Grafana is an open source analytics and monitoring tool that uses InfluxDB to store time series data and provide visualization dashboards. It collects metrics like application and server performance from Telegraf every 10 seconds, stores the data in InfluxDB using the line protocol format, and allows users to build dashboards in Grafana to monitor and get alerts on metrics. An example scenario is using it to collect and display load time metrics from a QA whitelist VM.

1. Grafana Introduction
RiCo Chen

2. Agenda
◎What is grafana
◎AFT Architecture
◎Write Protocol of influxdb
◎AFT Scenario

3. What is grafana
• Open source software for time series analytics
• Popular project and more company use it
(intel,paypal,netapp…)
• Advanced , visualize and rich metrics dashboard
• Reporting and monitor server once 24 hours
• Alert Notification feature

4. AFT Architecture
Telegraf
http
(every 10
sec)
Influxdb
2.Result
Grafana
Load
Time
Data
from QA’s
whitelist
VM
1.QL

5. Write Protocol of influxdb
• Line Protocol (text based format)
• Write data with http/https API
• Measurement means table
• Point means record of table
• Point include tag , field(Required)
and timestamp(Unix nanosecond)

6. AFT Scenario
• Application metrics for Load Time of UGS

7. • Business metric

8. • Server metrics

9. • Alert Notification

10. Q & A

11. Reference
Grafana
Influxdb
