OpenSlava Infrastructure Automation Patterns
The document discusses the Accenture Cloud Platform and its various components, including cloud infrastructure, service discovery, and orchestration. It highlights the use of Chef for configuration management and automation in managing cloud resources. Additionally, it addresses challenges in cloud computing and best practices for cookbook development.
More Related Content
Similar to OpenSlava Infrastructure Automation Patterns
OpenSlava Infrastructure Automation Patterns
- 1. Antons Kranga DevOps:Cloud Automation October11, 2013 Organizers Top Media Partner Media Partner Supporter
- 2. Presenter - Technology Architectat Accenture - 10+ years experience in Enterprise Development - Projects: - Accenture Foundation Platform for Java - Accenture Cloud Platform - ALPJ - Monsoon
- 3.
- 4. Cloud Copyright © 2013Accenture All rights reserved.
- 5.
- 6. Definition of CloudComputing Copyright © 2013 Accenture All rights reserved.
- 7. Cloud Computing Copyright ©2013 Accenture All rights reserved.
- 8. Accenture Cloud Platform Testingas Service Monsoon ALPJ etc Cloud Broker API Copyright © 2013 Accenture All rights reserved.
- 9. Challenges of Cloud(What IaaS Offers) Web Tier Application Tier Database Copyright © 2012 Accenture All rights reserved.
- 10. Challenges of Cloud(What Users Want) Web Tier Application Tier Database Copyright © 2012 Accenture All rights reserved.
- 11.
- 12.
- 13. OS Type: RedHat OSVersion: 6.2 Tomcat Home: /etc/tomcat Tomcat Port: 8080 MySQL IP: 10.10.0.1 MySQL Root Password: password include_recipe “java“ package "tomcat6“ artifact_deploy "tomcat6“ do version "latest“ artifact_location "foo.war" deploy_to node[:tomcat][:work_dir] end service "tomcat6" do action [:enable, :start] end Attributes Recipe OS Specific Instructions
- 14. Chef Workstation Copyright ©2012 Accenture All rights reserved. Virtualized Infrastructure
- 15. Virtualized Infrastructure Chef Workstation ChefServer REST CMDB Cookbooks Roles ... Copyright © 2012 Accenture All rights reserved.
- 16. Virtualized Infrastructure Chef Workstation ChefServer REST CMDB Cookbooks Roles ... Copyright © 2012 Accenture All rights reserved.
- 17. Virtualized Infrastructure Chef Workstation knife UsesSSH to bootstraps Chef client Chef Server REST CMDB Cookbooks Roles ... Copyright © 2012 Accenture All rights reserved.
- 18. Virtualized Infrastructure Chef Workstation knife ChefServer e ch t en li fc at6 c tom REST CMDB Cookbooks Roles ... Copyright © 2012 Accenture All rights reserved.
- 19. Virtualized Infrastructure Chef Workstation knife ChefServer e ch t en li fc at6 c tom REST HTTP call signed with certificate CMDB Cookbooks Roles ...
- 20. Virtualized Infrastructure Chef Workstation knife ChefServer e ch t en li fc at6 c tom REST CMDB Cookbooks Roles ...
- 21. Virtualized Infrastructure Chef Workstation knife ChefServer e ch t en li fc at6 c tom REST CMDB Cookbooks t6 ca m a to jav les ab pt i Cookbooks Roles ... Copyright © 2012 Accenture All rights reserved.
- 22. Virtualized Infrastructure Chef Workstation knife ohai acts oadf upl Chef Server e ch t en li fc at6 c tom REST CMDB Cookbooks t6 ca m a to jav les ab pt i Cookbooks Roles ... Copyright © 2012 Accenture All rights reserved.
- 23.
- 24. Node 1 Node 2 Node3 Node N
- 25. Node 1 Node 2 Register Node3 Register Register Database Node N Register
- 26. Node 1 Node 2 Register Node3 Register Register Discover nodes Database Node N Register
- 27. Node 1 Node 2 Register Node3 Register Register Discover nodes Database Node N Register
- 28.
- 29. LB Node 1 Node 2 Node3 Node N
- 30. Single point of failure LB Node1 Node 2 Node 3 Node N
- 31. LB Node 1 Node 2 Heartbeat Node3 LB2 Node N
- 32. Shared virtual IP LB Node1 Node 2 Heartbeat Node 3 LB2 Node N
- 33. Dealing with stickysessions
- 34. Shared virtual IP LB Tomcat1 Tomcat 2 Heartbeat Tomcat 3 LB2 Tomcat N
- 35. Shared virtual IP LB Tomcat1 Tomcat 2 Heartbeat Tomcat 3 LB2 Tomcat N Save session Save session Save session Save session Memcached 1 Memcached 2 Memcached 3 Memcached N Same Server Same Server Same Server Same Server
- 36. Shared virtual IP LB Tomcat1 Save session Tomcat 2 Save session Heartbeat Tomcat 3 Save session LB2 Tomcat N Save session Memcached 1 Repl Memcached 2 Repl Memcached 3 Repl Memcached N Same Server Same Server Same Server Same Server
- 37. Shared virtual IP Ifsession repl not hitting netw capacity Tomcat 1 Save session LB Tomcat 2 Save session Heartbeat Tomcat 3 Save session LB2 Tomcat N Save session Memcached 1 Repl Memcached 2 Repl Memcached 3 Repl Memcached N Same Server Same Server Same Server Same Server
- 38. Shared virtual IP LB Tomcat1 Tomcat 2 Heartbeat Tomcat 3 save session Memcached Large RAM VM LB2 Tomcat N
- 39.
- 40. Shared virtual IP LB Tomcat1 Save session Tomcat 2 Save session Heartbeat Tomcat 3 Save session LB2 Tomcat N Save session Memcached 1 Repl Memcached 2 Repl Memcached 3 Repl Memcached N Same Server Same Server Same Server Same Server
- 41. Shared virtual IP LB Tomcat1 Save session Tomcat 2 Save session Heartbeat Tomcat 3 Save session LB2 Tomcat N Save session Memcached 1 Repl Memcached 2 Repl Memcached 3 Repl Memcached N Same Server Same Server Same Server Auto scaling group Same Server
- 42. Dealing with stickysessions
- 43. Node 1 Node 2 Register Node3 Register Register Discover nodes Database Node N Register
- 44. Node 1 Node 2 Node3 Node N publish facts publish facts publish facts publish facts Message Broker
- 45. Node 1 publish facts subscribeevents Node 2 publish facts subscribe events Node 3 publish facts subscribe events Message Broker Node N publish facts subscribe events
- 46. Node 1 publish facts subscribeevents Node 2 publish facts subscribe events heartbeat heartbeat Node 3 publish facts subscribe events heartbeat heartbeat Message Broker Node N publish facts subscribe events
- 47. Virtualized Infrastructure Chef Server InfraManagement: 1. Provisioning 2. Service Discovery CMDB Message Broker
- 48. Operating Scenarios: Operations VirtualizedInfrastructure Chef Server Infra Management: 1. Provisioning 2. Patching CMDB Server Orchestration: 1. Cluster Orchestration 2. Scalability 3. Deployment Orchestration mCollective Multi zone example
- 49.
- 50. Node 1 Node 2 Node3 Auto scaling group Node N
- 51. Node 1 Node 2 Node3 Auto scaling group Cloud storage Node N
- 52. Node 1 Node 2 Node3 Log agent Log agent Log agent Auto scaling group Log collector Cloud storage Node N Log agent
- 53.
- 54. Node 1 Node 2 Node3 Node N
- 55. Want to apply change/patch Node1 Node 2 Node 3 Node N
- 56. Node 1 Node 2 Node3 Node N Node M
- 57. All changes included Node 1 Node2 Node 3 Migrate data Node N Node M
- 58. Node 1 Node 2 Node3 Shared data Cloud storage Node N Node M
- 59.
- 60.
- 61. Virtualized Infrastructure Chef Server ChaosMonkey CMDB
- 62.
- 63.
- 64. community cookbook wrapper cookbook wrapper cookbookadds new functionality to community version of the cookbook instead of changing it directly
- 65. include_recipe “tomcat“ community cookbook wrapper cookbook chef_gem"chef-rewind“ rewind "template[catalina.xml]“ do # add your custom staff end
- 66. Cookbook Quality • Food Critic:Cookbook style analysis tool • URL: http://acrmp.github.com/foodcritic/ • Integration: Travis CI • Cookbook Style Guide: https://github.com/ampledata/cookbook-style-guide Copyright © 2012 Accenture All rights reserved.
- 67. Takeaways - Accenture CloudPlatform - Monsoon - Accenture Lightweight Platform for Java - Accenture Foundation Platform for Java - Opscode Chef
