1. S.B. Jain Institute Of Technology
Management & Research
Presented by: Suraj Shukla Nimish Jain
Akshay kale Pranay Nandanwar
Yogesh Sarode Kamalnayan Khungar
Under the guidance of : Prof Madhav Deshpande

2. INTRODUCTION

3. PROPOSED WORK
 To implement Image Processing system on
Cyclone II FPGA.
 To convert part of that system into hardware using
C2H compiler

4. CO-DESIGN
 Embedded system approach for combine modelling
of software and hardware are called Co-Design .
 Boosts the system performance
 Reduces execution time

6. SOPC BUILDER
 System-on-a-programmable-chip (SOPC)
 Reduced time
 Lesser hardware
 Available on Quartus II

7. SOFTCORE PROCESSOR
 A soft-core processor is a hardware description
language (HDL) model of a specific processor (CPU)
that can be customized for a given application and
synthesized for an FPGA target.
 Platform independence
 Open-source Cores

8. NIOS II
 Second Generation Soft-Core 32 Bit RISC
Microprocessor
 8/16/32-bits memory controller for external PROM
and SRAM
 5 or 6 stages pipeline configuration
 Full 32-bit instruction set, data path, and address
space
 32 general-purpose registers
 32 interrupt sources
 Dedicated instructions for computing 64-bit and 128-
bit products of multiplication

9. Architecture of NIOS II processor

10. C2H COMPILER
The award winning Nios II embedded
processor C-to-Hardware (C2H) acceleration
compiler is a tool that boosts the
performance of time-critical ANSI C functions
by converting them into hardware
accelerators in the FPGA.

11. CYCLONE II
 Immensely successful
 68,416 logic
elements(LEs)
 622 usable I/O pins
 High performance
 Low power consumption
 Less cost as compared to
other FPGA’s

12. FEATURES
 Push-button acceleration of ANSI/ISO C
code
 GHz performance with mW power
consumption
 Tight integration with software design flow
 Efficient latency-aware scheduling and
pipelining of memory transactions

13. IMAGE PROCESSING
 Importance in the field of communication
 Obligation (Necessity)
 Transmitter end – Compression
 Receiver end – Decompression &
Enhancement
 Image would be compressed & enhanced
using DCT or DWT

14. MOTIVATION
 Co design to reduce time for execution
 FPGA supports complex systems on
chip(SOC)
 The NIOS II soft-core processor has highest
operating frequency

15. TOOLS TO BE USED
 Coding in GCC
 FPGA Flow
 Simulation: NIOS II IDE
 Implementation: Quartus II 8.1

16. Date Planned work
Till 5th Aug 2012 Study of softcore processor (NIOS II) &
Cyclone II FPGA (EP2C)
& image enhancement algorithm.
6th Aug 2012 to
5th Sept 2012
Designing C code for image enhancement
algorithm
6th Sept 2012 to
5th Oct 2012
System designing using Quartus 2 &
simulation using
NIOS II IDE
6th Oct 2012 to
5th Nov 2012
C2H compilation
6th Nov 2012 to
5th Dec 2012
Thesis writing

17. REFERENCES
[1] Coelo Jr, C. J. N., Da Silva Jr., D. C., and Fernandes, A. O. “Hardware
software codesign of embedded systems”, Proceedings of the 11th Brazilian
Symposium on Integrated Circuit Design, January 1998, pp. 2–8.
[2] Ernst, R.: “Co design of embedded systems: status and trends”, Proceedings
of IEEE Design and Test, April–June 1998, pp.45–54.
[3] P. Chou, R. Ortega, G. Borriello, “The Chinook hardware/software Co-design
System,”
Proceedings ISSS, Cannes, France, 1995, pp. 22-27.
[4] T. Ismail, A. Jerraya, “Synthesis Steps and Design Models for Codesign,”
IEEE Computer,no. 2, pp. 44-52, Feb 1995.
[5] Xiao-Wei Wang; Wei-Nan Chen; Ying Wang; Cheng-Lian Peng; A Co-design
Flow for Reconfigurable Embedded Computing System with RTOS Support
Embedded Software and Systems, 2009. ICESS '09. International Conference
on Digital Object Identifier: 10.1109/ICESS.2009.84 Publication Year: 2009 ,
Page(s): 467 – 474

18. THANK YOU............

19. QUESTIONS?
