Service Clustering for Autonomic
Clouds Using Random Forest
Rafael Brundo Uriarte
IMT Lucca
Sotirios Tsaftaris Francesco Tiezzi
IMT Lucca University of Camerino
CCGrid - 7th May 2015 - Shenzhen, China

Contents
1 Introduction
2 Requirements and Existing Solutions
3 RF+PAM
4 Evaluation
5 Conclusions
Uriarte, Tsaftaris and Tiezzi 1/29

Introduction
Introduction Uriarte, Tsaftaris and Tiezzi 2/29

Cloud Computing
Everything-as-a-Service
Dynamism
Heterogeneity
Virtualization
Large-Scale
Introduction Uriarte, Tsaftaris and Tiezzi 3/29

Autonomic Computing
Introduction Uriarte, Tsaftaris and Tiezzi 4/29

Autonomic Clouds
Restricted Knowledge
Approaches to alleviate the problem:
Machine Learning
Service Clustering
Introduction Uriarte, Tsaftaris and Tiezzi 5/29

Applications in the Domain
Anomalous Behaviour Detection
Service Scheduling
Application Proﬁling
SLA Risk Assessment
Introduction Uriarte, Tsaftaris and Tiezzi 6/29

Requirements and Existing Solutions
Requirements and Existing Solutions Uriarte, Tsaftaris and Tiezzi 7/29

Requirements
Characteristics Requirements
Security, Heterogeneity,
Dynamism
Mixed Types of
Features
Large-Scale, Dynamism On-line Prediction
Large-Scale, Multi-Agent
Loosely-Coupled
Parallelism
Heterogeneity
Large Number of
Features
Requirements and Existing Solutions Uriarte, Tsaftaris and Tiezzi 8/29

Existing Approaches
Solutions which handle mixed data types usually are not
scalable (e.g. HClustream)
Expert intervention is not feasible due to the dynamism
Distance Metric Learning Approaches require labelled data
or are computationally expensive.
Requirements and Existing Solutions Uriarte, Tsaftaris and Tiezzi 9/29

RF+PAM
RF+PAM Uriarte, Tsaftaris and Tiezzi 10/29

Random Forest
Mixed Features
Large Number of Features
Eﬃcient and Scales Well
Easily Parallelizable
RF+PAM Uriarte, Tsaftaris and Tiezzi 11/29

Random Forest
Clustering with Random Forest
Originally Developed for Classiﬁcation
On-Line Random Forest
Intrinsic Measure of Similarity
Clustering Algorithm (e.g. PAM)
RF+PAM Uriarte, Tsaftaris and Tiezzi 12/29

Similarity Using RF: Criteria
RF+PAM Uriarte, Tsaftaris and Tiezzi 13/29

Problems
Similarity Matrix (Big Memory Footprint)
Re-cluster on Every New Observation
RF+PAM Uriarte, Tsaftaris and Tiezzi 14/29

Solution: RF+PAM
Oﬀ-line Training and On-line Prediction
Similarity Learning and Standard Clustering
RF+PAM Uriarte, Tsaftaris and Tiezzi 15/29

Solution: RF+PAM
Build Forest, Calculate Similarities, Cluster, Select
the medoids and Store the references of the leaves.
RF+PAM Uriarte, Tsaftaris and Tiezzi 16/29

Solution: RF+PAM
Parse service and Assign the cluster of the most
similar medoid to it.
RF+PAM Uriarte, Tsaftaris and Tiezzi 17/29

Evaluation
Evaluation Uriarte, Tsaftaris and Tiezzi 18/29

Experiments
1. Cluster Quality
2. On-Line Prediction
3. Use Case
Evaluation Uriarte, Tsaftaris and Tiezzi 19/29

Cluster Quality
Clustering quality compared to 2 other
approaches (same dataset)
Better results in all criteria
Connectivity - Connectedness of the clusters
Dunn Index - Cluster density and Separation
Silhouette - Conﬁdence in the assignment
Evaluation Uriarte, Tsaftaris and Tiezzi 20/29

On-line Prediction
On-Line vs Batch Mode
K-Fold Cross-Validation
Compared the Adjusted Rand Index (ARI) for 2
datasets:
Monitoring data of Google’s production
clouds - 12500 servers
Requests of a grid of the Dutch Universities
Research Testbed (DAS-2) - 200 servers
Evaluation Uriarte, Tsaftaris and Tiezzi 21/29

Results: ARI
K Google DAS-2
100 0.81 (0.32) 0.70 (0.23)
50 0.75 (0.19) 0.68 (0.17)
20 0.73 (0.09) 0.67 (0.11)
10 0.70 (0.06) 0.63 (0.09)
5 0.69 (0.05) 0.61 (0.07)
Evaluation Uriarte, Tsaftaris and Tiezzi 22/29

Use Case
Schedules according to the Dissimilarity
Similar services separated
Algorithms:
1. Random
2. Dissimilarity
3. Isolated
Evaluation Uriarte, Tsaftaris and Tiezzi 23/29

Use Case
9 VMs
Arrival Rates
Types of Service
Services’ SLA
Evaluation Uriarte, Tsaftaris and Tiezzi 24/29

Results
Evaluation Uriarte, Tsaftaris and Tiezzi 25/29

Conclusions
Conclusions Uriarte, Tsaftaris and Tiezzi 26/29

Summary
We propose RF+PAM to alleviate the problem
of limited knowledge in AC
Validated RF+PAM with 3 Experiments
Scheduling Algorithm
Conclusions Uriarte, Tsaftaris and Tiezzi 27/29

Future Works
More Use Cases
Better Implementation
Conclusions Uriarte, Tsaftaris and Tiezzi 28/29

Thank you!
Questions?
Rafael Brundo Uriarte
rafael.uriarte@gmail.com
Conclusions Uriarte, Tsaftaris and Tiezzi 29/29

Prune Trees
Parsing is very fast and eﬃcient
Prune requires analysis (time consuming)
Conclusions Uriarte, Tsaftaris and Tiezzi 29/29

Retraining
Ratio of predictions/training services (user deﬁned):
Parallel training
Trade-oﬀ between updating/prediction
Other solutions:
Dissimilarity to Medoids
On-line Clustering (Current Limitations and
Prediction Speed)
Conclusions Uriarte, Tsaftaris and Tiezzi 29/29
