This document provides a configuration example for NAT failover between two ISP links on a Cisco router. The configuration defines two outside interfaces connected to each ISP, assigns inside and outside NAT roles, creates an IP SLA to ping the primary ISP router, defines route maps to match traffic to each ISP, creates NAT rules to translate traffic to each ISP, tracks the primary ISP reachability, and establishes a default route to the primary ISP tracked by the IP SLA and a secondary static default route to the secondary ISP.

1. NATFailoverwithDual ISP onCisco RouterconfigurationExplained withExample
I am explaininghere howtoconfigure NATwhenthere are multipleISP'sforinternetconnectivity
and we wantproperFailoveri.e whenPrimaryISPgoesdown thenSecondary ISP linktakesover.
Configuration:- Belowisthe configurationsneedtobe done at CustomerEndRouter
interfaceFastEthernet0/0 //This interfaceis connected totheISP 1
ip address 2.2.2.2 255.0.0.0 //Enter Your IP address providedby ISP 1
ip nat outside // Interfaceis usedfor NATOutside
ip virtual-reassembly
duplex half
!
interfaceFastEthernet1/0 //This interfaceis connected tothe ISP 2
ip address 3.3.3.2 255.0.0.0 //Enter Your IP address providedby ISP 1
ip nat outside // Interfaceis usedfor NATOutside
ip virtual-reassembly
duplex auto
speed auto
!
interfaceFastEthernet1/1 // Interface connected toyourLAN
ip address 172.16.0.1255.255.0.0 //LAN IP Address
ip nat inside //NAT insidedonehere
ip virtual-reassembly
duplex auto
speedauto

2. ip sla 1 //IPSLA commandwhere 1 is the SLA number
icmp-echo 4.4.4.2 source-ip2.2.2.2 //4.4.4.2 is the destination/remote router interface to be pinged and 2.2.2.2 is the source IP address
interface from we ping the remote server or interface
frequency50
timeout 50
ip sla schedule 1 life forever start-time now //SLA start immediate andforever
access-list 101 permit ipanyany //Create Accesslist ownthis is a examplethat allowall host
route-mapisp1 permit 10 // Create Router Mapto ISp1
match ipaddress 101 //match The access list 101, which network/host,range ofnetwork is allowed
match interface FastEthernet0/0 // Match the interface
route-mapisp2 permit 10 // Create the router Mapto ISP2
match ip address 101 //match The accesslist 101, whichnetwork /host,range of networkis allowed
match interface FastEthernet1/0 //Match Interface connected to ISP2
Crate the NAT rule
ip nat inside source route-map isp1 interface FastEthernet0/0 overload
ip nat inside source route-map isp2 interface FastEthernet1/0 overload
track 1 rtr 1 reachability //Create track to Trackkthe IPSLA 1 we have created
Now you need to ceate the default router
ip route 0.0.0.0 0.0.0.0 2.2.2.1 track 1 //Default route Pointingtowards ISP1 withtrack1
ip route 0.0.0.0 0.0.0.0 3.3.3.1 10 // Default router withPointing towards ISP2 with Administrative distance AD 10
