This document summarizes a study that compared different algorithms for mapping eye gaze data to on-screen objects. Nine algorithms from literature were tested, including ones that expand object size, associate gaze with the nearest object, or accumulate "interest" over time. A new "competing algorithm" was also proposed, which adds interest to the gazed object and subtracts from others. Testing involved presenting words, icons, and dots of varying sizes to participants and recording their eye movements. The algorithms were then evaluated based on correct selection rates and selection times. Results showed that a fractional mapping algorithm performed best but also had the highest incorrect rate, while the new "dynamic competing algorithm" showed the next best results with a high incorrect rate. Object type
