Connector API Apps
- 1. tSponsors Sameer Chabungbam Principal Program Manager, Microsoft Connector API Apps BizTalk Summit 2015 – London ExCeL London | April 13th & 14th
- 2. Microsoft Azure What we will see today •What are Connectors and API Apps? •Building your first Connector •Make your Connector work for Logic App •Implementing a Trigger •Summary
- 3. Microsoft Azure API APPS Easily build and consume APIs in the cloud WEB APPS Web apps that scale with your business LOGIC APPS Automate business process across SaaS and on-premises MOBILE APPS Build Mobile apps for any device Azure App Service
- 4. Microsoft Azure A powerful platform for building and managing APIs Build once and consume any type of app anywhere, at any time A rich ecosystem for distributing and monetizing APIs Azure App Service API Apps
- 5. Microsoft Azure Build on top of Azure App Service Web App Support all kinds of REST APIs, new or existing Simple yet powerful authentication support. Free your API up from complex authentication handling Expose API definition for metadata driven clients and SDK code-gen Powerful Platform
- 6. Microsoft Azure One API platform for Web App, Mobile App and Logic App. Maximize the value of the API. Easy to optimize for each type of apps. Integrated experience across different types of apps. Build Once Consume Everywhere
- 7. Microsoft Azure Public gallery for certified partners and community developers. Organization gallery with RBAC for enterprise. Distribution and monetization channel to all Microsoft cloud customers. Rich Ecosystem
- 8. • Box • Chatter • Dropbox • Azure HD Insight • OneDrive • SharePoint Server • SharePoint Online • SQL Server • Office 365 • Oracle DB • QuickBooks • Salesforce • SugarCRM • SAP • Azure Service Bus • Azure Storage Blob • Twilio • Twitter • IBM DB2 • Informix • Websphere MQ • Azure Web Jobs • Yammer • Facebook • HTTP, HTTPS • File • FTP • SFTP • POP3 • SMTP • Flat File Encoder • Validate • Extract (XPath) • Transform • X12 • EDIFACT • AS2 • TPM • Rules Connectors Protocols BizTalk Services Built-in API Apps And more on the way…
- 9. Microsoft Azure Building your first Connector The Basics
- 10. Microsoft Azure Demo Building a Storage Queue Connector
- 11. Microsoft Azure What we saw • Tools and SDK • Visual Studio 2013 • Azure SDK 2.5.1 or above • Write a Web API • Make it into an API App • Add Azure API App SDK • Edit ApiApp.json • Test locally using Swagger UI • Publish your API App 11
- 12. Microsoft Azure Connector for Logic Apps The Essentials 12
- 13. Microsoft Azure Optimize for Logic Apps •Display names •Response type •Advanced operations and properties For Operation: “summary” For Parameters and Properties: “x-ms-summary” “default” response field “x-ms-visibility” extension: “advanced” “internal”
- 14. Microsoft Azure Swashbuckle • Generates swagger metadata for your API App • Allows you to customize swagger generation • Operation Filters • Schema Filters • Document Filters • All in SwaggerConfig.cs 14
- 15. Microsoft Azure Demo Add summary and XML Documentation Add default response
- 16. Microsoft Azure Dynamic Swagger • Generate metadata depending on API App Configuration • Discover entities • Provide a strongly typed API • Operations can be dynamically added • Input and output parameters can be strongly typed • Enhances user experience • Allowed values as enumerations
- 17. Microsoft Azure Demo Discover Queues in the configured Storage Account
- 18. Microsoft Azure What we saw •Add summary and other documentation in your API Metadata •Enable XML Comments •Use Operation Filters to customize your swagger 18
- 19. Microsoft Azure Triggers • Triggers define when Logic Apps are run • Manual or Schedule or WebHooks • Connector Triggers – Polling or Push • Connector Triggers (Polling) • 200: Data is available, run the logic • 202: No data is available, check again later • ‘triggerState’ parameter to externalize state • Optimize for Logic Apps • Hide trigger specific properties
- 20. Microsoft Azure Demo Add Trigger to run when Message is available
- 21. Microsoft Azure Next Steps •Debugging your API App •Writing a Hybrid API App •Using OAUTH •Adding diagnostics and error handling •Packaging your API App
- 22. Microsoft Azure Key Takeaways • A powerful platform for APIs • A rich ecosystem for distributing and monetizing APIs • Build your own API App or use from Marketplace • Optimize your API Apps for Logic Apps • Get involved – feedback, build your connector!
- 23. Microsoft Azure 23 Thank You Contact: sameerch@microsoft.com
Editor's Notes
- App Service has everything you need to build apps that target both web and mobile clients from a single app back-end. Using API Apps, you can connect your app to dozens of popular services like Office 365 and salesforce.com in minutes, and integrate your own APIs so they can be used within any app. And finally with Logic Apps, you can automate business processes using a simple no-code experience.
- Today we are announcing App Service, a new service in Azure, which brings together the functionality of Azure Websites, Azure Mobile Services, and Azure Biztalk Services into a single development experience.
- API Apps are built on top of – the same platform which powers Azure Web Apps, PROVEN technonology USE EXISTING TECHNOLOGY you are already familiar with Focus on API Development. Simple authentication Isolated Storage Hybrid Connections API Definition and powerful tooling around it SWAGGER 2.0 and WADL AutoREST provides Client SDK Leave API Management to the platform
- You can build your API App once, and publish it. Consume the same API App from Web Apps, Mobile Apps, and Logic Apps.
- All the connectivity and tools you need to automate your modern business – with over 40 connectors and growing all the time with the ability for any 3rd party to contribute to our gallery.
