1. ABSTRACT SUPERCLASSES AND
ABSTRACT METHODS
Chapter 8.3:

2. Polymorphism
 Polymorphism is an object-oriented concept that allows
us to create versatile software designs that deals with
multiple objects.
 The term polymorphism literally means "having many
forms“ – can refer to multiple types of related objects
over time in consistence way.
 Polymorphism is one of the most elegant uses of
inheritance.
 A polymorphic reference is a variable that can refer
to different types of objects at different points in time.
Specifically, a reference variable of a superclass type
can refer to any object of its subclasses in the
inheritance hierarchy.

3. Polymorphic Reference
 For example, if the Animal class is used to
derive a class called Cat, then a Animal
reference could be used to point to a Cat
object
 Similarly, Animal can refer to any of its
subclasses
Animal myPet;
myPet = new Cat();
Animal
CatRabbit
myPet = new Rabbit();

4. Polymorpic Reference
 Another example:
 UndergraduateStudent and GraduateStudent are
subclasses of Student, the following statements are valid:
Student stud1 = new Student();
stud1 = new UndergraduateStudent();
stud1 = new GraduateStudent();

5. Polymorphic Behaviour
 When a method is invoked using the
superclass variable, it is the class of the
object (not of the variable type) that
determines which method is run.
Student stud1 = new Student();
stud1.computeCourseGrade();
stud1 = new UndergraduateStudent();
stud1.computeCourseGrade();
stud1 = new GraduateStudent();
stud1.computeCourseGrade();

6. Polymorphic Behaviour
 The superclass type variable can only be used to
invoke methods in subclass that also exist in the
superclass (overridden by subclass). New
methods in subclass is not visible to the
superclass variable.
 Eg. If UndergraduateStudent has a method
printUG():
Student stud1 = stud1 = new UndergraduateStudent();
stud1.printUG(); //======== error!!

7. Creating the roster Array
 We can maintain our class roster using an
array, combining objects from the Student,
UndergraduateStudent, and
GraduateStudent classes.
Student roster = new Student[40];
. . .
roster[0] = new GraduateStudent();
roster[1] = new UndergraduateStudent();
roster[2] = new UndergraduateStudent();
. . .

8. State of the roster Array
 The roster array with elements referring to
instances of GraduateStudent or
UndergraduateStudent classes.

9. Sample Polymorphic
Message
 To compute the course grade using the roster
array, we execute
 If roster[i] refers to a GraduateStudent, then
the computeCourseGrade method of the
GraduateStudent class is executed.
 If roster[i] refers to an UndergraduateStudent,
then the computeCourseGrade method of the
UndergraduateStudent class is executed.
for (int i = 0; i < numberOfStudents; i++) {
roster[i].computeCourseGrade();
}

10. The instanceof Operator
 The instanceof operator can help us learn the
class of an object.
 The following code counts the number of
undergraduate students.
int undergradCount = 0;
for (int i = 0; i < numberOfStudents; i++) {
if ( roster[i] instanceof UndergraduateStudent ) {
undergradCount++;
}
}

11. Abstract class
 a class that cannot be instantiated but that can be
the parent of other classes.
 objects can ONLY be created from subclass that
inherits from the abstract super (parent) class
 the subclass is forced to implement the abstract
method inherited from the super class through the
overriding process

12. Java Abstract classes
 An abstract class is a class that is declared
with the reserved word abstract in its heading.
abstract class ClassName {
. . . . . // definitions of methods and variables
}

13. Abstract classes rules
 An abstract class can contain instance
variables, constructors, the finalizer, and
nonabstract methods
 An abstract class can contain abstract
method(s).
 If a class contains an abstract method, then the
class must be declared abstract.
 We cannot instantiate an object from abstract
class. We can only declare a reference
variable of an abstract class type.
 We can instantiate an object of a subsclass of
an abstract class, but only if the class gives the
definitions of all the abstract methods of the
superclass.

14. Abstract method
 An abstract method is a method that has only the
header without body.
 The header of an abstract method must contain the
reserved word abstract and ends with semicolon(;).
 Syntax:
<AccessSpecifier> abstract ReturnType
MethodName(ParameterList);
 E.g.
public abstract void print();
public abstract String larger(int value);
void abstract insert(Object item);

15. Example of an abstract class &
method
public abstract class Animal
{
protected String type;
public void setType(String t)
{ type = t;
}
public abstract void sound();
}

16. Abstract method rules
 Abstract method declaration must be ended with
semicolon (;)
 Abstract method cannot be private type because a
private members cannot be accessed.
 Constructor and static method cannot be used as
abstract method.
 Must be overridden by non-abstract subclass

17. Abstract class declaration
abstract class Card {
String recipient; // name of who gets the card
public abstract void greeting(); //abstract greeting() method
}

18. Abstract Class Card and its
Subclasses
abstract Card
abstract greeting( )
AidulFitriCard
greeting( )
BirthdayCard
greeting( )
String recipient
int ageint syawalYear

19. Abstract method MUST be
overridden by subclass
public abstract class Card
{
String recipient;
public abstract String greeting();
}
public class AidulFitriCard extends Card
{
int syawalYear;
public String greeting()
{
……….
}
}
public class BirthdayCard extends Card
{
int age;
public String greeting()
{
………..
}
}

20. AidulFitriCard Class
public class AidulFitriCard extends Card
{
int syawalYear;
public AidulFitriCard(String who, int year) {
recipient = who;
syawalYear = year;
}
public String greeting()
{
System.out.println(“To “ + recipient);
System.out.println(“Selamat Hari Raya Aidul Fitri”);
System.out.println(“1 Syawal “ + syawalYear);
}
}

21. BirthdayCard Class
public class BirthdayCard extends ________
{
int age;
public _____________(String who, int year) {
recipient = who;
age = year;
}
public String greeting()
{
System.out.println(“Happy birthday to “+ _______);
System.out.println(“You are now “ +age+ “ years old.”);
}
}

22. CardTester Program
public class CardTester {
public static void main ( String[] args ) {
String name;
Scanner input = new Scanner(System.in);
System.out.print(“Your name please>");
name = input.nextLine();
Card myCard = new AidulFitri( me, 1429 );
myCard.greeting();
myCard = new BirthdayCard( me, 35 );
myCard.greeting();
}
}
 Demonstrate abstract class and polymorphism
