This document discusses Microsoft's integration strategy and Host Integration Server 2000. It provides an overview of Microsoft's approach to data integration, application integration, and network integration with non-Windows environments. Key capabilities covered include OLE DB and ODBC providers for accessing mainframe data, COMTI for wrapping mainframe transactions as COM objects, and the MSMQ-MQSeries bridge for messaging integration.

1. Building Enterprise Interoperability Applications Using Microsoft Host Integration Server 2000 Peter Ty MCDBA, MCSE, MCP+SB Technology Specialist Microsoft Hong Kong Ltd. [email_address]

4. Microsoft’s Integration Strategy The Evolution of Heterogeneous Integration Time Transaction integration Web integration Data integration Network integration Integration Needs

8. Microsoft’s Integration Strategy Host Integration Server 2000 Offerings “ Providing a comprehensive set of components for integrating Windows with host systems” Providing comprehensive application integration Application Providing comprehensive data integration Data Providing comprehensive network integration Network

10. Data Integration Host Data Integration Scenarios Non-Windows Platform Client-initiated query Host-initiated query Heterogeneous database integration Future Business Process

11. Data Integration Data Access: Client-Initiated Query DCOM Rich Client n -Tier Empower users to access data while enhancing manageability and scalability ODBC/OLE DB data providers TCP/IP SNA Rich Client 2-Tier Empower individuals to access data directly from the desktop Browser Client n -Tier Develop flexible Web-based applications to access legacy data IIS / ASP HTTP MTS / COM+ TCP/IP SNA ODBC/OLE DB Data Providers DB2, VSAM, OS/400, and Oracle Business Process

12. Data Integration IBM Host Data Integration Source System Application Distributed Data Management is a methodology that allows data on one system to be shared and accessed by another system. Target System Target System Target System

13. Data Integration DDM File Models Supported Distributed Data Management (DDM) Application Relational Data RDBMS DRDA Record Data RLIO Record Stream Data SLIO Stream File xxxxxxxxxxx BOF EOF Queue Data Data Queue Queue Write Read

14. Data Integration Distributed Relational Data Access (DRDA) IBM Host DDM Application Server DB2 Source System Application DDM Application Requester DRDA OLE DB ODBC

16. Data Integration DRDA Transport Architecture DB2 Service (DRDA AR) OLE DB WinSock TCP/IP ODBC ODBC App OLE DB App ADO ADO App WinAPPC APPC SNA Server DRDA AS DB2 TCP/IP SNA LU 6.2 Stored Procedures

21. Data Integration Distributed Transformation Server (DTS) DTS Data Pump Source OLE DB for DB2 Provider Step 1: Pull data Destination OLE DB for SQL Server Provider Step 3: Push data Destination Source COM+ Step 2: Manipulate data

22. Data Integration Distributed Query Processor (DQP) OLE DB for DB2 Provider OLE DB for SQL Server Provider OLE DB for DB2 Provider SQL Server 2000 SVR2 Shipping Details DB2 for OS/390 SVR3 Product Details DB2 for OS/400 SVR1 Order Details Application SQL Server DQP Stored Procedures Query SVR1 Query SVR2 Query SVR3

23. Data Integration Snapshot Replication – Concept and Architecture Publisher Subscriber SQL Server Distributor SQL Server Distributor Snapshot Agent Distribution Agent Data Schema Distribution Database Data Schema Retrieve Apply HIS 2000 HIS 2000

25. Application Integration Application Integration Strategies Non-Windows BizTalk Server 2000 COM Proxy XML Proxy Message Queue Bridge COM COM or DCOM Message Queuing Business Process Business Process Business Process Business Process XML Business Process Business Process XML

27. Application Integration COMTI Architectural Overview MTS/COM+ IIS / ASP COM / DCOM COMTI CICS DB2 / VSAM CICS TP BizTalk Server APPC TCP/IP APPC TCP/IP IMS IMS Database IMS TP Step 1: Process Invocation Step 2: Transaction Invocation Step 3: Transaction Runtime DTC 2PC HTTP XML Business Process

28. Application Integration COMTI – Host Communications MTS Business Process MTS Component COMTI Proxy .TLB COMTI Component Builder IIS / ASP IMS Terminal IMS Control Region IMS Message Queue IMS Database IMS TP APPC TCP/IP COMTI accesses CICS TPs through the CICS mirror transaction (CSMI) and IMS TPs via the IMS message queue. CICS Mirror TP CSMI TCP/IP Listener DB2 / VSAM COMMAREA APPC TCP/IP Linked-to CICS TP

29. Application Integration COMTI – Client Communication Visual Basic Program Private Sub GetBalance_Click() … 'do the COMTI invocation Set objBank = CreateObject("Cedar.Bank") lngReturn = objBank.cedrbank(txtName.Text, _ txtAccount.Text, curRetBalance) … Exit Sub MTS MTS Component “ Cedar.Bank” COMTI Proxy .TLB DCOM CICS Mirror TP CSMI APPC COMMAREA Linked-to-Program AccNum (in) AccBal (out) Name (in) Analyze [input] data in COMMAREA Do work using local resource managers Place [output] data in COMMAREA EXEC CICS RETURN LINK from mirror transaction

30. Application Integration XML-to-Host Integration XML-enable host transactions with BizTalk Server 2000 and Host Integration Server 2000. Invocation Execution Asynchronous (messaging-based) MQSeries CICS/IMS MSMQ - MQSeries Bridge MSMQ Transformation BizTalk Send Receive XML EDI Other Invocation COMTI Execution CICS/IMS Synchronous (COM+-based) Business Process COM OLE DB

32. Application Integration MSMQ-MQSeries Bridge Apps Sender Apps Receiver MSMQ World MQSeries World Send Receive Providing asynchronous, messaging-based, communication integration between heterogeneous applications Send Receive Translation Bridging MSMQ - MQSeries Bridge MSMQ MQ Series

35. Gateway Functionality Host Platforms Remote Clients Network Integration Providing Comprehensive Network Support Windows 2000® Server TCP/IP, IPX/SPX, NetBEUI, Banyan VINES, AppleTalk, DLC, DecNet Windows Macintosh OS/2 Windows NT MS-DOS Unix Windows for Workgroups OpenVMS Windows 9 x Telnet

41. Questions?
