchical task based control
Given
◮ a configuration q,
◮ two tasks of decreasing priorities:
◮ T1 ∈ C∞
(C × R, Rm1
),
◮ T2 ∈ C∞
(C × R, Rm2
),
compute a control vector ˙q
◮ that makes T1 converge toward 0 and
◮ that makes T2 converge toward 0 if possible.
The stack of tasks
28. Introduction
Theoretical foundations
Software
Hierarchical task based control
Given
◮ a configuration q,
◮ two tasks of decreasing priorities:
◮ T1 ∈ C∞
(C × R, Rm1
),
◮ T2 ∈ C∞
(C × R, Rm2
),
compute a control vector ˙q
◮ that makes T1 converge toward 0 and
◮ that makes T2 converge toward 0 if possible.
The stack of tasks
29. Introduction
Theoretical foundations
Software
Hierarchical task based control
Jacobian:
◮ we denote
◮ Ji = ∂Ti
∂q for i ∈ {1, 2}
◮ then
◮ ∀q ∈ C, ∀t ∈ R, ∀ ˙q ∈ Rn
, ˙Ti = Ji (q, t) ˙q + ∂Ti
∂t (q, t)
We try to enforce
◮ ˙T1 = −λ1T1 ⇒ T1(t) = e−λ1t T1(0) → 0
◮ ˙T2 = −λ2T2 ⇒ T2(t) = e−λ2t T2(0) → 0
◮ λ1 and λ2 are called the gains associated to T1 and T2.
The stack of tasks
30. Introduction
Theoretical foundations
Software
Hierarchical task based control
Jacobian:
◮ we denote
◮ Ji = ∂Ti
∂q for i ∈ {1, 2}
◮ then
◮ ∀q ∈ C, ∀t ∈ R, ∀ ˙q ∈ Rn
, ˙Ti = Ji (q, t) ˙q + ∂Ti
∂t (q, t)
We try to enforce
◮ ˙T1 = −λ1T1 ⇒ T1(t) = e−λ1t T1(0) → 0
◮ ˙T2 = −λ2T2 ⇒ T2(t) = e−λ2t T2(0) → 0
◮ λ1 and λ2 are called the gains associated to T1 and T2.
The stack of tasks
31. Introduction
Theoretical foundations
Software
Hierarchical task based control
Jacobian:
◮ we denote
◮ Ji = ∂Ti
∂q for i ∈ {1, 2}
◮ then
◮ ∀q ∈ C, ∀t ∈ R, ∀ ˙q ∈ Rn
, ˙Ti = Ji (q, t) ˙q + ∂Ti
∂t (q, t)
We try to enforce
◮ ˙T1 = −λ1T1 ⇒ T1(t) = e−λ1t T1(0) → 0
◮ ˙T2 = −λ2T2 ⇒ T2(t) = e−λ2t T2(0) → 0
◮ λ1 and λ2 are called the gains associated to T1 and T2.
The stack of tasks
32. Introduction
Theoretical foundations
Software
Hierarchical task based control
Jacobian:
◮ we denote
◮ Ji = ∂Ti
∂q for i ∈ {1, 2}
◮ then
◮ ∀q ∈ C, ∀t ∈ R, ∀ ˙q ∈ Rn
, ˙Ti = Ji (q, t) ˙q + ∂Ti
∂t (q, t)
We try to enforce
◮ ˙T1 = −λ1T1 ⇒ T1(t) = e−λ1t T1(0) → 0
◮ ˙T2 = −λ2T2 ⇒ T2(t) = e−λ2t T2(0) → 0
◮ λ1 and λ2 are called the gains associated to T1 and T2.
The stack of tasks
33. Introduction
Theoretical foundations
Software
Hierarchical task based control
Jacobian:
◮ we denote
◮ Ji = ∂Ti
∂q for i ∈ {1, 2}
◮ then
◮ ∀q ∈ C, ∀t ∈ R, ∀ ˙q ∈ Rn
, ˙Ti = Ji (q, t) ˙q + ∂Ti
∂t (q, t)
We try to enforce
◮ ˙T1 = −λ1T1 ⇒ T1(t) = e−λ1t T1(0) → 0
◮ ˙T2 = −λ2T2 ⇒ T2(t) = e−λ2t T2(0) → 0
◮ λ1 and λ2 are called the gains associated to T1 and T2.
The stack of tasks
34. Introduction
Theoretical foundations
Software
Moore Penrose pseudo-inverse
Given a matrix A ∈ Rm×n, the Moore Penrose pseudo inverse
A+ ∈ Rn×m of A is the unique matrix satisfying:
AA+
A = A
A+
AA+
= A+
(AA+
)T
= AA+
(A+
A)T
= A+
A
Given a linear system:
Ax = b, A ∈ Rm×n
, x ∈ Rn
, b ∈ Rm
x = A+b minimizes
◮ Ax − b over Rn,
◮ x over argmin Ax − b .
The stack of tasks
35. Introduction
Theoretical foundations
Software
Moore Penrose pseudo-inverse
Given a matrix A ∈ Rm×n, the Moore Penrose pseudo inverse
A+ ∈ Rn×m of A is the unique matrix satisfying:
AA+
A = A
A+
AA+
= A+
(AA+
)T
= AA+
(A+
A)T
= A+
A
Given a linear system:
Ax = b, A ∈ Rm×n
, x ∈ Rn
, b ∈ Rm
x = A+b minimizes
◮ Ax − b over Rn,
◮ x over argmin Ax − b .
The stack of tasks
36. Introduction
Theoretical foundations
Software
Moore Penrose pseudo-inverse
Given a matrix A ∈ Rm×n, the Moore Penrose pseudo inverse
A+ ∈ Rn×m of A is the unique matrix satisfying:
AA+
A = A
A+
AA+
= A+
(AA+
)T
= AA+
(A+
A)T
= A+
A
Given a linear system:
Ax = b, A ∈ Rm×n
, x ∈ Rn
, b ∈ Rm
x = A+b minimizes
◮ Ax − b over Rn,
◮ x over argmin Ax − b .
The stack of tasks
37. Introduction
Theoretical foundations
Software
Moore Penrose pseudo-inverse
Given a matrix A ∈ Rm×n, the Moore Penrose pseudo inverse
A+ ∈ Rn×m of A is the unique matrix satisfying:
AA+
A = A
A+
AA+
= A+
(AA+
)T
= AA+
(A+
A)T
= A+
A
Given a linear system:
Ax = b, A ∈ Rm×n
, x ∈ Rn
, b ∈ Rm
x = A+b minimizes
◮ Ax − b over Rn,
◮ x over argmin Ax − b .
The stack of tasks
38. Introduction
Theoretical foundations
Software
Hierarchical task based control
Resolution of the first constraint:
˙T1 = J1 ˙q +
∂T1
∂t
= −λ1T1 (1)
J1 ˙q = −λ1T1 −
∂T1
∂t
(2)
˙q1 −J+
1 (λ1T1 +
∂T1
∂t
) (3)
Where J+
1 is the (Moore Penrose) pseudo-inverse of J1.
˙q1 minimizes
◮ J1 ˙q + λ1T1 + ∂T1
∂t = ˙T1 + λ1T1
◮ ˙q over argmin J1 ˙q + λ1T1 + ∂T1
∂t
Hence,
◮ if λ1T1 + ∂T1
∂t is in Im(J1), (1) is satisfied
The stack of tasks
39. Introduction
Theoretical foundations
Software
Hierarchical task based control
Resolution of the first constraint:
˙T1 = J1 ˙q +
∂T1
∂t
= −λ1T1 (1)
J1 ˙q = −λ1T1 −
∂T1
∂t
(2)
˙q1 −J+
1 (λ1T1 +
∂T1
∂t
) (3)
Where J+
1 is the (Moore Penrose) pseudo-inverse of J1.
˙q1 minimizes
◮ J1 ˙q + λ1T1 + ∂T1
∂t = ˙T1 + λ1T1
◮ ˙q over argmin J1 ˙q + λ1T1 + ∂T1
∂t
Hence,
◮ if λ1T1 + ∂T1
∂t is in Im(J1), (1) is satisfied
The stack of tasks
40. Introduction
Theoretical foundations
Software
Hierarchical task based control
Resolution of the first constraint:
˙T1 = J1 ˙q +
∂T1
∂t
= −λ1T1 (1)
J1 ˙q = −λ1T1 −
∂T1
∂t
(2)
˙q1 −J+
1 (λ1T1 +
∂T1
∂t
) (3)
Where J+
1 is the (Moore Penrose) pseudo-inverse of J1.
˙q1 minimizes
◮ J1 ˙q + λ1T1 + ∂T1
∂t = ˙T1 + λ1T1
◮ ˙q over argmin J1 ˙q + λ1T1 + ∂T1
∂t
Hence,
◮ if λ1T1 + ∂T1
∂t is in Im(J1), (1) is satisfied
The stack of tasks
41. Introduction
Theoretical foundations
Software
Hierarchical task based control
Resolution of the first constraint:
˙T1 = J1 ˙q +
∂T1
∂t
= −λ1T1 (1)
J1 ˙q = −λ1T1 −
∂T1
∂t
(2)
˙q1 −J+
1 (λ1T1 +
∂T1
∂t
) (3)
Where J+
1 is the (Moore Penrose) pseudo-inverse of J1.
˙q1 minimizes
◮ J1 ˙q + λ1T1 + ∂T1
∂t = ˙T1 + λ1T1
◮ ˙q over argmin J1 ˙q + λ1T1 + ∂T1
∂t
Hence,
◮ if λ1T1 + ∂T1
∂t is in Im(J1), (1) is satisfied
The stack of tasks
42. Introduction
Theoretical foundations
Software
Hierarchical task based control
Resolution of the first constraint:
˙T1 = J1 ˙q +
∂T1
∂t
= −λ1T1 (1)
J1 ˙q = −λ1T1 −
∂T1
∂t
(2)
˙q1 −J+
1 (λ1T1 +
∂T1
∂t
) (3)
Where J+
1 is the (Moore Penrose) pseudo-inverse of J1.
˙q1 minimizes
◮ J1 ˙q + λ1T1 + ∂T1
∂t = ˙T1 + λ1T1
◮ ˙q over argmin J1 ˙q + λ1T1 + ∂T1
∂t
Hence,
◮ if λ1T1 + ∂T1
∂t is in Im(J1), (1) is satisfied
The stack of tasks
43. Introduction
Theoretical foundations
Software
Hierarchical task based control
In fact
∀u ∈ Rn
, J1 ˙q1+(In − J+
1 J1)u = J1 ˙q1
therefore,
˙q = ˙q1 + (In − J+
1 J1)u
also minimizes J1 ˙q + λ1T1 + ∂T1
∂t .
P1 = (In − J+
1 J1) is a projector on J1 kernel:
J1P1 = 0
∀u ∈ Rn, if ˙q = P1u, then, ˙T1 = ∂T1
∂t .
The stack of tasks
44. Introduction
Theoretical foundations
Software
Hierarchical task based control
In fact
∀u ∈ Rn
, J1 ˙q1+(In − J+
1 J1)u = J1 ˙q1
therefore,
˙q = ˙q1 + (In − J+
1 J1)u
also minimizes J1 ˙q + λ1T1 + ∂T1
∂t .
P1 = (In − J+
1 J1) is a projector on J1 kernel:
J1P1 = 0
∀u ∈ Rn, if ˙q = P1u, then, ˙T1 = ∂T1
∂t .
The stack of tasks
45. Introduction
Theoretical foundations
Software
Hierarchical task based control
In fact
∀u ∈ Rn
, J1 ˙q1+(In − J+
1 J1)u = J1 ˙q1
therefore,
˙q = ˙q1 + (In − J+
1 J1)u
also minimizes J1 ˙q + λ1T1 + ∂T1
∂t .
P1 = (In − J+
1 J1) is a projector on J1 kernel:
J1P1 = 0
∀u ∈ Rn, if ˙q = P1u, then, ˙T1 = ∂T1
∂t .
The stack of tasks
46. Introduction
Theoretical foundations
Software
Hierarchical task based control
In fact
∀u ∈ Rn
, J1 ˙q1+(In − J+
1 J1)u = J1 ˙q1
therefore,
˙q = ˙q1 + (In − J+
1 J1)u
also minimizes J1 ˙q + λ1T1 + ∂T1
∂t .
P1 = (In − J+
1 J1) is a projector on J1 kernel:
J1P1 = 0
∀u ∈ Rn, if ˙q = P1u, then, ˙T1 = ∂T1
∂t .
The stack of tasks
47. Introduction
Theoretical foundations
Software
Controlling the second task
We have
˙q = ˙q1 + P1u
˙T2 = J2 ˙q +
∂T2
∂t
˙T2 = J2 ˙q1 +
∂T2
∂t
+ J2P1u
We want
˙T2 = −λ2T2
Thus
−λ2T2 = J2 ˙q1 +
∂T2
∂t
+ J2P1u
J2P1u = −λ2T2 − J2 ˙q1 −
∂T2
∂t
The stack of tasks
48. Introduction
Theoretical foundations
Software
Controlling the second task
We have
˙q = ˙q1 + P1u
˙T2 = J2 ˙q +
∂T2
∂t
˙T2 = J2 ˙q1 +
∂T2
∂t
+ J2P1u
We want
˙T2 = −λ2T2
Thus
−λ2T2 = J2 ˙q1 +
∂T2
∂t
+ J2P1u
J2P1u = −λ2T2 − J2 ˙q1 −
∂T2
∂t
The stack of tasks
49. Introduction
Theoretical foundations
Software
Controlling the second task
We have
˙q = ˙q1 + P1u
˙T2 = J2 ˙q +
∂T2
∂t
˙T2 = J2 ˙q1 +
∂T2
∂t
+ J2P1u
We want
˙T2 = −λ2T2
Thus
−λ2T2 = J2 ˙q1 +
∂T2
∂t
+ J2P1u
J2P1u = −λ2T2 − J2 ˙q1 −
∂T2
∂t
The stack of tasks
50. Introduction
Theoretical foundations
Software
Controlling the second task
Thus
−λ2T2 = J2 ˙q1 +
∂T2
∂t
+ J2P1u
J2P1u = −λ2T2 − J2 ˙q1 −
∂T2
∂t
u = −(J2P1)+
(λ2T2 + J2 ˙q1 +
∂T2
∂t
)
˙q2 ˙q1 + P1u
= ˙q1 − P1(J2P1)+
(λ2T2 + J2 ˙q1 +
∂T2
∂t
))
minimizes ˙T2 + λ2T2 over ˙q1 + Ker J1.
The stack of tasks
51. Introduction
Theoretical foundations
Software
Controlling the second task
Thus
−λ2T2 = J2 ˙q1 +
∂T2
∂t
+ J2P1u
J2P1u = −λ2T2 − J2 ˙q1 −
∂T2
∂t
u = −(J2P1)+
(λ2T2 + J2 ˙q1 +
∂T2
∂t
)
˙q2 ˙q1 + P1u
= ˙q1 − P1(J2P1)+
(λ2T2 + J2 ˙q1 +
∂T2
∂t
))
minimizes ˙T2 + λ2T2 over ˙q1 + Ker J1.
The stack of tasks
55. Introduction
Theoretical foundations
Software
Libraries
◮ jrl-mathtools: implementation of small size matrices,
◮ to be replaced by Eigen
◮ jrl-mal: abstract layer for matrices,
◮ to be replaced by Eigen
◮ abstract-robot-dynamics: abstraction for humanoid
robot description,
◮ jrl-dynamics: implementation of the above abstract
interfaces,
◮ jrl-walkgen: ZMP based dynamic walk generation.
The stack of tasks
56. Introduction
Theoretical foundations
Software
Libraries
◮ jrl-mathtools: implementation of small size matrices,
◮ to be replaced by Eigen
◮ jrl-mal: abstract layer for matrices,
◮ to be replaced by Eigen
◮ abstract-robot-dynamics: abstraction for humanoid
robot description,
◮ jrl-dynamics: implementation of the above abstract
interfaces,
◮ jrl-walkgen: ZMP based dynamic walk generation.
The stack of tasks
57. Introduction
Theoretical foundations
Software
Libraries
◮ jrl-mathtools: implementation of small size matrices,
◮ to be replaced by Eigen
◮ jrl-mal: abstract layer for matrices,
◮ to be replaced by Eigen
◮ abstract-robot-dynamics: abstraction for humanoid
robot description,
◮ jrl-dynamics: implementation of the above abstract
interfaces,
◮ jrl-walkgen: ZMP based dynamic walk generation.
The stack of tasks
58. Introduction
Theoretical foundations
Software
Libraries
◮ jrl-mathtools: implementation of small size matrices,
◮ to be replaced by Eigen
◮ jrl-mal: abstract layer for matrices,
◮ to be replaced by Eigen
◮ abstract-robot-dynamics: abstraction for humanoid
robot description,
◮ jrl-dynamics: implementation of the above abstract
interfaces,
◮ jrl-walkgen: ZMP based dynamic walk generation.
The stack of tasks
59. Introduction
Theoretical foundations
Software
Libraries
◮ jrl-mathtools: implementation of small size matrices,
◮ to be replaced by Eigen
◮ jrl-mal: abstract layer for matrices,
◮ to be replaced by Eigen
◮ abstract-robot-dynamics: abstraction for humanoid
robot description,
◮ jrl-dynamics: implementation of the above abstract
interfaces,
◮ jrl-walkgen: ZMP based dynamic walk generation.
The stack of tasks
60. Introduction
Theoretical foundations
Software
dynamic-graph
◮ Entity
◮ Signal: synchronous interface
◮ Command: asynchronous interface
◮ Factory
◮ builds a new entity of requested type,
◮ new entity types can be dynamically added (advanced).
◮ Pool
◮ stores all instances of entities,
◮ return reference to entity of given name.
The stack of tasks
61. Introduction
Theoretical foundations
Software
dynamic-graph
◮ Entity
◮ Signal: synchronous interface
◮ Command: asynchronous interface
◮ Factory
◮ builds a new entity of requested type,
◮ new entity types can be dynamically added (advanced).
◮ Pool
◮ stores all instances of entities,
◮ return reference to entity of given name.
The stack of tasks
62. Introduction
Theoretical foundations
Software
dynamic-graph
◮ Entity
◮ Signal: synchronous interface
◮ Command: asynchronous interface
◮ Factory
◮ builds a new entity of requested type,
◮ new entity types can be dynamically added (advanced).
◮ Pool
◮ stores all instances of entities,
◮ return reference to entity of given name.
The stack of tasks
63. Introduction
Theoretical foundations
Software
Signal
Synchronous interface storing a given data type
◮ output signals:
◮ recomputed by a callback function, or
◮ set to constant value
◮ warning: setting to constant value deactivate callback,
◮ input signals:
◮ plugged by an output signal, or
◮ set to constant value,
◮ warning: setting to constant value unplugs,
The stack of tasks
64. Introduction
Theoretical foundations
Software
Signal
Synchronous interface storing a given data type
◮ output signals:
◮ recomputed by a callback function, or
◮ set to constant value
◮ warning: setting to constant value deactivate callback,
◮ input signals:
◮ plugged by an output signal, or
◮ set to constant value,
◮ warning: setting to constant value unplugs,
The stack of tasks
65. Introduction
Theoretical foundations
Software
Signal
Synchronous interface storing a given data type
◮ output signals:
◮ recomputed by a callback function, or
◮ set to constant value
◮ warning: setting to constant value deactivate callback,
◮ input signals:
◮ plugged by an output signal, or
◮ set to constant value,
◮ warning: setting to constant value unplugs,
The stack of tasks
66. Introduction
Theoretical foundations
Software
Signal
Synchronous interface storing a given data type
◮ output signals:
◮ recomputed by a callback function, or
◮ set to constant value
◮ warning: setting to constant value deactivate callback,
◮ input signals:
◮ plugged by an output signal, or
◮ set to constant value,
◮ warning: setting to constant value unplugs,
The stack of tasks
67. Introduction
Theoretical foundations
Software
Signal
Synchronous interface storing a given data type
◮ dependency relation: s1 depends on s2 if s1 callback
needs the value of s2,
◮ each signal s stores time of last recomputation in member
s.t
◮ s is said outdated at time t if
◮ t > s.t , and
◮ one dependency s dep of s
◮ is out-dated or
◮ has been recomputed later than s: s dep.t > s.t .
◮ reading an out-dated signal triggers recomputation.
◮ New types can be dynamically added (advanced)
The stack of tasks
68. Introduction
Theoretical foundations
Software
Signal
Synchronous interface storing a given data type
◮ dependency relation: s1 depends on s2 if s1 callback
needs the value of s2,
◮ each signal s stores time of last recomputation in member
s.t
◮ s is said outdated at time t if
◮ t > s.t , and
◮ one dependency s dep of s
◮ is out-dated or
◮ has been recomputed later than s: s dep.t > s.t .
◮ reading an out-dated signal triggers recomputation.
◮ New types can be dynamically added (advanced)
The stack of tasks
69. Introduction
Theoretical foundations
Software
Signal
Synchronous interface storing a given data type
◮ dependency relation: s1 depends on s2 if s1 callback
needs the value of s2,
◮ each signal s stores time of last recomputation in member
s.t
◮ s is said outdated at time t if
◮ t > s.t , and
◮ one dependency s dep of s
◮ is out-dated or
◮ has been recomputed later than s: s dep.t > s.t .
◮ reading an out-dated signal triggers recomputation.
◮ New types can be dynamically added (advanced)
The stack of tasks
70. Introduction
Theoretical foundations
Software
Signal
Synchronous interface storing a given data type
◮ dependency relation: s1 depends on s2 if s1 callback
needs the value of s2,
◮ each signal s stores time of last recomputation in member
s.t
◮ s is said outdated at time t if
◮ t > s.t , and
◮ one dependency s dep of s
◮ is out-dated or
◮ has been recomputed later than s: s dep.t > s.t .
◮ reading an out-dated signal triggers recomputation.
◮ New types can be dynamically added (advanced)
The stack of tasks
71. Introduction
Theoretical foundations
Software
Signal
Synchronous interface storing a given data type
◮ dependency relation: s1 depends on s2 if s1 callback
needs the value of s2,
◮ each signal s stores time of last recomputation in member
s.t
◮ s is said outdated at time t if
◮ t > s.t , and
◮ one dependency s dep of s
◮ is out-dated or
◮ has been recomputed later than s: s dep.t > s.t .
◮ reading an out-dated signal triggers recomputation.
◮ New types can be dynamically added (advanced)
The stack of tasks
72. Introduction
Theoretical foundations
Software
Signal
Synchronous interface storing a given data type
◮ dependency relation: s1 depends on s2 if s1 callback
needs the value of s2,
◮ each signal s stores time of last recomputation in member
s.t
◮ s is said outdated at time t if
◮ t > s.t , and
◮ one dependency s dep of s
◮ is out-dated or
◮ has been recomputed later than s: s dep.t > s.t .
◮ reading an out-dated signal triggers recomputation.
◮ New types can be dynamically added (advanced)
The stack of tasks
74. Introduction
Theoretical foundations
Software
dynamic-graph-python
Python bindings to dynamic-graph
◮ module dynamic graph linked to
libdynamic-graph.so
◮ class Entity
◮ each C++ entity class declared in the factory generates a
python class of the same name,
◮ signals are instance members,
◮ commands are bound to instance methods
◮ method help lists commands
◮ method displaySignals displays signals
◮ class Signal
◮ property value to set and get signal value
◮ remote interpreter to be embedded into a robot controller
(advanced)
The stack of tasks
75. Introduction
Theoretical foundations
Software
dynamic-graph-python
Python bindings to dynamic-graph
◮ module dynamic graph linked to
libdynamic-graph.so
◮ class Entity
◮ each C++ entity class declared in the factory generates a
python class of the same name,
◮ signals are instance members,
◮ commands are bound to instance methods
◮ method help lists commands
◮ method displaySignals displays signals
◮ class Signal
◮ property value to set and get signal value
◮ remote interpreter to be embedded into a robot controller
(advanced)
The stack of tasks
76. Introduction
Theoretical foundations
Software
dynamic-graph-python
Python bindings to dynamic-graph
◮ module dynamic graph linked to
libdynamic-graph.so
◮ class Entity
◮ each C++ entity class declared in the factory generates a
python class of the same name,
◮ signals are instance members,
◮ commands are bound to instance methods
◮ method help lists commands
◮ method displaySignals displays signals
◮ class Signal
◮ property value to set and get signal value
◮ remote interpreter to be embedded into a robot controller
(advanced)
The stack of tasks
77. Introduction
Theoretical foundations
Software
dynamic-graph-python
Python bindings to dynamic-graph
◮ module dynamic graph linked to
libdynamic-graph.so
◮ class Entity
◮ each C++ entity class declared in the factory generates a
python class of the same name,
◮ signals are instance members,
◮ commands are bound to instance methods
◮ method help lists commands
◮ method displaySignals displays signals
◮ class Signal
◮ property value to set and get signal value
◮ remote interpreter to be embedded into a robot controller
(advanced)
The stack of tasks
78. Introduction
Theoretical foundations
Software
dynamic-graph-python
Python bindings to dynamic-graph
◮ module dynamic graph linked to
libdynamic-graph.so
◮ class Entity
◮ each C++ entity class declared in the factory generates a
python class of the same name,
◮ signals are instance members,
◮ commands are bound to instance methods
◮ method help lists commands
◮ method displaySignals displays signals
◮ class Signal
◮ property value to set and get signal value
◮ remote interpreter to be embedded into a robot controller
(advanced)
The stack of tasks
80. Introduction
Theoretical foundations
Software
dynamic-graph-tutorial
>>> from dynamic graph.tutorial import InvertedPendulum, FeedbackController
>>> a = InvertedPendulum (’IP’)
>>> b = FeedbackController (’K’)
>>> a.displaySignals ()
--- <IP> signal list:
|-- <Sig:InvertedPendulum(IP)::input(double)::force (Type Cst) AUTOPLUGGED
‘-- <Sig:InvertedPendulum(IP)::output(vector)::state (Type Cst)
>>> a.help ()
Classical inverted pendulum dynamic model
List of commands:
-----------------
getCartMass: Get cart mass
getPendulumLength: Get pendulum length
getPendulumMass: Get pendulum mass
incr: Integrate dynamics for time step provided as input
setCartMass: Set cart mass
setPendulumLength: Set pendulum length
setPendulumMass: Set pendulum mass
>>> a.help (’incr’)
incr:
Integrate dynamics for time step provided as input
take one floating point number as input
>>>
The stack of tasks
81. Introduction
Theoretical foundations
Software
dynamic-graph-tutorial
>>> from dynamic graph.tutorial import InvertedPendulum, FeedbackController
>>> a = InvertedPendulum (’IP’)
>>> b = FeedbackController (’K’)
>>> a.displaySignals ()
--- <IP> signal list:
|-- <Sig:InvertedPendulum(IP)::input(double)::force (Type Cst) AUTOPLUGGED
‘-- <Sig:InvertedPendulum(IP)::output(vector)::state (Type Cst)
>>> a.help ()
Classical inverted pendulum dynamic model
List of commands:
-----------------
getCartMass: Get cart mass
getPendulumLength: Get pendulum length
getPendulumMass: Get pendulum mass
incr: Integrate dynamics for time step provided as input
setCartMass: Set cart mass
setPendulumLength: Set pendulum length
setPendulumMass: Set pendulum mass
>>> a.help (’incr’)
incr:
Integrate dynamics for time step provided as input
take one floating point number as input
>>>
The stack of tasks
82. Introduction
Theoretical foundations
Software
dynamic-graph-tutorial
>>> from dynamic graph.tutorial import InvertedPendulum, FeedbackController
>>> a = InvertedPendulum (’IP’)
>>> b = FeedbackController (’K’)
>>> a.displaySignals ()
--- <IP> signal list:
|-- <Sig:InvertedPendulum(IP)::input(double)::force (Type Cst) AUTOPLUGGED
‘-- <Sig:InvertedPendulum(IP)::output(vector)::state (Type Cst)
>>> a.help ()
Classical inverted pendulum dynamic model
List of commands:
-----------------
getCartMass: Get cart mass
getPendulumLength: Get pendulum length
getPendulumMass: Get pendulum mass
incr: Integrate dynamics for time step provided as input
setCartMass: Set cart mass
setPendulumLength: Set pendulum length
setPendulumMass: Set pendulum mass
>>> a.help (’incr’)
incr:
Integrate dynamics for time step provided as input
take one floating point number as input
>>>
The stack of tasks
83. Introduction
Theoretical foundations
Software
dynamic-graph-tutorial
>>> from dynamic graph.tutorial import InvertedPendulum, FeedbackController
>>> a = InvertedPendulum (’IP’)
>>> b = FeedbackController (’K’)
>>> a.displaySignals ()
--- <IP> signal list:
|-- <Sig:InvertedPendulum(IP)::input(double)::force (Type Cst) AUTOPLUGGED
‘-- <Sig:InvertedPendulum(IP)::output(vector)::state (Type Cst)
>>> a.help ()
Classical inverted pendulum dynamic model
List of commands:
-----------------
getCartMass: Get cart mass
getPendulumLength: Get pendulum length
getPendulumMass: Get pendulum mass
incr: Integrate dynamics for time step provided as input
setCartMass: Set cart mass
setPendulumLength: Set pendulum length
setPendulumMass: Set pendulum mass
>>> a.help (’incr’)
incr:
Integrate dynamics for time step provided as input
take one floating point number as input
>>>
The stack of tasks
84. Introduction
Theoretical foundations
Software
dynamic-graph-tutorial
>>> from dynamic graph.tutorial import InvertedPendulum, FeedbackController
>>> a = InvertedPendulum (’IP’)
>>> b = FeedbackController (’K’)
>>> a.displaySignals ()
--- <IP> signal list:
|-- <Sig:InvertedPendulum(IP)::input(double)::force (Type Cst) AUTOPLUGGED
‘-- <Sig:InvertedPendulum(IP)::output(vector)::state (Type Cst)
>>> a.help ()
Classical inverted pendulum dynamic model
List of commands:
-----------------
getCartMass: Get cart mass
getPendulumLength: Get pendulum length
getPendulumMass: Get pendulum mass
incr: Integrate dynamics for time step provided as input
setCartMass: Set cart mass
setPendulumLength: Set pendulum length
setPendulumMass: Set pendulum mass
>>> a.help (’incr’)
incr:
Integrate dynamics for time step provided as input
take one floating point number as input
>>>
The stack of tasks
85. Introduction
Theoretical foundations
Software
dynamic-graph-tutorial
Package provides
◮ C++ code of classes InvertedPendulum and
FeedbackController,
◮ explanation about how to create a new entity type in C++,
◮ information about how to create a command in C++,
◮ information about how to create a python module defining
the bindings in cmake,
◮ python script that runs an example.
The stack of tasks
86. Introduction
Theoretical foundations
Software
dynamic-graph-tutorial
Package provides
◮ C++ code of classes InvertedPendulum and
FeedbackController,
◮ explanation about how to create a new entity type in C++,
◮ information about how to create a command in C++,
◮ information about how to create a python module defining
the bindings in cmake,
◮ python script that runs an example.
The stack of tasks
87. Introduction
Theoretical foundations
Software
dynamic-graph-tutorial
Package provides
◮ C++ code of classes InvertedPendulum and
FeedbackController,
◮ explanation about how to create a new entity type in C++,
◮ information about how to create a command in C++,
◮ information about how to create a python module defining
the bindings in cmake,
◮ python script that runs an example.
The stack of tasks
88. Introduction
Theoretical foundations
Software
dynamic-graph-tutorial
Package provides
◮ C++ code of classes InvertedPendulum and
FeedbackController,
◮ explanation about how to create a new entity type in C++,
◮ information about how to create a command in C++,
◮ information about how to create a python module defining
the bindings in cmake,
◮ python script that runs an example.
The stack of tasks
89. Introduction
Theoretical foundations
Software
dynamic-graph-tutorial
Package provides
◮ C++ code of classes InvertedPendulum and
FeedbackController,
◮ explanation about how to create a new entity type in C++,
◮ information about how to create a command in C++,
◮ information about how to create a python module defining
the bindings in cmake,
◮ python script that runs an example.
The stack of tasks
90. Introduction
Theoretical foundations
Software
sot-core
Class FeatureAbstract
◮ function of the robot and environment states
◮ position of an end-effector,
◮ position of a feature in an image (visual servoing)
◮ with values in a Lie group G (SO(3), SE(3), Rn,...),
◮ with a mapping e from G into Rm such that
e(0G) = 0
The stack of tasks
91. Introduction
Theoretical foundations
Software
sot-core
Class FeatureAbstract
◮ function of the robot and environment states
◮ position of an end-effector,
◮ position of a feature in an image (visual servoing)
◮ with values in a Lie group G (SO(3), SE(3), Rn,...),
◮ with a mapping e from G into Rm such that
e(0G) = 0
The stack of tasks
92. Introduction
Theoretical foundations
Software
sot-core
Class FeatureAbstract
◮ function of the robot and environment states
◮ position of an end-effector,
◮ position of a feature in an image (visual servoing)
◮ with values in a Lie group G (SO(3), SE(3), Rn,...),
◮ with a mapping e from G into Rm such that
e(0G) = 0
The stack of tasks
93. Introduction
Theoretical foundations
Software
sot-core
Class FeatureAbstract
◮ function of the robot and environment states
◮ position of an end-effector,
◮ position of a feature in an image (visual servoing)
◮ with values in a Lie group G (SO(3), SE(3), Rn,...),
◮ with a mapping e from G into Rm such that
e(0G) = 0
The stack of tasks
102. Introduction
Theoretical foundations
Software
Packages specific to robots
sot-hrp2
◮ defines a class Robot that provides
◮ ready to use features for feet, hands, gaze and center of
mass,
◮ ready to use tasks for the same end effectors,
◮ an entity Dynamic,
◮ an entity Device (interface with the robot control system)
sot-hrprtc-hrp2
◮ provide an RTC component to integrate sot-hrp2 into the
robot controller.
The stack of tasks
103. Introduction
Theoretical foundations
Software
Utilities
◮ dynamic graph.writeGraph (filename): writes the
current graph in a file using graphviz dot format.
◮ dynamic graph.sot.core.FeaturePosition wraps
two FeaturePoint6d: a value and a reference,
◮ MetaTask6d:
◮ MetaTaskPosture:
◮ MetaTaskKine6d:
◮ MetaTaskKinePosture:
◮ MetaTaskCom:
The stack of tasks
104. Introduction
Theoretical foundations
Software
Utilities
◮ dynamic graph.writeGraph (filename): writes the
current graph in a file using graphviz dot format.
◮ dynamic graph.sot.core.FeaturePosition wraps
two FeaturePoint6d: a value and a reference,
◮ MetaTask6d:
◮ MetaTaskPosture:
◮ MetaTaskKine6d:
◮ MetaTaskKinePosture:
◮ MetaTaskCom:
The stack of tasks
105. Introduction
Theoretical foundations
Software
Utilities
◮ dynamic graph.writeGraph (filename): writes the
current graph in a file using graphviz dot format.
◮ dynamic graph.sot.core.FeaturePosition wraps
two FeaturePoint6d: a value and a reference,
◮ MetaTask6d:
◮ MetaTaskPosture:
◮ MetaTaskKine6d:
◮ MetaTaskKinePosture:
◮ MetaTaskCom:
The stack of tasks
106. Introduction
Theoretical foundations
Software
Utilities
◮ dynamic graph.writeGraph (filename): writes the
current graph in a file using graphviz dot format.
◮ dynamic graph.sot.core.FeaturePosition wraps
two FeaturePoint6d: a value and a reference,
◮ MetaTask6d:
◮ MetaTaskPosture:
◮ MetaTaskKine6d:
◮ MetaTaskKinePosture:
◮ MetaTaskCom:
The stack of tasks
107. Introduction
Theoretical foundations
Software
Utilities
◮ dynamic graph.writeGraph (filename): writes the
current graph in a file using graphviz dot format.
◮ dynamic graph.sot.core.FeaturePosition wraps
two FeaturePoint6d: a value and a reference,
◮ MetaTask6d:
◮ MetaTaskPosture:
◮ MetaTaskKine6d:
◮ MetaTaskKinePosture:
◮ MetaTaskCom:
The stack of tasks
108. Introduction
Theoretical foundations
Software
Utilities
◮ dynamic graph.writeGraph (filename): writes the
current graph in a file using graphviz dot format.
◮ dynamic graph.sot.core.FeaturePosition wraps
two FeaturePoint6d: a value and a reference,
◮ MetaTask6d:
◮ MetaTaskPosture:
◮ MetaTaskKine6d:
◮ MetaTaskKinePosture:
◮ MetaTaskCom:
The stack of tasks
109. Introduction
Theoretical foundations
Software
Utilities
◮ dynamic graph.writeGraph (filename): writes the
current graph in a file using graphviz dot format.
◮ dynamic graph.sot.core.FeaturePosition wraps
two FeaturePoint6d: a value and a reference,
◮ MetaTask6d:
◮ MetaTaskPosture:
◮ MetaTaskKine6d:
◮ MetaTaskKinePosture:
◮ MetaTaskCom:
The stack of tasks
114. Introduction
Theoretical foundations
Software
Running the stack of tasks into OpenHRP-3.1
You need to install:
◮ ros-electric
◮ OpenHRP-3.1
you will find instructions in https://wiki.laas.fr/robots/HRP/Software
Then follow instructions in sot-hrprtc/README.md:
https://github.com/stack-of-tasks/sot-hrprtc-hrp2
The stack of tasks
115. Introduction
Theoretical foundations
Software
Running the stack of tasks into OpenHRP-3.0.7
Assumptions
◮ OpenHRP 3.0.7 is installed
◮ The Stack of Tasks has been installed thanks to previous
slide with install sot.sh in the directory:
/home/ user / devel / ros unstable
◮ Your /opt/grx3.0/HRP2LAAS/bin/config.sh is well setup.
The golden commands
$>roscore
#Launching HRP2 simulation with OpenHPR
$>roslaunch hrp2 bringup openhrp bridge . launch robot := hrp2 14
mode:= d g w i t h s t a b i l i z e r simulation := true
$>rosrun dynamic graph bridge run command
$>>> . . . # create the solver ( see next s l i d e )
$>rosservice c a l l / start dynamic graph
The stack of tasks
116. Introduction
Theoretical foundations
Software
Running the stack of tasks into OpenHRP-3.0.7
Initialize the application: create tracer and solver
[ INFO ] [ WallTime : 1370854858.786392] waiting for
service . . .
I n t e r a c t i n g with remote server .
>>> from dynamic graph . sot . a p p l i c a t i o n . v e l o c i t y .
precomputed tasks import i n i t i a l i z e
>>> solver = i n i t i a l i z e ( robot )
>>> robot . i n i t i a l i z e T r a c e r ( )
The stack of tasks
117. Introduction
Theoretical foundations
Software
Running the stack of tasks into OpenHRP-3.0.7
Build the graph including the pattern generator
[ INFO ] [ WallTime : 1370854858.786392] waiting for
service . . .
I n t e r a c t i n g with remote server .
>>> from
dynamic graph . sot . pattern generator . walking
import CreateEverythingForPG , walkFewSteps
With meta selector
The stack of tasks
118. Introduction
Theoretical foundations
Software
Running the stack of tasks into OpenHRP-3.0.7
Create the graph
>>> CreateEverythingForPG ( robot , solver )
At t h i s stage
( ’ modelDir : ’ ,
’ ˜ / devel / ros−unstable / i n s t a l l / share / hrp2−14 ’ )
( ’modelName : ’ , ’ HRP2JRLmainsmall . wrl ’ )
( ’ s p e c i f i c i t i e s P a t h : ’ ,
’ HRP2SpecificitiesSmall . xml ’ )
( ’ jointRankPath : ’ , ’ HRP2LinkJointRankSmall . xml ’ )
After Task for Right and Left Feet
The stack of tasks
