1. Operator Precedence Parsing

2. Bottom-up Parsing
In general the bottom-up parsing is also
known as shift-reduce parsing.
Types of bottom-up parsing:
1. Operator-Precedence parsing
2. LR parsing

3. Operator Precedence Parser
An operator precedence parser is a bottom-up
parser that interprets an operator grammar. This
parser is only used operator grammars. Ambiguous
grammars are not allowed in any parser except
operator precedence parser.
Operator precedence grammar is kinds of shift
reduce parsing method. It is applied to a small class
of operator grammars.

4. Operator Precedence Grammar
A grammar is said to be operator precedence
grammar if it has two properties:
No R.H.S. of any production has a ∈.
No two non-terminals are adjacent.
Operator precedence can only established between
the terminals of the grammar. It ignores the non-
terminal.

5. Operator Precedence Grammar
Example-1
E→AB E→EOE E→E+E |
A→a E→id E*E |
B→b O→+|*|/ E/E | id
not operator
grammar
not operator
grammar
operator
grammar

6. Operator Precedence Grammar
Example-2
S→SAS/a S→SbSbS/a/SbS
A→bSb/b
Replace non terminal A and
convert it into operator
grammar
not operator
grammar operator grammar

7. Operator Precedence Relations:
There are the three operator precedence
relations:-
a ⋗ b means that terminal "a" has the higher
precedence than terminal "b".
a ⋖ b means that terminal "a" has the lower
precedence than terminal "b".
a ≐ b means that the terminal "a" and "b" both
have same precedence.

8. Operator Precedence parsing Rule:
How to assign these relation ???
Rule-01:
If precedence of a is higher than precedence of b, a>b
If precedence of b is same as precedence of a, a = b
If precedence of a is lower than precedence of b, a <b
Rule-02:
An identifier(id) is always given the higher precedence than
any other symbol.
$ symbol is always given the lowest precedence.
Rule-03:
If two operators have the same precedence, then we consider
the rule of associativity.

9. Building the operator precedence parsing
table:
Example:-consider the following grammar
E-> E+E | E*E | id
For this grammar the precedence table looks
something like this:
The table size is n*n where n is the number of
terminal symbols in the grammar
c
id + * $
id - .> .> .>
+ <. .> <. .>
* <. .> .> .>
$ <. <. <.
acc

10. Operator-Precedence Parsing Algorithm
The input string is w$, the initial stack is $ and a table holds precedence
relations between certain terminals
Algorithm:
set p to point to the first symbol of w$ ;
repeat forever
if ( $ is on top of the stack and p points to $ ) then
return
else {
let a be the topmost terminal symbol on the stack and let b be the symbol pointed to
by p;
/* SHIFT */if ( a <. b or a =· b ) then {
push b onto the stack;
advance p to the next input symbol;
}
else if ( a .> b ) then /* REDUCE */
repeat pop stack
until ( the top of stack terminal is related by <. to the terminal most recently
popped );
else error();
}

11. Operator-Precedence Parsing –Example
Problem-01: Consider the following grammar-
E → EAE | id
A → + | x
Construct the operator precedence parser and parse the string id + id
x id.
Solution-
 We convert the given grammar into operator precedence grammar.
The equivalent operator precedence grammar is-
E → E + E | E x E | id
The terminal symbols in the grammar are
{ id, + , x , $ }
We construct the operator precedence
table as-
c
id + * $
id - .> .> .>
+ <. .> <. .>
* <. .> .> .>
$ <. <. <.
acc

12. Operator-Precedence Parsing Algorithm --
Example
Given Grammar
E → E + E | E x E | id
c
id + * $
id - .> .> .>
+ <. .> <. .>
* <. .> .> .>
$ <. <. <.
acc
stack
$
input
id+id*id$
action
$ <. id shift
$id +id*id$ id .> + reduce E  id
$ +id*id$ shift
$+ id*id$ shift
$+id *id$ id .> * reduce E  id
$+ *id$ shift
$+* id$ shift
$+*id
$+*
$
$
id .> $ reduce E  id
* .> $ reduce E  E*E
$+ $ + .> $ reduce E  E+E
$ $ accept
parse the string id + id x id$

13. Advantages and Disadvantages
Advantages:
– It is simple to implement operator precedence parsing.
– powerful enough for expressions in programming
languages
Disadvantages:
– It cannot handle the unary minus .
– It is applicable only to a small class of grammars.

14. Precedence Functions
The storage space however can be efficiently managed if
we can build an efficient data structure to represent
adequately the precedence relationships between the
terminals.
For this we can construct two functions f and g where the
following hold:
1. If a. >b then f(a)>g(b)
2. If a< . b then f(a)<g(b)
3. If a. =b then f(a)=g(b)

15. Constructing Precedence Functions
To construct these functions we create a directed graph
with nodes fi and gi where i is the ith terminal, obeying the
following rules:
 If a. =b then fa and fb are merged, and ga and gb are
merged
 If a. >b then a directed edge is introduced from fa to gb
 If a< . b then a directed edge is introduced to fa from gb
Following these rules, the precedence graph for the above
mentioned precedence table looks something like this:
Example: consider the following table c
id + * $
id - .> .> .>
+ <. .> <. .>
* <. .> .> .>
$ <. <. <.
acc

16. Constructing Precedence Functions
Using the algorithm leads to the following graph:
c
id + * $
id - .> .> .>
+ <. .> <. .>
* <. .> .> .>
$ <. <. <.
acc
f*
f$
fid
f+
gid
g+
g*
g$

17. Constructing Precedence Functions
From which we extract the following precedence functions:
