A brief description and short example of Android Data Binding from version 6 and above, along with a brief description of Butterknife (by Jake Wharton).

1. Android Data Binding in Android
Lollipop and Beyond
Oswald Campesato
Consultant/Training:
www.iquarkt.com
ocampesato@yahoo.com

2. Standard Android Data Binding (<v6)
• 1) Specify a value for the id attribute of a widget
via the “@+id” syntax in activity_main.xml
• 2) Use findViewById() in onCreate() to locate
Android widgets in activity_main.xml

3. Sample activity_main.xml (<v6)
• <Button android:id="@+id/button1"
• android:layout_width="fill_parent"
• android:layout_height="wrap_content"
• android:layout_alignParentBottom="true"
• android:text="@string/clickme" />
•
• <TextView
• android:layout_width="fill_parent"
• android:layout_height="wrap_content"
• android:text="@string/hello"
• android:layout_above="@id/button1"
• />

4. findViewById() in MainActivity
public class MainActivity extends Activity
{
private Button myButton = null;
private String TAG = "myButton";
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
this.myButton = (Button)this.findViewById(R.id.button1);
}

5. Android Data Binding (v6 or higher)
1) Define the Java User class (written by you)
2) Add a <layout> element with a child <data> element
<layout
xmlns:android="http://schemas.android.com/apk/res/android">
<data> <variable name="user” type="com.example.User"/>
</data>
3) add the following in the android block in build.gradle:
android {
. . .
dataBinding.enabled = true
}
4) change the inflater code in onCreate()

6. New activity_main.xml (v>=6)
<?xml version="1.0" encoding="utf-8"?>
<layout xmlns:android=
"http://schemas.android.com/apk/res/android">
<data> <variable name="user" type="com.example.User"/> </data>
<LinearLayout
android:orientation="vertical"
android:layout_width="match_parent"
android:layout_height="match_parent">
<TextView android:layout_width="wrap_content"
android:layout_height="wrap_content"
android:text="@{user.firstName}"/>
</LinearLayout>
</layout>

7. Contents of User class
package com.example.oswaldcampesato2.mybinding1;
public class User {
private String firstName = "Dave";
private String lastName = "Smith";
public User() {};
public void setFirstName(String firstName) {
this.firstName = firstName;
}
public String getFirstName() { return firstName; }
}

8. New Inflater Code
ActivityMainBinding binding =
DataBindingUtil.setContentView(
this, R.layout.activity_main);
The ActivityMainBinding class matches the file:
activity_main.xml
Another example:
ActivityUserBinding matches activity_user.xml

9. Android Studio 2.2 (version 7)
Error message: "Failed to resolve:
com.android.support.constraint:constraint-layout:1.0.0-alpha4"
Solution:
1) Download Android Studio 2.2 Preview 7
2) Update SDK Tools to the latest 25.2.1
3) Download ConstraintLayout & Solver for ConstraintLayout in SDK
Manager
4) Add com.android.support.constraint:constraint-layout:1.0.0-alpha5 to
gradle.build
More details:
• http://stackoverflow.com/questions/38450414/error30-13-failed-to-
resolve-com-android-support-constraintconstraint-layo

10. Android Studio 2.2 (version 7)
1) build.gradle:
classpath 'com.android.tools.build:gradle:2.2.0-alpha7'
2) gradle-wrapper.properties:
distributionUrl=https://services.gradle.org/distributions/gradle-
2.14.1-all.zip
3) gradle.build:
com.android.support.constraint:constraint-layout:1.0.0-alpha5
[Downloads: http://services.gradle.org/distributions]

11. What about ButterKnife?
Created by Jake Wharton
Uses binding annotation
https://github.com/JakeWharton/butterknife

12. Sample Annotations (1)
class ExampleActivity extends Activity {
@BindView(R.id.user) EditText username;
@BindView(R.id.pass) EditText password;
@BindString(R.string.login_error) String
loginErrorMessage;
@OnClick(R.id.submit) void submit() {
// ...
}
...
}

13. Build.gradle (project-level)
buildscript {
repositories {
mavenCentral()
}
dependencies {
classpath
'com.neenbedankt.gradle.plugins:android-apt:1.8'
}
}

14. Build.gradle (module-level)
apply plugin: 'android-apt'
android {
...
}
dependencies {
compile 'com.jakewharton:butterknife:8.2.1'
apt 'com.jakewharton:butterknife-compiler:8.2.1'
}

15. Sample Annotations (2)
@Override public void onCreate(Bundle
savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.simple_activity);
ButterKnife.bind(this);
// TODO Use fields...
}

16. Android Studio 2.0 Installation
• 1) Launch error for Android Studio:
“'tools.jar' seems to be not in Android Studio classpath.
Please ensure JAVA_HOME points to JDK rather than JRE.”
Option #1: use Java8
Option #2: copy tools.jar from $JAVA_HOME/lib into
/Applications/AndroidStudio.app/Content/lib
• 2) Incorrect permissions for Android Studio:
Log path '/Users/…/Library/Logs/AndroidStudio2.1' is
inaccessible.
Solution: chmod 775 $HOME/…/AndroidStudio2.1

17. Android Studio 2.0 Installation
3) Internal Error. Please report to
https://https://code.google.com/p/android/issues
java.lang.RuntimeException:
com.intellij.ide.plugins.PluginManager$StartupAbortedExcep
tion: Fatal error initializing
'com.android.tools.idea.AndroidInitialConfigurator'
Solution: download/install this version of AS:
http://tools.android.com/download/studio/builds/2-0-preview-
3b
4) Error: LSOpenURLsWithRole() failed with error -10810 for
the file /Applications/Android Studio.app.
