1. Securing SharePoint Apps
Using OAuth
Kashif Imran
kashif_imran@hotmail.com

2. Agenda
• Issues with SharePoint Development/Security In the Past
• SharePoint Apps
• Security Primer
• App Authentication in SharePoint 2013
• OAuth
• OAuth Flow in SharePoint 2013 and Security Tokens
• Managing App Principals
• Questions

3. Issues with SharePoint Security
• Farm Solutions
• Runs within the SharePoint workerprocess (w3wp.exe)
• Access to Server Object Model
• By default runs with current user’s permission
• Developer can use SPSecurity.RunWithElevatedPrivileges that reverts code to Windows
identity of host application pool
• Farm stability issues
• Installation and upgrade (iisreset)
• Upgrade farm to newer version of SharePoint
• Sandboxed Solutions
• SPUCWorkerProcess.exe
• Access to Server Object Model
• Feature activation has full access to content (runs as site administrator)
• Always runs as current user, can not use SPSecurity.RunWithElevatedPrivileges
• Deprecated in SharePoint 2013 in favor of developing apps for SharePoint

4. SharePoint Apps
• A web application that is registered with SharePoint using an app
manifest.
• Customize and extend SharePoint without full-trust access
• Get its own security principal
• Interacts with SharePoint using Client Object Model/REST
• Distributed as app package (.app) to the public marketplace or
corporate app catalog
• Installed at site or tenant scope
• Any Programming language/technology that can communicate with
SharePoint via REST and OAuth

5. Types of SharePoint Apps
• SharePoint-hosted
• App resources stored in child
site known as (app web)
• App can only have client-side code
• Cloud-Hosted
• App resources deployed on remote server
known as remote web
• App can have both client-side and
server-side code
• 2 Types of Cloud-Hosted Apps
• Autohosted (Hosted in Azure)
• Provider-hosted (Deployed by provider)

6. Security Primer
• Authentication (AuthN)
• Authentication establishes an identity
• SP 2010 supports user authentication
• SP 2013 supports user and app authentication
• Authorization (AuthZ)
• Based on ACL
• Ensure current principal has the proper permissions
• SP 2010 supports permission only for users
• SP 2013 supports permission for users and apps
• Security Principal
• An entity that is understood by a security system
• An entity on which you can configure permission for resources
• Examples: User in AD, FBA User, AD Group or FBA Role, SharePoint App

7. Claims-based Identity Model
• Way for applications to acquire the identity information about internal or external users
• Abstracts individual elements of identity and access control into “Notion of claims” and “Concept of issuer or an authority”
• Applications do not need to authenticate users, store user accounts or passwords, etc.
• Original intention behind the claims-based identity model was to enable federation between organization, but claims are not just
for federation
• Claim
• Statement that one subject (user or organization) makes about itself of another subject. E.g.: name, group, ethnicity etc.
• Why call these “claims” and not “attributes”? “Delivery method” => User delivers claims to application instead of application looking these up
in some directory
• Claims are NOT what a user can or can not do, they are what a user is or is not
• Each claim is made by an issuer, and you trust the claim only as much as you trust the issuer
• Issuer, Type, Value => (Google, Email, darwaish@gmail.com)
• Security Token
• Serialized set of claims that is digitally signed by the issuing authority (Claims are unchanged and comes from whoever signed in)
• Successful outcome of sign in
• SAML (Security Assertion Markup Language), SWT (Simple Web Token), JWT (JSON Web Token)

8. Relying Party and STS
• Relying Party (RP)
• An application that relies on claims
• Claims aware application
• Claims-based application
• Security Token Service
• Service component that builds, signs and issues security tokens
• Implicit authN (no token, no party)
• WS-Trust, WS-Fed, SAML
• IP-STS:
• authenticates a client and creates SAML token
• Façade for one or more identity stores
• RP-STS (R-STS: Resource STS, FP-STS: Federation Provider STS)
• Transforms token issues by another STS
• Does not authenticate the client but relies on SAML token provided by IP-STS that it trusts
• Façade for one boundary
• Federation Patterns
• Passive (Web Clients) WS-Trust emulated using GET, POST, redirects and cookies.
• Active: Code to acquire tokens explicitly

9. Windows Identity Foundation (WIF)
• .NET library encapsulating the inner workings of WS-Federation and
WS-Trust
• System.IdentityModel
• System.IdentityModel.Services
• IPrincipal (IsInRole, Identity), IIdentity (AuthenticationType,
IsAuthenicated, Name)
• IClaimsPrincipal = IPrincipal + Identities
• IClaimsIdentity = IIdentity + Claims
• Claims: Property bag, Subject, issuer, originalissuer, claimtype, value,
valuetype

10. SharePoint Claims

11. App Authentication in SharePoint 2013
• App are first class security principals and granted permissions separate
from user permission
• Granted as all or none and No hierarchy of permission
• App authentication is only supported in CSOM and REST API end points
• App authentication is NOT supported in custom web service entry points
• Apps have Full rights against app web, can request permissions for other
webs
• Full Control permission can not be used for OfficeStore apps
• Project Server permissions available if PWA is installed

12. Demo
App Permissions

13. SP Permission Policies
• App + User Policy
• Both user and app require permission on the resource
• App-Only Policy
• Only app needs permissions on resource
• Allow app code to elevate above permission of current user
• Only supported for server-side code in cloud-hosted apps
• AllowAppOnlyPolicy=“true” in AppManifest.xml
• Permission granted during install (all or nothing)
• User Policy
• Not used when app makes a call to SharePoint

14. SP 2013 AuthN Flow for CSOM/REST Endpoint

15. Types of App Authentication in SharePoint
• 3 basic types of app authentication
• Internal authentication
• External authentication using OAuth
• Office 365
• External authentication using S2S
• On-premise

16. Internal Authentication
• Used in Client-side calls from pages in app web or remote web which
use cross domain library
• Incoming calls require a SAML token holding an established user
identity
• Call targets unique domain of app web associated with an app
• SharePoint maps target URL to instance of an app
• App code is not required to create and manage security tokens

17. App Web
• App by default has full permissions to read/write content to app web
• No default permissions on any location in the SharePoint host environment
• App.master provides UI to go back to host web
• Isolated in its own private domain
• https://{ TenancyName}-{14 char App UID}. sharepoint.com/ sites/{ ParentSiteName}/{
AppName}/
• http:// apps-{ UniqueID}. sp2013apps.local/ sites/{ ParentSiteName}/{ AppName}/
• Why Private Domain?
• XSS: JavaScript code can not call back to host web
• JavaScript do not run with the same established user identity as host web
• SharePoint environment sees JavaScript callbacks from appweb with unique URLs and can
authenticate apps
• {StandardTokens}: { HostUrl}, {AppWebUrl}, { Language}
• Use Internal Authentication: App is not required to create/manage security tokens

18. Demo
App Web and Internal Authentication

19. External Authentication
• Calls to SP from server-side code running in remote web
• Used for both OAuth and S2S
• Incoming calls require access token with app identity
• Access token can optionally carry user identity as well
• Call can target any CSOM or REST endpoint in any site
• App code is required to create and manage security tokens

20. Demo
External Authentication

21. OAuth
• Manage app permission on the web
• OAuth.net
• Internet protocol/spec for creating/mapping app identity
• A cross platform, open protocol for authenticating apps
• Internet standard used by Google, Facebook, Twitter
• Authorize requests by an app for SharePoint to access SharePoint resources on behalf of a user
• SP2013 uses OAuth 2.0 (very different from OAuth 1.0)
• OAuth specs provides details on how to create access tokens
• Used for external auth in Office 365
• Delegated authorization codes or access tokens are issues by OAuth STS (Windows Azure Control Services)
• Remote web must communicate with ACS to obtain access tokens
• Access tokens pass to SharePoint host in CSOM or REST API calls
• WS-Federation STS and SAML passive sign-in STS are primarily intended to issue sign-in tokens
• In SP2013, OAuth STS is uses only for issuing context tokens and not used as identity providers

22. OAuth Concepts
• Content Owner(s)
• SharePoint user(s) who can grant permissions to site content
• Content Server
• SharePoint web server that hosts site with the content that is to be accessed
• Client App/ClientID/AppID
• Remote web that needs permissions to access site content
• Authentication Server
• Trusted service that provides apps with access tokens allowing access to
content
• Windows Azure ACS in Sp2013 apps case

23. App Principals
• Tenancy-scoped configuration for app identity
• App principals must be registered with SharePoint and ACS
• App Principal Properties
• Client Id: GUID based identifier for app principal
• Client Secret: Key to encrypt message between app and ACS
• App Host Domain: Base URL of domain hosting remote web
• Redirect URL: URL to a page used to configure security

24. Security Tokens used in OAuth
• Context Token
• Contextual information passed to app
• JWT
• Valid for 12 hours
• Cache key: identify unique user
(user, app, tenant)
• Refresh Token
• Used by client app to acquire an access token
• Valid for 6 months
• Access Token
• Token passed to SharePoint to app
when using external authentication
• Valid for 12 hours

25. OAuth Workflow in Office 365

26. Context Token

27. Access Token

28. Steps to use OAuth in O365
• Create new Cloud-hosted app project
• Register App Principal
• Registration handled automatically in autohosted apps
• Registration requires manual steps in provider hosted apps
• Registration requires extra steps for apps published to Office Store. Have to get client
id/secret from Seller Dashboard
• App principal properties
• Client ID: Guid or app principal
• Clint secret: key used to encrypt message sent between app and ACS
• App host domain: base url which defined hosting domain for remote web
• Redirect URL: URL to a page used to configure on the fly security
• Add code in remote web to manage tokens
• Code required to retrieve access tokens from ACS
• Explicit code required to add access token to csom and rest api calls

29. Demo
OAuth Tokens and App Principal

30. Managing App Principals in O365
• /_layouts/15/…
• AppRegNew.aspx
• AppInv.aspx
• AppPrincipals.aspx
• PowerShell for SPOnline to administer SharePoint apps and app
principals

31. Questions
• ???
