1) The document proposes an intelligent power distribution system using GSM control to provide continuous power supply to consumers and safety from the distribution system.
2) It has two main parts - a GSM control unit that allows switching feeders via SMS without direct contact, and an automatic power line switching unit that switches power to an auxiliary feeder if the main feeder faults.
3) When a fault occurs, it sends alerts to responsible personnel via GSM and switches power to ensure continuous supply, while the GSM control also allows remote switching for maintenance without risk of electric shock.
