The basics of understanding electronics and physical interaction with Arduino presented and taught by Jörn Sandner, Prof. Franziska Hübler and Jeremy Abbett for the University of Applied Arts - Hamburg and Miami Ad School Europe.

1. MAKING THINGS TALK
An introduction to the basics of making with Arduino | HAW x MASE | Hamburg, Germany | 16.04.2012
flickr user hildeengwenverbouwen
Jörn Sandner | Prof. Franziska Hübler | Jeremy Tai Abbett

2. TOPICS
Introduction Introduction in Programming
Basic Electronics Getting Started
The Arduino Board Exercises
Image via http://vasastudio.com/

3. TOPICS
Introduction Introduction in Programming
Basic Electronics Getting Started
The Arduino Board Exercises

4. WHAT ARE WE DOING
Hardware
Getting closer to electronic circuits
Software
Writing simple software for hardware

5. THE ONE IN FRONT
Jörn Sandner
Master Microelectronic Systems
Study at the FH Heide
plus one semester at the HAW Hamburg

7. TOPICS
Introduction Introduction in Programming
Basic Electronics Getting Started
The Arduino Board Exercises

8. VOLTAGE & CURRENT
Voltage: speed of Current: amount
the electrons of electrons
> potential difference > resistance of the circuit

9. CIRCUIT
button light (LED)
resistor
+ -
battery

10. CIRCUIT
current direction
+ -
battery

11. FUNCTIONAL VIEW
“input” “output”
button light (LED)
resistor
+ -
battery

12. FUNCTIONAL VIEW
“input” “output”
button light (LED)
resistor
+ -
battery
NOW: Put some “intelligence” in between

13. TOPICS
Introduction Introduction in Programming
Basic Electronics Getting Started
The Arduino Board Exercises

14. THE ARDUINO BOARD
Serial to USB Converter Digital In & Out Pins
USB Port
Power LED
Microcontroller
Power Supply Connection
Power Pins Analog Input Pins

15. SOFTWARE
arduino.cc fritzing.org

16. DIGITAL OUT / DIGITAL IN
‣ Two States
‣ ON / HIGH / 1
‣ OFF / LOW / 0
‣ Port mode (in/out)
controlled by software
‣ 12 Ports available
‣ some with special functions

17. DIGITAL OUT / DIGITAL IN
voltage
HIGH
5V+
4
3
2
1 LOW
GND
0 1 2 3 4 5 6 7 8 9 10 time

18. DIGITAL PORTS
“input” “output”
On/Off On/Off

19. ANALOG PORTS
‣ Value range instead
of state
‣ Input 0 -1023
‣ Output 0 -255 (analog output
shared with digital out)

20. ANALOG PORTS
0 1023
255
0

21. ANALOG IN
voltage
5V+
4
3
2
1
GND
0 1 2 3 4 5 6 7 8 9 10 time

22. ANALOG OUT
‣ There is no real variable voltage output
‣ Analog signal is generated by waveform with
constant voltage and constant frequency

23. ANALOG OUT
voltage
5V+
4
3
2
1
GND
0 1 2 3 4 5 6 7 8 9 10 time

24. ANALOG OUT
Always same
period
voltage
Always 5V
5V+
4
3
2
1
GND
0 1 2 3 4 5 6 7 8 9 10 time

25. ANALOG OUT
Always same
period
voltage
Always 5V
5V+
4
Getting different values
by moving the middle
3 line within the period
2
1
GND
0 1 2 3 4 5 6 7 8 9 10 time

26. ANALOG OUT
voltage
50% 75% 25% 100%
5V+
4
3
2
1
GND
0 1 2 3 4 5 6 7 8 9 10 time

27. ANALOG OUT
voltage
5V+
4
3
2
1
GND
0 1 2 3 4 5 6 7 8 9 10 time

28. ANALOG RANGE ADAPTION
1023
255
0
0

29. TOPICS
Introduction Introduction in Programming
Basic Electronics Getting Started
The Arduino Board Exercises

30. PROGRAMMING
Basic setup (bare minimum)
void setup()
{
// running one time
// do basic setup of the Arduino Board
}
void loop()
{
// running for ever
// your code
}

31. PROGRAMMING
Blink
/*void setup()
{
// Pin 13 connected
pinMode(13, OUTPUT);
}
void loop()
{
digitalWrite(13, HIGH); // set the LED on
delay(1000); // wait for a second
digitalWrite(13, LOW); // set the LED off
delay(1000); // wait for a second
}

32. SOME STRUCTURES
‣ Your Arduino is busy when busy
‣ One task at time
‣ The program code is executed sequentially –
step by step
‣ A command has to wait until it‘s previous has executed

33. SOME PROGRAMMING
BASICS
‣ Save and recall values
‣ int myValue = 54;
‣ Call functions
‣ digitalWrite(myValue, HIGH);
‣ myValue = analogRead(0);
‣ Conditional execution
‣ if (myValue == 54) { // } else { // }
‣ Repeat commands
‣ for(int i = 0; i<10; i++) { // }

34. SOME FUNCTIONS
‣ pinMode()
‣ digitalWrite()
‣ digitalRead()
‣ analogReference()
‣ analogRead()
‣ analogWrite() – PWM
‣ outValue = map (inValue, 0, 1023, 0, 255); //
remember range conversion
See http://arduino.cc/en/Reference/HomePage

35. TOPICS
Introduction Introduction in Programming
Basic Electronics Getting Started
The Arduino Board Exercises

36. GETTING STARTED
WITH BLINKING LED
‣ Gather in groups
‣ Get a Fritzing Kit
‣ Start Arduino software
‣ Follow me…

37. TOPICS
Introduction Introduction in Programming
Basic Electronics Getting Started
The Arduino Board Exercises

38. ANALOG OUT
WITH FADING
http://www.youtube.com/watch?v=Y2cLxmNnpOE

39. ANALOG IN WITH SERVO
AND POT
http://www.youtube.com/watch?v=SS6cntJ_LqQ

40. ANALOG IN WITH SERVO
AND LDR
http://www.youtube.com/watch?v=m9J3mDYy0Sg

41. PANDORA’S BOX
20 cm
Lady Ada Sensors
http://www.ladyada.net/learn/sensors/
Interfacing With Hardware
http://arduino.cc/playground/Main/InterfacingWithHardware
Index of Arudino Knowledge
http://www.freeduino.org/
20 cm

42. THE END OF THE BEGINNING
Jörn Sandner | Prof. Franziska Hübler | Jeremy Tai Abbett
