1. @h_ingo
Analytics with MongoDB
alone and with Hadoop Connector
Henrik Ingo
Solution Architect, MongoDB

2. The Science in Data Science
• Collect data
• Explore the data, use visualization
• Use math
• Make predictions
• Test predictions
– Collect even more data
• Repeat...

3. Why MongoDB?
When MongoDB?

4. 5 NoSQL categories
Redis
Cassandra
Key Value
Graph
Neo4j
Wide Column
Document
Map Reduce
Hadoop

5. MongoDB and Enterprise IT Stack
CRM, ERP, Collaboration, Mobile, BI
Data Management
Online Data
Offline Data
RDBMS
RDBMS
Hadoop
EDW
Infrastructure
OS & Virtualization, Compute, Storage, Network
Security & Auditing
Management & Monitoring
Applications

6. How do we do it with MongoDB?

7. Collect data

8. Exponential Data Growth
http://www.worldwidewebsize.com/

9. Volume Velocity Variety

10. Volume Velocity Variety
Upserts avoid
unnecessary reads
Asynchronous writes
Data
Data
Sources
Data
Sources
Data
Sources
Sources
Spread writes over
multiple shards
Writes buffered in RAM
and flushed to disk in
bulk

11. Volume Velocity Variety
MongoDB
RDBMS
{
_id : ObjectId("4c4ba5e5e8aabf3"),
employee_name: "Dunham, Justin",
department : "Marketing",
title : "Product Manager, Web",
report_up: "Neray, Graham",
pay_band: “C",
benefits : [
{
type :
"Health",
plan : "PPO Plus" },
{
type :
"Dental",
plan : "Standard" }
]
}

12. Visualization

13. Visualization
d3js.org, …

14. Use math

15. Data Processing in MongoDB
• Pre-aggregated documents
• Aggregation Framework
• Map/Reduce
• Hadoop Connector

16. Pre-aggregated documents
Design Pattern

17. Pre-Aggregation
Data for
URL /
Date
{
_id: "20101010/site-1/apache_pb.gif",
metadata: {
date: ISODate("2000-10-10T00:00:00Z"),
site: "site-1",
page: "/apache_pb.gif" },
daily: 5468426,
hourly: {
"0": 227850,
"1": 210231,
...
"23": 20457 },
minute: {
"0": 3612,
"1": 3241,
...
"1439": 2819 }
}

18. Pre-Aggregation
Data for
URL /
Date
query = { '_id': "20101010/site-1/apache_pb.gif" }
update = { '$inc': {
'hourly.12' : 1,
'minute.739': 1 } }
db.stats.daily.update(query, update, upsert=True)

19. Aggregation framework

20. Dynamic Queries
Find all logs for a
URL
db.logs.find( { ‘path’ : ‘/index.html’ } )
Find all logs for a
time range
db.logs.find( {
‘time’ : {
‘$gte’: new Date(2013, 0),
‘$lt’: new Date(2013, s1) }
} )
Find all logs for a
host over a range of
dates
db.logs.find( {
‘host’ : ‘127.0.0.1’,
‘time’ : {
‘$gte’: new Date(2013, 0),
‘$lt’: new Date(2013, 1) }
} )

21. Aggregation Framework
Requests db.logs.aggregate( [
{ '$match': {
per day by
'time': {
URL
'$gte': new Date(2013, 0),
'$lt': new Date(2013, 1) } } },
{ '$project': {
'path': 1,
'date': {
'y': { '$year':
'$time' },
'm': { '$month':
'$time' },
'd': { '$dayOfMonth': '$time' } } } },
{ '$group': {
'_id': {
'p': '$path',
'y': '$date.y',
'm': '$date.m',
'd': '$date.d' },
'hits': { '$sum': 1 } } },
])

22. Aggregation Framework
{
‘ok’: 1,
‘result’: [
{ '_id': {'p':’/index.html’,'y':
{ '_id': {'p':’/index.html’,'y':
{ '_id': {'p':’/index.html’,'y':
{ '_id': {'p':’/index.html’,'y':
{ '_id': {'p':’/index.html’,'y':
]
}
2013,'m':
2013,'m':
2013,'m':
2013,'m':
2013,'m':
1,'d':
1,'d':
1,'d':
1,'d':
1,'d':
1
2
3
4
5
},
},
},
},
},
'hits’:
'hits’:
'hits’:
'hits’:
'hits’:
124 },
245 },
322 },
175 },
94 }

23. Aggregation Framework Benefits
• Real-time
• Simple yet powerful interface
• Scale-out
• Declared in JSON, executes in C++
• Runs inside MongoDB on local data

24. Map Reduce in MongoDB

25. MongoDB Map/Reduce

26. Map Reduce – Map Phase
Generate hourly
rollups from log
data
var map =
function() {
var key = {
p: this.path,
d: new Date(
this.ts.getFullYear(),
this.ts.getMonth(),
this.ts.getDate(),
this.ts.getHours(),
0, 0, 0) };
emit( key, { hits: 1 } );
}

27. Map Reduce – Reduce Phase
Generate hourly
rollups from log
data
var reduce = function(key, values) {
var r = { hits: 0 };
values.forEach(function(v) {
r.hits += v.hits;
});
return r;
}
)

28. Map Reduce - Execution
query = { 'ts': {
'$gte': new Date(2013, 0, 1),
'$lte': new Date(2013, 0, 31) } }
db.logs.mapReduce( map, reduce, {
‘query’: query,
‘out’: {
‘reduce’ : ‘stats.monthly’ }
} )

29. MongoDB Map/Reduce Benefits
• Runs inside MongoDB
• Sharding supported
• JavaScript
– Pro: functionality, expressiveness
– Con: overhead
• Input can be a collection or query!
• Output directly to document or collection
• Easy, when you don’t want overhead of Hadoop

30. Hadoop Connector

31. MongoDB with Hadoop

32. MongoDB with Hadoop

33. MongoDB
MongoDB with Hadoop

34. How it works
•
Adapter examines MongoDB input collection and
calculates a set of splits from data
•
Each split is assigned to a Hadoop node
•
In parallel hadoop pulls data from splits on
MongoDB (or BSON) and starts processing locally
•
Hadoop merges results and streams output back to
MongoDB (or BSON) output collection

35. Read From MongoDB (or BSON)
mongo.job.input.format=com.mongodb.hadoop.MongoInputFormat
mongo.input.uri=mongodb://my-db:27017/enron.messages
mongo.job.input.format=com.mongodb.hadoop.BSONFileInputFormat
mapred.input.dir= file:///tmp/messages.bson
mapred.input.dir= hdfs:///tmp/messages.bson
mapred.input.dir= s3:///tmp/messages.bson

36. Write To MongoDB
(or BSON)
mongo.job.output.format=com.mongodb.hadoop.MongoOutputFormat
mongo.output.uri=mongodb://my-db:27017/enron.results_out
mongo.job.output.format=com.mongodb.hadoop.BSONFileOutputFormat
mapred.output.dir= file:///tmp/results.bson
mapred.output.dir= hdfs:///tmp/results.bson
mapred.output.dir= s3:///tmp/results.bson

37. Document Example
{
"_id" : ObjectId("4f2ad4c4d1e2d3f15a000000"),
"body" : "Here is our forecastnn ",
"filename" : "1.",
"headers" : {
"From" : "phillip.allen@enron.com",
"Subject" : "Forecast Info",
"X-bcc" : "",
"To" : "tim.belden@enron.com",
"X-Origin" : "Allen-P",
"X-From" : "Phillip K Allen",
"Date" : "Mon, 14 May 2001 16:39:00 -0700 (PDT)",
"X-To" : "Tim Belden ",
"Message-ID" :
"<18782981.1075855378110.JavaMail.evans@thyme>",
"Content-Type" : "text/plain; charset=us-ascii",
"Mime-Version" : "1.0"
}
}

38. Graph Sketch

39. Receiver Sender Pairs
{"_id": {"t":"bob@enron.com",
"f":"alice@enron.com"},
"count" : 14}
{"_id": {"t":"bob@enron.com",
"f":"eve@enron.com"},
"count" : 9}
{"_id": {"t":"alice@enron.com",
"f":"charlie@enron.com"},
"count" : 99}
{"_id": {"t":"charlie@enron.com",
"f":"bob@enron.com"},
"count" : 48}
{"_id": {"t":"eve@enron.com",
"f":"charlie@enron.com"},
"count" : 20}

40. Map Phase – each document get’s
through mapper function
@Override
public void map(NullWritable key, BSONObject val,
final Context context){
BSONObject headers = (BSONObject)val.get("headers");
if(headers.containsKey("From") && headers.containsKey("To")){
String from = (String)headers.get("From"); String to =
(String) headers.get("To"); String[] recips = to.split(",");
for(int i=0;i<recips.length;i++){
String recip = recips[i].trim();
context.write(new MailPair(from, recip), new
IntWritable(1));
}
}
}

41. Reduce Phase – output Maps are
grouped by key and passed to Reducer
public void reduce(final MailPair pKey,
final Iterable<IntWritable> pValues,
final Context pContext ){
int sum = 0;
for ( final IntWritable value : pValues ){
sum += value.get();
}
BSONObject outDoc = new BasicDBObjectBuilder().start()
.add( "f" , pKey.from)
.add( "t" , pKey.to )
.get();
BSONWritable pkeyOut = new BSONWritable(outDoc);
pContext.write( pkeyOut, new IntWritable(sum) ); }

42. Query Data
mongos> db.streaming.output.find({"_id.t": /^kenneth.lay/})
{ "_id" : { "t"
"f"
}
{ "_id" : { "t"
"f"
}
{ "_id" : { "t"
"f"
{ "_id" : { "t"
"f"
{ "_id" : { "t"
"f"
{ "_id" : { "t"
"f"
{ "_id" : { "t"
"f"
: "kenneth.lay@enron.com",
: "15126-1267@m2.innovyx.com" }, "count" : 1
: "kenneth.lay@enron.com",
: "2586207@www4.imakenews.com" }, "count" : 1
:
:
:
:
:
:
:
:
:
:
"kenneth.lay@enron.com",
"40enron@enron.com" }, "count" : 2 }
"kenneth.lay@enron.com",
"a..davis@enron.com" }, "count" : 2 }
"kenneth.lay@enron.com",
"a..hughes@enron.com" }, "count" : 4 }
"kenneth.lay@enron.com",
"a..lindholm@enron.com" }, "count" : 1 }
"kenneth.lay@enron.com",
"a..schroeder@enron.com" }, "count" : 1 }

43. Hadoop Connector Benefits
•
Full multi-core parallelism to process MongoDB data
•
mongo.input.query
•
Full integration w/ Hadoop and JVM ecosystem
•
Mahout, et.al.
•
Can be used on Amazon Elastic MapReduce
•
Read and write backup files to local, HDFS and S3
•
Vanilla Java MapReduce, Hadoop Streaming, Pig, Hive

44. Make predictions & test

45. A/B testing
• Hey, it looks like teenage girls clicked a lot on that ad
with a pink background...
• Hypothesis: Given otherwise the same ad, teenage
girls are more likely to click on ads with pink
backgrounds than white
• Test 50-50 pink vs white ads
• Collect click stream stats in MongoDB or Hadoop
• Analyze results

46. Recommendations – social filtering
• ”Customers who bought this book also bought”
• Computed offline / nightly
• As easy as it sounds!
google it: Amazon item-to-item algorithm

47. Personalization
• ”Even if you are a teenage girl, you seem to be 60%
more likely to click on blue ads than pink.”
• User specific recommendations a hybrid of offline &
online recommendations
• User profile in MongoDB
• May even be updated real time

48. @h_ingo
Questions?
Henrik Ingo
Solution Architect, MongoDB
