1. Graph Databases
&
Neo4J
Girish Khanzode

2. Graph Databases
• Graph Based NoSQL Database
• Property Graph Model
• Neo4j
• Noe4j Architecture
• Data Storage
• Programmatic Data Access
• Core API
• Lucene
• Auto Index lifecycle
• Traversers API
• Cypher
• Graph Algorithms
• Neo4j HA
• Cache Sharding
• References

3. Graphs
• A collection nodes (things) and edges (relationships) that
connect pairs of nodes
– Suitable for any data that is related
• Can attach properties (key-value pairs) on nodes and
relationships
• Relationships connect two nodes and both nodes and
relationships can hold an arbitrary amount of key-value pairs

4. Graph Relations are Universal

5. Graph

6. Graphs
• Well-understood patterns and algorithms
– Studied since Leonard Euler's 7 Bridges (1736)
– Codd's Relational Model (1970)
• Knowledge graph - beyond links, search is smarter when considering how things
are related
• Facebook graph search – people interested in finding things in their part of the
world
• Bing + Britannica: referencing and cross-referencing
• People - relationships to people, to organizations, to places, to things - personal
graph

7. A Graph Database
• Relationships are first citizens
• NoSQL database optimized for connected data
– Social networking, logistics networks, recommendation engines
– Relationships are as important as the records
– 1000 times faster than RDBMS for connected data
• Uses graph structures with nodes, edges and properties to store data
• Open source graph databases - Neo4j, InfiniteGraph, InfoGrid,OrientDB
• Very fast querying across records

8. Graph Database

9. A Graph Database
• Transactional with the usual operations
• RDBMS - can tell sales in last year
• Graph database – can tell customer which book to buy next
• Index-free adjacency
– Every node is a pointer to its adjacent element
• Edges hold most of the important information and relations
– nodes to other nodes
– nodes to properties

10. Graph Based NoSQL Database
• No rigid format of SQL or the tables and columns representation
• Uses a flexible graphical representation - addresses scalability concerns
• Data can be easily transformed from one model to the other using a
graph based NoSQL database
• Nodes are organised by some relationships with one another represented
by edges between the nodes
• Both nodes and the relationships have some defined properties

11. Graph Based NoSQL Database
• Labelled, directed, attributed multi-graph - Graphs contains nodes which
are labelled properly with some properties and these nodes have some
relationship with one another which is shown by the directional edges
• While relational database models can replicate the graphical ones, the
edge would require a join which is a costly proposition

12. Advantages
• Easier Relationships Analysis
• Very fast for associative data sets
– Like social networks
• Map more directly to object oriented applications
– Object classification and Parent->Child relationships

13. Disadvantages
• If data is just tabular with not much relationship between the
data, graph databases do not fare well
• OLAP support for graph databases not mature

14. Performance Experiment
• Compute social network path exists
• 1000 persons
• Average 50 friends per person
• pathExists(a, b) limited to depth 4
# persons query time
Relational
database
1000 2000ms
Neo4j 1000 2ms
Neo4j 1000000 2ms

15. Property Graph Model
name: the Doctor
age: 907
species:Time Lord
first name: Rose
late name:Tyler
vehicle: Skoda
model:Type 40

16. Graphs -Whiteboard-friendly
• No decomposition, ER design, normalization / de-
normalization as needed with RDBMS

17. Neo4j
• A Graph Database
• A Property Graph containing Nodes, Relationships with Properties on
both
• Manage complex, highly connected data
• Scalable - High-performance with High-Availability
– Traverse 1,000,000+ relationships / second on commodity hardware
• Server with REST API, or Embeddable on the JVM

18. Neo4j
• Full ACID transactions
• Schema free, bottom-up data model design
• Stable
• Easier than RDBMS since no need for normalization
• Implemented in Java
• Open Source

19. Neo4j
• Schema free – Data does not have to adhere to any convention
• Support for wide variety of languages - Java, Python, Perl, Scala,Cypher
• A graph database can be thought of as a key-value store, with full support
for relationships.
• Graph databases don’t avoid design efforts
• Good design still requires effort

20. Why Neo4J?
• The internet is a network of pages connected to each other.
What is a better way to model that than in graphs?
• No time lost fighting with less expressive data-stores
• Easy to implement experimental features
• A single instance of Neo4j can house at most 34 billion nodes,
34 billion relationships and 68 billion properties

21. Core API
REST API
JVM Language Bindings
Traversal Framework
Caches
Memory-Mapped (N)IO
Filesystem
Java Ruby Clojure…
Graph Matching
Noe4j Architecture

22. Software Architecture

23. Data Storage
• Neo4j stores graph data in a number of different store files
• Each store file contains the data for a specific part of the
graph
– neostore.nodestore.db
– neostore.relationshipstore.db
– neostore.propertystore.db
– neostore.propertystore.db.index
– neostore.propertystore.db.strings
– neostore.propertystore.db.arrays

24. Node Store
• Size: 9 bytes
– 1st byte - in-use flag
– Next 4 bytes - ID of first relationship
– Last 4 bytes - ID of first property of node
• Fixed size records enable fast lookups

25. Relationship store
• neostore.relationshipstore.db
• Size: 33 bytes
• 1st byte - In use flag
• Next 8 bytes - IDs of the nodes at the start and end of the relationship
• 4 bytes - Pointer to the relationship type
• 16 bytes - pointers for the next and previous relationship records for each of the start and end nodes. (
property chain)
• 4 bytes - next property id

26. Relationships Storage

27. Data Size
nodes 235 (∼ 34 billion)
relationships 235 (∼ 34 billion)
properties 236 to 238 depending on property types (maximum ∼ 274
billion, always at least ∼ 68 billion)
relationship
types
215 (∼ 32 000)

28. Neo4j API – LogicalView

29. Programmatic Data Access
• JavaAPIs - JVM languages bind to sameAPIs
• JRuby, Jython, Clojure, Scala…
• Manage nodes and relationships
• Indexing – find data without traversal
• Traversing
• Path finding
• Pattern matching

30. Core API
• Deals with graphs in terms of their fundamentals
• Nodes - properties
– KV Pairs
• Relationships
– Start node
– End node
– Properties
• KV Pairs

31. Create Node
GraphDatabaseService db = new EmbeddedGraphDatabase("/tmp/neo");
Transaction tx = db.beginTx();
try {
Node theDoctor = db.createNode();
theDoctor.setProperty("character", "the Doctor");
tx.success();
} finally
{
tx.finish();
}

32. Create Relationships
Transaction tx = db.beginTx();
try {
Node theDoctor = db.createNode();
theDoctor.setProperty("character", "The Doctor");
Node susan = db.createNode();
susan.setProperty("firstname", "Susan");
susan.setProperty("lastname", "Campbell");
susan.createRelationshipTo(theDoctor,DynamicRelationshipType.withName("COMPANION_OF"));
tx.success();
} finally
{
tx.finish();
}

33. Index a Graph
• Graphs themselves are indexes
• Can create short-cuts to well-known nodes
• In program, keep a reference to any interesting node
• Indexes offer flexibility in what constitutes an “interesting
node”

34. Lucene
• The default index implementation for Neo4j
– Default implementation for IndexManager
• Supports many indexes per database
• Each index supports nodes or relationships
• Supports exact and regex-based matching
• Supports scoring
– Number of hits in the index for a given item
– Great for recommendations

35. Create a Node Index
GraphDatabaseService db = …
Index<Node> planets = db.index().forNodes("planets");
Type
Type
Indexname
CreateOR
retrieve

36. Create a Relationship Index
GraphDatabaseService db = …
Index<Relationship> enemies = db.index().forRelationships("enemies");
Type
Type
Indexname
CreateOR
retrieve

37. Exact Matches
GraphDatabaseService db = …
Index<Node> actors = doctorWhoDatabase.index().forNodes("actors");
Node rogerDelgado = actors.get("actor", "Roger Delgado“).getSingle();
Valueto
match
Firstmatch
only
Key

38. Query Matches
GraphDatabaseService db = …
Index<Node> species = doctorWhoDatabase.index().forNodes("species");
IndexHits<Node> speciesHits = species.query("species“,"S*n");
Query
Key

39. Transactions to Mutate Indexes
• Mutating access is still protected by transactions which cover both index and graph
GraphDatabaseService db = …
Transaction tx = db.beginTx();
try {
Node nixon= db.createNode();
nixon("character", "Richard Nixon");
db.index().forNodes("characters").add(nixon,
"character“, nixon.getProperty("character"));
tx.success();
} finally {
tx.finish();
}

40. Auto Index lifecycle
• Auto Index - stays consistent with the graph data
• Specify the property name to index while creation
• If node/relationship or property is removed from the graph it is removed
from the index
• If database started with auto indexing enabled but different auto indexed
properties than the last run, then already auto-indexed entities will be
deleted as they are worked upon
• Re-indexing is a manual
– Existing properties not indexed unless touched

41. Auto Index lifecycle
AutoIndexer<Node> nodeAutoIndex = graphDb.index().getNodeAutoIndexer();
nodeAutoIndex.startAutoIndexingProperty("species");
nodeAutoIndex.setEnabled( true );
ReadableIndex<Node> autoNodeIndex = graphDb.index().getNodeAutoIndexer().getAutoIndex();
Node -> Relationship Indexes Supported

42. Core API
• Basic (nodes, relationships)
• Fast
• Imperative
• Flexible - Easily intermix mutating operations

43. Traversers API
• Mechanisms to query graph navigating from starting node to
related nodes according to algorithm to get answers
• Expressive
• Fast
• Declarative (mostly)
• Opinionated

44. Cypher - A Graph Query Language
• Query Language for Neo4j
• A declarative graph pattern matching language
– SQL for graphs
– Tabular results
• aggregation, ordering and limits
• Mutating operations
• CRUD
• Easy to formulate queries based on relationships
• Many features stem from improving pain points of SQL like join tables

45. Cypher - A Graph Query Language

46. Cypher

47. Query
• Query:
MATCH(n:Crew)-[r:KNOWS*]-m
WHERE n.name = ‘Neo’
RETUEN nAS Nep,r,m

48. Operations
• Aggregation - COUNT, SUM, AVG, MAX, MIN, COLLECT
• Where clause
start doctor=node:characters(name = 'Doctor‘)
match (doctor)<-[:PLAYED]-(actor)-[:APPEARED_IN]->(episode) where actor.actor = 'Tom
Baker‘ and episode.title =~ /.*Dalek.*/
return episode.title
• Ordering
– order by <property>
– order by <property> desc

49. Graph Algorithms
• Neo4j has built-in algorithms
• Callable through JVM and REST APIs
• Higher level of abstraction
• Graph Matching
– Look for patterns in a data set - retail analytics
– Higher-level abstraction than raw traversers
• REST API
– Access the server
• Binary protocol
– JSON as default format

50. Neo4j HA - High Availability Cluster
• A scalability package known as high availability or HA that
uses a master-slave cluster architecture
– Full data redundancy
– Service fault tolerance
– Linear read scalability
– Master-slave replication
• Single data-centre or global zones
– tolerance for high-latency

51. Neo4j HA
• Redundancy - improved uptime
– automatic failover
• In a Neo4j HA cluster the full graph is replicated to each instance in the
cluster.
• Full dataset is replicated across the entire cluster to each server
• Read operations can be done locally on each slave
• Read capacity of the HA cluster increases linearly with the number of
servers

52. Neo4j HA

53. HA Cluster Architecture
• Cluster performs automatic master election
• Supports master-slave replication for clustering and DR
across sites

54. HA Cluster Architecture

55. Write to a Master
• All write operations are co-ordinated by the master
• Writes to the master are fast
• Slaves eventually catch up

56. Write to a Master

57. Write to a Slave
• Writes to a slave cause a synchronous transaction
with the master
• Other slaves eventually catch up

58. Write to a Slave

59. Server Overload Problem
• Unlike other classes of NOSQL database, a graph does not
have predictable lookup since it is a highly mutable structure
• We want to co-locate related nodes for traversal
performance, but we don’t want to place so many connected
nodes on the same database that it becomes heavily loaded
• The black-hole problem - popular nodes get lumped together
on a single instance, but there is low point cut

60. Server Overload Problem

61. Thinly Spread Network
• The opposite is also true, that we don’t want too widely connected nodes
across different database instances since it will incur a substantial
performance penalty at runtime as traversals cross the (relatively latent)
network
• Load-leveling alone can lead to many relationships crossing instances
• These are very expensive to traverse, networks are many orders of
magnitude slower than in-memory traversals

62. Thinly Spread Network

63. Minimal Point Cut
• The best approach is to balance a graph across database instances by
creating a minimum point cut for a graph, where graph nodes are placed
such that there are few relationships that span shards
• Good strategy is to take a local view of the graph (no global locks) and
work incrementally (short bursts)
• Take into account use patterns
• Unlike other NoSQL stores, graph s are not predictable so we can not use
techniques like consistent hashing for scale out

64. Minimal Point Cut

65. Cache Sharding
• A strategy for large data sets of terabyte scale
• Mandates consistent request routing
• For instance, requests for user A are always sent to server 1,
while requests for user B are always sent to server 2 and so on
• The key assumption is that requests for user A typically touch
parts of the graph around user A, such has his or her friends,
preferences, likes and so on

66. Cache Sharding
• This means that the neighbourhood of the graph around user
A will be cached on server 1, while the neighbourhood around
user B will be cached on server 2
• By employing consistent routing of requests, the caches of all
servers in the HA cluster can be utilized maximally
• Strategy is highly effective for managing a large graph that
does not fit in RAM

67. Consistent Routing
• Always try to route related requests to the same server to hopefully
benefit from warm caches

68. Domain Specific Sharding
• No easy to shard graphs like documents or KV stores
• High performance graph databases limited in terms of data set size that
can be handled by a single machine
• Use replicas to speed up and improve availability but limits data set size
limited to a single machine’s disk/memory
• No perfect algorithm exists but domain insight of expert helps

69. Domain Specific Sharding
• Some domains can shard easily (geo, most web apps) using consistent
routing approach and cache sharding
– Geo - where the connections between cities are few compared with the
connections within the cities. So can place cities or countries on different
nodes
• Eventually (Petabytes) level data cannot be replicated practically
• Need to shard data across machines

70. References
1. http://www.neo4j.org
2. http://www.neo4j.org/learn/cypher
3. Bachman, Michal (2013)GraphAware -TowardsOnline Analytical Processing in Graph Databases
http://graphaware.com/assets/bachman-msc-thesis.pdf
4. Hunger, Michael (2012). Cypher and Neo4j http://vimeo.com/83797381
5. Mistry, Deep Neo4j: A Developer’s Perspective
http://osintegrators.com/opensoftwareintegrators%7Cneo4jadevelopersperspective
6. MapGraph:A High LevelAPI for Fast Development of High Performance GraphAnalytics on GPUs
7. Parallel Breadth First Search on GPU Clusters
8. DB-Engines Ranking of Graph DBMS

71. ThankYou
Check Out My LinkedIn Profile at
https://in.linkedin.com/in/girishkhanzode
