SQL Azure provides a relational database as a service on the Windows Azure platform. It aims to be familiar to SQL Server developers by using the same programming model and tools. SQL Azure databases are automatically replicated and scaled to ensure high availability and performance. The initial release will focus on supporting common web and departmental application scenarios. Over time, additional SQL Server capabilities will be added as services on SQL Azure.

1. Introduction to SQL AzureLynn LangitMicrosoft – Developer Evangelisthttp://blogs.msdn.com/SoCalDevGal

2. Windows Azure PlatformCompute:Virtualized compute environment based on Windows ServerStorage: Durable, scalable, & available storageManagement: Automated, model-driven management of the serviceDatabase:Relational processing for structured/unstructured dataService Bus: General purpose application busAccess Control: Rules-driven, claims-based access control

3. Extending SQL Data Platform to CloudReference DataBusiness IntelligenceData SyncReportingSQL Azure DatabaseSymmetric Programming ModelData Hub AggregationInitial ServicesDatabase – Core SQL Server database capabilities Future ServicesData Sync – Enables the sync framework (soon after PDC)Additional SQL Server capabilities available as a service: Business Intelligence and ReportingNew services: Reference Data and Secure Data Hub

4. Microsoft SQL AzureClear Feedback: “I want a database in the Cloud”Familiar SQL Server relational modelUses existing APIs & toolsFriction free provisioning and reduced managementBuilt for the Cloud with availability and scaleAccessible to all from PHP, Ruby, and JavaFocus on combining the best features of SQL Server running at scale with low friction

5. The Evolution of SQL AzureEvolvesBrowserApplicationApplicationApplicationBrowserApplicationApplicationODBC, OLEDB, ADO.Net PHP, Ruby, …REST ClientSQL Client*REST ClientCloudCloudWindows AzureREST (Astoria)Web AppADO.Net + EFREST ClientHTTP+RESTHTTP+RESTHTTPTDSHTTPWindows AzureWeb AppSQL Client*Data CenterData CenterTDS + TSQL ModelREST/SOAP + ACE ModelSQL AzureOLD SDS* Client access enabled using TDS for ODBC, ADO.Net, OLEDB, PHP-SQL, Ruby, …

6. Database ChoicesValue Props:Full h/w control – size/scale100% compatibilityRoll-your-own HA/DR/scaleValue Props:100% of API surface areaRoll-your-own HA/DR/scaleDedicatedOn-premise SQL Server or other s/w on-premise Resource governance @ machine Security @ DB Server/OSValue Props:Auto HA, Fault-ToleranceFriction-free scaleSelf-provisioningHigh compatibilityResourcesHosted Hosted SQL Server or other Resource governance @ VM Security @ DB Server/OSSQL Azure (RDBMS)Virtual DB serverResource governance @ LDB Security @ LDBSharedLow“Friction”/ControlHighSQL Azure V1 targets scenarios that live in the lower left quadrant

7. Scenarios for V1Departmental ApplicationsSimple application built by individual or departmentNeed simple deployment, self-management, IT: “Empowerment and Governance”Web ApplicationsSmall business or startup that uses the cloud as their ITSimple deployment, self-management, scale on demandISVISV hosting software on behalf of customerMulti-tenant support for billing and isolationData Hub (Shortly After V1)Sharing and aggregating of data across tiers and across enterprisesCentralized place for data, high scale, sync with existing data sources

8. V1 Application TopologiesSQL Azure access from outside MS Datacenter (On-premises – ADO.NET)SQL Azure access from within MS Datacenter (Azure compute – ADO.NET)Application/ BrowserApp Code / ToolsADO.NET Data Svcs/REST - EFHTTP/SSOAP/RESTHTTP/SApp Code(ASP.NET)Windows AzureT-SQL (TDS)T-SQL (TDS)SQL Data ServicesSQL Data ServicesMSDatacenterMSDatacenterCode FarCode Near

9. Service Provisioning ModelEach account has zero or more serversAzure wide, provisioned in a common portalBilling instrumentEach server has one or more databasesContains metadata about the databases and usageUnit of authenticationUnit of Geo-locationGenerated DNS based nameEach database has standard SQL objectsUnit of consistencyUnit of multi-tenancyContains Users, Tables, Views, Indices, etc.Most granular unit of billing Account Server Database

10. ArchitectureShared infrastructure at SQL database and belowRequest routing, security and isolationScalable HA technology provides the glueAutomatic replication and failoverProvisioning, metering and billing infrastructureMachine 5Machine 6Machine 4SQL InstanceSQL InstanceSQL InstanceSQL DBSQL DBSQL DBUserDB1UserDB2UserDB3UserDB4UserDB1UserDB2UserDB3UserDB4UserDB1UserDB2UserDB3UserDB4SDS Provisioning (databases, accounts, roles, …, Metering, and BillingScalability and Availability: Fabric, Failover, Replication, and Load balancingScalability and Availability: Fabric, Failover, Replication, and Load balancing

11. SQL AzureDeploymentWeb Portal(API)DB ScriptSQL AzureTDS

12. SQL AzureAccessing databasesWeb Portal(API)Your AppSQL AzureTDSChange Connection String

13. Database ReplicasSingle DatabaseMultiple ReplicasReplica 1Single PrimaryReplica 2DBReplica 3

14. Hardware BoundaryHardware BoundaryShared EnvironmentCDBDAHardware BoundaryHardware BoundaryCCBAABD

15. SQL AzureDatabase Monitoring & RecoveryWeb Portal(API)!Your AppSQL AzureTDS

16. Programming ModelSmall Data SetsUse a single databaseSame model as on premise SQL ServerLarge Data Sets and/or Massive ThroughputPartition data across many databasesUse parallel fan-out queries to fetch the dataApplication code must be partition aware in v1For v1 will publish best practices for scale outPost-v1 we are looking at building an abstraction to hide some of the complexities of partitioning

17. Sharding Databases1 x 10GB database1 Instances10 x 1GB databases10 Instances

18. SQL Tooling & DevelopmentDemo

19. Managing your account

20. Viewing database information

22. Sample screen – requires VS2010

24. Compatibility GoalsSupport common application patternsLogical/policy based administrationPatterns work from SQL Server to SQL AzureMulti-tenancy considerationsThrottling and load balancingLimits on DB size, transaction duration, …V1: Address the needs of the majority of web and departmental application

25. Sample of SQL CompatibilityIn Scope for v1Out of Scope for v1Tables, indexes and viewsStored ProceduresTriggersConstraintsTable variables, session temp tables (#t)…Distributed TransactionsDistributed QueryCLRService BrokerSpatial Physical server or catalog DDL and views

26. Connection ModelUse existing client librariesADO.NET, ODBC, PHPClient libraries pre-installed in Azure rolesSupport for ASP.NET controlsClients connect directly to a databaseCannot hop across DBs (no USE)

27. Logical vs. Physical AdministrationSQL Azure focus on logical administrationSchema creation and managementQuery optimizationSecurity management (Logins, Users, Roles)Service handles physical managementAutomatically replicated with HA “out of box”Transparent failover in case of failureLoad balancing of data to ensure SLADBA role places more focus on logical management

28. DeploymentSupport for basic deployment optionsSQL scripts work (but not attach database)Geo-location of Windows Azure compute and SQL Azure DatabasesSupport for Application and multi-server management modelSupport for application packagesCloud or on-premise is a deployment time choiceVisibility of data across on-premise and the cloudSupport existing and new forms of deployment

29. Security ModelUses regular SQL security modelAuthenticate logins, map to users and rolesAuthorize users and roles to SQL objectsLimited to standard SQL Auth loginsUsername + password Future AD Federation, WLID, etc as alternate authentication protocolsSecurity model is 100% compatible with on-premise SQL

30. PricingWeb Edition1 GB Database$9.99 / monthBandwidth$0.10 /GB inbound$0.15 /GB outboundBusiness Edition10GB Database$99.99 / monthBandwidth$0.10 /GB inbound$0.15 /GB outboundSpecified by MAXSIZE on CREATE DATABASE command or portal (post-CTP1)Can NOT switch betweenen Web and Business EditionsMonthly billing period

31. Platform Readiness (EHA)Exchange Hosted Archive (EHA) is high scale archival serviceRuns on SQL Azure infrastructureIn production prior to SQL Azure v1Rebuilt to address cost and scale issueshttp://www.microsoft.com/casestudies/Case_Study_Detail.aspx?CaseStudyID=4000003098Reduced COGS with increased customerand business benefit:Larger scale (e.g. larger customers ~20TB+ each)

32. More self-managing (e.g. fault-tolerance)

33. Better query performance for fan-out

34. Faster provisioning of new customersSQL AzureOpportunities and FuturesPartitioned databasesGeo-location and geo-redundancyDistributed querySecurity w/AD, WLID, etcSupport for multiple levels of hardware and software isolation

35. Release PlanSQL Azure CTP Commercial Availability (V1)InternalAdoptionSQL Azure Early Adopters SQL Azure Early Adopters CTP – On-board invitation-only early adoptersSQL Azure CTP - Register for an invitation codeCommercial Availability with Windows Azure in 2009Sign up for our CTP: http://msdn.microsoft.com/en-us/sqlserver/dataservices/default.aspxPDCMIX ‘09WWPCWWPCTechEd May 09Jul 09Sep 09Apr 09Jun 09Aug 09Oct 09Mar 09Nov 09

36. Key TakeawaysSQL Azure available – PDC ’09Integrated part of the SQL Data PlatformLeverage you existing SQL Server knowledge and toolsSQL Azure is the data platform of the Windows Azure Platform

37. Want to Know More?Windows Azure Platformhttp://www.azure.com/Windows Azure Platform Training Kithttp://www.microsoft.com/downloads/details.aspx?FamilyID=413E88F8-5966-4A83-B309-53B7B77EDF78&displaylang=enMSDN Development Centerhttp://msdn.microsoft.com/en-us/sqlserver/dataservicesTeam Bloghttp://blogs.msdn.com/ssds
