WebSphere MQ is messaging and queuing middleware from IBM that allows applications to communicate asynchronously by sending messages to queues. It provides guaranteed message delivery, decoupling of sending and receiving applications, and publish/subscribe capabilities. Programs using the MQ API can connect to queue managers to put and get messages from queues without having direct connections to each other. Messages have properties and data, and can be persistent or non-persistent. Queues store messages and allow parallel access by multiple applications.
WebSphere MQ includes a alternative of APIs and supports the Java™ Message Service (JMS) API. WebSphere MQ is that the market-leading messaging integration middleware product. Originally introduced in 1993 (under the IBM MQSeries® name), WebSphere MQ provides associate degree an, reliable, scalable, secure, and superior transport mechanism to handle businesses property necessities.
