Network Virtualization with MidoNet in CloudStack

•Download as PPTX, PDF•

1 like•1,159 views

Network Virtualization with MidoNet in CloudStack Presented at CloudStack Collaboration Conference, June 2013 in Santa Clara, by Yoshi Tamura and Dave Cahill

Technology Economy & Finance

Network Virtualization with
MidoNet in CloudStack
YOSHI TAMURA
Midokura
Jun 23, 2013

Copyright ©2012 Midokura All rights reserved
Hello CloudStack community!
2
YOSHI TAMURA
Product Manager, Midokura

Copyright ©2012 Midokura All rights reserved
Agenda
3
 Midokura’s focus
 Challenges in IaaS Cloud Network
 Introduction to MidoNet
 MidoNet and CloudStack (Dave Cahill)

Copyright ©2012 Midokura All rights reserved
IaaS Cloud – Elasticity and Automation
4
Photo Credit: skarpi - www.skarpi.is via Compfight cc

Copyright ©2012 Midokura All rights reserved
Midokura’s Focus
5
Photo Credit: dampoint via Compfight cc

Copyright ©2012 Midokura All rights reserved
Let’s build a network for IaaS Cloud !
6
Flat L2 network!
It’s simple!

7
Photo Credit: Studio Toveraap via Compfight cc

Copyright ©2012 Midokura All rights reserved
Let’s build a network for IaaS Cloud !
8
How about
VLAN then!?

9
Photo Credit: CHRISTOPHER MACSURAK via Compfight cc

Copyright ©2012 Midokura All rights reserved 10
Actually, we
want L3 too…
Firewall and
Load Balancer
please!
Let’s build a network for IaaS Cloud !

11
Photo Credit: CHRISTOPHER MACSURAK via Compfight ccPhoto Credit: JBurkunkvia Compfight cc

Copyright ©2012 Midokura All rights reserved
Tenant/Project A
Network A1
VM1 VM3
Network A2
VM5
Tenant/Project B
Network B1
VM2 VM4
uplink
Provider Virtual
Router (L3)
Tenant A
Virtual Router
Tenant B
Virtual Router
VM6
Virtual L2
Switch B1
Virtual L2
Switch A1
Virtual L2
Switch A2
TenantB ofﬁce
Tenant B
VPN Router
Ofﬁce
Network
Requirements for IaaS Cloud Network
12

Copyright ©2012 Midokura All rights reserved 14Photo Credit: milos milosevic via Compfight cc

Copyright ©2012 Midokura All rights reserved
VLAN
15
 4096 limit on number of unique tags
 Large spanning trees terminating on many hosts
 High churn in switch control planes due to MAC learning
 Need MLAG for L2 multi-path (vendor specific)
VLAN1
VLAN2

Copyright ©2012 Midokura All rights reserved 16
 Mostly used by Carriers/Telco but too much for IaaS
 Network gear could be very expensive
MPLS VPN
tag
tag

Copyright ©2012 Midokura All rights reserved 17
 Not scalable to cloud scale
 Expensive hardware
 Not fault tolerant (HSRP?)
 L2 and L3 isolation. What about NAT, LB, FW?
c.f.：http://infrastructureadventures.com/tag/vrf-lite/
Core
VLAN 10
VLAN11
VLAN12
Product
VLAN 20
VLAN21
VLAN22
Sales
VLAN 99
VRF VRF VRF
VRF

Copyright ©2012 Midokura All rights reserved 19
VM
VM
Edge
EdgeEdge
Edge Edge
Edge
Virtual network
changes don't affect
underlay state
Use scalable IGP to build multi-path
underlay with cheap HW
IP encapsulation
provides isolation
without using VLAN
Decoupled from
physical network.
Wired once
Edge-to-Edge Overlays

Overlays are the best approach!
But not sufficient...
We still need a scalable control plane.
20

Copyright ©2012 Midokura All rights reserved 21
VM
VM
DB
DB
DB
Internet
EdgeMN EdgeMN
EdgeMN
Edge
MN
Edge
MN
Edge
MN
Our solution ➡ MidoNet
Stores
Virtual NW
configs
Transmits the
packets through
the tunnel
Emulates the
whole NW
topology at ingress
