This document discusses ozone as an emerging technology for cleaning, disinfecting, and sanitizing process equipment without dismantling. It outlines the advantages of ozone cleaning-in-place (CIP) such as faster reaction time, no hazardous chemicals, savings in time, water and energy use, and environmental friendliness. Performance metrics and estimated savings from ozone CIP are provided. The document also includes diagrams of an integrated ozone system and lists available ozone generator models for various applications including raw water treatment, CIP, air disinfection, and waste water treatment.

1. …............................................................................................
Ozone – An Emerging Technology

2. 2
Index
No Description Page
1. Objective . . . . . . . . . . . . . . . . . . . . . . . . . . . 03
2. Advantages Of Ozone C I P . . . . . . . . . . . . . . . . . . . . 04
3. Performance . . . . . . . . . . . . . . . . . . . . . . . . . . 05
4. Savings with Ozone C I P . . . . . . . . . . . . . . . . . . . . 06
5. Integrated Ozone System [IOS] - Line Diagram . . . . . . . . . . . . 07
6. Integrated Ozone System [IOS] . . . . . . . . . . . . . . . . . . 08
7. Model Range – Air | Raw Water | C I P | Waste Water . . . . . . . . . . 09

3. OBJECTIVE -
CIP
To Clean, Disinfect & Sanitize Process equipment,
pipes, vessels, tanks, reactors, etc. internally
without dismantling them.
3
OBJECTIVE –
Ozone CIP
To Clean, Disinfect & Sanitize Process equipment
- Fast | effectively | reliably
- With no hazardous chemical byproduct
- Saving in time, energy, consumables
- No excess residual
- Environmental friendly.

4. Advantages
 Ozone has highest oxidation potential & works much faster
 Zero Chlorine & similar hazardous chemical for sanitation
 Online Instant monitoring of sanitation power
 Negligible hazardous Disinfectant By-Products [DBPs]
 No need to rinse excess ozone residual
 Produced on site, no need to order, transport, store &
handling
4
 Great saving in time, energy, chemical, water & waste water
 Ozone CIP is highly effective, reliable & consistent.
 FDA & USDA recognized & approved as GRAS for direct
contact
 Wider bacterial spectrum coverage for complete disinfection
 Easy to upgrade for Ozone CIP & simple integrating /
retrofitting

5. Performance
 Guaranteed
 Online Monitoring
 Fast
 Reliable
 Without By-product
 Zero Residual
 Economical
 Environmental Friendly
5

6. 30 – 40 minute - Saving in Time
40 – 50 % - Saving in Water
40 – 50 % - Saving in Waste Water
100 % - Saving in Disinfectant
30 – 70 % - Saving in energy
Savings

7. Integrated Ozone
System [IOS]

8. Integrated Ozone
System [IOS]

9. Models
Raw Water
Disinfection
Clean In Place
[CIP]
 IOS/PH – 02
 IOS/PH – 05
 IOS/PH – 10
 IOS/PH – 15
 IOS/PH – 30
 IOS/PH – 60
 IOS/PH – 70
 IOS/PH – 85
 IOS/PH - 100
 IOS/CIP – 02
 IOS/CIP – 05
 IOS/CIP – 10
 IOS/CIP – 15
 IOS/CIP – 30
 IOS/CIP – 60
 IOS/CIP – 70
 IOS/CIP – 85
 IOS/CIP - 100
Air
Disinfection
Waste
Water
 IOS/WW – 5
 IOS/WW – 10
 IOS/WW – 15
 IOS/WW – 25
 IOS/WW– 40
 IOS/WW – 60
 IOS/WW – 70
 IOS/WW – 85
 IOS/WW - 100
 PAO/LC – 250
 PAO/LC – 500
 PAO/LC – 10OO
 OG/LC – 2
 OG/LC - 5
 OG/LC - 10
 OG/LC - 15
 OG/LC - 25
 OG/LC - 40

10. Solution Engineer : Mr. Sunil Shah
Contact : +91-93212 34527
Mail ID : sunilshah@chemtronicsindia.com
URL : www.chemtronicsindia.com
www.ozonegeneratorindia.com
Thank You
