2. 目次
GTC2018 での NVIDIA 自動運転関係・技術発表及び関連アナウンスメント (補
足スライド入り)
1. S8666: Deploying Autonomous Vehicles with NVIDIA DRIVE
2. S8531: Deep Learning Infrastructure for Autonomous Vehicles
3. S8294: NVIDIA DRIVE Safety: NVIDIA's Strategies for Enabling Safety in Automotive
Platforms
4. S8324: Synthetic Data Generation for an All-in-One Driver Monitoring System
5. ANNOUNCEMENT: NVIDIA and ARM Partner to Bring Deep Learning to Billions of IoT
Devices
P2
4. ANNOUNCING “PEGASUS”
ROBOTAXI DRIVE PX
レベル5 完全自動運転
▪ Xavier (Volta GPU integrated) x 2
▪ Next generation discrete-GPU x 2
▪ 320 TOPS CUDA TensorCore
▪ ASIL D Certification
▪ Combined Memory Bandwidth: >1TBytes/sec
▪ Automotive I/Os
▪ 16x GMSL High-speed Camera Inputs
▪ Multiple 10Gbit Ethernet
▪ CAN, Flexray
▪ Late Q1 Early Access Partners
▪ Supercomputing Data Center in your Trunk
補足スライド
5. DRIVE DEVELOPMENT PLATFORM
Development Platform for DRIVE Xavier & DRIVE Pegasus
– building on the capabilities of DRIVE PX 2
Auto-grade ASIL-D Safety MCU
Upto 16x CAN
2x Flexray
Ethernet:
4x 10Gbps
7x 1Gbps or 100Mbps
5x 100Mbps
2x Xavier SOC:
CV & DL Accelerator
CUDA Processing
137GB/s LPDDR4x
2x discrete GPU:
Next Gen CUDA GPU
Tensor Core
Support for IST
384GB/s GDDR6
Raw Sensor Input
16x GMSL
91Gbps
XAVIER
Next
Generation
GPU
Next
Generation
GPU
DeSer
DeSer
DeSer
XAVIER
DeSer
MCU
PCIE
Switch
NVLINK
NVLINK
ENET
2x Xavier Developer I/O
HDMI
4 x USB
UART (via USB)
JTAG
Only with
Pegasus
DRIVE PX2 | DRIVE Xavier | DRIVE Pegasus | One Architecture
6. DRIVE SOFTWARE
NVIDIA Deliverables
DRIVE Development Platform
Sensors
Sensors
& Maps
NVMEDIA DRIVE OS, CUDA
CUDA accelerated libraries
(notably TensorRT)
DriveWorks Algorithm Modules
Autonomous Driving Applications
DriveWorks
Tools DNNs
Included Not included
DRIVE OS (Linux or QNX)
NVMEDIA
SAL
Sensor Abstraction
Layer
CUDA libraries
(CuDNN…)
DriveWorks Algorithm Modules
TensorRT NvMedia
(VPI)
Open GL
ES
VPI: Vision Primitives / Programmable Interface
(OpenVX, VisionWorks supported by CUDA)
7. NvMedia
(Camera,
ISP,
Encoder
TensorRT
NvMedia
(VPI)
CUDA
OpenGL
Xavier CPU
Video Encoder
0.9 - 1.4 Gpix/s
Video Decoder
– Gpix/s
Deep Learning
Accelerator (DLA)
5 FP16 / 10 INT8 TOPs DL
ISP
1.5 Gpix/s
VIC
2 Gpix/s
PVA
0.5 - 1.3 TOPS
Stereo & OF
(SOFE)
6 TOPS
X 16
Camera
• Raw data for DNN
training
• Detection,
classification,
segmentation
• Computer vision,
autonomous vehicle
algorithms
• Archiving, computer
data for DNN,
automotive simulation
• Visualization, in-
vehicle display
GPU Compute
1.3FP32 TFLOPS CUDA
20INT8 TOPs DL
GPU Graphics
1.3 TFLOPS FP32
Human
Interface
Compressed
Storage
Math
Computation
DNN
Inference
Raw
Data Storage
Computer
Vision
• Autonomous vehicle
algorithms
Lidar
Radar
...
XAVIER SOC ENGINES
& DRIVE OS
Xavier HW Engines DRIVE OS
SW APIs
Inputs
Data
Destination
Purpose
ISP: Image Signal Processor
VIC: Video Imaging Controller
PVA: Programmable Vision Accelerator
OF: Optical Flow
SOFE: Stereo Optical Flow Engine
8. DRIVEWORKS
Modules (with C APIs):
Sensor, Vehicle I/O abstraction
Automotive image processing modules
• Stereo/Rectification, Color Correction…
Automotive Computer Vision modules
• Point Cloud Processing, SFM(Structure
from Motion), 2D Tracker…
Tools
Recording, Replaying, Visualization.
Abstracting the vehicle
9. DRIVE DEVZONE
SW Installer & Dev. Tools
Latest SW
Documentation
Links to Support
Updates on Ecosystem
https://developer.nvidia.com/DRIVE
10. REVISITING THE FLOW…
to put an Autonomous Vehicle on the road?
Curated
Annotated
Training Data
Data Acquired
From Sensors
Trained
Deep Neural
Network
Autonomous Vehicle
Applications
Autonomous Vehicle
Application Development
Test/Drive
Simulation
& Re-Simulation
HD Map
Neural
Network
Training
1
2
3
Data Acquisition to train DNN and create HD Map
Autonomous Vehicle Application Development
Testing In-Vehicle or With Simulation
1
2
3
DRIVE PX
DRIVE PX
(HIL)
DRIVE PX
DGX (SIL)
13. 2018 2019
DRIVE AI COMPUTER
Development to Production | One Architecture
DRIVE™ Xavier
30 TOPS | 1x Xavier
DRIVE™ Pegasus
320 TOPS | 2x Xavier + 2x Next Gen GPU
DRIVE PX 2
24 TOPS | 2x Parker + 2x Pascal dGPU
DRIVE™ Development Platform - Xavier
60 TOPS | 2x Xavier
DRIVE™ Development Platform - Pegasus
320 TOPS | 2x Xavier + 2x Next Gen GPU
DEVELOPMENT PRODUCTION
14. SIMULATION —
THE PATH TO BILLIONS OF MILES
World drives trillions of miles each year.
U.S. has 770 accidents per billion miles.
A fleet of 20 test cars cover 1 million miles
per year.
15. ANNOUNCING
NVIDIA DRIVE SIM
AND CONSTELLATION
AV VALIDATION SYSTEM
▪ Virtual Reality AV Simulator
▪ Same Architecture as DRIVE Computer
▪ Simulate Rare and Difficult Conditions
▪ Recreate Scenarios
▪ Run Regression Tests
▪ Drive Billions of Virtual Miles
10,000 Constellations Drive 3B Miles per Year
DRIVE SIM
Generating
Virtual Reality
3D Image
Stimulus
Constallation
Running
Autonomous Driving
Application on real
HW
Interfaces
HW Platform
3D Virtual Images
Car Responses
Example: 4 Camera based Autonomous Driving Simulation
HIL (Hardware In the Loop) Simulation
20. NVIDIA DRIVE FUNCTIONAL SAFETY ARCHITECTURE
HD Map
DRIVE XAVIER DDPX DGX (DDPX Emulation)
AutoSIM
(Photo Realistic 3D-CG by DGX
for Corner Cases etc)
DRIVE OS
▪ Diverse Engines
▪ Dual Execution
▪ ECC/Parity
▪ Diagnosis, BIST
Hypervisor
CUDA, TensorRT
ISO 26262
DRIVE AV
System Operates Safely Even when Faults Detected
Holistic System — Process & Methods, Processor Design, Software, Algorithms, System Design, Validation
ISO 26262 ASIL-D Safety Level | Partnership with BlackBerry QNX and TTTech | New AutoSIM Virtual Reality 3D Simulator
Same GPU
Architecture
Re-SIM
(Captured Real Data)
Traffic Environment Input(Stimulus)
and Testing/VerificationHIL SIL
HIL: Hardware (DDPX) In the Loop
SIL: Software(DGX) In the LoopISO26262
ASIL-D
21. DRIVE SOFTWARE
NVIDIA Deliverables
DRIVE Development Platform
Sensors
Sensors
& Maps
NVMEDIA DRIVE OS, CUDA
CUDA accelerated libraries
(notably TensorRT)
DriveWorks Algorithm Modules
Autonomous Driving Applications
DriveWorks
Tools DNNs
Included Not included
DRIVE OS (Linux or QNX)
NVMEDIA
SAL
Sensor Abstraction
Layer
CUDA libraries
(CuDNN…)
DriveWorks Algorithm Modules
TensorRT NvMedia
(VPI)
Open GL
ES
VPI: Vision Primitives / Programmable Interface
(OpenVX, VisionWorks supported by CUDA)
補足スライド
22. Critical Components are ASIL-D
QNX RTOS, Classic AUTOSAR, & Hypervisor
To be Safe, must be Secure
Secure boot, Security Services, Firewall, & OTA
To be Safe, must be Real-time
QNX RTOS for mission application
Hypervisor for Quality of Service (QoS)
DRIVE OS
Safe, Secure, & Real-time
23. NVIDIA CONFIDENTIAL. DO NOT DISTRIBUTE.
WHY QNX
FOR
SAFETY?
Safety OS Key Selection Criteria:
ISO 26262 ASIL D Certified RTOS
ISO 26262 qualified tool chain (up to TCL 3)
POSIX PSE52 standards certification
- Requirement for CUDA, cuDNN support
Common Unix heritage with Linux
- Rich dependent library support
TCL3: Tool Confidence Level
POSIX PSE52: support application portability at source code level
25. NVIDIA CONFIDENTIAL. DO NOT DISTRIBUTE.
SOFTWARE SAFETY FRAMEWORK
Three Level Safety Supervision (3LSS) architecture
Coherent with Xavier SOC safety architecture and DRIVE platform
• Support for Xavier SOC HW Safety Manager
• Integrated into DRIVE OS to be available for DRIVE platform
• Anchored by ASIL D capable Safety-MCU on DRIVE platform
Provides standard mechanism for handling of potentially safety critical errors and
performing diagnostics
Supporting freedom from interference in execution, memory and information
exchange domains
Overview
26. NVIDIA SAFETY FRAMEWORK
THREE LEVEL SAFETY SUPERVISION (3LSS)
L1SS
One Partition on Hypervisor
CCPLEX(CPU Complex) = Carmel CPU x 8
L2SS
Safety OS & AutoSAR
SCE(Safety Control Engine) = R5 CPU x 2 in Lock-step)
L3SS
Safety OS & AutoSAR
External ASIL-D MCU
SHM (Safety Hardware Manager)
Safety Supervision Serial Channel on SPI I/F Error Signaling Pin
Heartbeat Monitoring on SPI I/F
Safety PMIC (Power Management IC)
XAVIER
▪ Diverse Engines
▪ Dual Execution
▪ ECC/Parity
▪ Diagnosis
▪ BIST (Built In Self
Test)
27. SOFTWARE SAFETY FRAMEWORK
Flexible and extendable to handle the increasing safety requirements
Configurable and portable to new DRIVE versions
Off the shelf safety solution, optimizing/reducing effort on application side.
Enables easy deployment of safety applications on DRIVE platform
• Provides safety services such as flow monitoring
Supports the fault tolerant foundation of our Drive platform
Outcome
29. NVIDIA DRIVE IX SDK
IX (Intelligent eXperience) Toolkit
Sense Inside & Outside the Vehicle | Deep Learning Powered | Early Access Q4
Your Car is an AI
Customer Application
DRIVE OS
DRIVE AV
Object, Path, Wait Perception
DRIVE IX
Gaze, Head Pose, Gestures,
Recognize Face,
Voice Recognition & Lip Reading
Exterior Driver
Recognition
Automatic
Personalization
Inattentive Driver
Alert
Cyclist
Alert
Distracted Driver
Alert
Driver/Passenger
Recognition
Multiple In-Car Sensors
補足スライド
31. NEED FOR SYNTHETIC DATA
No devices available – e.g. face landmarks at extreme angles
Manual labelling – limited by human precision and error
Manpower and time limits – recording in different environments
Sensor interference with scene – glasses for eye tracking, optical markers
Needs high resolution devices – head poses, gaze
Lacks associativity and completeness – multiple recordings for multiple parameters
Where does real world data fall short?
32. NEED FOR SYNTHETIC DATA
More flexible - environment parameters, camera distance, background
Error free - Free from manual labelling errors / Human errors
Accurate - Synthetic data readings are highly accurate. No sensor noise
High resolution as well as low resolution images can be generated
Allows labelling of occluded areas
3D as well as 2D labels can be accurately generated
Fast and economical
Where does synthetic data offer advantages?
34. DATA GENERATION PIPELINE
Steps involved in synthetic data generation:
3D Head Scan with High Resolution
Retopology
Defining Mesh Deformation
Annotation
35. DATA GENERATION PIPELINE
High Resolution 3D Head Scan
• Capture accurate 3D face details using depth sensor
or multiple synchronized cameras using triangulation
• High density mesh (~0.1 mm resolution)
• Why can’t we use such high resolution scan?
• Needs lots of computation power to transform each
mesh vertex
• More manual efforts for defining deformation and
key shapes
http://ten24.info/10-x-high-resolution-head-scans-avaliable-to-download/
[2]
36. DATA GENERATION PIPELINE
Retopology
Reduce mesh vertices count to save on
computation cost
• Reduced vertex count (~1000 x reduction)
• Add displacement map to preserve details
• Easier to define shape keys manually on reduced mesh
37. DATA GENERATION PIPELINE
Mesh Deformation
• Define shape keys and set vertices manually
to define a face feature (e.g. eyes looking
down, smile, eyebrow raised)
• Intermediate values are interpolated
automatically
• Allows programmatic control of parameters
[1]
38. DATA GENERATION PIPELINE
Landmark annotation
• Manually mark points of interest
• Allows tracking and automatic labelling of face landmarks
• 2D and 3D point coordinates are available as the environment is synthetic
• Occluded points could be accepted/rejected programmatically
[1]
39. DATA GENERATION PIPELINE
Example annotated image
Following features are saved along with image in a file
• Face bounding box
• Face landmarks
• Head pose
• Gaze
• Eye lid, pupil(eyeball), iris markers
• Face ID
41. PARAMETER SETTING
Head Pose control
• Position camera to cover head
• Camera oriented towards center of both eyes
• Head orientations can be set to captured values
to mimic human head motions
42. PARAMETER SETTING
Gaze control
• Position subject with respect to camera
• Set target gaze location
• Rotate eyes to look at target location
• Render cases which honor anatomic constraints
• Unobstructed ( Pupil is partly exposed > 35% )
• Within anatomically allowed pitch/yaw range
• Visible to the camera
Constraints
45. POST PROCESSING
Domain adaption is used to operate on synthetic data to closely resemble real
data. Following techniques can be used to adopt to real world domain:
Gaussian filtering/Blurring – This effect imitates focal blur of the camera
Noise addition – Imitates sensor noise, environment noise/dust
Brightness/contrast correction – To simulate different lighting conditions
Scaling – To make up for face distance, bounding box tightness
Mirroring – Most of the use cases are agnostic to mirroring; others can use
transformed parameters
48. DEPLOYMENT
Execution SEC/FRAME 150K FRAMES COMMENTS
CPU 40 70 days Consumes entire CPU
GPU 8 14 days 30-60% GPU(~5 sec/frame)
GCF (10 GPUs) 0.8 1.4 days
Training a DNN requires images in the order of ~150K and higher
Speed up of 5x with a GPU and (10x) times using GCF (GPU Compute Farm)
49. 目次
GTC2018でのNVIDIA自動運転関係・技術発表及び関連アナウンスメント (補
足スライド入り)
1. S8666: Deploying Autonomous Vehicles with NVIDIA DRIVE
2. S8531: Deep Learning Infrastructure for Autonomous Vehicles
3. S8294: NVIDIA DRIVE Safety: NVIDIA's Strategies for Enabling Safety in Automotive
Platforms
4. S8324: Synthetic Data Generation for an All-in-One Driver Monitoring System
5. ANNOUNCEMENT: NVIDIA and ARM Partner to Bring Deep Learning to Billions of IoT
Devices
50. NVIDIA AND ARM PARTNER TO BRING DEEP LEARNING
TO BILLIONS OF IOT DEVICES
NVIDIA Deep Learning Accelerator IP to be Integrated into ARM Project Trillium
Platform, Easing Building of Deep Learning IoT Chips
GPU Technology Conference — NVIDIA and Arm today announced that they are partnering to bring deep
learning inferencing to the billions of mobile, consumer electronics and Internet of Things devices that
will enter the global marketplace.
Under this partnership, NVIDIA and Arm will integrate the open-source NVIDIA Deep Learning
Accelerator (NVDLA) architecture into Arm’s Project Trillium platform for machine learning. The
collaboration will make it simple for IoT chip companies to integrate AI into their designs and help put
intelligent, affordable products into the hands of billions of consumers worldwide.
Tuesday, March 27, 2018
51. ANNOUNCING DRIVE XAVIER SAMPLING IN Q1
Most Complex SOC Ever Made | 9 Billion Transistors, 350mm2, 12nFFN | ~8,000 Engineering Years
Diversity of Engines Accelerate Entire AV Pipeline | Designed for ASIL-D AV
Volta GPU
FP32 / FP16 / INT8 Multi
Precision
512 CUDA Cores
1.3 CUDA TFLOPS
20 Tensor Core TOPS
ISP
1.5 GPIX/s
Native Full-range HDR
Tile-based Processing
PVA
1.6 TOPS
Stereo Disparity
Optical Flow
Image Processing
Video Processor
1.2 GPIX/s Encode
1.8 GPIX/s Decode
16 CSI
109 Gbps
1Gbps E & 10Gbps Eithernet
256-Bit LPDDR4
137 GB/s
DLA
5 TFLOPS FP16
10 TOPS INT8
Carmel ARM64 CPU
8 Cores
10-wide Superscalar
2700 SpecInt2000
Functional Safety
Features
Dual Execution Mode
Parity & ECC
World’s First
Autonomous
Machine
Processor
52. NVDLA (NVIDIA DEEP LEARNING ACCELERATOR)
XAVIER SOCにも内蔵
更なる電力効率向上
Command Interface
Tensor Execution Micro-controller
Memory Interface
Input DMA
(Activations and
Weights)
Unified
512KB
Input
Buffer
Activations
and
Weights
Sparse Weight
Decompre-
ssion
Native
Winograd
Input
Transform
MAC
Array
2048 Int8
or
1024 Int16
or
1024 FP16
Output
Accumu-
lators
Output Post
processor
(Activation
Function,
Pooling etc.)
Output
DMA
係数が疎になる性質を利用して
メモリバンド幅削減
極力乗算を減らす最新アルゴリズムで
チップサイズ、消費電力低減
期待される数々の最新技術例
他機能は理にかなった
合理的なアクセラレーション
Reference NVDLA: http://nvdla.org
53. なぜ AI 推論で演算精度・乗算回数を低減する必要があるか?
Artem Vasilyev, “CNN Optimization for Embedded Systems and FFT”
CS231n: CNN for Visual Recognition Course, Stanford, 2017
INT16では乗算は加算の
13倍の電力を消費
FPFF16では乗算は加算の
2.25倍の電力を消費
FP32では乗算は加算の
4.7倍の電力を消費
可能な限り演算精度を
下げる必要があることは
言うまでもない。
乗算回数低減はcuDNNライブラリや
DLA (Deep Learning
Accelerator) アーキテクチャで実施
154. 自動運転全般、アルゴリズム関連
• S81014 - Advancing State-of-the-Art of Autonomous Vehicles and Robotics
Research using AWS GPU Instances (Presented by Amazon Web Services)
• TRIによるAWSの活用事例、開発環境の紹介
• S8140 - Deep Learning for Automated Systems: From the Warehouse to the Road
• Clemson Univ. 自動運転ソフトウェア開発フロー
• S8862 - Autonomous Algorithms
• Panelセッション。NNAISENSE社によるAUDI自動駐車実験の紹介や、fka社による経路生成におけ
るDNNの活用など
155. マップ、ローカライゼーション関連
• S8834 - In-Vehicle Change Detection, Closing the Loop in the Car
• HERE – セルフヒーリングマップ、フリート用センサーの紹介
• S8861 - Crowd-sourcing, Map updates, and Predictions as Complementary
Solutions for Mapping
• Panel (explorer.ai, VoxelMaps, DeepMap) – クラウドソーシングによるマップ、
Voxelベースの地図、オープンプロジェクト等
• S8618 - GPU Accelerated LIDAR Based Localization for Automated Driving
Applications
• FORD – GPUによるローカライゼーションの高速化
156. • S8758 - The Future of the In-Car Experience
• Affectiva社による感情検出AIの紹介、学習データセットの事例や転移学習の成果について
• S8970 - Creating AI-Based Digital Companion for Mercedes-Benz Vehicles
• Mercedes Benzでの車載AIの実装
インキャビン関連
