My presentation from Atlanta Linux Fest on how to allow users secure access to your network using open source technologies. Examples include how to add two-factor authentication to Apache, OpenVPN, Astaro, NX etc.
![Securing Network Access with Open Source Solutions Nick Owen 9/19/09 @wikidsystems [email_address]](https://image.slidesharecdn.com/securingnetworkaccesswithoss-090922080257-phpapp02/85/Securing-Network-Access-with-Open-Source-solutions-1-320.jpg)
Recommended
More Related Content
What's hot
What's hot (20)
Viewers also liked
Viewers also liked (14)
Similar to Securing Network Access with Open Source solutions
Similar to Securing Network Access with Open Source solutions (20)
Recently uploaded
Recently uploaded (20)
Securing Network Access with Open Source solutions
- 1. Securing Network Access with Open Source Solutions Nick Owen 9/19/09 @wikidsystems [email_address]
- 4. Our Goal: Securely allow access to the network with simplicity and flexibility.
- 9. Who or what is connecting? Evil Princess Duck Bot Sweet Chicky Chirpalot
- 22. Configure Radius on Astaro
- 23. Enable Radius
- 24. Point it to the OTP or Radius server
- 25. Associate the Group with a VPN
- 26. Create A WiKID Domain
- 27. Create a Radius Network Client
- 29. Done!
- 30. For the End-User
- 31. Select Domain & Enter PIN
- 32. Enter OTP & Connect
- 35. Apache Radius Example Install mod-auth-radius $ sudo apt-get install libapache-mod-auth-radius In your httpd.conf add: AddRadiusAuth radius_server:1812 shared_secret 5 AddRadiusCookieValid 60 Remember Radius is port 1812 *UDP*
- 36. Apache Radius Example con't Enter this into your apache2.conf: <location> Options Indexes FollowSymlinks AuthType Basic AuthName "WiKID RADIUS authentication" AuthBasicAuthoritative Off AuthBasicProvider radius AuthRadiusAuthoritative on AuthRadiusActive On Require valid-user </location> Restart Apache!
- 42. Pretty Lame Diagram VPN, SSH, HTTPS Gateway Desktop, Mail, Web Auth/Radius Server RADIUS, LDAP, etc SSH, RDP, VNC, HTTPS
- 46. Any questions? [email_address] @wikidsystems
