Ingress Protection (IP) Testing Per BS EN 60529, IEC 60529 for Lighting Products ITC INDIA Providing IP (Ingress Protection) Testing Per BS EN 60529, IEC 60529 for Lighting Products. ITC INDIA NABL Accredited Electrical Safety Testing laboratory can Determine a products susceptibility to solid particle (including dust) ingress and liquid (water) ingress. Kindly send us your testing requirements with the product technical details to submit you our testing charges. We are waiting for your earliest reply. You can call or write us for any clarification. Thanks & Regards, Puneet Sharma M: +91.8196980555 E-mail:-(itcindiaone@gmail.com) ITC India Pvt. Ltd

1. ITC INDIA Pvt.ltd
Web:www.itcindia.org

2. YOU BUILD ,WE TEST
We, ITC India , are a leading testing company
having reach all over the country .We are
committed to perform our services of
testing/inspection and Equipment Validation
independently and diligently.
We try to provide our customers with accurate
feedback and also a test report which is convincing
to our client’s client . We value and nourish the
trust reposted by our client in our testing ability

3. IP Testing for (Ingress Protection)
 According to following standard:
* IEC-60529/BSEN-60529

4. Ingress Protection
 Ingress protection (IP) testing at ITC NABL accredited
test laboratory can determine a products susceptibility
to solid particle (including dust) ingress and liquid
(water) ingress.
 Protection tests specified in :
- BS EN 60529/IEC 60529.

5. Ingress Protection Testing
 The standard we most commonly use at ITC for ingress
protection is BS EN 60529/IEC 60529. Within this
standard it outlines an international classification
system to test the sealing effectiveness of enclosures of
electrical equipment against the the equipment of
solid particles and liquid.
 This classification system utilizes the letters "IP"
("Ingress Protection") normally followed by two digits.

6. Purpose
 The testing will assess the protection of the equipment
against ingress of solid bodies and/or liquids, varying
over differing degrees of protection, depending upon
the requirements you place on your product.
 We will then measure the effects of this exposure, and
give the product an appropriate IP rating.

7. Ingress Protection (IP) Ratings
IP rating Level of protection
Solid ingress
IP1X Protected against solid objects greater than 50mm diameter
IP2X Protected against solid objects greater than 12.5mm diameter
IP3X Protected against solid objects greater than 2.5mm diameter
IP4X Protected against solid objects greater than 1.0mm diameter
IP5X Dust protected
IP6X Dust tight (with a vacuum applied to the product)

8. Ingress and liquid (water) ingress
IP rating Level of protection
Liquid ingress
IPX1 Protected against dripping water
IPX2 Protected against dripping water when tilted up to 15 degrees
IPX3 Protected against spraying water
IPX4 Protected against splashing water
IPX5 Protected against water jets
IPX6 Protected against powerful water jets
IPX7 Protected against the effects of temporary immersion in water
IPX8 Protected against the effects of continuous immersion in water

9. Test Equipment (SOLID)
S.No Title/Name Pictures of the apparatus
1. IP 1x
• Solid foreign objects of > 50 mm.
2. IP 2x
• Solid foreign objects of > 12.5 mm.
3. IP 3x
• Solid foreign objects of > 2.5 mm.

10. Test Equipment (SOLID)
S.No Title/Name Pictures of the apparatus
1. IP 4x
•Solid foreign objects of > 1.0 mm.
2. IP 5x
• Dust (protected).
3. IP 6x
• Dust (tight).

11. Test Equipment (SOLID)
S.No Title/Name Pictures of the apparatus
1. IP x1
•Vertically falling water drops..
2. IP x2
•Vertically falling water drops when enclosure tilted up to 15°.
3. IP x3
•Spraying water.

12. Test Equipment (SOLID)
S.No Title/Name Pictures of the apparatus
1. IP x4
• Splashing water.
2. IP x5
• Water jets.
3. IP x6
• Powerful water jets.

13. Test Equipment (SOLID)
S.No Title/Name Pictures of the apparatus
1. IP x7
• The effects of temporary immersion in water.
2. IP x8
•The effects of continuous immersion in water.

14. ITC INDIA – Provides
 Safety Testing
 IEC/IS/UL/EN Compliance Testing
 CE CERTIFICATION
 INSTALLATION/PERFORMANCE QUALIFICATION
 THIRD PARTY INSPECTION

15. ACCREDITATIONS/APPROVALS
 NABL
 IABCBL
 DGSND
 RDSO

16. Services
 Consumer , Household Appliance Equipment
 Machinery Equipment
 EMC/EMI
 Lighting & Entertainment Equipment
 Information technology Equipment
 Equipment/ Installation Equipment
 Laboratory & Testing Equipment
 Electro medical Equipment
 Photovoltaic modules
 IP Testing
 Battery
 Third Party Inspection
 Environmental Testing

17. Institute of testing and Certification
(INDIA) PRIVATE LIMITED
#362,Industrial Area, Phase-2 Panchkula -134113 (Haryana) INDIA
Tel. + 941-172-5066372 Web: www.itcindia.org | info@itcindia.org

18. Thanks for Visiting
