Contract Engineering Services provides electromechanical design, analysis, prototyping, and engineering services. They have over 20 years of experience working with clients in industries like medicine, energy, optics, materials science, and consumer products. Their services include CAD, FEA, rapid prototyping, product design, and prototype fabrication.

1. Providing a range of
Electromechanical design,
analysis, and prototyping
services to inventors,
researchers, and technology
clients.
Analysis/FEA
Design/CAD
Invention Development
Special Machinery
Product Design
Prototype Fabrication
Contract
Engineering
Services

2. Contract Engineering
Services is a unique
resource.
For over 20 years, we have
provided engineered
solutions to a diverse
clientele of businesses and
professionals working in
medicine, energy, optics,
advanced materials, and
consumer products.
We “speak the language” of
manufacturers, inventors,
researchers and product
developers who need
electromechanical
engineering support.
Exploded view of an
Oarlock mechanism
designed by CES for a
recreational equipment
client.
Numerous injection-molded
plastic component are used
in this device - each
designed for optimum
strength, weight, and
moldability.

3. We work closely with our clients, to truly
understand and clarify their problems and
objectives.
Then we apply our SolidWorks CAD, FEA,
Rapid Prototyping – and a wealth of
practical industry experience – to provide
our clients with the resources of an “in
house” engineering department, without
adding onsite staff.
And, we maintain this personal contact
throughout the solution effort.
From Concept to
Prototype - a patented
Vial Shaker appliance for
laboratory automation.

4. In addition, we address our
client’s need for “hands-on”
support – such as shop
drawings and prototype
fabrication – functions which
are always required as part of
any solution effort, and which
the typical “consultant” can’t
provide.

5. These photos illustrate
machinery designed,
fabricated and installed
by CES for a Client
manufacturer of Nitinol
products.
CES provided all design,
fabrication, on-site
assembly and test of
several versions of this
system.
Special Machinery

6. CES specializes in design of
unique machinery and tooling for
research applications.
Shown here is equipment we
designed to assemble, clean and
test a one-of-a-kind filament-
wound composite fuel tank.
Our wide experience enables us to
accept design challenges that
specialized "consultants" cannot.
Industrial Tooling

7. At right, a CES design for
Control Panel and Printer of an
innovative neonatal end-tidal
breath monitoring product.
Working with a leading heart surgeon,
at left is a surgical instrument designed
by CES, enabling minimally invasive
repair of heart mitral valves. Note the
extremely compact size – the barrel is
only 9mm in diameter.
Medical Instruments

8. At left, an electro-optical
system designed by CES and
packaging an Ebert double-
monochromator, a Peltier-
effect cooled photomultiplier
tube, and all power/signal
electronics.
An electro-optical system designed by
CES for a major manufacturer of high-
performance military optical systems.
Optical Instruments

9. Illustrated is a lightweight,
ruggedized, Fuel Cell Power Supply
designed for a Military Client.
The entire case was composed of
plastic components fabricated by a
Rapid Prototyping process called
Selective Laser Sintering (SLS).
Strong functional components can
now be obtained by SLS directly from
CAD files, with no molds or tooling
required.
Additionally, SLS can produce
components with internal channels
and other features unproducible by
other methods.
Rapid
Prototyping

10. CES has extensive experience in plastic
component design for both consumer and
commercial applications.
At left, an innovative rowing oarlock
designed by CES, part of patented
rowing-oar system.
Above, part of a complex,
thermostatically-actuated louvered
residential ventilation system.
Consumer Products

11. Illustrated are portions of a CES- patented
Continuously-Variable Transmission (CVT).
CES can assist you in all
technical phases of invention
and patent development.
Invention and Patent
Development

12. Contract Engineering Services
2043 East Joppa Road
Suite 339
Baltimore, Maryland 21234
phone 410-668-8383
Email support@ceseng.biz
http://www.ceseng.biz
